2021 MV Agusta F3 Rosso: DEEP RED.
Introducing the 2021 MV Agusta F3 Rosso…
The F3 is the newest member of the ROSSO line. The all-in-one fairing, clip-on handlebars, and undeniable MV Agusta character, in a more accessible package. The new 2021 F3 adds that extra something to the ROSSO range. The ultimate in MV Agusta sports attitude has never been so accessible.
DESIGN. ROSSO EMOTIONS
The F3 Rosso takes F3 characteristic features to the extreme. Lines designed for performance but projected into the future. Style and performance that find their maximum expression in the contrast between the red superstructure and the completely black components.
2021 MV Agusta F3 Rosso Totalmotorcycle.com Key Features
- EURO 5 LOW-FRICTION ENGINE
- HIGH-PRESSURE INJECTORS
- BI-DIRECTIONAL FLOW RADIATOR
- REDESIGNED EXHAUST
- NEW IMU INERTIAL PLATFORM
- CONTINENTAL ABS WITH CORNERING FUNCTION
- 5.5” TFT DISPLAY
- 3 Cylinders
- 147HP Engine max Power @ 13.000 R.P.M
- 240KM/H Max speed
- 798CC Engine displacement
- 173KG Dry weight
- 13.3:1 Compression Ratio
2021 MV Agusta F3 Rosso Totalmotorcycle.com Features and Benefits
CHASSIS
• FRAME PLATES REDESIGNED TO INCREASE TORSIONAL AND LONGITUDINAL STIFFNESS
• NEW TWIN-FLOW OIL RADIATOR WITH MORE THAN 5% EFFICIENCY INCREASE
ADVANTAGES:
COMFORT, STABILITY, AGILITY AND SAFETY. FASTER AND SAFER
ENGINE
• COUNTER-ROTATING CRANKSHAFT
• NEW SINTERED VALVE GUIDES AND DLC COATED TAPPETS TO REDUCE FRICTION
• TITANIUM VALVES
• NEW CRANKSHAFT MAIN BEARINGS, PISTON ROD BEARINGS AND COUNTERSHAFT BEARINGS TO REDUCE FRICTION AND TO INCREASE RELIABILITY
• MODIFIED EXHAUST COLLECTOR TO IMPROVE ENGINE TUNING AND OPTIMISE POWER/TORQUE IN CURVES
• NEWLY DESIGNED EXHAUST SILENCER
• NEW CLUTCH BASKET OPTIMISED TO IMPROVE ENGAGEMENT
ADVANTAGES: BETTER OPERATION AND RELIABILITY, IN FULL COMPLIANCE WITH EURO 5 REGULATIONS
ELECTRONICS
• NEW ABS MK100 CONTINENTAL MODULE WITH CORNERING FUNCTION FOR CONSTANT SAFETY EVEN IN CURVES
• NEW INERTIAL PLATFORM
• NEW COLOUR 5.5” TFT DASHBOARD
• MOBISAT TRACKER
• GPS AND BLUETOOTH
• MV RIDE APP
• NAVIGATOR INTEGRATED IN THE DASHBOARD
• FRONT LIFT CONTROL
• NEW HANDLEBAR CONTROLS WITH LAUNCH CONTROL
• NEW EAS 3.0 ELECTRONIC GEAR SENSOR
• NEW ENGINE MANAGEMENT ALGORITHMS FOR A DIRECT CONNECTION BETWEEN THROTTLE AND REAR WHEEL
• CRUISE CONTROL
ADVANTAGES:
A BETTER FEELING RIDE. THE ADVANCED ELECTRONICS MAKES RIDING EASIER, MORE INTUITIVE AND SAFER MECHANICAL AND ELECTRONIC REVOLUTION
Like all three-cylinder platform bikes, the F3 receives a number of technical updates to improve its usability and performance for 2021.
While the goal of a supersport is ultimate performance, further heightened by the arrival of new engine components, the ROSSO has also seen MV Agusta technicians working to ensure riding pleasure on the road. Its sportiness remains obvious and pronounced. The chassis, unanimously considered the best in the segment, remains a point of reference. With the F3 ROSSO, the legend that is the MV Agusta sports bike is made available to a wide audience. Now MV Agusta’s refined design and exclusive technical details are available to a wider audience.
FRAME: ENHANCED EXCELLENCE
Long considered to be the best medium-sized supersport in terms of its chassis, the F3 takes another step forward for 2021. Redesigned frame plates and a particular focus on the swingarm connection area has led to increased torsional and longitudinal stiffness, characteristics that improve riding precision but also rider feeling.
AN EVEN MORE ADVANCED ENGINE
Unlike other bikes in the ROSSO range, the F3 doesn’t relinquish even a touch of the power that the famous “three-piston” engine complete with counter-rotating crankshaft is able to supply. The engine has undergone constant development work.
With maximum declared power of 147 HP, the MV Agusta three-cylinder is still one of the most powerful in the category. The meticulous work to refine the 2021 model – Euro5 homologated of course – has seen MV Agusta technicians further reduce internal friction by using a DLC treatment for
the new buckets and new materials for the valve guides. While the valves are still titanium, the main bearings, rods and countershaft are new, redesigned to reduce friction and further improve reliability. The exhaust system has been completely overhauled, from manifold to silencer, with the aim of improving delivery to fill out the torque and power curves at all speeds.
All without compromising the classic and unmistakeable sound of the MV Agusta three-piston. The injectors are also new, now able to handle an additional 0.5 bar of injection pressure. The ECU firmware is updated, as are the engine management logics and control algorithms, which make for more precise and refined throttle management. To improve cooling, a new bi-directional flow radiator is used for a 5% boost in efficiency.
