2022 Harley-Davidson CVO Road Glide Limited: FOR THE RIDER WHO LEADS, ALONE OR WITH A PARTNER ON BOARD.
Introducing the 2022 Harley-Davidson CVO Road Glide Limited…
The CVO Road Glide Limited model is loaded with luxury and long-haul comfort, head-turning style and power that always satisfies. Premium audio, heated seats and grips, and the precise handling of the aerodynamic Road Glide model sharknose fairing make this motorcycle a statement making joy to ride.
The ultimate in long-range touring and luxury. Features best-in-class power and advanced technology.
NEW decorative insert finishes
NEW Harley-Davidson Audio powered by Rockford Fosgate Stage I for premium sound
Twin-Cooled Milwaukee-Eight 117 powertrain maintains power and performance in the most-challenging conditions
Road Glide model fairing features splitstream venting to limit head buffeting; Dual Daymaker LED headlamps push out an impressive punch with a bright-white beam that lights up the road; all other lighting is LED
Heated seat with dual-zone rider/passenger control for added comfort in cool weather
Heated Kahuna Collection hand grips match shifter pegs, brake pedal cover, muffler end caps, and rider / passenger boards
Tomahawk custom wheels
NEW Paint Options
Wicked Orange Pearl/Black Hole with Lightning Silver Two-Tone and Bright Chrome finishes
Hightail Yellow Pearl/Black Hole with Lightning Silver Two-Tone and Bright Chrome finishes
Dante’s Red with Dante’s Black Sunglo Fade Flame Pattern and Gloss Black finishes
2022 Harley-Davidson CVO Road Glide Limited Totalmotorcycle.com Key Features
- Upright riding position
- Passenger seat with backrest
- Frame mounted fairing
- Rider safety enhancements available
THIS IS THE RIGHT BIKE FOR
- Riders seeking a one-of-a-kind touring experience
- Enthusiasts who like bold styling with premium paint and Tomahawk wheels
- Heated grips for long-hauling comfort
Harley-Davidson Custom Vehicle Operations (CVO)
Premium limited-production factory custom models from Harley-Davidson Custom Vehicle Operations (CVO) offer the most-discerning rider a very special motorcycle designed to represent the pinnacle of style and design from the world’s most-desirable motorcycle brand. Exclusive and hand-crafted paint and designs are executed to a level of intricate quality that is unmatched in the motorcycle and automotive categories. Each is powered by a Milwaukee-Eight 117 powertrain. Other standard features include a premium Harley-Davidson Audio powered by Rockford Fosgate system, a Boom! Audio 30K Bluetooth Helmet Headset, and Cornering Rider Safety Enhancements by Harley-Davidson, technology designed to enhance rider confidence during unexpected situations or poor road conditions. Each CVO model offers all-new paint options for 2022.
(See 2022 CVO release for complete details.)
CVO Street Glide Model is a super-premium bagger for the rider who rolls loud and proud. The classic silhouette of the batwing fairing topped with jaw-dropping paint and finish details, premium audio and the pavement-peeling power of the Milwaukee-Eight 117 engine make this one outrageous bike.
CVO Road Glide Model is designed for the rider who wants to run out front behind its distinctive dual LED headlamps, frame-mounted shark nose fairing and the unrelenting performance of the Milwaukee-Eight 117 powertrain. Powerhouse audio, an exclusive 21-inch front wheel, fabulous custom paint and extraordinary attention to detail complete this very desirable bike.
CVO Road Glide Limited Model is loaded with luxury and long-haul comfort, head-turning style and power that always satisfies. Premium audio, heated seats and grips, and the aerodynamic Road Glide model shark nose fairing make this motorcycle the ultimate Harley-Davison Touring machine.
CVO Tri Glide Model is a super-premium trike offering distinctive style, powerful performance and long-haul touring capability plus the added confidence of a third wheel. The CVO Tri Glide is loaded with premium audio, luxurious comfort features and an astounding finish and attention to detail, on a chassis designed from the wheels up as a trike.
