2020 Harley-Davidson Low Rider S Guide

2020 Harley-Davidson Low Rider S

2020 Harley-Davidson Low Rider S 2020 Harley-Davidson Low Rider S 2020 Harley-Davidson Low Rider S 2020 Harley-Davidson Low Rider S

Measure Your Heart Rate In MPH.

2020 Harley-Davidson Low Rider S:

The Low Rider® style has been giving people a new perspective for decades. And this year, we’re taking that thrilling perspective even further with the all-new Low Rider® S. The Low Rider® S is an all-new blacked-out performance-cruiser with a style that’s as aggressive as its ride. Loads of Milwaukee-Eight 114 Engine torque for blasting off from stoplights, hitting entrance ramps, and rolling on the passing power. Pure sound with a soul-satisfying rumble. Blacked-out finishes, moto-style bars with 4-inch risers, and mini speed screen let everyone know that this machine wasn’t built for those who want to take the conventional route. The defining element of the tall-bike style —the 1-inch diameter motocross-style handlebar is mounted on 4-inch risers to put you in an aggressive riding position.

Low Rider® S is an all-new blacked-out performance-cruiser with a style that’s as aggressive as its ride.



New Low Rider S Model Combines Performance with Attitude

The new Low Rider S motorcycle takes a performance-first approach that emphasizes power, agile handling, and enhanced rider control combined with traditional Harley-Davidson character. Handling of the Softail chassis is enhanced by premium suspension components tuned for aggressive riding stoked by the power of a muscular Milwaukee-Eight® 114 engine. Styling cues from the coastal build scene include a raised handlebar, mini fairing, solo seat and blacked-out finishes.







2020 Harley-Davidson Low Rider S Totalmotorcycle.com Key Features

One look at the Low Rider S is all it takes to see how far the Softail® family has come. It’s the latest in a new revolution of custom motorcycles we launched in 2018. With every Softail, you get a lighter frame, responsive new suspension, and the power of the Milwaukee-Eight® v-twin engine. In keeping with the custom tradition, each model has its own attitude and style. Ranging from the blacked-out nostalgia of the Heritage Classic to the futuristic edge of the Fat Bob® and FXDR 114 models. Find the one that fits your style. You’re in for one hell of a ride.

Engine

Milwaukee-Eight® 114

Engine Torque

119 ft-lb

Weight, As Shipped

650 lb.

Seat Height, Laden

26.5 in.





NEW HARLEY-DAVIDSON® LOW RIDER® S MODEL ROLLS OUT

A Softail® Chassis, Milwaukee-Eight® 114 Engine Muscle, and Defiant Attitude

High bars and horsepower define the new Harley-Davidson® Low Rider® S model, a cruiser that takes a performance-first approach to customizing. The Low Rider S model is built around a Harley-Davidson Softail® chassis enhanced by premium suspension components tuned for aggressive riding stoked by the unrelenting power of a muscular Milwaukee-Eight® 114 engine, with styling cues inspired by the coastal build scene and Harley heritage.

“The look of the new Low Rider S is really rooted in the legacy of the Low Rider models of the 1980s, that has a devoted following which has spread world-wide from origins in Southern California, and in the recent Dyna-based Low Rider S model,” said Brad Richards, Harley-Davidson Vice President of Styling & Design. “We’ve applied that coastal style and performance-first attitude to the Softail chassis to create a Low Rider S that’s more powerful and agile than ever, with a heavy dose of tough-as-nails attitude.”



HARD-EDGE COASTAL STYLE

Raised hand controls are a defining element of the coastal custom influence. The Low Rider S model mounts a one-inch diameter motocross-style handlebar on four-inch high straight risers to put the rider in an aggressive and active position. A color-matched mini-fairing frames the headlamp and blocks the wind when chasing down the freeway. A high back solo seat is shaped to hold the rider in place under hard acceleration.

