2020 Harley-Davidson Freewheeler Guide

2020 Harley-Davidson Freewheeler

2020 Harley-Davidson Freewheeler 2020 Harley-Davidson Freewheeler 2020 Harley-Davidson Freewheeler 2020 Harley-Davidson Freewheeler 2020 Harley-Davidson Freewheeler

GOOD THINGS COME IN THREES. HERE’S PROOF.

2020 Harley-Davidson Freewheeler:

The Freewheeler® has all-new braking enhancements like cornering enhanced Reflex™ linked brakes with ABS and traction control. Classic styling details, like bobtail fenders, slash cut pipes, 12-inch mini apes and Enforcer aluminum wheels. There’s enough cargo space to hold two full-face helmets plus extra gear. Power is plentiful, thanks to a Milwaukee-Eight® 114 V-Twin engine. Dual bending valve 49mm front forks and easily adjustable rear suspension make the ride smooth.

Stripped-down custom style meets the confidence of three wheels. You get braking enhancements like ABS, traction control and hill hold. And plenty of power, thanks to a Milwaukee-Eight® 114 engine.





2020 Harley-Davidson Freewheeler Totalmotorcycle.com Key Features

Custom touring style and easy handling features that lets you roll with confidence for longer. It’s everything you love about H-D Touring, just on three wheels. The new premium touring front and rear suspension is calibrated specifically for trike models. Easy tool-free preload adjusting, new cornering enhanced linked brake system with ABS and Traction Control, and luxurious seating put you in control of an unmatched ride. Incorporates an Antilock Braking System (ABS) and Traction Control System (TCS) that work together to provide enhanced cornering capability. In addition, the Milwaukee-Eight® 114 engine gives you passing and horizon-chasing power.

Engine

Milwaukee-Eight® 114

Engine Torque

165 Nm

Weight, As Shipped

1,085 lb.

Seat Height, Laden

26.2 in.







2020 Harley-Davidson Freewheeler Totalmotorcycle.com Features

Twin-Cooled™ Milwaukee-Eight® 114 Engine

The most displacement in standard H-D® Touring models. You get 114 cubic inches of passing and horizon-chasing power.

Reflex™ Defensive Rider Systems (RDRS)

A new collection of technologies that help give you confidence and control in less-than-ideal situations. The systems utilize advanced chassis control, electronic brake control and powertrain technology to assist you with accelerating and braking in a straight line or while in a turn.



Reflex™ Linked Brembo® Brakes with Standard ABS

Designed to help prevent the wheels from locking under braking to assist the rider in maintaining control when braking in a straight-line. ABS operates independently on front and rear brakes to keep the wheels rolling and help prevent uncontrolled wheel lock in urgent situations.



High Performance Suspension

Premium Harley-Davidson touring suspension technology is calibrated specifically for Trike models, delivering a smooth and responsive ride.



12″ Mini-Ape Hanger Bars

The 12-inch Mini-Ape hanger bars on the Freewheeler® model are the tallest rise you can get from an OE manufacturer. They pull the hand controls back toward the rider, and reduce the force it takes to turn the front wheel for easy riding and easy handling.



Bobtail Rear Fenders

The pair of Harley-Davidson® bobtail rear fenders give the bike classic cruiser lines and styling details.



Chrome Slash Cut Mufflers

The Milwaukee-Eight® 114 engine puts its exhaust note out to the world through these chrome slash down pipes.



Enforcer Cast Aluminum Wheels

There’s an Enforcer front wheel leading the way, and you’ve got two more to match in the back. Up front, the brake rotors have been redesigned to show off more of the premium custom look of the wheels.



7-Piece Nacelle

A classic style chrome headlight nacelle is tucked tight against the frame and forks for a tighter, smaller look. It also accommodates a clean-looking windshield mounting system.



Unique Trunk System

It’s a one-of-a-kind design that opens left to right (with one hand) and extends the entire length of the body for a clean look. Enough cargo space to easily accommodate two full-face helmets.



Steering Head and Front Forks

The responsiveness is dialed in with a stiff front end and 49mm front forks, plus a steering damper that controls feedback from the road.







