2019 Yamaha XSR900 Guide

2019 Yamaha XSR900

2019 Yamaha XSR900 2019 Yamaha XSR900 2019 Yamaha XSR900 2019 Yamaha XSR900 2019 Yamaha XSR900

VINTAGE SPIRIT WITH MODERN TECHNOLOGY.

2019 Yamaha XSR900:

Based on the popular FZ-09, the XSR900 is a beautiful blend of 3-cylinder performance and eye catching “authentic sports” styling. The XSR includes all of the FZ-09’s key features plus traction control and ABS equipped brakes. A natural riding position offers solid riding comfort while the slipper clutch with assist highlights the more serious sports side of the XSR. Tasty, timeless styling combined with plenty of Yamaha’s latest technologies, the XSR is guaranteed to provide a fun, exciting ride.

An authentic performance motorcycle that blends Yamaha triple-cylinder technology with neo-retro style.

BORN TO RULE

44 MPG Estimated



///Power

Liquid-cooled, 847 cc inline 3-cylinder fuel-injected engine with a downdraft intake. The engine has been tuned to provide plenty of low to mid-range torque with strong yet linear throttle response.

///Styling

You won’t find a lot of plastic parts on the XSR900. The “authentic sports” styling highlights Yamaha’s long racing heritage, but don’t be fooled, there is plenty of cutting edge technology under the aluminum shrouded fuel tank.

///Instrumentation

Multifunction, digital instrument displays all the info discerning sport riders demand. From a bar style tach to gear position indicator, to instant & average fuel economy, this classic round design liquid crystal instrument adds function and style.



Yamaha’s Sport Heritage models have been created by drawing on the company’s in-depth experience gained from the design and manufacture of the world’s most famous and iconic motorcycles that spans seven decades.

During this time the world of motorcycling has change almost beyond recognition. And yet the unique emotions and intense excitement experienced when riding on two wheels has always stayed the same. The Faster Sons design philosophy fuses fashionable vintage style with advanced engine and chassis technology, to create some of the most beautiful, enjoyable and exciting models.

With their timeless design, naked bodywork and natural riding position, the XSR900 and XSR700 capture the very essence of motorcycling, while at the same time delivering thrilling performance with agile handling and the very latest in electronic control technology.

Race-inspired Garage Metal colour arrives March 2019
For 2019 the authentic and timeless style of the XSR Sport Heritage models is reinforced with a bold yet simple Garage Metal colour scheme inspired by the red/white bodywork that was made famous by Yamaha’s GP-winning bikes in the 1970s.

Featuring a thick red horizontal stripe with a solid black outline over a deep aluminium silver body colour, this vintage design harks back to the era when Yamaha established itself the most exciting and innovative brand in the market – and the vintage theme is accentuated by the red stitching used in the seat.

With its high quality finish and timeless style, the Garage Metal colour perfectly complements the unique character of the XSR900 and XSR700 by blending authenticity and modernity in equal measure.

Garage Metal XSR models will be available in Yamaha dealers from March 2019.







2019 Yamaha XSR900 Totalmotorcycle.com Key Features
  • A Style All Its Own
    The XSR900™ blends Yamaha’s world-class engineering with standout neo-retro style, creating a new type of machine for riders looking for an authentic and honest motorcycle that doesn’t sacrifice performance. Drawing influence from Yamaha’s classic “XS” series of motorcycles, the XSR oozes class, with exposed aluminum details, retro-influenced bodywork, stepped seat and custom lighting and instrumentation.
  • Advanced Crossplane Crankshaft Concept Engine
    The XSR900 features a thrilling 847cc Crossplane Crankshaft Concept liquid-cooled inline 3-cylinder, DOHC, 4-valve-per-cylinder engine based on the FZ-09™. The compact motor offers the best balance of both 2- and 4-cylinder designs, with an exciting, torquey and quick-revving engine character.
  • Cutting-Edge Electronics
    The XSR900 combines a classic heritage with modern performance, featuring ride-by-wire YCC-T® engine control, adjustable D-MODE throttle response, and an adjustable Traction Control System, allowing the rider to make the most of the potent engine and chassis.
  • Powerful Braking with ABS
    The XSR900 provides exceptional braking power with confidence thanks to sportbike-spec brakes backed up with the security of ABS.
  • Compact, Sporty Chassis
    The narrow aluminum frame features sport-oriented geometry to achieve light and nimble handling. Adjustable suspension front and rear allows the rider to customize their XSR900 to match road conditions and personal preferences.


