2020 BMW S1000RR Guide

2020 BMW S1000RR

2020 BMW S1000RR 2020 BMW S1000RR 2020 BMW S1000RR 2020 BMW S1000RR 2020 BMW S1000RR

THE SUPERBIKE OF SUPERLATIVES.

2020 BMW S1000RR:

Always pushing to the limit and in search of the ideal line, you’ve got 205 HP USA /152 kW Europe / 207 HP Canada, beneath you. Unbridled power pushes your RR to the max – with a maximum torque of 83 lb-ft at 11,000 rpm and a torque curve of at least 74 lb-ft over a range of 5,500 to 14,500 [rpm]. Ten years after the first generation of the RR first mesmerized the world of motorcycles, we’re now entering the next level of performance. We have updated almost every component of the 2020 BMW S1000RR – from the front to the rear. The result: less weight and noticeably higher performance. Are you ready for the pole position and for victory? The 2020 BMW S1000RR awaits you.





Designed for the pole position.

Anyone who looks at it immediately understands that this is a high performance motorcycle. Every part of the 2020 BMW S1000RR has been designed to get the most out of it. Take, for instance, the frame layout with its new suspension technology that makes the 2020 BMW S1000RR lighter and more precise. In addition, there is the ergonomically focused seating position, which is unrivaled thanks to the modified frame and fairing design. The standard LED headlights give the bike a dynamic and aggressive look. The front indicators have moved from the fairing to the rearview mirrors, which not only looks aesthetically pleasing, but it also provides improved visibility. Seen from the rear, the 2020 BMW S1000RR dominates in terms of design and functionality: “All-in-one” is the motto here. In addition to license plate lighting, the license plate bracket now also includes LED turn signals, tail lights and brake lights.



Ready for the track.

When it comes to top performance, the 2020 BMW S1000RR is your perfect partner. And not just on the road, but also on the track. In a few simple steps, you can dismantle both the rearview mirror and the license plate bracket and you’ve got a racing bike.

The optionally available M Package turns your 2020 BMW S1000RR into the ultimate racing machine. Here the weight is once more reduced by around 7.7 lbs down to a mere 427 lbs. In addition to the Motorsport finish, the M carbon wheels, the M battery, the M seat with M passenger seat cover and the M swing arm pivot you also get Ride Modes Pro with the configurable Ride Modes Race Pro 1-3 and electronic assistance systems, such as DTC +/- Shift, ABS Settings, engine mappings, wheelie control and slide control and a whole lot more.



Four-cylinder in-line engine.

205 HP at 13,000 rpm

83 lb-ft (min.) at 11,000 rpm

427 lbs curb weight, measured with M Package

14,600 maximum rpm

Water/oil-cooled four-cylinder four-stroke in-line engine



Four cylinders and unrivaled performance.

The newly designed, four-cylinder engine is the new RR power train. Not only was the peak output increased to 205 HP at 13,000 rpm, but the torque curve was also optimized. Thanks to the new BMW ShiftCam technology, which selects the valve opening time and the valve lift by means of the camshaft, significantly more torque and power is applied even in low and medium engine speed ranges.

In addition, numerous other components were adapted to further optimize weight, space and design. These include a new timing concept, hollow-drilled titanium intake valves and an improved and self-reinforcing multi-disc, anti-hopping wet clutch (-20N). The engine is now narrower and about 9 lbs lighter, which improves both the handling and the ergonomics. You will notice this immediately when you first get on.





BMW Motorrad USA has announced pricing, features, packages, and options for the new 2020 BMW S1000RR, scheduled to arrive in BMW dealer showrooms this summer. The third-generation BMW S 1000 RR will have a Manufacturer’s Suggested Retail Price of $16,995 USA (excluding tax and destination fee).





2020 BMW S1000RR Totalmotorcycle.com Key Features

The BMW S 1000 RR plays by its own rules: appearance here always means pure performance. Dynamic stands for the purest form of racing sport and riding pleasure. Added to this is the constant balance between reason and unreasonableness. And all of this with unchanged and impressive performance values – despite being adapted to the EU-4 standard.