All bright finishes are replaced with black finishes for an aggressive look. The powertrain, primary cover and tank console are finished in Wrinkle Black; the derby cover, intake, and lower rocker covers are Gloss Black. Mufflers and exhaust shields are Jet Black. Forks, triple-clamp, riser and handlebar, and rear fender supports are Matte Black. The LED layback tail lamp has a smoked lens. The five-gallon Softail fuel tank features an iconic Harley-Davidson graphic. Radiate cast-aluminum wheels (19-inch front and 16-inch rear diameter) are finished in Matte Dark Bronze for an intriguing contrast to the motorcycle’s dark components. Two solid color options are available: Vivid Black and Barracuda Silver.



THE SOFTAIL MODEL FOUNDATION

The Harley-Davidson Softail motorcycle frame is a foundation for performance. The frame design is optimized to reduce weight without sacrificing stiffness while maintaining the classic look of a hard tail with a thoroughly modern ride. The rigid-mounted Milwaukee-Eight V-Twin engine contributes to a platform that delivers strong acceleration and responsive handling and braking performance. A single coil-over shock features emulsion technology and an optimized angle between the frame and swingarm for enhanced travel and response. Under-seat hydraulic pre-load adjustment allows the rider to maintain optimal suspension performance for the prevailing load and road conditions. A 43mm inverted fork stiffens the front end for improved response to steering input. Single-cartridge internal technology responds quickly to inputs and keeps the front wheel planted for improved braking and handling performance. Fork rake is reduced to 28 degrees from the 30-degree rake of the standard Low Rider®model, resulting in more-responsive handling. Dual front brakes with 300mm discs deliver stronger braking performance with less lever effort than the single front disc brake on the standard Low Rider model. Standard ABS (antilock braking system) provides confident braking performance when conditions are less than ideal. The Low Rider S model rolls on high-performance Michelin® Scorcher® 31 tires.



MILWAUKEE-EIGHT 114 ENGINE MUSCLE

The Milwaukee-Eight 114 engine (114 CID; 1868cc), the only engine choice for the Low Rider S model, delivers the most displacement offered in the Softail chassis from the factory, cranking out 119 ft. lb. of torque at 3000 rpm. A dual internally counter-balanced system reduces engine vibration while maintaining the familiar Harley-Davidson feel, while deep-breathing, four-valve cylinder heads and dual spark plugs squeeze the most power possible from every ounce of fuel. The engine is equipped with a Gloss Black Ventilator air intake with an exposed filter element to improve air flow into the engine, and 2-into-2 offset shotgun mufflers for an aggressive, performance look.

Dealer-installed Screamin’ Eagle® Performance Parts Stage Upgrades from Harley-Davidson Genuine Motor Parts & Accessories are available to boost engine performance even further.

The 2020 Low Rider S model has a base price of $17,999*.

* Prices listed are the Manufacturer’s Suggested Retail Prices for base models. Options such as color are available at additional cost. Prices exclude tax, title, licensing, registration fees, destination charges, added accessories, and additional dealer charges, if any, and are subject to change. Harley-Davidson reimburses dealers for performing manufacturer-specified pre-delivery inspection and setup tasks. Dealer prices may vary.







2020 Harley-Davidson Low Rider S Totalmotorcycle.com Features

Milwaukee-Eight 114 Engine

Loads of torque for blasting off from stoplights, hitting entrance ramps, and rolling on the passing power. Pure sound with a soul-satisfying rumble.



Reduced Rake

The Low Rider® S model frame rake is reduced to 28 degrees from the 30 degree rake of the standard Low Rider® model, resulting in more responsive handling.



Inverted Front Fork

Inverted design stiffens the front end for improved response to steering input, and the single-cartridge internal technology responds quickly to inputs and keeps the front wheel planted for improved braking and handling performance.



Softail® Frame

The frame retains the classic Softail® lines, but its lightweight design and stiffness translate to a responsive ride unlike anything you’ve felt before.



Mono-shock rear suspension

Easily adjustable mono-shock rear suspension allows for dynamic cornering capability, quicker acceleration, and braking while preserving the hardtail look.