QUICKER, MORE PRECISE GEARING
The clutch now has a reinforced clutch basket, boosted in terms of its manageability and quietness. The Quick-Shift EAS 3.0 with bi-directional function is now in its third generation and improves the quality of shifting, now softer and more precise thanks to the introduction of a new sensor.
ELECTRONICS, MORE COMPREHENSIVE THAN EVER
From the dashboard to the ABS, by way of the ECU commands and firmware, the electronics on the F3 ROSSO have really taken a step up.
The new IMU inertial platform, designed and developed in Italy by Milan firm e-Novia exclusively for MV Agusta, recognizes the position of the bike, for swift management of all controls based on the lean angle. The ABS, now developed by Continental, comes complete with cornering function while the TC traction control can intervene more precisely by considering the bike’s lean angle. The IMU also means that the updated FLC (front lift control) can manage a controlled wheelie rather than prevent it altogether. All this is controlled via a connected 5.5” TFT display that can communicate with the MV Ride App. This app (for IOS and Android) not only allows trip recording and sharing on the main social media platforms, but it also offers the ability to customise every aspect of the bike (including engine settings), directly from a smartphone. Thanks to the mirroring function, the rider now has navigation with turn-by-turn directions in addition to recording and sharing itineraries.
SUPERSTRUCTURES
As previously mentioned, the F3 ROSSO aims for maximum performance but also highlevel usability on the road. As with every model in the ROSSO range, the colour RED dominates the superstructures, in this case, paired with the black of the engine, frame and wheels, for a truly aggressive visual impact.
2021 MV Agusta F3 Rosso – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: $ See Dealer for Pricing in USD
Canada MSRP Price: $ See Dealer for Pricing in CDN
Europe/UK MSRP Price: € Euro
Type
Three cylinder, 4 stroke, 12 valve
Timing system
“D.O.H.C” with mechanical chain tensioner and DLC tappet
Total displacement
798 cm3 (48.7 cu. in.)
Compression ratio
13.3:1
Starting
Electric
Bore x stroke
79 mm x 54.3 mm (3.1 in. x 2.1 in.)
Max. power – r.p.m. (at the crankshaft)
108 kW (147 hp) at 13.000 r.p.m.
Max. torque – r.p.m.
88 Nm (8.98 kgm) at 10.100 r.p.m.
Cooling system
Cooling with separated liquid and oil radiators
Engine management system
Integrated ignition – injection system MVICS 2.1 (Motor & Vehicle Integrated Control System) with six injectors. Engine control unit Eldor Nemo 2.1, throttle body bore 50 mm diameters full ride by wire Mikuni, pencil-coil with ion- sensing technology, control of detonation and misfire. Torque control with four maps. Traction Control with eight levels of intervention
Electronic quick-shift
MV EAS 3.0 (Electronically Assisted Shift Up & Down)
Clutch
Wet, multi-disc slipper clutch
Transmission
Cassette style; six speed, constant mesh
Primary drive
22/41
First gear: Speed
13/37
Second gear: Speed
16/34
Third gear: Speed
18/32
Fourth gear: Speed
19/30
Fifth gear: Speed
21/30
Sixth gear: Speed
22/29
Final drive ratio
17/43
Maximum speed*
240.0 km/h (149.1 mph)
Voltage
12 V
Alternator
350 W at 5.000 r.p.m.
Battery
12 V – 8.6 Ah
Frame type
ALS Steel tubular trellis
Rear swing arm pivot plates material
Aluminium alloy
Front suspension type
Marzocchi “UPSIDE DOWN” telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment
Fork dia.
43 mm (1.69 in.)
Fork travel
125 mm (4.92 in.)
Rear suspension type
Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment
Single sided swing arm material
Aluminium alloy
Wheel travel
130 mm (5.12 in.)
Front brake
Double floating disc with Ø 320 mm (Ø 12.6 in.) diameter, with steel braking disc and flange
Front brake caliper
Brembo radial-type monobloc, with 4 pistons Ø 34 mm (Ø 1.34 in.)
Rear brake
Single steel disc with Ø 220 mm (Ø 8.66 in.) dia.
Rear brake caliper
Brembo with 2 pistons – Ø 34 mm (Ø 1.34 in.)
ABS System
Continental MK100 with RLM (Rear Wheel Lift-up Mitigation) and with cornering function
Front wheel: Material/size
Alluminium alloy 3.50” x 17”
Rear wheel: Material/size
Alluminium alloy 5.50” x 17”
Front tyre
120/70 – ZR 17 M/C (58 W)
Rear tyre
180/55 – ZR 17 M/C (73 W)
Fairing material
Thermoplastic – Aluminium belly-pan
Wheelbase
1.380 mm (54.33 in.)
Overall length
2.030 mm (79.92 in.)
Overall width
730 mm (28.74 in.)
Saddle height
830 mm (32.68 in.)
Min. ground clearance
120 mm (4.72 in.)
Trail
99 mm (3.89 in.)
Dry weight
173 kg (381.4 lbs.)
Fuel tank capacity
16,5 l (4.36 U.S. gal.)
Environmental Standard
Euro 5
Combined fuel consumption
6.1 l/100 km
CO2 Emissions
139 g/km
Exclusive features
Titanium components: Intake and exhaust valves; Exclusive content: Dashboard TFT 5.5”color display – Cruise control Launch control – Bluetooth – GPS – MV Ride App for navigation mirroring, app-controlled engine, rider aids setup – Mobisat tracker
Optional
The full Special Parts range is available on the MV Agusta website
Reference
* Top speed attained on closed course.
Every country could have a price variation due to local import duties and taxes.
MV Agusta is committed to the constant improvement of our products. Therefore the information and technical characteristics of the vehicles are subject to change without notice.
