2020 Yamaha YZF-R125 Guide

2020 Yamaha YZF-R125

2020 Yamaha YZF-R125 2020 Yamaha YZF-R125 2020 Yamaha YZF-R125 2020 Yamaha YZF-R125 2020 Yamaha YZF-R125

Re-DEFINE YOUR REALITY.

2020 Yamaha YZF-R125:

Inspired by the legendary YZF-R1 and developed with pure R-Series DNA, the YZF-R125 is engineered to give you instant power with exceptional control.

The YZF-R125 engine is the most sophisticated 125cc design we’ve ever built. Its Variable Valve Actuation system and high-flow cylinder head deliver strong low rpm torque with exciting high rpm power – giving quick acceleration, fast pick up, a high top speed and outstanding fuel efficiency.

The aggressive YZF-R1-derived bodywork and dual LED headlights project a strong and forceful look – and the compact Deltabox frame together with an aluminium swingarm and wide 140-section rear tyre confirm the YZF-R125’s status as the ultimate lightweight supersport. Re-define your reality.



YZF-R125

Yamaha’s YZF-R models have set the standard for two decades. Winners on the track and leaders on the street, these high-tech R-Series bikes offer uncompromising performance, cutting edge technology and ultra-cool style.







2020 Yamaha YZF-R125 Totalmotorcycle.com Key Features

◾Assist & Slipper (A&S) clutch for optimum control
◾YZR-M1 MotoGP-inspired supersport cockpit
◾Sleek R-series body with dual twin-eye LED headlights
◾High combustion efficiency for smooth power
◾Compact Deltabox frame ensures lightweight handling
◾Lightweight aluminum swingarm for high speed stability
◾11-litre R-series style fuel tank
◾Sophisticated high-visibility LCD instruments
◾Wide 140-section rear tire for supersport handling
Full Features & Techspecs



New colours for the YZF-R6, YZF-R3 and YZF-R125 supersport models

Yamaha’s R-world features the most complete selection of high performance supersport motorcycles. Inspired by Yamaha’s M1 MotoGP bike and led by the flagship YZF-R1M and YZF-R1, the outstanding 2020 R-Series line-up gives every thrill-seeking rider the opportunity to move rapidly through the capacity ranks and progress all the way to the top.

For 2020 the YZF-R6, YZF-R3 and YZF-R125 will be available in a number of new colour options and featuring a new graphic design, including the Icon Blue version which is in line with the current livery of the Yamaha racing teams in the world championship, further reinforcing the strong R-Series family links and underline their pure race-bred DNA.

2020 colour options

YZF-R6:

  • Icon Blue
  • Midnight Black

YZF-R3:

  • Icon Blue
  • Midnight Black

YZF-R125:

  • Icon Blue
  • Competition White
  • Tech Black







2020 Yamaha YZF-R125 Totalmotorcycle.com Features and Benefits

Outstanding braking performance

Equipped with a large diameter 292mm front disc and a 230mm rear disc, the YZF-R125’s braking systems produce outstanding performance. Featuring state-of-the-art calipers and lightweight discs that deliver powerful and progressive stopping power, this sophisticated braking setup gives you precise and accurate control.



Excellent combustion efficiency

To achieve high levels of intake efficiency the YZF-R125 engine is equipped with large intake and exhaust valves as well as a compact combustion chamber. Combined with the high-tech VVA – as well as the large throttle body and sports exhaust system – this configuration produces impressive acceleration.



Sporty and comfortable riding position

Besides its race-bred YZR-M1 style cockpit, the YZF-R125 is also equipped with a 2-piece rider and passenger seat featuring thick foam for a smooth ride. With an optimised handlebar position and aluminum rear set footrests, the YZF-R125’s ergonomics give a balanced riding experience that’s both sporty and comfortable.



Wide 140-section rear tyre

To confirm its strong R-series DNA the YZF-R125 runs with a wide 140/70-17 rear tyre that gives excellent stability and confident cornering. Offering a good balance of grip and durability, this supersport style tyre is designed to enable you to optimise the potential of the engine’s wide spread of power, and its wide-section accentuates the bike’s aggressive R-series stance.



