2021 KTM 1290 Super Adventure S Guide

2021 KTM 1290 Super Adventure S : THE WORLD JUST GOT SMALLER.

Introducing the 2021 KTM 1290 Super Adventure S…

Covering ground quickly and effortlessly is what the KTM 1290 SUPER ADVENTURE S is made for. An Adventure-specced V-Twin with 160 hp & 138 Nm means that entire cross-country journeys are dispatched easily, while Adaptive Cruise Control and Semi-active Suspension together with reworked rider-focussed ergonomics and technology bring agility and long distance comfort to an entirely new level. It’s a bold claim, but we’ll make it – the KTM 1290 SUPER ADVENTURE S is the new benchmark.

Invigorating the Adventure motorcycle segment with the release of its over-1000cc ADVENTURE models for the past eight years, KTM has taken full advantage of the development feedback to introduce a new era of rider-focused design and ground-breaking technology with the 2021 KTM 1290 SUPER ADVENTURE S.

Introducing a third generation of over-1000cc KTM ADVENTURE models, the KTM 1290 SUPER ADVENTURE S is the sportiest and most technologically advanced Adventure bike to ever roll its wheels off the production line in Mattighofen, Austria. Forged to provide the benefits of a versatile sports-tourer with diligence paid to ergonomics and comfort over any terrain, in brief it’s the ultimate high-performance Adventure bike.

2021 KTM 1290 Super Adventure S Totalmotorcycle.com Key Features

KTM 1290 SUPER ADVENTURE S – MODEL HIGHLIGHTS
// New ergonomics -> new fuel tank, lower seat & new plastics
// Reworked bodywork -> shorter chassis, new subframe & longer swingarm
// Optimized weight distribution -> added agility & comfort
// New generation electronics -> innovative ACC & reworked cornering MTC
// More intuitive 7” TFT display -> optimal accessibility
// Redesigned handlebar switches, improved CCU
// Revised 1301cc LC8 engine -> 160 hp & 138 Nm
// Next generation of Semi-Active Suspension
// Remodeled optional technology -> Suspension Pro, Rally Pack & Tech Pack

OUT NOW: THE NEW KTM 1290 SUPER ADVENTURE S LAUNCHES A NEW ERA OF ENGINEERING MASTERY AND PERFORMANCE-FOCUSED TECHNOLOGY

Redesigned ergonomics
Focusing on keener handling, the new KTM 1290 SUPER ADVENTURE S introduces a chassis overhaul that further enhances weight distribution and riding agility. A sharper cornering sensation is achieved by moving the steering head back by 15 mm and re-locating the front section of the engine. Additionally, the longer open-lattice swingarm contributes to a more stable feeling under acceleration. The subframe has been crafted to provide a lower seat height without sacrificing durability or practicality.

Surrounding the rider is a new 23-liter, keyless-cap fuel tank and a set of bodywork that augment the bike’s agile feeling. Every centimeter of the paneling has been analyzed in order not to impede the riding sensation. Providing additional comfort for the long rides, the new seat is two-tiered and adjustable by 20 mm. Also customizable are the handlebar levers, the all-new TFT and the windshield that has been developed through wind tunnel testing and can be moved by 55 mm. Overall, the KTM 1290 SUPER ADVENTURE S excels for its lower centralization of masses and refined weight balance. It begs to be ridden hard or caressed to speed over long distances.

Technology to boost performance
Regulating the ride is the new generation of electronic aids with a less intrusive level of traction control in RAIN, STREET, SPORT, OFFROAD and an updated (optional) RALLY mode. To take you to the best riding terrain with less fuss, the KTM 1290 SUPER ADVENTURE S introduces an innovative Adaptive Cruise Control system as standard for 2021. Developed in collaboration with Bosch, the radar-based system automatically adjusts the safe distance to traffic ahead according to five stages that can be set with the re-designed handlebar switches.

The riding experience is further boosted with the brand new 7” TFT display that is hooked to a new Connectivity Unit for seamless smartphone pairing. The larger dashboard view has quicker and more practical menu systems as well as clear aesthetic infographics to clearly indicate various sections of the bike. The dash sits on top of a redesigned storage department with a USB charging socket. To communicate with the new display, the KTM 1290 SUPER ADVENTURE S comes with all-new switches on both sides of the handlebar, which offer a new and more seamless user experience. A new set of quick select and favorites buttons will allow for set-up changes on the fly and while the rider stays focused on the roads ahead.