Cornering Rider Safety Enhancements by Harley-Davidson
Standard on CVO models and an option for all Grand American Touring models, including the Street Glide ST and Road Glide ST models, Cornering Rider Safety Enhancements by Harley-Davidson is a collection of technologies designed to assist the rider in maintaining the rider’s intended path through a curve. This technology package provides the following enhancements:
Cornering Electronically Linked Brakes
Cornering-Traction Control with modes
Drag Torque Slip Control
Vehicle Hold Control
Tire Pressure Monitoring (TPMS)
HARLEY-DAVIDSON CVO MOTORCYCLES REPRESENT PINNACLE OF STYLE AND DESIGN
Advanced technology, exclusive components and obsessive attention to detail distinguish four new 2022 motorcycle models from Harley-Davidson Custom Vehicle Operations (CVO). Limited-production, super-premium CVO motorcycles represent the pinnacle of forward-looking style, design and craftsmanship from Harley-Davidson, the world’s most-desirable motorcycle brand.
CVO models for 2022 include the CVO Road Glide Limited, the CVO Street Glide, the CVO Road Glide and the CVO Tri Glide. Each model offers exclusive paint colors and designs executed to a level of intricate quality and hand-crafted detail that is unmatched in the motorcycle and automotive categories.
“Gunslinger is our partner in custom paint that’s been that’s been adding incredible artisanal techniques to our CVO arsenal and family for a long time now, and they’re inspiring us to push the limits, so we try to do the same thing with them,” said Brad Richards, Harley-Davidson Vice President of Design. “When most manufacturers are at the limits of a robot, Gunslinger can go in there with an artist who has the ability to brush by hand and deliver the sharpest pinstripe possible. That hand applied technique allows for very intricate two-tones, three-tones, airbrush drop shadows, and really transcends the ‘expected’ by delivering a truly custom look.”
Each CVO model is also equipped with Milwaukee-Eight 117 engine, plus the complete technology suite of Cornering Rider Safety Enhancements and the advanced Boom! Box GTS infotainment system equipped with high-performance Harley-Davidson Audio powered by Rockford Fosgate.
2022 Harley-Davidson CVO Road Glide Limited Totalmotorcycle.com Features and Benefits
Milwaukee-Eight 117 V-Twin
The new pinnacle of torque and displacement with a factory-installed powertrain. Precision oil/air cooling. 126 ft. lbs. of torque at 3750 RPM. Tuned heavy breather intake and high flow exhaust maximize engine performance, a boost you can feel with every twist of the throttle.
Premium paints and finishes
Heated Kahuna Collection hand grips match Kahuna shifter pegs, brake pedal cover, muffler end caps, heated grips and rider and passenger boards
Fugitive custom wheels
CVO Road Glide Limited motorcycle
All the features you need for a ride that feels comfortable and rides secure.
H-D Touring Chassis
Daymaker Adaptive LED headlamp and bright LED lighting for enhanced visibility
Corner Safety Enhancements
HARLEY-DAVIDSON AUDIO POWERED ROCKFORD FOSGATE
Amplify your audio experience with Harley-Davidson audio powered by Rockford Fosgate stage I speakers. These high-performance two-way speakers feature a durable injection molded woofer and a separate bridge-mounted tweeter.
BOOM! BOX GTS INFOTAINMENT
An evolved interface experience that offers a contemporary look, feel and function, with exceptional durability and features designed specifically for motorcycling. Every element is optimized to enhance the rider’s interaction with the bike and connectivity with the world.
The Boom! Audio 30k Bluetooth headset lets you call hands-free on your Bluetooth mobile phone, listen to stereo music or voice instructions of GPS navigation and have intercom conversations with your passenger or fellow riders.