A&S (Assist & Slipper) clutch

To help you take full advantage of the free-revving engine performance, the YZF-R125 is equipped with an A&S clutch that gives a light feel at the lever for easy operation and precise control. This design ensures smooth and efficient acceleration, and during deceleration the A&S clutch helps to prevent rear wheel lock ups.



R-series LED twin-eye body design

Inspired by the iconic YZF-R1, the confident and aggressively styled face features dual LED headlights that reinforce the shared family DNA. Its M1 MotoGP style front fairing underlines the race-bred specification, and with a 12 LED taillight and premium finish, there’s no mistaking the pure R-series DNA in the YZF-R125’s stunning bodywork.



Deltabox frame

Delivering smooth and light handling characteristics as well as excellent high speed comfort, the YZF-R125 is one of the best-handling bikes in its category. Its Deltabox frame uses optimum front and rear geometry as well as a short aluminum swingarm and 41mm upside down forks to give you the ultimate 125 supersport chassis specification.



Lightweight aluminum swingarm

Yamaha R-series models are designed to give you the ultimate in style, performance and technology, and to underline its position as the premium 125 supersport, the YZF-R125 features a lightweight aluminum swingarm. Manufactured using Yamaha’s advanced casting technology, its short dimensions, low weight and optimised rigidity deliver sporty handling performance.



11-litre fuel tank

The YZF-R125’s aggressive race-bred bodywork is complemented by a sleek fuel tank that emphasises the bike’s pure supersport pedigree. Consisting of a steel inner tank protected by lightweight close-fitting external covers with a high quality finish, the 11-litre tank can be easily removed for routine maintenance.



MotoGP-inspired YZR-M1 type cockpit

Everything about the YZF-R125 is designed to give you the ultimate supersport experience. Inspired by Yamaha’s MotoGP bike, the racy cockpit features a high quality handlebar crown, as well as a high-visibility LED instrument panel and brake lever protector that put you in total control on the track and on the street.



High-visibility LCD instruments

When you turn on the YZF-R125 you’ll be greeted with a personal greeting from the high-tech instruments – and once you’re moving the multi-function display gives you information on gear position and shift timing, as well as a VVA indicator. Housed in a stylish and sporty panel, these high-visibility instruments keep you informed.









2020 Yamaha YZF-R125 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ Team Yamaha Blue
Canada MSRP Price: $ CDN
Europe/UK MSRP Price: £See dealer for pricing in GBP (On The Road inc 20% Vat)

NA

*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as
applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is
useful in making real-world comparisons with other models.





2020 Yamaha YZF-R125 – Totalmotorcycle.com Canada Specifications/Technical Details

NA





2020 Yamaha YZF-R125 – Totalmotorcycle.com European Specifications/Technical Details

Engine

Engine type liquid-cooled;4-stroke;SOHC;4-valves

Displacement 125cc

Bore x stroke 52.0 mm x 58.7 mm

Compression ratio 11.2 : 1

Maximum power 11.0kW (15.0PS) @ 10,000 rpm

Maximum Torque 11.5Nm (1.16kg-m) @ 8,000 rpm

Lubrication system Wet sump

Clutch Type Wet;multiple-disc coil spring

Ignition system TCI (digital)

Starter system Electric

Transmission system Constant Mesh;6-speed

Final transmission Chain

Fuel consumption 2.13l/100km

CO2 emission 49g/km

Carburettor Electronic Fuel Injection

Chassis

Frame Steel Deltabox

Front travel 130 mm

Caster Angle 26º

Trail 95mm

Front suspension system Upside-down telescopic fork, Ø41 mm

Rear suspension system Swingarm;(Link type suspension)

Rear Travel 114 mm

Front brake Hydraulic single disc, Ø292 mm

Rear brake Hydraulic single disc, Ø220 mm

Front tyre 100/80-17 M/C

Rear tyre 140/70-17 M/C

Dimensions

Overall length 1,990 mm

Overall width 755 mm

Overall height 1,140 mm

Seat height 820 mm

Wheel base 1,325 mm

Minimum ground clearance 160 mm

Wet weight (including full oil and fuel tank) 142 kg

Fuel tank capacity 11.0litres

Oil tank capacity 1.15litres





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