XSR900
•    850cc inline 3-cylinder 4-stroke liquid-cooled DOHC engine
•    Torque-rich crossplane concept engine design
•    Lightweight short-wheelbase aluminium chassis
•    Traction Control System and D-MODE adjustable engine settings
•    Born to customize

XSR700
•    689cc inline 2-cylinder 4-stroke liquid-cooled DOHC engine
•    Crossplane-concept design for deep and powerful linear torque output
•    Light, slim and compact chassis
•    Dual 282mm wavy front discs
•    Built for optimum riding enjoyment



Race-inspired Aluminum/Red color for 2019 XSR700 and XSR900

For 2019, the authentic and timeless style of the XSR Sport Heritage models is reinforced with a bold yet simple Aluminum/Red color scheme inspired by the red and white bodywork that was made famous by Yamaha’s GP-winning bikes in the 1970s. Featuring a thick red horizontal stripe with a solid black outline over a deep aluminum silver body color, which is accentuated by the red stitching used in the seat, this vintage design harkens back to the era when Yamaha established itself as the most exciting and innovative brand in the market.

With its high-quality finish and timeless style, the Aluminum/Red color perfectly complements the unique character of the XSR900 and XSR700 by blending authenticity and modernity in equal measure.







2019 Yamaha XSR900 Totalmotorcycle.com Features and Benefits

Engine

  • Advanced Crossplane Crankshaft Concept Engine
    The XSR900 features a thrilling 847cc liquid-cooled inline 3-cylinder, DOHC, 4-valve-per-cylinder Crossplane Crankshaft Concept engine based on the FZ-09. With a 78mm x 59.1mm bore and stroke and 11.5:1 compression ratio, the compact motor produces a torquey and quick-revving engine character.
  • Advanced Ride-by-Wire Throttle with D-MODE
    The XSR900 is equipped with Yamaha’s Chip Controlled Throttle (YCC-T) for precise throttle control, as well as Yamaha’s selectable D-MODE, which allows the rider to adjust engine character on the fly. STD Mode is set to accommodate a wide range of riding conditions, A Mode gives the rider a sportier throttle response in the low-to mid-rpm range, and B Mode lets the rider enjoy a softer throttle response.
  • Adjustable Traction Control
    The XSR900’s Traction Control System lets the rider get on the gas with more confidence, by regulating ignition timing, fuel injection and throttle valve opening based on wheel speeds. Three modes are available: Mode “1” is for minimal intervention, Mode “2” is for maximum intervention, and “OFF” switches the system off entirely.
  • Vibration Reducing Counterbalancer
    To reduce vibration and provide a smooth, modern engine character, the motor uses a geared counterbalancer that revolves in the opposite direction as the crankshaft.
  • Fracture-Split Connecting Rods
    Just like Yamaha’s racetrack-developed supersport models, the XSR900 makes use of fracture-split connecting rods for the ultimate in precision and performance. The fracture-split method splits the big-end ring of a connecting rod in two by applying a sharp impact, to create a perfectly matching surface when it is bolted around the crankshaft.
  • Unique Staggered Intake Funnels
    To create the XSR900’s potent mid-range torque and unique intake sound, the engine’s intake funnels have been designed with three uneven lengths. Combined with the YCC-T system, the XSR900 gives its rider the ‘right-now’ thrust ideal for street riding.
  • Compact 6-Speed Transmission
    The XSR900’s 6-speed transmission takes full advantage of the low-to-mid-range torque and excellent response of the inline triple, while further enhancing the narrow 3-cylinder design.
  • Assist-and-Slipper Clutch
    The XSR900 includes an advanced assist-and-slipper clutch unit that provides both greater clamping force and back-torque reduction. This allows for the use of lighter clutch springs – reducing clutch lever effort by 20% – as well as minimizing rear-wheel hop under aggressive deceleration.

