2019 Yamaha TT-R50E Guide

2019 Yamaha TT-R50E

2019 Yamaha TT-R50E 2019 Yamaha TT-R50E 2019 Yamaha TT-R50E

THE FUN STARTS HERE.

2019 Yamaha TT-R110E:

Push button electric start and three‑speed automatic transmission make this the perfect bike for learning.

Our littlest TT-R boasts big YZ styling, four-stroke power, a three-speed automatic-clutch gearbox and it even comes with push-button electric starting. So go ahead… play in the dirt!

The TT-R50E from Yamaha has surely got to be every youngster’s dream come true.

Sophisticated 4-stroke power for kids.

Everything about this rider-friendly mini-bike is designed to create a fun and enjoyable experience for riders between 4 and 7 years of age. For simple riding, the electric-start 50cc 4-stroke engine is equipped with a semi-automatic 3-speed gearbox – and for added parental control the TT-R50E can only be started with the ignition key inserted.

The rugged blue bodywork has been inspired by Yamaha’s GP-winning MX bikes, and with long-travel suspension and knobbly tyres, the TT-R50E is ready to provide many hours of fun for all the family.

///Engine

Air-cooled, 50cc, SOHC, 2-valve, 4-stroke powerplant produces smooth, reliable novice friendly power that eases the new rider up the learning curve.

///Electric Start

Convenient, push-button electric starting makes it a snap to get running takes one of the hassles out of learning how to ride.









2019 Yamaha TT-R110E Totalmotorcycle.com Key Features

Top Features

  • Convenient Electric Start
    The TT-R50E gets the same pushbutton electric starting feature as our full line of electric-start TT-Rs.
  • Accessible Performance
    Great for learning and/or playing, complete with 49cc of four-stroke fun feeding power through a three-speed automatic-clutch transmission.
  • Ultra-Low Seat Height
    Big YZ styling meets little people’s stature; the seat’s only 21.9 inches from the dirt.
  • Advanced Suspension
    Inverted fork and Monocross® rear end provide great handling.
  • Robust Final Drive
    Large chain cover for maximum protection and minimal maintenance.







2019 Yamaha TT-R110E Totalmotorcycle.com Features and Benefits
  • Useable, Entry-Level Motor
    49cc air-cooled, SOHC powerplant puts out smooth, reliable four-stroke power perfect for kids and small novices.
  • Automatic Clutch
    Three-speed gearbox with automatic centrifugal clutch makes learning to shift gears a breeze.
  • Convenient Electric Start
    Convenient electric starter for effortless starting.
  • Compact Engine
    Compact-design cases keep overall engine width down for a narrow feel and great handling.
  • Responsive Power
    11mm Mikuni® VM-type carburetor with automatic on/off electric heater ensures crisp, dependable throttle response.
  • Low Maintenance Engine
    Automatic cam chain tensioner reduces maintenance.
  • Digital Ignition
    CDI ignition system delivers hot, reliable spark and requires minimal maintenance.
  • Forestry-Friendly Exhaust
    Lightweight, upswept exhaust system is quiet and contains a USFS-approved spark arrestor.
  • Simple and Strong Frame
    Curved steel backbone frame keeps the TT-R50E narrow and has three engine-mounting points for excellent rigidity and handling.
  • Compact Inverted Fork
    Inverted fork with 22mm sliders provides 3.8 inches of smooth front wheel travel for a great ride and handling.
  • Lightweight Single Shock
    Monocross® rear suspension is controlled by a single coil-over shock and provides 2.8 inches of bump-smothering rear wheel travel.
  • Enclosed Drum Brakes
    Front and rear 80mm drum brakes deliver strong, dependable stopping power, and the rear’s activated by a right foot pedal just like the big YZs.
  • Durable Knobby Tires
    10-inch front and rear wheels with knobby tires offer great grip and exceptional wear.
  • Ultra-Low Seat Height
    Low, 21.9-inch seat height allows most kids to put both feet down for enhanced handling and added confidence.
  • Standard Security
    Key-type ignition switch deters unauthorized riding.
  • Adjustable Restrictor
    Throttle stop screw lets the adult supervisor restrict speed while beginners are learning.
  • Racy Styling
    Cool-looking YZ bodywork includes an integrated front fender/number plate.
  • Folding Sidestand
    Standard sidestand tucks up out of the way when not in use.
  • Grippy Footpegs
    Large, folding, cleated foot pegs provide excellent footing.