Raw Dark Look

Blacked-out finishes, moto-style bars with 4-inch risers, and mini speed screen let everyone know that this machine wasn’t built for those who want to take the conventional route.



Raised Controls

The defining element of the tall-bike style. The 1-inch diameter motocross-style handlebar is mounted on 4-inch risers to put you in an aggressive riding position.



Cast-Aluminum Wheels

Radiate Cast-Aluminum Wheels are finished in a matte dark bronze to complete its raw dark look.



Dual Front Disc Brakes

Stronger braking performance with less lever effort than the single front disc brake on the standard Low Rider® model, and standard ABS (anti-lock braking system) for confident braking performance when conditions are less than ideal.







2020 Harley-Davidson Low Rider S – Totalmotorcycle.com  American Specifications/Technical Details
US MSRP Price from: $17999
USD
Canada MSRP Price from: $23599 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

Pricing

  • Vivid Black $17,999
  • Color $18,399
  • ABS Option Standard
  • Security System Option Standard
  • California Emissions $200
  • Freight $390

Engine

  • Engine2 Milwaukee-Eight® 114
  • Bore 4.016 in.
  • Stroke 4.5 in.
  • Displacement 114 cu in.
  • Compression Ratio 10.5:1
  • Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-2 offset shotgun; catalyst in muffler

Dimensions

  • Length 92.7 in.
  • Seat Height, Laden 26.5 in.
  • Ground Clearance 4.7 in.
  • Rake (steering head) (deg) 28
  • Trail 5.7 in.
  • Wheelbase 63.6 in.
  • Tires, Front Specification 110/90B19,62H,BW
  • Tires, Rear Specification 180/70B16,77H,BW
  • Fuel Capacity 5 gal
  • Oil Capacity (w/filter) 5 qt
  • Weight, As Shipped 650 lb.
  • Weight, In Running Order 679 lb.

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque3 119 ft-lb
  • Engine Torque (rpm) 3,000
  • Lean Angle, Right (deg.) 30.1
  • Lean Angle, Left (deg.) 30.1
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy 47 mpg

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type7 Dark bronze, Radiate cast aluminium wheel
  • Wheels, Rear Type Dark bronze, Radiate cast aluminum wheel
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps6 High beam, turn signals, neutral, low oil pressure, engine diagnostics, auxilary lighting, cruise, ABS, security, low battery voltage, low fuel
  • Gauges 4-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication; 4-inch analog tachometer







2020 Harley-Davidson Low Rider S – Totalmotorcycle.com  Canadian Specifications/Technical Details

Pricing

  • Vivid Black $ 23,599
  • Color $ 24,049
  • ABS Option Standard
  • Security System Option Standard

Engine

  • Engine1 Milwaukee-Eight® 114
  • Bore 102 mm
  • Stroke 114 mm
  • Displacement 1,868 cc
  • Compression Ratio 10.5:1
  • Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-2 shotgun; catalyst in muffler

Dimensions

  • Length 2,355 mm
  • Seat Height, Unladen 690 mm
  • Ground Clearance 120 mm
  • Rake (steering head) (deg) 30
  • Trail 145 mm
  • Wheelbase 1,615 mm
  • Tires, Front Specification 110/90B19,62H,BW
  • Tires, Rear Specification 180/70B16,77H,BW
  • Fuel Capacity 18.9 l
  • Oil Capacity (w/filter) 4.7 l
  • Weight, As Shipped 295 kg
  • Weight, In Running Order 308 kg

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 161 Nm
  • Engine Torque (rpm) 3,000
  • Lean Angle, Right (deg.) 30.1
  • Lean Angle, Left (deg.) 30.1
  • Fuel Economy5 5 l/100 km

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type9 Dark bronze, Radiate cast aluminum wheel
  • Wheels, Rear Type Dark bronze, Radiate cast aluminum wheel
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, turn signals, neutral, low oil pressure, engine diagnostics, auxilary lighting, cruise, ABS, security, low battery voltage, low fuel
  • Gauges 4-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication; 4-inch analog tachometer











Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