Standard features

  • 4 Ride Modes (Rain/Sport/Dynamic/Race)
  • ABS Pro
  • Adjustable Clutch Lever
  • Adjustable Hand Brake Lever
  • Adjustable Rear Suspension Preload/Compression/Rebound Damping
  • Aluminum Fuel Tank
  • Anti-Hopping Clutch
  • Cast Aluminum Wheels
  • Connectivity with TFT Display
  • Detachable License Plate Bracket
  • Drop Sensor
  • DTC (Dynamic Traction Control)
  • Electronic Immobilizer
  • Gear Shift Assist Pro
  • Hill Start Control
  • Info Flat Screen
  • Integral Race ABS (Disengageable)
  • LED Headlight with Style Element
  • LED Tail Light
  • LED Turn Signals
  • Multi-Controller
  • Multifunction Display
  • On-Board Computer
  • Radial Front Brakes
  • Ready for GP Gear Shift Pattern
  • ShiftCam (Variable Camshaft Control)
  • Single Seat
  • Steering Damper
  • Tachometer
  • Torque Control Assist
  • Upside-Down Forks with Adjustable Preload/Compression/Rebound Damping



Additional Standard Equipment and Features (vs. MY 2019)

  • LED Headlight and turn signals
  • Connectivity with 6.5” TFT display
  • On Board Computer and Multi-Controller
  • Gear Shift Assist Pro
  • Hill Start Control
  • 4 standard ride modes (Rain, Road, Dynamic, Race)
  • Adjustable Clutch Lever
  • Cornering-optimized ABS Pro
  • All-new dynamic design w/ optimal aerodynamics
  • Substantial engine and technology improvements

*The model year 2020 BMW S1000RR includes new standard features valued at over $2,000.

Engine/Design Enhancements (vs. MY 2019)

  • 25 lb total weight reduction from 459 lbs to 434 lbs

(Additional weight reduction of 7.7 lbs. with M Package)

  • Engine is ~9 lbs. lighter: improved handling/ergonomics
  • BMW ShiftCam Variable Engine Timing system
  • 205 hp vs. 200 hp
  • More balanced power delivery
  • Improved HP/torque curve at low/medium engine speed
  • 37 mpg vs. 35 mpg
  • New suspension geometry: less weight, higher level of precision



Packages
Select Package (MSRP $1,400):
• Tire Pressure Monitor
• Next-Generation DDC (Dynamic Damping Control)
• Heated Grips
• Cruise Control

Updated Race Package (MSRP $1,600):
• Ride Modes Pro
• Forged Wheels
• M Lightweight Battery
• M Chassis Kit (Rear Ride Height Adjustment and Swing Arm Pivot Point)

New M Package (MSRP $3,700) – Initial Supply is Limited:
• M Motorsport Paint
• M Carbon Wheels
• Ride Modes Pro
• M Sport Seat
• M Lightweight Battery
• M Chassis Kit (Rear Ride Height Adjustment and Swing Arm Pivot Point
• 7.7 lb. weight savings = 427 lbs. total wet weight

Single Options
Ride Modes Pro (MSRP $250)
• +3 Ride Modes: Race Pro 1, 2, 3
• Hill Start Control Pro (HSC Pro)
• Dynamic Brake Control (DBC)
• Launch Control
• Pit Lane Limiter
• DTC +/-
• Wheelie Control

Design Option Wheels (MSRP $140)
• Black Wheels with Red Striping

Passenger Kit
• Passenger Seat and Passenger Foot Pegs) (MSRP $0)

Anti-Theft Alarm (MSRP $395)





2020 BMW S1000RR Totalmotorcycle.com Features and Benefits

Technology made for maximum performance in every situation.

