2021 Husqvarna TC85 17/14 Guide

2021 Husqvarna TC85 1714

2021 Husqvarna TC85 1714 2021 Husqvarna TC85 1714 2021 Husqvarna TC85 1714

2021 Husqvarna TC85 17/14 : YOUNG BLOOD.

Introducing the 2021 Husqvarna TC85 17/14…

The 85cc class bridges the gap between the junior ranks and full-sized motocross, taking emerging riders one step closer to the big leagues. As such, the advanced hardware featured on the larger Husqvarna range is found on the TC 85. Featuring the latests engine and chassis technology, the TC 85 ensures young riders have the confidence to push harder, while maintaining maximum composure on track.

Setting the bar in the ultra-competitive 85 cc class, the TC 85 features much of the same technology found in the successful full-size Husqvarna motocross line-up. With a chromium molybdenum steel frame and state of the art WP suspension, young mini riders can focus on performance with total confidence.

Featuring an engine that delivers a broad and controllable power delivery the TC 85 offers top-level performance and durability for the stars of tomorrow.







2021 Husqvarna TC85 17/14 Totalmotorcycle.com Key Features

Guaranteeing the champions of tomorrow enjoy all the benefits of Husqvarna Motorcycles’ full-sized motocross models, the TC 85, TC 65, TC 50 and EE 5 ensure the highest levels of on-track performance. Prioritizing youth-specific ergonomics and user-friendly aesthetics, each model inspires confidence, which allows youngsters to focus on their riding while having fun.

  • Unrivaled engine performance and rideability
  • WP XACT forks with AER technology – optimal performance and light weight
  • Confidence instilling ergonomics thanks to broad, flat seat and one-piece airbox covers
  • Striking new graphics on the TC 85, TC 65 and TC 50 – showcasing Husqvarna Motorcycles’ dynamic approach to off-road motorcycling
  • New, high-grip seat cover for greater comfort
  • New roller actuated throttle assembly for TC 85 – smoother throttle motion and improved durability
  • New Formula brake calipers, clutch and brake assemblies for TC 85 – excellent stopping power and improved reliability
  • New NEKEN tapered diameter, aluminum handlebars with optimized ergonomics for TC 65 and TC 50







2021 Husqvarna TC85 17/14 Totalmotorcycle.com Features and Benefits

Chassis
FRAME

Crafted to provide precise feedback to young riders, the chromium molybdenum steel frame is made using advanced robot welding and hydroformed tubes.

WP XACT FRONT SUSPENSION

Much like the forks on the larger MX range, the WP XACT consists of a 43mm split fork design using a capsulated air spring in the left leg and the trusted oil damping system in the right leg. These components offer remarkable suspension performance with 280 mm wheel travel.

WP PDS rear shock

The WP PDS shock absorber is fitted to the TC 85. PDS meaning “progressive damping system” allows the rear end to stay stable over smaller bumps or rough terrain while also soaking up bigger hits with ease.

Subframe

Made from lightweight aluminium, the subframe features a short and compact profile. The profile not only contributes to the overall low weight but also improves mass centralisation.

Technology
Airbox

The TWIN AIR filter can be easily accessed without tools, by simply removing the left side panel for quick maintenance. The airbox design allows optimum airflow and maximum filter protection.

Cooling

The TC 85 features radiators designed with computational fluid dynamics to ensure the ideal passage of air through the cooling fins for optimum engine temperature and the highest performance.

Swingarm

Manufactured using a gravity die-cast production process, the one-piece aluminum swingarm offers exceptional strength at the lowest possible weight. For easy maintenance, the chain adjustment markings are visible from above making chain adjustment even simpler.

Exhaust

The exhaust system on the TC 85 is perfectly suited to the power characteristics of the engine and contributes to the outstanding performance and rideability all round. Additionally, the short and lightweight silencer improves mass centralisation while keeping noise levels to a minimum.

Performance
Engine

The TC 85 engine uses the latest in 2-stroke technology to deliver unrivalled performance in the competitive 85cc class. With an unchanged bore and stroke, the engine is1.5 pounds lighter and delivers improved power and ride-ability along the complete RPM range.

Cylinder

The cylinder is designed around an innovative power valve system, the system controls both the exhaust valve and the sub-exhaust port for impressive power, torque and controllability. As a result, the TC 85 delivers significant mid-range performance, reducing the need to use the clutch in loamy or sandy conditions.

Crankcase

Manufactured using a high pressure die-cast production process, the crankcases are designed with thinner wall thickness to save weight, while retaining strength and durability. This design also aids in a more compact arrangement, positioning the shaft arrangements closer to the centre of gravity for improved handling.
Clutch

Replacing the previous coil spring design, the TC 85 features a new diaphragm spring clutch. The new design is 1 pound lighter, more compact and also benefits from added durability. The clutch is actuated using a formula hydraulic system meaning that play is always compensated for and the clutch point remains the same under different conditions as well as over time.

Components
ODI lock-on grips

The TC 85 is fitted with high quality ODI lock on grips standard. The system includes a vulcanized grip on the right side while the lock on grip on the left does not require glue or wire for mounting.

Wheels

Black Excel rims and CNC machined hubs are fitted with Maxxis tires that deliver outstanding performance on a variety of terrain. The block pattern and rubber compound deliver exceptional straight-line stability and excellent traction and predictability.

Bodywork

The TC 85 features bodywork scaled to precisely fit the proportions of an 85 rider. The contact points and feeling deliver exceptional ergonomics, instilling confidence while also leaving room for free and unrestricted movement.

Brakes

New brake callipers from Formula, a 220mm wave disc up front and 210mm wave disc at the rear provide improved brake feel and consistent brake pad wear to ensure confident braking in any riding condition. Additionally, a new clutch and brake assembly reduces wear and ensures maximum reliability and durability.









2021 Husqvarna TC85 17/14 – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: $6199 USD
Canada MSRP Price: $ 6999 CDN
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)
Engine
Engine type Single cylinder, 2-stroke
Displacement 84,9 cc
Bore/stroke 47/48,95 mm
Starter Kickstarter
Carburetor Keihin PWK 28
Control Rotation speed dependent exhaust flap
Lubrication Mixture lubrication 1:40
Transmission 6 gears
Gear ratios 11:29  14:28  16:26  19:26  21:25  20:21
Primary ratio 20:64
Final drive 13:46
Cooling Liquid cooling
Clutch Wet multi-disc clutch, Formula hydraulics
Ignition MEDJ digital
Chassis
Frame Central double-cradle-type 25CrMo4 steel
Subframe Aluminium
Handlebar  Tapered Aluminium, Ø 28/22 mm
Front suspension WP XACT Upside-Down fork, Ø 43 mm
Rear suspension WP XACT PDS monoshock
Suspension travel front/rear 280/305 mm
Front brake Disc brake Ø 240 mm
Rear brake Disc brake Ø 220 mm
Front/rear rims 1.40 x 17″; 1.60 x 14″ Alu
Front/rear tires 70/100 x 17″; 90/100 x 14″
Chain 1/2 x 5/16″
Silencer Aluminium
Steering head angle 66°
Triple clamp offset 14 mm
Wheel base 1,290 mm ± 10 mm
Ground clearance 352 mm
Seat height 850 mm
Tank capacity 5,2 Liter
Weight (without fuel)  67 kg



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