Chassis/Suspension

  • A Style All Its Own
    The XSR900 blends Yamaha’s world-class engineering with standout neo-retro style, creating a new type of machine for riders looking for an authentic and honest motorcycle that doesn’t sacrifice performance. Drawing influence from Yamaha’s classic “XS” series of motorcycles, the XSR oozes class, with exposed aluminum details, retro-influenced bodywork, stepped seat and custom lighting and instrumentation.
  • Compact, Sporty Chassis
    Underneath the new bodywork, an aluminum frame features a sport-oriented wheelbase, with rake and trail geometry working with the compact 3-cylinder engine to achieve light and nimble handling.
  • Adjustable Suspension
    Both front and rear suspension systems feature spring preload and rebound damping adjustments for a truly customizable ride. Up front, an inverted fork with 41mm inner tubes provides 5.4 inches of travel, while the rear linkage-type monoshock uses a nearly horizontal layout for improved mass-centralization, along with 5.1 inches of rear wheel travel.
  • Powerful Braking with ABS
    The XSR900 provides exceptional braking power thanks to sportbike-spec front brakes, consisting of paired floating 298mm discs with radially-mounted 4-piston calipers and a 245mm rear disc. ABS works to prevent wheel lock under hard deceleration.
  • Lightweight Wheels
    Lightweight 10-spoke cast aluminum wheels are fitted with a 120/70ZR17 front tire and 180/55ZR17 rear tire for excellent traction.

Additional Features

  • Advanced Instrumentation
    The new round LCD panel features a ton of information: digital tachometer, speedometer, gear position, eco mode indicator, TCS and D-MODE indicators, ambient and coolant temperature, a fuel gauge and range of trip computer functions, including a clock, instant and average fuel consumption, fuel reserve trip meter and the usual trip meters.
  • Neo-Retro Lighting
    Up front, a large, round multi-reflector headlight provides both style and illumination in equal measure, complete with trick aluminum supports, while out back, a round all-LED tail and brake light is mounted above the rear fender.
  • Stylish and Ergonomic Fuel Tank
    A compact 3.7 gallon fuel tank with offset fuel filler is shrouded by beautifully shaped and hand-finished aluminum covers for a timeless design.
  • Sporty, All-Purpose Ergonomics
    A wide, tapered aluminum handlebar, dished saddle and forged aluminum foot controls provide a comfortable upright riding position ideal for urban traffic or hustling down a twisty road.
  • Unique XSR900 Detailing
    Every aspect of the XSR900 shows Yamaha’s attention to detail: The single-piece stepped saddle features a stitched “XSR900” logo. The mirrors are classic teardrop shapes with excellent rearward visibility. The compact radiator is flanked by exposed aluminum covers. The front fender uses retro-influence aluminum stays. The XSR900 demands a second look, every time.





Vintage Yamaha colours for the 2019 XSR900 and XSR700

2019 Faster Sons vintage clothing collection
Yamaha’s Faster Sons clothing collection gets a whole new range of cool designs that complement the timeless feel of the Sport Heritage bikes. Featuring a strong and simple look that’s been inspired by the 70’s US motocross scene, these trendy new T-shirts, hoodies, sweaters, caps and buffs perfectly capture the authentic and original Yamaha spirit.

With their fashionable good looks and premium quality, these easy going casuals are designed to make everyone feel good – whether they’re a rider, Yamaha fan or just someone who appreciates their cool vintage appeal. The new Faster Sons vintage collection will be available in Yamaha dealers from the end of February 2019.

Yamaha Genuine Options: Make it all yours
Getting your new Yamaha Sport Heritage model is the beginning of a great relationship – because these bikes were born to be customized, and you can create your own unique XSR and enhance its specification to suit your lifestyle by fitting a range of Yamaha Genuine Options.

For each motorcycle in the range the Genuine Options line can cover three broad groups. Functional parts such as screens, luggage and heated grips are designed to make your ride as comfortable as possible – while styling parts such as billet and carbon fibre covers, mesh grills and anodized components add some bling.