The RR is a technical high-flyer with road grip: The four standard modes RAIN, ROAD, DYNAMIC and RACE already cover numerous riding styles in a variety of conditions. Optional Ride Modes Pro mode lays the racing world at your feet with the three additional modes RACE Pro 1, RACE Pro 2 and RACE Pro 3, with Launch Control, Pitlane Limiter, HSC Pro (Hill Start Control Pro) and DBC (Dynamic Brake Control). With the multi-controller you can configure the following settings via the full-color 6.5″ TFT display: the throttle response incl. engine characteristics, the engine braking torque, the traction control (DTC) incl. wheelie control, ABS and DDC (Dynamic Damping Control). And with the push of a button you can adjust the settings while riding via DTC +/- Shift. Thanks to the latest 6-axis sensor technology and torque precontrol, DTC support is particularly smooth and powerful, and performs no matter the gear, speed and inclination.

With the next-generation DTC, you get more efficient, powerful and safer traction control and thus even more forward momentum.





More stability and better force application.

The new RR has, as the only street-legal standard superbike, an aluminum undercarriage, which had previously only been used on the racing scene. The 0.66 lb lighter weight significantly reduces the unsprung mass and results in significantly less reaction from the chassis when accelerating. In addition, the shock absorber, which can be adjusted in terms of tension and rebound as well as the suspension, is installed farther away from the engine and is thus less exposed to heat. This has significant advantages for the shock absorber. By changing the strut ratio from 1.9:1 to 1.65:1 and having a larger damper piston, a smaller spring rate was able to be selected. This friction minimization increases comfort and performance since the power build-up in the strut occurs quickly and accurately. The entire system is thus much gentler on the tires.

Perfect damping on all routes.

Dynamic Damping Control (DDC) showcases a newly developed control philosophy of the electronic chassis and mechanical damping component. Regardless of whether you’re on a country road or the track – the electronic valve always provides the maximum damping, depending on the riding mode and purpose. It is now parallel to the mechanical valve. If necessary, the damping is reduced or increased in 10 milliseconds via this bypass line. The newly anodized floating piston rod is extremely sensitive. If required, the Shim Package can also be adapted by chassis specialists.

The fork is also controlled by means of a linear position sensor with DDC. Damping is regulated here globally and in traction and compression stages. The suspension can be manually varied as needed.



BMW ShiftCam technology: a combination of optimized torque and top-end performance.

When you first accelerate you will immediately notice: that this bike’s torque curve is captivating even at low and middle speeds thanks to BMW’s ShiftCam technology. The intake valves are controlled as needed by means of a control camshaft. Depending on the speed, the valve lift and timing of the valve opening are adjusted to ensure the best performance for you and your RR.



ABS and ABS Pro: from maximum stability to the highest possible performance.

The RR has standard ABS and ABS Pro, depending on your riding mode: RAIN, ROAD, DYNAMIC, RACE or optional RACE Pro-1 to 3. So you decide whether your bike needs the maximum stability or the highest possible performance



Standard Gear Shift Assist Pro: switch gears in milliseconds with maximum stability and performance.

On the road or on the track: This feature is a must. With the standard feature Gear Shift Assist Pro, you can smoothly shift up or down without pulling the clutch lever, so you can fully concentrate on the road. At the same time, the load-bearing influences on the body and rear wheel have been reduced to a minimum. The result: you’re faster, more stable and can enjoy even higher performance and more riding pleasure.



Completely newly developed Dynamic Damping Control (DDC): ideal damping for country roads and the track.

The RR comes optionally equipped with the next generation DDC. Now the electronic valve is parallel to the mechanical valve. If necessary, the damping is reduced or increased in 10 milliseconds via this bypass line. For the road or the track, you can rely on exceptional damping. The suspension spring can also be adjusted manually.



Lighting design: LED, visible, dynamic, aggressive.

The standard LED headlights give the RR its new unmistakable sporty-aggressive look. This applies not only to the front headlights but to the front turn signals, which have been moved from the fairing to the mirrors on the new RR. For the rear of the bike, the turn signal, brake and tail light have been combined into one component.



6.5″ TFT display: everything in sight – and under control.

