2022 BMW F900XR: HIGHER, FASTER, FURTHER.
Introducing the 2022 BMW F900XR…
XR stands for the uncompromising combination of athleticism and long-distance performance: Adrenaline for days, curve for curve. On the F 900 XR, you can keep hunting these curves without stopping – mile after mile. Even its thrilling design promises pure performance. While the upright, relaxed sitting position and the wind and weather protector show: Only one person decides when your ride is over – you.
Thanks to the full assortment of equipment, you are just as well-equipped for sport riding and travel as you are for the city. The F 900 XR is the bike that matches you and your attitude.
#NeverStopChallenging
The F 900 XR combines athleticism and long-distance performance without compromise. Even its exciting design demonstrates how much fun curve hunters will have on it. Thanks to the full assortment of equipment, you can also enjoy this unique riding experience every day. Learn all about the technical data and standard equipment here.
2022 BMW F900XR Totalmotorcycle.com Key Features
- New Style Triple Black with Black storm metallic includes hand protectors.
- Style Exclusive with Galvanic Gold metallic is dropped.
- Two-cylinder in-line engine.
- Dynamic ESA.
- Adaptive cornering light.
- Seat heights: Wide range that just fits.
- Height-adjustable windshield.
- Always well-informed with BMW Motorrad Connectivity and TFT display.
- Convenient storage space.
- 3 year warrenty – Ride on & on & on. Get up to 3-years or 36,000 miles warranty on all new motorcycles.
Standard equipment
coloured TFT display with BMW Motorrad Connectivity
LED headlight (low / high beam)
LED indicators
ASC
riding modes Rain/Road
adjustable hand brake and clutch levers
12V socket
windshield adjustment
Optional equipment (OE)
headlight Pro incl. adaptive curve light
riding modes Pro incl. ABS Pro / DTC / MSR / DBC
Dynamic ESA (electronic suspension adjustment)
case holders
main stand
keyless ride
lowered suspension kit
Optional accessories (OA)
Soft panniers and touring cases
luggage rack
topcase
LED fog lights
hand protectors
engine spoiler
windshield Sport
alternative seats
2022 BMW F900XR Totalmotorcycle.com Features and Benefits
Clear body language – the unmistakable XR.
The motivation of the F 900 XR can be seen at the very first glance. The striking LED light guides of the newly developed headlight emphasize the commanding nature of the F 900 XR – a feeling that you know best. The fairing builds further upon this dynamic excitement. Precise edges define its aggressive design. The slim and visually short tail invokes the athletic energy of this long-distance performer.
Expressive colors.
The three color variants highlight the precisely set beading and defined surfaces of the F 900 XR. All variants have one thing in common: pure forward thrust.
Style Triple Black
Fully fledged riding pleasure and always chasing after the next bend: Black Storm Metallic 2 paint impressively emphasizes this performance characteristic of the F 900 XR.
Sport style: Racing Red
The dynamically aggressive red contrasts with the technical seeming Granite Gray Metallic Matte and shows: The heart of an athlete beats in you. Which your F 900 XR already exemplifies. The short Sport windshield and the gold anodized fork tubes underline the dynamism of this motorcycle.
Base color: Light White
Tank cover and radiator grille in Granite Gray Metallic Matte with silver rims: Cool, determined, puristic; draw the gaze of others to you.
Upright and relaxed.
At the end of the day, you’ve put in just the right number of miles onto the odometer and have just enough in your bones. The ergonomics of the F 900 XR are designed for sporty long-distance performance. Take on curve after curve behind its protective front fairing. Maximum variability is the rule here, with seat heights from 30.5 to 34.25 inches, as well as a fully adjustable hand lever and flexible two-level windshield. The optimal position of the footrest and seat enables your passenger to join in on the passion for every mile.
Your resting heart rate: 68 lb-ft.
The racing line before your eyes and your gaze far ahead, you take every curve calmly and confidently. One after the other, again and again. Just typical #NeverStopChallenging. Well, if this insatiable desire for every straightaway, this drive to always go further, meet the right partners: The high-torque two cylinder in-line engine of the F 900 XR delivers between 4,500 and 8,500 rpm for 68 lb-ft. The optional Dynamic ESA delivers optimal suspension comfort and very stable handling. Those who press forward like this leave the others behind.
Systematic safety features.
Numerous other innovations ensure a pleasant and relaxed ride. The Dynamic Brake Control (DBC) and Engine Braking Control (EBC) deliver more control for emergency braking and for abrupt releases of the accelerator as well as sudden downshifts.
Visionary – literally.