2020 Harley-Davidson Freewheeler – Totalmotorcycle.com  American Specifications/Technical Details
US MSRP Price from: $27999
USD
Canada MSRP Price from: $33999 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

Pricing

  • Vivid Black $27,999
  • Color $28,499
  • Custom Color $29,599
  • ABS Option Standard
  • Security System Option Standard
  • Cruise Control Option Standard
  • California Emissions $200
  • Freight $856

Engine

  • Engine1 Milwaukee-Eight® 114
  • Bore 4.016 in.
  • Stroke 4.5 in.
  • Displacement 1,868 cc (114 cu in)
  • Compression Ratio 10.5:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Shorty slash down-style chrome finish mufflers

Dimensions

  • Length 103 in.
  • Seat Height, Laden7 26.2 in.
  • Ground Clearance 4.9 in.
  • Rake (steering head) (deg) 26
  • Trail 3.96 in.
  • Wheelbase 65.7 in.
  • Tires, Front Specification MT 130/60B19 M/C 61H
  • Tires, Rear Specification P205/65R15
  • Fuel Capacity 6 gal.
  • Oil Capacity (w/filter) 5 qt.
  • Weight, As Shipped 1,085 lb.
  • Weight, In Running Order 1,118 lb.
  • Luggage Capacity -Volume 2 cu ft

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 165 Nm
  • Engine Torque (rpm) 2,250
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy5 43 mpg

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 10.534
  • Gear Ratios (overall) 2nd 7.302
  • Gear Ratios (overall) 3rd 5.423
  • Gear Ratios (overall) 4th 4.392
  • Gear Ratios (overall) 5th 3.741
  • Gear Ratios (overall) 6th 3.157

Chassis

  • Wheels, Front Type9 Enforcer Cast Aluminum
  • Wheels, Rear Type Enforcer Cast Aluminum
  • Brakes, Caliper Type Front: 32mm 4 piston fixed Rear: floating 36mm piston integrated park brake

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, running lights, battery, neutral, low oil pressure, engine diagnostics, cruise control, security system, gear indicator, low fuel warning, reverse, park brake
  • Gauges Speedometer, fuel gauges; display features odometer, trip A, trip B, range to empty, and gear indicator







2020 Harley-Davidson Freewheeler – Totalmotorcycle.com  Canadian Specifications/Technical Details

Pricing

  • Vivid Black $ 33,999
  • Colour $ 34,999
  • Custom Colour $ 36,099
  • ABS Option Standard
  • Security System Option Standard
  • Cruise Control Option Standard

Engine

  • Engine1 Milwaukee-Eight®114
  • Bore 102 mm
  • Stroke 114 mm
  • Displacement 1,868 cc
  • Compression Ratio 10.5:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Shorty slash down-style chrome finish mufflers

Dimensions

  • Length 2,615 mm
  • Seat Height, Unladen 700 mm
  • Ground Clearance 125 mm
  • Rake (steering head) (deg) 26
  • Trail 101 mm
  • Wheelbase 1,670 mm
  • Tires, Front Specification MT 130/60B19 M/C 61H
  • Tires, Rear Specification P205/65R15
  • Fuel Capacity 22.7 l
  • Oil Capacity (w/filter) 4.7 l
  • Weight, As Shipped 492 kg
  • Weight, In Running Order 507 kg
  • Luggage Capacity -Volume 0.06m3

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 150 Nm
  • Engine Torque (rpm) 3,500
  • Fuel Economy: Estimated City/Hwy5 5.5 l/100 km

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 10.534
  • Gear Ratios (overall) 2nd 7.302
  • Gear Ratios (overall) 3rd 5.423
  • Gear Ratios (overall) 4th 4.392
  • Gear Ratios (overall) 5th 3.741
  • Gear Ratios (overall) 6th 3.157

Chassis

  • Wheels, Front Type9 Enforcer Cast Aluminum
  • Wheels, Rear Type Enforcer Cast Aluminum
  • Brakes, Caliper Type Front: 32mm 4 piston fixed Rear: floating 36mm piston integrated park brake

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, running lights, battery, neutral, low oil pressure, engine diagnostics, cruise control, security system, gear indicator, low fuel warning, reverse, park brake, miles to empty.
  • Gauges Speedometer, fuel gauges; display features odometer, trip A, trip B, range to empty, and gear indicator











Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