The benchmark in the superbike segment: the TFT display of the RR. With 6.5″ you have a perfect overview of your bikes information. You can choose between the Pure Ride screen that’s reduced to the essentials, or one of three Core Ride screens that display other important information. Everything under control with the multi-controller on the left handlebar: Simply scroll through the menu of your 6.5″ TFT display and access the various functions and settings – without taking your hands off the handlebars, so you maintain full control.



Ergonomics: more comfort, support and freedom of movement.

Not only is the new RR a lot lighter at a mere 434 lbs, it’s also got the perfect ergonomics. The frame, tank, seat, tail and footpegs have all been modified for more support, freedom of movement, more feedback and better knee closure.

The interplay of the milled footpegs and the new handlebar ergonomics with the M seat, in addition to even more feedback, lets you ride longer and concentrate on achieving faster lap times.



Strut and swing arm: performance, sensitivity and adjustability – everything for your personal victory.

The new RR is equipped with an aluminum swing arm and offers you better power distribution and less reaction from the chassis when accelerating. That saves the tires. The standard shock absorber of the new RR is now further away from the engine and is therefore less exposed to heat. In addition, a larger damper piston improves damping in all riding situations.



Standard seat and special equipment: always firmly in the saddle.

When you look at the standard seat, you’ll immediately know that perfect feedback was the goal. This allows not only more freedom of movement, but also the perfect amount of contact with the motorcycle while riding. The standard seat height is 32.4” and the inner-leg curve is 71.9”.

In addition to the standard seat, there’s also the optional M seat for the new RR. Its firmness and slip-resistant cover save power when accelerating or braking hard, and bring more stability to the bike. The M seat is part of the M Package. It is available in three seat heights (32 in, 32.4 in and 33.4 in) as a special accessory.



License plate bracket with lighting components: everything all in one and easily dismantled.

It’s so fast to convert your RR from a cruising bike to a racing machine: the tail light integrated into the LED turn signals and the license plate light are both attached to the license plate bracket unit. The big advantage here is that in just a few simple steps you can remove the license plate bracket and lighting and be ready for the track in no time.



4 standard Ride Modes / Optional Race Pro 1-3 riding modes: a question of attitude.

Four Ride Modes are standard with the RR: RAIN, ROAD, DYNAMIC and RACE. All four are perfectly tailored to the respective conditions and provide more performance or more stability and safety, as desired. Racers, in particular, get their money’s worth with the special Ride Modes Pro option. The additional RACE Pro 1, RACE Pro 2 and RACE Pro 3 modes can be individually adapted to Engine (throttle), Engine Brake, Traction Control (DTC), Wheelie-Control (DTC), ABS and ABS Pro – so that you can achieve the best possible performance on every track.







2020 BMW S1000RR – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $16,995 USD
Canada MSRP Price: $18,900 – $20,100, CDN
Europe/UK MSRP Price: £15,290 GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AU

Engine

Type

Liquid cooled, 4-stroke in-line 4-cylinder engine, four titanium valves per cylinder, double overhead camshafts, wet sump lubrication, BMW ShiftCam

Bore x stroke

80 mm x 49.7 mm

Capacity

999 cc

Rated output

205 hp (151 kW) at 13,000 rpm

Max. torque

83 lb-ft (113 Nm) at 11,000 rpm

Compression ratio

13.3:1

Mixture control / engine management

Electronic fuel injection with ride-by-wire throttle system, variable intake, and knock sensor

Emission control

Closed-loop 3-way catalytic converter, emission standard EU-4

Performance / fuel consumption

Maximum speed

Over 125 mph

Fuel consumption

37 mpg (WMTC)

Fuel type

Premium Unleaded

Electrical system

Alternator

Three-phase 450 W Generator

Battery

12 V / 8 Ah, maintenance-free

Power transmission

Clutch

Multi-disc clutch in oil bath, anti-hopping clutch, mechanically operated, integrally-reinforced

Gearbox

Constant-mesh 6-speed gearbox with straight cut gears

Drive

Chain 525 17/45

Chassis / brakes

Frame

Aluminum composite bridge frame, partially self-supporting engine

Front wheel location / suspension

Upside-down telescopic fork Ø 45 mm, compression and rebound stage adjustable, adjustable preload