Advanced componentry
The heart of the KTM 1290 SUPER ADVENTURE S is the revised and Euro5 compliant V-twin. The eye-widening 160 hp and 138 Nm come in a lighter form (-1.6 kg) thanks to thinner engine cases and a new oil circuit. The engine breathes through an upgraded two-headed exhaust and shifts with a revised PANKL gear mechanism that brings big improvements in the optional Quickshifter+.

New pistons have further raised reliability and the whole unit retains better cooling thanks to a new water/oil system. The two new radiators work with the redesigned bodywork to channel warm air away from the rider’s legs. 15,000 km service intervals and low fuel consumption round-off the re-energized powerplant.

Furthermore, the lean angle dependent Motorcycle Traction Control has two different controllers, one for wheel slip and another for pitch angle, with their own data and strategies. The Cornering ABS and Offroad ABS systems are products of the new Bosch Motorcycle Stability Control, while Motor Slip Regulation is optional.

The KTM 1290 SUPER ADVENTURE S will hurtle along bumpy trails courtesy of a new generation of WP APEX Semi-Active Technology, suspension. The SAT boasts augmented damping thanks to new valves while the 6D lean angle sensor inputs directly into the unit for a thorough outline of rider behavior.

Part of the updated range of KTM PowerParts specifically designed for the KTM 1290 SUPER ADVENTURE S is the Suspension Pro package that offers individual damping for the fork and the shock, automatic preload adjustment and an on/off Anti Dive setting. With the additional Rally Pack featuring the RALLY riding mode and the respective MTC slip adjuster, all of the Suspension Pro and Rally Pack features together with the Quickshifter+, the Motor Slip Regulation, the Hill Hold Control and the adaptive brake light are included in the all-in-one Tech Pack.

Joachim Sauer – KTM Product Manager: “The 2021 KTM 1290 SUPER ADVENTURE S is a sporty bike designed to offer unparalleled riding fun in any terrain. With this model KTM enters its third generation of big Travel-Enduro bikes for street and gravel adventurers. Collecting feedback from the market, we focused on enhancing rider feeling and ergonomics while introducing ground-breaking advancements, such as the Adaptive Cruise Control, the KTM way. To appreciate the magic of our ACC, you need to consider that the ideal roads to experience the thrilling performance of the KTM 1290 SUPER ADVENTURE S may lie hours away. With highways in between, ACC will let you breeze through the transit keeping you ready to strike whenever possible. The new generation model will carry you as far, long and as hard as you want while keeping the original KTM DNA strong with its elevated performance potential.”

The new generation KTM 1290 SUPER ADVENTURE S will be available at KTM dealers internationally (excluding North America) starting March 2021.

2021 KTM 1290 Super Adventure S Totalmotorcycle.com Features and Benefits

Engine & Exhaust

Cooling

The KTM 1290 SUPER ADVENTURE S now features 2 separate radiators instead of a one-piece unit. The result is better heat dissipation, and improved cooling all-round. Cleverly designed air ducts now also stream cool air towards the engine, not only keeping the motorcycle cool, but the rider’s legs cool too.

Engine

With a sledgehammer hit of 160 hp and a massive 138 Nm of earth-twisting torque, the proven V-twin LC8 engine once again takes the accolades as the most compact, lightest, and best performing engine in the segment. Its greener too, meeting all EURO5 regulations and will deliver 15.000 km service intervals and low fuel consumption, trip after trip, mile after mile.

Transmission

Helping the KTM 1290 SUPER ADVENTURE S shift – in more ways than one – is a 6-speed PANKL transmission with a new, lighter aluminum shifting drum with optimized tracks for faster, smoother gear changes. Shifting forks have also been coated in copper to reduce wear and tear. This also helps the Quickshifter+ engage quicker for ultra-fast, slick gear changes.

PASC Clutch

Not only does the slipper clutch open when the engine back-torque becomes too high, it also assists when you open up the throttle. The former prevents destabilizing rear wheel chatter when braking sharply or decelerating; the latter reduces the lever force required for changing gears, allowing the clutch to be controlled with one trigger happy finger – saving you energy while riding.

Cylinder heads

A key element in the smooth power delivery of the 75° V-twin is each cylinder’s state-of-the-art 4-valve DOHC cylinder head. These combine twin plug ignition, flow-optimized ports and a slick low-friction valve drive train with cams from each cylinder’s twin overhead camshafts driving DLC-coated cam followers.

DLC coating

Diamond-Like Carbon – or DLC for short – is an extremely hard, durable coating used in many engine parts, such as cam followers, to assist sliding behavior. It improves performance and our engines love it!