The F 900 XR is setting standards when it comes to illumination. It has an adaptive cornering light – available for the first time in the mid-range segment. Placed in the newly developed striking LED headlamps, it provides perfect illumination for corners at a 7° angle: an obvious plus when riding at night or with poor lighting conditions.
2022 BMW F900XR – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $11695 to $11945 USD
Canada MSRP Price: $12800 to $14000 CDN
Europe/UK MSRP Price: from £ See Dealer GBP (total selling price)
Engine
Type
Water-cooled 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts, dry sump lubrication
Bore x stroke
86 mm x 77 mm
Capacity
895 cc
Rated output
99 hp at 8,500 rpm
Max. torque
68 lb-ft at 6,750 rpm
Compression ratio
13.1 : 1
Mixture control / engine management
Electronic injection
Emission control
Closed-loop 3-way catalytic converter, emission standard EU-5
Performance / fuel consumption
Maximum speed
Over 124 mph
Fuel type
Premium Unleaded
Electrical system
Alternator
Permanent magnetic alternator 416 W (nominal power)
Battery
12 V / 12 Ah, maintenance-free
Power transmission
Clutch
Multiple-disc wet clutch (anti hopping), mechanically operated
Gearbox
Constant mesh 6-speed gearbox integrated in crankcase
Drive
Endless O-ring chain with shock damping in rear wheel hub
Chassis / brakes
Frame
Bridge-type frame, steel shell construction
Front wheel location / suspension
Upside-down telescopic fork, Ø 43 mm
Rear wheel location / suspension
Cast aluminum dual swing arm, central spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable
Suspension travel front / rear
6.7”/ 6.8” (170 mm / 172 mm)
OE suspension lowering kit: 5.9” / 6.0” (150 mm / 152 mm)
Wheelbase
60” (1,521 mm)
Caster
4.1” (105.2 mm)
Steering head angle
60.5°
Wheels
Cast aluminum wheels
Rim, front
3.50″ x 17″
Rim, rear
5.50″ x 17”
Tires, front
120/70 ZR 17
Tires, rear
180/55 ZR 17
Brake, front
Dual disc brake, floating brake discs, Ø 320 mm, 4-piston radial brake calipers
Brake, rear
Single disc brake, Ø 265 mm, single-piston floating caliper
ABS
BMW Motorrad ABS
Dimensions / weights
Length
85.0” (2,160 mm)
Width (incl. mirrors)
33.9” (860 mm)
Height (excl. mirrors)
52.0” – 55.9” (1,320 mm – 1,420 mm)
Seat height, unladen weight
32.5”
Inner leg curve, unladen weight
Standard Seat: 72.4”, High Seat: 73.6”, Low Seat: 70.7”
Unladen weight, road ready, fully fueled
482 lbs (219 kg)
1)
Permitted total weight
966 lbs (438 kg)
Payload (with standard equipment)
483 lbs (219 kg)
Usable tank volume
4.1 gal (15.5 L)
Reserve
Approx. 1 gal (3.5 L)
1) According to guideline VO (EU) 168/2013 with all fluids, with standard equipment and fuelled with at least 90% of usable tank volume.
2022 BMW F900XR – Totalmotorcycle.com Canada Specifications/Technical Details
Engine
Type
Water-cooled 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts, dry sump lubrication
Bore / stroke
86 mm x 77 mm
Capacity
895 cc
Rated output
77 kW / (105 hp) at 8,500 rpm
Max. torque
92 Nm at 6,500 rpm
Compression ratio
13.1 :1
Mixture control
Electronic injection
Emission control
Closed-loop 3-way catalytic converter, emission standard EU-5
Performance / fuel consumption
Maximum speed
over 200 km/h
Fuel consumption per 100 km based on WMTC
4.2 l
CO2 emission based on WMTC
99 g/km
Fuel type
Unleaded super, minimum octane number 95 (RON)
Electrical system
Alternator
permanent magnetic alternator 416 W (nominal power)
Battery
12 V / 12 Ah, maintenance-free
Power transmission
Clutch
Multiple-disc wet clutch (anti hopping), mechanically operated
Gearbox
Constant mesh 6-speed gearbox integrated in crankcase
Drive
Endless O-ring chain with shock damping in rear wheel hub
Chassis / brakes
Frame
Bridge-type frame, steel shell construction
Front wheel location / suspension
Upside-down telescopic fork, Ø 43 mm
Rear wheel location / suspension
Cast aluminium dual swing arm, central spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable
Suspension travel, front / rear
170 mm / 172 mm
(OE suspension lowering kit: 150 mm / 152 mm)
Wheelbase
1,521 mm
Castor
105.2 mm
Steering head angle
60,5°
Wheels
Cast aluminium wheels
Rim, front
3.50″ x 17″
Rim, rear
5.50″ x 17”
Tire, front
120/70 ZR 17
Tire, rear
180/55 ZR 17
Brake, front
Dual disc brake, floating brake discs, Ø 320 mm, 4-piston radial brake calipers
Brake, rear
Single disc brake, Ø 265 mm, single-piston floating caliper
ABS
BMW Motorrad ABS
Dimensions / weights
Seat height
825 mm (OE suspension lowering kit: 775 mm, OE low seat: 795 mm, OA high seat: 840 mm, OA comfort seat: 845 mm, OA extra high seat: 870 mm)
Inner leg curve
1,840 mm (OE suspension lowering kit: 1,765 mm, OE low seat: 1,795 mm, OA high seat: 1,870 mm, OA comfort seat: 1,880 mm, OA extra high seat: 1,900 mm)
Usable tank volume
15.5 l
Reserve
- 3.5 l
Length
2,160 mm
Height (excl. mirrors)
1,320-1,420 mm
Width (excl. mirrors)
860 mm
Unladen weight, road ready, fully fuelled
219 kg
1)
Permitted total weight
438 kg
Payload (with standard equipment)
219 kg
1) According to guideline VO (EU) 168/2013 with all fluids, with standard equipment and fuelled with at least 90% of usable tank volume.