Rear wheel location / suspension

“WSBK” Aluminium swing arm, full floater pro, compression and rebound damping adjustable, adjustable preload

Suspension travel front / rear

4.7” / 4.6” (120 mm / 117 mm)

Wheelbase

56.7” (1,441 mm)

Castor

3.7” (93.9 mm)

Steering head angle

66.5°

Wheels

Aluminum cast wheels

Rim, front

3.50 x 17″

Rim, rear

6.00 x 17″

Tires, front

120/70 ZR 17

Tires, rear

190/55 ZR 17

Brake, front

Dual floating disc brakes, 4-piston fixed calipers, diameter 320 mm

Brake, rear

Single disc brake, diameter 220 mm, single piston floating caliper

ABS

BMW Motorrad Race ABS (partly-integral) with selectable modes; can be switched off. ABS Pro settings for RAIN, ROAD, DYNAMIC modes, but no ABS Pro in RACE mode.

Dimensions / weights

Length

81.6″ (2,073 mm)

Width (incl. mirrors)

33.4″ (848 mm)

Height (excl. mirrors)

45.3″ (1,151 mm)

Seat height, unladen weight

Standard Seat: 32.4″

Inner leg curve, unladen weight

Standard Seat: 71.9ʺ

Unladen weight, road ready, fully fueled

Standard: 434 lbs (197 kg), M Package: 427 lbs (193.5 kg)

1)

Permitted total weight

895 lbs (407 kg)

Payload (with standard equipment)

463 lbs (210 kg)

Usable tank volume

4.4 gal (16.5 l)

Reserve

Approx. 1 gal (4 l)

1) As defined in EU directive 93/93/EEC, filled with all operating fluids, fueled to at least 90% of usable tank capacity







2020 BMW S1000RR – Totalmotorcycle.com Canada Specifications/Technical Details

Type

Water/oil-cooled 4-cylinder 4-stroke in-line engine, four titanium valves per cylinder, BMW ShiftCam

Bore / stroke

80 mm x 49.7 mm

Capacity

999 ccm

Rated output

152 kW (207 hp) at 13,500 rpm

Max. torque

113 Nm at 11,000 rpm

Compression ratio

13.3:1

Mixture control

Electronic injection, variable intake pibe

Emission control

Closed-loop 3-way catalytic converters, EU-4 norm

Performance / fuel consumption

Maximum speed

299 km/h

Fuel consumption per 100 km based on WMTC cycle

6.4 l

CO2 emission based on WMTC

149 g/km

Fuel type

Unleaded super(premium), octane number 95 – 98 (RON) (knock control; rated output at 98 RON)

Electrical system

Alternator

450 W

Battery

12 V / 8 Ah, maintenance-free

Power transmission

Clutch

Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement

Gearbox

Constant-mesh 6-speed gearbox with straight cut gears

Drive

Chain 525 17/45

Tractioncontrol

DTC

Chassis / brakes

Frame

Bridge-type frame, cast aluminium, load-bearing engine

Front wheel location / suspension

Upside-down telescopic fork Ø 45 mm, compression and rebound stage adjustable, adjustable preload

Rear wheel location / suspension

“WSBK” Aluminium swing arm, full floater pro, compression and rebound damping adjustable, adjustable preload

Suspension travel, front / rear

120 mm / 117 mm

Wheelbase

1,441 mm

Castor

93.9 mm

Steering head angle

66.9°

Wheels

Aluminium cast wheels

Rim, front

3.50″ x 17″

Rim, rear

6.00″ x 17″

Tire, front

120/70 ZR 17

Tire, rear

190/55 ZR 17

Brake, front

Twin disc brake, 4-piston fixed caliper, diameter 320 mm

Brake, rear

Single disc brake, single piston floating caliper, diameter 220 mm

ABS

BMW Motorrad Race ABS (part-integral), disengageable, modes to select

ABS Pro

ABS Pro settings for RAIN, ROAD, DYNAMIC mode, no ABS in RACE mode

Dimensions / weights

Seat height

824 mm

Inner leg curve

1,827 mm

Usable tank volume

16.5 l

Reserve

approx. 4 l

Length

2,073 mm

Height (excl. mirrors)