Twin ignition

The twin plug ignition system controls the two differently sized spark plugs in each cylinder head independently of each other. This results in improved combustion and a smoother, optimally controlled combustion sequence. What that means to you, is better-controlled power, lower fuel consumption, and reduced emissions.

Pistons

The pistons in the KTM 1290 SUPER ADVENTURE S are forged, and are derived from Formula 1 technology. The result is a high loading capacity despite its extremely short and lightweight design. The piston skirts have an additional state-of-the-art, Grafal® finish. It further reduces friction and is particularly hard wearing.

Crankshaft

The extremely low crankshaft reciprocating weight enhances the responsiveness and free-revving nature of the engine. With a flow-optimized crank web shape, the particularly low-loss running of the crank drive is further enhanced.

Overdrive

The sixth gear serves as a long overdrive in the KTM 1290 SUPER ADVENTURE S’s well-spaced gearbox. This saves fuel and adds to your cruising comfort.

Ride-by-wire

Smooth throttle response is what you get, beyond simply being free of a throttle cable, which is why the KTM 1290 SUPER ADVENTURE S’s ride-by-wire system is so attractive. It ensures perfect dosage of the readily available and plentiful torque, while electronically translating rider throttle commands into throttle valve positions, which are perfectly adjusted to suit different riding conditions.

Long service intervals

With a 15,000 km service interval, adventure riders can head off into the wilderness with complete confidence. This comes courtesy of a unique mix of the highest quality components combined with a fully developed, proven, and reliable engine.

Power-to-weight-ratio

The combination of lightweight chassis engineering and a compact, powerful engine take the KTM 1290 SUPER ADVENTURE S to the top of its class in terms of power-to-weight ratio and ride dynamics. The result is one of the lightest, and best performing adventure motorcycles in its segment.

Exhaust

Providing the bark for the bite, the KTM 1290 SUPER ADVENTURE S features a completely reworked exhaust system. Two new headers lead the exhaust gas to a hydroformed collector chamber with two catalytic converters. These, in conjunction with 3 lambda sensors allow the emissions to stay within the latest EURO5 limits. Meanwhile, at the business end, a newly designed stainless-steel silencer provides a typically v-twin tone.

Airfilter

Thanks to a reworked airbox, riders can now easily access the air filter by simply removing 4 screws to remove the storage compartment ahead of the fuel filler cap. Also, the filter itself now features vertical ribs, instead of horizontal. which helps direct dust or sand towards the bottom of the air box, without getting sucked into the filter slats. Overall, a better design for hardcore adventurers.

Cooling

Engine

Chassis

Fuel tank

A completely redesigned 23 liter, 3-part fuel tank. This is made up of two large fuel cells on each side of the frame, with an upper, central vessel that supplies fuel to the lateral units. The fuel cap is also new and electronically controlled. But the best bit? A storage compartment reminiscent of the iconic KTM 990 ADVENTURE has been included in the new design, complete with a USB socket and big enough to hold your cellphone, sunglasses, or wallet.

Frame

A new, reworked, and lightweight, chrome-molybdenum stainless steel trellis frame featuring laser-cut tubes, combines with forged elements for an ultra-strong component on the KTM 1290 SUPER ADVENTURE S. The steering head has been moved 15 mm rearwards, to shorten the overall frame for improved cornering behavior, while the front engine mount has been rotated forward by 2 degrees to aid in hard acceleration, keeping the front end firmly planted on the ground. A newly designed, lightweight, and high-strength aluminum side stand completes the package.

Swingarm

Extended by 15 mm to optimize tracking stability in conjunction with the shorter frame, the die-cast, open-lattice swingarm retained it lightweight and pin-point manufacturing to provide stiffness and uncompromised control when out on the road.

Suspension

There’s no modest way to say this, but – the KTM 1290 SUPER ADVENTURE S is fitted the most advanced suspension system on the market. Featuring a new generation of innovative WP Semi-Active Suspension technology (SAT) with electronically controlled magnetic valves for variable damping, providing a wide range of adjustability for maximal comfort and safety. Best yet, all the settings and adjustments to the suspension can be made via the dashboard and are indicated on the TFT screen. In addition, the optional Suspension PRO package allows the rider to benefit from an automatic setting of the rear shock preload or individually adjustable settings for the shock or fork.

Steering Damper

Heading off the beaten track often leads to encountering some pretty rough roads. Thankfully, things are kept in check my a WP steering damper as standard. Linked between the frame and the triple clamp, the steering damper ensures things are kept tidy when the road isn’t.

