2020 Harley-Davidson Iron 883 Guide

2020 Harley-Davidson Iron 883

2020 Harley-Davidson Iron 883 2020 Harley-Davidson Iron 883 2020 Harley-Davidson Iron 883 2020 Harley-Davidson Iron 883 2020 Harley-Davidson Iron 883

EVERYTHING YOU NEED, NOTHING YOU DON’T.

2020 Harley-Davidson Iron 883:

The Iron 883™ sets the standard for the raw, stripped-down, blacked-out look. Fine-tuned suspension. Tuck and roll seat. Black cast aluminum wheels with machined highlights.

An original icon of the Harley-Davidson® Dark Custom style. It sets the standard for the raw, stripped-down, blacked-out look.





2020 Harley-Davidson Iron 883 Totalmotorcycle.com Key Features

The Sportster® motorcycle has been a feature on the motorcycling landscape since it first hit the scene in 1957. This is the machine that’s done it all. Drag racing, flat track racing, land speed records, and every kind of street riding or cross-country trek riders could dream up. Simple, righteous, bare-knuckle style. Legendary engine. Easily affordable. Infinitely customizable. Updated for the modern era. Take it wherever you want to go.

Engine

Air-cooled, Evolution®

Engine Torque

53.8 ft-lb

Weight, As Shipped

545 lb.

Seat Height, Laden

25.7 in.





2020 Harley-Davidson Iron 883 Totalmotorcycle.com Features

Blacked-Out Look

It’s the poster bike of the anti-chrome movement. You’ve got a black powder-coated 883cc engine with black rocker covers. Black on the throwback round air cleaner cover. Chopped fenders, to show off a little rubber and black front forks with gaiters to add a little old-school nostalgia.



Street Inspired Paint

We created paint jobs with colors that look right against the backdrop of the urban grid, and don’t need a lot of maintenance. These are tough finishes, as mean as the meanest street.



Low Seat & Slammed Suspension

The combination of a lowered front and rear suspension together with a low, narrow solo seat—just 25.7-inches high—provides comfort and confidence for riders of all sizes and experience. The ride is responsive and plush, whether you’re dodging urban potholes or out exploring the back roads.



Tuck and Roll Seat

A solo seat that combines modern comfort with an authentic “tuck and roll” design inspired by the early days of the bobber.



Machined 9-Spoke Wheels

Nine-spoke wheels that are black as night where the rim meets the rubber and set off by a more contemporary mechanical look machined into the spokes.

883cc Air-Cooled Evolution® Engine

Authentic Harley-Davidson style through and through, dripping with power. The rubber-mounted 883cc Evolution® engine runs hard and rides smooth for thousands of miles so you can just worry about taking in the freedom of boulevards and back streets.



Drag-Style Handlebar

Born at the drag strip, the low-rise, slammed black drag-style handlebar is an old-school garage feature that puts you in a forward, aggressive riding position.







2020 Harley-Davidson Iron 883 – Totalmotorcycle.com  American Specifications/Technical Details
US MSRP Price from: $8999
USD
Canada MSRP Price from: $11499 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

Pricing

  • Color $8,999
  • Two-Tone Custom Color $9,899
  • ABS Option $795
  • Security System Option $395
  • California Emissions $100
  • Freight $360

Engine

  • Engine1 Air-cooled, Evolution®
  • Bore 3 in.
  • Stroke 3.811 in.
  • Displacement 53.9 cu in
  • Compression Ratio 9:01
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Black exhaust headers and black mufflers

Dimensions

  • Length 86 in.
  • Seat Height, Laden7 25.7 in.
  • Ground Clearance 5.5 in.
  • Rake (steering head) (deg) 30
  • Trail 4.6 in.
  • Wheelbase 59.6 in.
  • Tires, Front Specification 100/90B19 57H
  • Tires, Rear Specification 150/80B16 77H
  • Fuel Capacity 3.3 gal.
  • Oil Capacity (w/filter) 2.8 qt.
  • Weight, As Shipped 545 lb.
  • Weight, In Running Order 564 lb.

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 53.8 ft-lb
  • Engine Torque (rpm) 3,750
  • Lean Angle, Right (deg.) 27
  • Lean Angle, Left (deg.) 28
  • Fuel Economy5 51 mpg

Drivetrain

  • Primary Drive Chain, 34/57 ratio
  • Gear Ratios (overall) 1st 10.41
  • Gear Ratios (overall) 2nd 7.436
  • Gear Ratios (overall) 3rd 5.531
  • Gear Ratios (overall) 4th 4.584
  • Gear Ratios (overall) 5th 3.931

Chassis

  • Wheels, Front Type7 Black 9 Spoke with Machined Highlights
  • Wheels, Rear Type Black 9 Spoke with Machined Highlights
  • Brakes, Caliper Type Dual-piston front, Dual-piston rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
  • Gauges Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights







2020 Harley-Davidson Iron 883 – Totalmotorcycle.com  Canadian Specifications/Technical Details

Pricing

  • Colour $ 11,499
  • Two-Tone Custom Colour $ 12,599
  • ABS Option $ 615
  • Security System Option $ 355

Engine

  • Engine1 Air-cooled, Evolution®
  • Bore 76.2 mm
  • Stroke 96.8 mm
  • Displacement 883 cc
  • Compression Ratio 9:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Black exhaust headers and black mufflers

Dimensions

  • Length 2,185 mm
  • Seat Height, Unladen 760 mm
  • Ground Clearance 140 mm
  • Rake (steering head) (deg) 30
  • Trail 117 mm
  • Wheelbase 1,515 mm
  • Tires, Front Specification 100/90B19 57H
  • Tires, Rear Specification 150/80B16 77H
  • Fuel Capacity 12.5 l
  • Oil Capacity 2.6 l
  • Weight, As Shipped 247 kg
  • Weight, In Running Order 256 kg

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 73 Nm
  • Engine Torque (rpm) 3,750
  • Lean Angle, Right (deg.) 27
  • Lean Angle, Left (deg.) 28
  • Fuel Economy: Estimated City/Hwy5 4.6 l/100 km

Drivetrain

  • Primary Drive Chain, 34/57 ratio
  • Gear Ratios (overall) 1st 10.41
  • Gear Ratios (overall) 2nd 7.436
  • Gear Ratios (overall) 3rd 5.531
  • Gear Ratios (overall) 4th 4.584
  • Gear Ratios (overall) 5th 3.931

Chassis

  • Wheels, Front Type9 Black 9 Spoke with Machined Highlights
  • Wheels, Rear Type Black 9 Spoke with Machined Highlights
  • Brakes, Caliper Type Dual-piston front, Dual-piston rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
  • Gauges Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights











Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