1,151 mm

Width (incl. mirrors)

848 mm

Dry weight

175 kg (M Package 173.3 kg) without battery

Unladen weight, road ready, fully fuelled

197 kg (M Package 193.5 kg)

Permitted total weight

407 kg

Payload (with standard equipment)

210 kg

1) According to guideline VO (EU) 168/2013 with all fluids, with standard equipment and fuelled with at least 90% of usable tank volume.







2020 BMW S1000RR – Totalmotorcycle.com European Specifications/Technical Details

Type

Water/oil-cooled 4-cylinder 4-stroke in-line engine, four titanium valves per cylinder, BMW ShiftCam

Bore / stroke

80 mm x 49.7 mm

Capacity

999 ccm

Rated output

152 kW (207 hp) at 13,500 rpm

Max. torque

113 Nm at 11,000 rpm

Compression ratio

13.3:1

Mixture control

Electronic injection, variable intake pibe

Emission control

Closed-loop 3-way catalytic converters, EU-4 norm

Performance / fuel consumption

Maximum speed

299 km/h

Fuel consumption per 100 km based on WMTC cycle

6.4 l

CO2 emission based on WMTC

149 g/km

Fuel type

Unleaded super(premium), octane number 95 – 98 (RON) (knock control; rated output at 98 RON)

Electrical system

Alternator

450 W

Battery

12 V / 8 Ah, maintenance-free

Power transmission

Clutch

Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement

Gearbox

Constant-mesh 6-speed gearbox with straight cut gears

Drive

Chain 525 17/45

Tractioncontrol

DTC

Chassis / brakes

Frame

Bridge-type frame, cast aluminium, load-bearing engine

Front wheel location / suspension

Upside-down telescopic fork Ø 45 mm, compression and rebound stage adjustable, adjustable preload

Rear wheel location / suspension

“WSBK” Aluminium swing arm, full floater pro, compression and rebound damping adjustable, adjustable preload

Suspension travel, front / rear

120 mm / 117 mm

Wheelbase

1,441 mm

Castor

93.9 mm

Steering head angle

66.9°

Wheels

Aluminium cast wheels

Rim, front

3.50″ x 17″

Rim, rear

6.00″ x 17″

Tire, front

120/70 ZR 17

Tire, rear

190/55 ZR 17

Brake, front

Twin disc brake, 4-piston fixed caliper, diameter 320 mm

Brake, rear

Single disc brake, single piston floating caliper, diameter 220 mm

ABS

BMW Motorrad Race ABS (part-integral), disengageable, modes to select

ABS Pro

ABS Pro settings for RAIN, ROAD, DYNAMIC mode, no ABS in RACE mode

Dimensions / weights

Seat height

824 mm

Inner leg curve

1,827 mm

Usable tank volume

16.5 l

Reserve

approx. 4 l

Length

2,073 mm

Height (excl. mirrors)

1,151 mm

Width (incl. mirrors)

848 mm

Dry weight

175 kg (M Package 173.3 kg) without battery

Unladen weight, road ready, fully fuelled

197 kg (M Package 193.5 kg)

Permitted total weight

407 kg

Payload (with standard equipment)

210 kg

1) According to guideline VO (EU) 168/2013 with all fluids, with standard equipment and fuelled with at least 90% of usable tank volume.





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).

About Michael Le Pard 2658 Articles
"Mr. Totalmotorcycle". Owner and Founder of Total Motorcycle. Supporting over Motorcyclists and Motorcycling for 19 great years. Total Motorcycle is my pride and joy and being able to reach out 300 million people has been incredible but I could not have done it without the support of my visitors, readers and members, thank you so much! You are making a difference to millions of riders worldwide. Thank you.