Wheels & Tires

Featuring bespoke MITAS Terra Force-R rubber, which is specifically developed for new KTM 1290 SUPER ADVENTURE S, provides exceptional grip, handling behavior and optimal stability at highspeed.

Brakes

Precise. Powerful. Consistent. Just as you would expect from a set of Brembo brakes. Up front you’ll find twin 320 mm diameter discs, which are radially mounted, plus 4-piston fixed calipers. At the rear, excess speed is taken care of by a generously dimensioned 267 mm diameter disc. And in case of an emergency, Bosch’s two-channel 10.3 ME ABS is there to save the day.

Fuel tank

Frame

Ergonomics & Comfort

Windshield

Designed to fend off windblast at high speeds, the windshield has been optimized in the wind tunnel to keep riders comfortable for longer, faster journeys. Adjustment is easy too, thanks to right and left mounted handwheels controlling 55 mm of screen height.

Handlebar

Wide, adjustable, and ready for long hours in the saddle, the high-strength tapered aluminum handlebars are designed to provide riders with greater control, and uncompromised comfort. Newly developed and robust handguards have also been designed for optimal aerodynamic behavior when it comes to high-speed stability.

Illuminated Menu Switch

Illuminated switches don’t only look good, but make sense when you’re out in low light conditions and need to locate the important buttons in the blink of an eye.

Footpegs

Two foot peg positions: stock or 10 mm up and back (diagonally), allow riders to set the comfort level to suit their height and riding preference, which can make a big difference on a long adventure ride.

Seat height

Where you’ll be spending most of your time, the new seat on the KTM 1290 SUPER ADVENTURE S features separate seats for rider and passenger, with the former being adjustable by 20 mm, from 849 mm to 869 mm. Accessing the under-seat area is also made easier, with the seat latch released at the push of a button.

Windshield

Handlebar

Bodywork & Graphics

LED Headlight

Turning night into day, the new cornering integrated LED headlight has been designed to integrate the front Radar Sensor on the KTM 1290 SUPER ADVENTURE S, flanked by cornering and day time running lights. This results in a clean, KTM-distinctive look which provides impeccable illumination with a wide beam pattern to light up the road ahead.

Software & Electronics

KTM MyRide

There won’t be any Wi-Fi where you’re going, but with the KTM MY RIDE system, you’ll still have a connection to your smartphone. Syncing via Bluetooth, KTM MY RIDE allows you to access your phone, giving you access to incoming calls, your music library, and turn-by-turn navigation right on your TFT display. More info can be found at www.ktm.com/my-ride.

Dashboard

Taking charge at the helm is an all-new scratch-resistant 7-inch TFT display. Unmatched in terms of graphics and readability, adventurers can access information and make adjustments to the bike’s semi-active suspension on the fly, quickly and easily without navigating complex menus. This comes thanks to a 6-way switch cube on the handlebar. Connectivity is also taken care of by way of KTM MY RIDE, which connects via Bluetooth for turn-by-turn navigation, playing music, and even answering incoming calls. Still catching glare? The TFT screen is tilt-angle adjustable.

USB Phone Pocket

No bar-mounted cellphone cradle? No problem. A convenient compartment keeps your smartphone safe on the road. It keeps it charged too, thanks to its integrated USB socket. The optional incoming call and audio functions using KTM MY RIDE link the phone to the TFT via Bluetooth, so less time is spend staring at the small screen, and more time is spent looking ahead.

MSC with C-ABS

Controlling traction isn’t only relevant when putting the power down, but also when you back off the throttle and get onto the brakes. Thanks to the state-of-the-art MSC (Motorcycle Stability Control) system made by BOSCH, riders can push on in complete confidence. Lean-sensitive cornering ABS works in conjunction with the MSC systems to allows riders to always use the full power of their brakes while taking lean angle, stability, and road conditions into account. A unique Offroad ABS function will also allow you to push harder before there is any ABS interference.

TPMS

A crucial part of your adventure ride is, arguably, your tire pressure. Thankfully, the KTM 1290 SUPER ADVENTURE S is fitted with a TPMS (Tire Pressure Monitoring System) which monitors front and rear tire pressure and displays it on the TFT for easy viewing. Should there be any pressure loss, a warning will display on the dash.

