2021 KTM 50 SX Mini Guide

2021 KTM 50 SX Mini

2021 KTM 50 SX Mini 2021 KTM 50 SX Mini

2021 KTM 50 SX Mini : GENUINE DIRT BIKE.

Introducing the 2021 KTM 50 SX Mini…

The KTM 50 SX Mini is a true KTM for young MX riders aged between 4 and 10 years old. It is a genuine dirt bike that, like its bigger siblings, is produced with top-quality components. This makes the KTM 50 SX Mini the first choice when stepping into the world of MX. Developed with the youngster in mind, this package has an engine that delivers steady, controllable power, incorporating an automatic clutch that is ideal for novice riders. It also features the latest WP XACT front fork with revolutionary AER technology, fully adjustable rear suspension, ultra-cool graphics and the ability to make going fast fun.













2021 KTM 50 SX Mini Totalmotorcycle.com Key Features







2021 KTM 50 SX Mini Totalmotorcycle.com Features and Benefits

Exhaust

The exhaust system was designed to perfectly match the characteristics of the engine, ensuring maximum output and a smooth power delivery over the entire rev range.

Engine

The high performance cylinder, exhaust pipe and reed intake system are perfectly arranged for maximum performance, setting the standard in the highly competitive 50 cc class.

Frame

The modern frame is made from lightweight, high strength chromoly steel profiles and combines maximum longitudinal stiffness with optimum torsional rigidity. It guarantees easy handling and precise cornering, but also outstanding stability.

Wheels

Like the full-size KTM Factory racers, the 50 SX MINI has super lightweight, black anodized, aluminum rims providing the highest strength and durability. The OEM MAXXIS knobby tires grip superbly on any surface.

Front suspension

The KTM 50 SX MINI has the latest WP XACT fork, made by WP SUSPENSION. This upside-down front fork with 35 mm tube diameter and 205 mm of travel ensures outstanding comfort, damping characteristics and directional stability.

Rear suspension

The high quality WP XACT shock absorber is linked directly to the swingarm, providing excellent damping performance. It is fully adjustable, meaning you can set the damping perfectly to suit the rider’s preference and track conditions. The shock absorber allows for 147 mm of rear wheel travel.

Brakes

Both at the front and rear, state-of-the-art hydraulic disc brakes from FORMULA ensure best possible stopping power. The exclusive, self-cleaning Wave brake discs stand for the ultimate in race technology and outstanding performance.





2021 KTM 50 SX Mini – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $3899 USD
Canada MSRP Price: $ 4549 CDN
Europe/UK MSRP Price: £ 3599 (On The Road inc 20% Vat)

ENGINE

  • TRANSMISSIONSingle-speed automatic
  • STARTERKickstarter
  • STROKE40 mm
  • BORE39.5 mm
  • CLUTCHCentrifugal clutch (adjustable)
  • DISPLACEMENT49 cm³
  • DESIGN1-cylinder, 2-stroke engine

CHASSIS

  • WEIGHT (WITHOUT FUEL)40 kg
  • TANK CAPACITY (APPROX.)2.1 l
  • FRONT BRAKE DISC DIAMETER160 mm
  • REAR BRAKE DISC DIAMETER160 mm
  • FRONT BRAKEDisc brake
  • REAR BRAKEDisc brake
  • CHAIN1/2 x 3/16″
  • FRAME DESIGN25CrMo4 steel central-tube frame
  • FRONT SUSPENSIONXACT 35 WP Upside-Down fork, Ø 35 mm
  • GROUND CLEARANCE184 mm
  • REAR SUSPENSIONXACT WP mono shock
  • SEAT HEIGHT558 mm
  • STEERING HEAD ANGLE67.4 °
  • SUSPENSION TRAVEL (FRONT)100 mm
  • SUSPENSION TRAVEL (REAR)147 mm





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