2019 Yamaha TT-R110E – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $1699 USD
Canada MSRP Price: $1899 CDN
Europe/UK MSRP Price: £ See dealer for pricing in GBP (On The Road inc 20% Vat)
Australia MSRP Price: See dealer for pricing in AU

MSRP*

$1,699 – Team Yamaha Blue – Available from November 2018

Engine

Engine Type

49cc air-cooled SOHC 4-stroke; 2 valves

Bore x Stroke

36.0mm x 48.6mm

Compression Ratio

9.5:1

Fuel Delivery

Mikuni® VM11 carburetor

Ignition

CDI

Transmission

Constant-mesh 3-speed; automatic clutch

Final Drive

Chain

Suspension / Front

Inverted telescopic fork; 3.8-in travel

Suspension / Rear

Single shock; 2.8-in travel

Brakes / Front

Drum, 80mm

Brakes / Rear

Drum, 80mm

Tires / Front

2.50-10-4PR

Tires / Rear

2.50-10-4PR

L x W x H

51.4 in x 23.4 in x 31.3 in

Seat Height

21.9 in

Wheelbase

36.4 in

Rake (Caster Angle)

25.5°

Trail

1.3 in

Maximum Ground Clearance

5.3 in

Fuel Capacity

0.8 gal

Fuel Economy**

n/a

Wet Weight***

126 lb

Warranty

90 Day (Limited Factory Warranty)





*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as
applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is
useful in making real-world comparisons with other models.









2019 Yamaha TT-R110E – Totalmotorcycle.com Canada Specifications/Technical Details
Engine
4-stroke, air-cooled, SOHC, 2-valve, single
Displacement
50cc
Bore and Stroke
36 x 48.6mm
Compression Ratio
9.5:1
Maximum Torque
0.32 kg-m (2.3 ft-lb) @ 5,500 rpm
Fuel Delivery
Mikuni VM11
Ignition / Starting
CDI / Electric
Transmission
3-speed, semi auto (automatic clutch)
Final Drive
Chain
Chassis
Suspension (Front)
22 mm conventional fork / 96mm (3.8″) wheel travel
Suspension (Rear)
Monocross, single shock / 71mm (2.8″) wheel travel
Brakes (Front)
Drum
Brakes (Rear)
Drum
Tires (Front)
2.50-10
Tires (Rear)
2.50-10
Critical Data
Length
1,305mm (51.4″)
Width
595mm (23.4″)
Height
795mm (31.3″)
Wheelbase
925mm (36.4″)
Ground Clearance
135mm (5.3″)
Seat Height
555mm (21.9″)
Fuel Capacity
3 litres (0.66 imp. gallons)
Wet Weight
57kg (126 lb)
Colour(s)
Yamaha Racing Blue











2019 Yamaha TT-R110E – Totalmotorcycle.com European Specifications/Technical Details

Engine type

air-cooled, 4-stroke, SOHC, 2-valves

Displacement

49.5cc

Bore x stroke

36.0 mm x 48.6 mm

Compression ratio

9.5 : 1

Lubrication system

Wet sump

Clutch type

Wet, Muliple-disc and centrifugal automatic

Ignition system

CDI

Starter system

Electric

Transmission system

Constant Mesh, 3-speed

Final transmission

Chain

Fuel system

Fuel system

  • Chassis

Frame

Steel tube backbone

Front travel

96 mm

Caster angle

25.5º30′

Trail

34mm

Front suspension system

Telescopic forks

Rear suspension system

Swingarm

Rear travel

71 mm

Front brake

Drum, Ø80 mm

Rear brake

Drum, Ø80 mm

Front tyre

2.50-10 4PR

Rear tyre

2.50-10 4PR

  • Dimensions

Overall length

1,305 mm

Overall width

595 mm

Overall height

795 mm

Seat height

555 mm

Wheel base

925 mm

Minimum ground clearance

135 mm

Wet weight (including full oil and fuel tank)

57 kg

Fuel tank capacity

3.1litres

Oil tank capacity

1.0litres









2019 Yamaha TT-R110E – Totalmotorcycle.com Australian Specifications/Technical Details









Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