And if you’re looking for more performance, check out the line-up of exhausts, slip on mufflers, billet adjusters and much more.

Build your dream collection with the free MyGarage app
The MyGarage app is the best way to build your dream collection of Yamaha motorcycles – and it’s totally free! Download the app and you’re ready to start creating your very own personalized Yamaha.

With MyGarage you can add or remove a wide range of Genuine Options accessories and view the bike from any angle. Once you’ve created your dream bikes you can save them and share with friends – and when you’ve made the final decision on which version is right for you, simply send it to your Yamaha dealer who will turn it into reality.







2019 Yamaha XSR900 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $9499 USD
Canada MSRP Price: $11199 CDN
Europe/UK MSRP Price: £ See dealer for pricing in GBP (On The Road inc 20% Vat)
Australia MSRP Price: See dealer for pricing in AU

Engine Type 847cc liquid-cooled DOHC inline 3-cylinder 4-stroke; 12 valves

Bore x Stroke 78.0mm x 59.1mm

Compression Ratio 11.5:1

Fuel Delivery Yamaha Fuel Injection with YCC-T

Ignition TCI: Transistor Controlled Ignition

Transmission 6-speed; multiplate assist-and-slipper wet clutch

Final Drive Chain

Suspension / Front 41mm inverted fork, adjustable preload and rebound damping; 5.4-in travel

Suspension / Rear Single shock, adjustable preload and rebound damping; 5.1-in travel

Brakes / Front Dual 298mm discs; ABS

Brakes / Rear 245mm disc; ABS

Tires / Front 120/70ZR17

Tires / Rear 180/55ZR17

L x W x H 81.7 in x 32.1 in x 44.9 in

Seat Height 32.7 in

Wheelbase 56.7 in

Rake (Caster Angle) 25.0°

Trail 4.1 in

Maximum Ground

Clearance 5.3 in

Fuel Capacity 3.7 gal

Fuel Economy** 44 mpg

Wet Weight*** 430 lb

Warranty 1 Year (Limited Factory Warranty)

Color Aluminum/Red



*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as
applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is
useful in making real-world comparisons with other models.









2019 Yamaha XSR900 – Totalmotorcycle.com Canada Specifications/Technical Details
Engine
Liquid-cooled, DOHC, 12-valve (4-valves/cyl), inline-three cylinder
Displacement
847cc
Bore and Stroke
78 x 59.1 mm
Compression Ratio
11.5:1
Maximum Torque
8.9 kg-m (64.3 ft-lbs.) @ 8,500 rpm
Engine Management
YCC-T & D-Mode (3 positions) & Traction Control
Fuel Delivery
Mikuni 41mm throttle body F.I.
Estimated Fuel Consumption±
18.6kpl / 52.5 mpg (Imp.)
Lubrication
Wet sump
Ignition / Starting
TCI / Electric
Transmission
6-speed
Final Drive
“O”-ring chain
Chassis
Suspension (Front)
Adjustable 41mm inverted fork / 137mm (5.4″) wheel travel
Suspension (Rear)
Adjustable link Monocross / 130mm (5.1″) wheel travel
Brakes (Front)
Dual 298mm discs / radial mount, 4-piston calipers / ABS equipped
Brakes (Rear)
245mm disc / single piston caliper / ABS equipped
Tires (Front)
120/70ZR17
Tires (Rear)
180/55ZR17
Critical Data
Length
2,075mm (81.7″)
Width
815mm (32.1″)
Height
1,140mm (44.9″)
Wheelbase
1,440mm (56.7″)
Rake / Trail
25° / 103mm
Ground Clearance
135 mm (5.3″)
Seat Height
830mm (32.7″)
Fuel Capacity
14 litres (3.1 imp. gallons)
Wet Weight
195 kg (430 lb.)
Colour(s)
Blue
Matte Gray









2019 Yamaha XSR900 – Totalmotorcycle.com European Specifications/Technical Details

NA







2019 Yamaha XSR900 – Totalmotorcycle.com Australian Specifications/Technical Details

NA







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