MTC

Lean-angle-sensitive Motorcycle Traction Control (MTC) reacts to any disproportionate slippage of the rear wheel. This is done via two separate controllers, reading wheel-slip and pitch respectively, making calculations and adjustments in milliseconds. The result? Both straight-line acceleration and cornering efficiency are unhindered with power reduction less abrupt – even when the front wheel lifts off the deck. Want to take the power into your own hands? MTC can be turned off for hardcore offroad adventure.

ATIR

Failure to indicate is one thing. Forgetting to cancel your turn indicator is another. Thankfully, the KTM 1290 SUPER ADVENTURE S is fitted with an Automatic Turn Indicator Reset or ATIR. After 10 seconds of movement and 150 meters of riding distance, the turn indicator will reset automatically. A big improvement in terms of safety, as it is now impossible to forget to reset the indicators.

Offroad Ride Mode

The real adventure starts when the tarmac ends. For that, we give you OFFROAD MODE. One engaged, ride-by-wire smooths out the throttle response and limits peak power output to better suit offroad conditions. This means riders can lock the rear wheel with the rear brake- a prerequisite for committed offroad riding and deliberately executed slides – while allowing some wheel spin out of corners.Most importantly, the rider is able to hoist the front wheel over obstacles. The rider can also activate the Offroad ABS function to get optimal control in offroad conditions while maintaining full safety.

Offroad Traction Control

OFFROAD TRACTION CONTROL allows a certain slippage at the rear wheel. This is for those moments when you want full control, without any unwanted interference mastering controlled drifts.

Offroad ABS

In this mode, three things happen – ABS functionality is deactivated on the rear wheel but maintains some ABS functionality of the front wheel, rear-wheel lift-up detention is disabled, and cornering ABS is disabled. All this together means riders have complete control offroad with confidence. For advanced riders, it allows them to push harder before there is any ABS interference.

Rider Aids

Electronic rider aids provide more control, performance and enjoyment to the rider under a wider range of circumstances. The latest ABS and MTC (Motorcycle Traction Control) technology is designed to enhance your riding experience. Different ride modes are tailored for easy adjustment of the rider aid functions to suit a range of riding conditions. The simple adjustability of these features maximizes the powerful V-twin’s innovative technology and equipment across a much wider range of terrain.

Cruise Control

The KTM 1290 SUPER ADVENTURE S features revolutionary radar-based Adaptive Cruise Control. To appreciate the magic of our ACC, you need to consider the ideal roads may lie hours away. With highways in between, ACC will let you breeze through the transit keeping you ready to strike when you get chance. ACC ‘locks on’ to a preceding vehicle, automatically adjusting speed and maintaining a safe following distance at all times. This results in more relaxed highway blasting when you need to cover ground fast, giving new meaning to ‘intercontinental missile’.

KTM Race On

Forget about ignition keys and mechanically locked fuel caps. The KTM 1290 SUPER ADVENTURE S is fitted with a state-of-the-art keyless-go system with a unique Anti Relay Attack (ARA) system which reduces the risk of misuse of the keyless system by preventing the ignition from being turned on, without iteration on the key fob itself. Too complicated? The ARA system can be disabled completely in the dashboard menu.

KTM MyRide

Dashboard

2021 KTM 1290 Super Adventure S – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $ TBA USD
Canada MSRP Price: $ TBA CDN
Europe/UK MSRP Price: £14999 (On The Road inc 20% Vat)

Engine
◼ Torque 138Nm
◼ Transmission 6-speed
◼ Cooling Liquid cooled
◼ Power in KW 118kW
◼ Starter Electric starter
◼ Stroke 71mm
◼ Bore 108mm
◼ Clutch PASC (TM) slipper clutch, hydraulically actuated
◼ CO2 emissions 134g/km
◼ Displacement 1301cm³
◼ EMS Keihin EMS with RBW and cruise control, double ignition
◼ Design 2-cylinder, 4-stroke, V 75°
◼ Fuel consumption 5.7l/100 km
◼ Lubrication Forced oil lubrication with 3 oil pumps

Chassis
◼ Tank capacity (approx.) 23l
◼ ABS Bosch 10.3ME Combined-ABS (incl. Cornering-ABS and offroad mode)
◼ Front brake disc diameter 320mm
◼ Rear brake disc diameter 267mm
◼ Chain 525 X-Ring
◼ dry weight 220kg
◼ Frame design Chrome-moly tubular space frame, powder-coated
◼ Ground clearance 223mm
◼ Seat height 849mm
◼ Steering head angle 65.3°
◼ Suspension travel (front) 200mm
◼ Suspension travel (rear) 200mm

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