2022 BMW F900XR – Totalmotorcycle.com European Specifications/Technical Details
Engine
Type
Water-cooled 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts, dry sump lubrication
Bore / stroke
86 mm x 77 mm
Capacity
895 cc
Rated output
77 kW / (105 hp) at 8,500 rpm
Rated output (A2)
70 kW (95 hp) at 8,000 rpm
OE output reduction:
35 kW (48 hp) at 6,500 rpm
Max. torque
92 Nm at 6,500 rpm
Max. torque (A2)
88 Nm at 6,750 rpm
OE output reduction: 66 Nm at 4,500 rpm
Compression ratio
13.1 :1
Mixture control
Electronic injection
Emission control
Closed-loop 3-way catalytic converter, emission standard EU-5
Performance / fuel consumption
Maximum speed
over 200 km/h
Maximum speed (A2)
over 200 km/h
OE output reduction: 170 km/h
Fuel consumption per 100 km based on WMTC
4.2 l
CO2 emission based on WMTC
99 g/km
Fuel type
Unleaded super, minimum octane number 95 (RON)
Fuel type (A2)
unleaded regular fuel, minimum octane number 91 (RON)
Electrical system
Alternator
permanent magnetic alternator 416 W (nominal power)
Battery
12 V / 12 Ah, maintenance-free
Power transmission
Clutch
Multiple-disc wet clutch (anti hopping), mechanically operated
Gearbox
Constant mesh 6-speed gearbox integrated in crankcase
Drive
Endless O-ring chain with shock damping in rear wheel hub
Chassis / brakes
Frame
Bridge-type frame, steel shell construction
Front wheel location / suspension
Upside-down telescopic fork, Ø 43 mm
Rear wheel location / suspension
Cast aluminium dual swing arm, central spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable
Suspension travel, front / rear
170 mm / 172 mm
(OE suspension lowering kit: 150 mm / 152 mm)
Wheelbase
1,521 mm
Castor
105.2 mm
Steering head angle
60,5°
Wheels
Cast aluminium wheels
Rim, front
3.50″ x 17″
Rim, rear
5.50″ x 17”
Tyre, front
120/70 ZR 17
Tyre, rear
180/55 ZR 17
Brake, front
Dual disc brake, floating brake discs, Ø 320 mm, 4-piston radial brake calipers
Brake, rear
Single disc brake, Ø 265 mm, single-piston floating caliper
ABS
BMW Motorrad ABS
Dimensions / weights
Seat height
825 mm (OE suspension lowering kit: 775 mm, OE low seat: 795 mm, OA high seat: 840 mm, OA comfort seat: 845 mm, OA extra high seat: 870 mm)
Inner leg curve
1,840 mm (OE suspension lowering kit: 1,765 mm, OE low seat: 1,795 mm, OA high seat: 1,870 mm, OA comfort seat: 1,880 mm, OA extra high seat: 1,900 mm)
Usable tank volume
15.5 l
Reserve
- 3.5 l
Length
2,160 mm
Height (excl. mirrors)
1,320-1,420 mm
Width (excl. mirrors)
860 mm
Unladen weight, road ready, fully fuelled
219 kg
1)
Permitted total weight
438 kg
Payload (with standard equipment)
219 kg
1) According to guideline VO (EU) 168/2013 with all fluids, with standard equipment and fuelled with at least 90% of usable tank volume.
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