2022 Harley-Davidson CVO Road Glide Limited – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: from $41499 (Color), $47899 (Custom Color) USD
Canada MSRP Price: from $53799 (Colour), $56299 (Custom Colour) CDN
Europe/UK MSRP Price: from £38795 (Colour), £41495 (custom Colour) GBP (On The Road inc 20% Vat)
|Dimensions||FLTRKSE CVO™ Road Glide® Limited||Notes|
|Length||101.2 in. (2,570 mm)|
|Overall Width||43.1 in. (1,095 mm)|
|Overall Height||56.5 in. (1,435 mm)|
|Seat Height, Laden||28.2 in. (716 mm)||2|
|Seat Height, Laden (Low seat position)|
|Seat Height, Laden (High seat position)|
|Seat Height, Laden (Low seat position with optional ARH suspension)|
|Seat Height, Laden (High seat position with optional ARH suspension)|
|Seat Height, Unladen||29.9 in. (760 mm)|
|Seat Height, Unladen (Low seat position)|
|Seat Height, Unladen (High seat position)|
|Seat Height, Unladen (Low seat position with optional ARH suspension)|
|Seat Height, Unladen (High seat position with optional ARH suspension)|
|Static Ground Clearance||5.1 in. (130 mm)|
|Dynamic Ground Clearance (with optional suspension)|
|Rake (steering head) (deg)||26|
|Fork Angle (deg)||29.25|
|Trail||6.7 in. (170 mm)|
|Wheelbase||64 in. (1,625 mm)|
|Tires, Type||Dunlop® Harley-Davidson Series, bias blackwall front and rear|
|Tires, Front Model||D408F|
|Tires, Front Specification||BW 130/60B19 61H|
|Tires, Rear Model||D407|
|Tires, Rear Specification||BW 180/55B18 80H|
|Fuel Capacity||6 gal. (22.7 l)|
|Reserve Fuel Capacity, Fuel Injection (warning light)||1 gal. (3.8 l)|
|Oil Capacity (w/filter)||5 qt. (4.7 l)|
|Transmission Capacity||1 qt. (.95 l)|
|Primary Chain Case Capacity||1.1 qts. (1 l)|
|Coolant Capacity||0.8 qt. (0.75 l)|
|Weight, As Shipped||927 lb. (420 kg)|
|Weight, In Running Order||963 lb. (437 kg)|
|Gross Vehicle Weight Rating||1,360 lb. (617 kg)|
|Gross Axle Weight Rating, Front||500 lb. (227 kg)|
|Gross Axle Weight Rating, Rear||927 lb. (420 kg)|
|Luggage Capacity -Volume||4.7 cu ft (0.132 m3)|
|Engine||FLTRKSE CVO™ Road Glide® Limited||Notes|
|Engine||Twin-Cooled™ Milwaukee-Eight® 117|
|Valves||Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; four valves per cylinder|
|Bore||4.075 in. (103.5 mm)|
|Stroke||4.5 in. (114.3 mm)|
|Displacement||117 cu in (1,923 cc)|
|Fuel System||Electronic Sequential Port Fuel Injection (ESPFI)||3|
|Air Cleaner||Paper, washable|
|Exhaust||Dual, with crossover|
|Lubrication System||Pressurized, dry-sump|
|Drivetrain||FLTRKSE CVO™ Road Glide® Limited||Notes|
|Primary Drive||Chain, 34/46 ratio|
|Final Drive||Belt, 32/68 ratio|
|Clutch||Mechanically actuated 10 plate, wet Assist & Slip|
|Transmission||6-Speed Cruise Drive®|
|Gear Ratios (overall) 1st||9.593|
|Gear Ratios (overall) 2nd||6.65|
|Gear Ratios (overall) 3rd||4.938|
|Gear Ratios (overall) 4th||4|
|Gear Ratios (overall) 5th||3.407|
|Gear Ratios (overall) 6th||2.875|
|Chassis||FLTRKSE CVO™ Road Glide® Limited||Notes|
|Frame||Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded.|
|Swingarm||Mild steel; two-piece drawn and welded section; forged junctions; MIG welded.|
|Front Fork||49mm Dual Bending Valve|
|Front Fork, Optional|
|Rear Shocks||Premium standard height hand-adjustable rear suspension|
|Rear Shocks, Optional|
|Wheels, Optional Style Type||Gloss Black Tomahawk||4|
|Wheels, Front Type||Gloss Black and Contrast Chrome Tomahawk||4|
|Wheels, Front Width||3 in. (76 mm)|
|Wheels, Front Height||19 in. (483 mm)|
|Wheels, Rear Type||Gloss Black and Contrast Chrome Tomahawk||4|
|Wheels, Rear Width||5 in. (127 mm)|
|Wheels, Rear Height||18 in. (457 mm)|
|Brakes, Caliper Type||32 mm, 4-piston fixed front and rear|
|Brakes, Rotor Type||Dual floating rotors (front), fixed rotor (rear)|
|Brakes, Front Diameter||11.8 in. (300 mm)|
|Brakes, Front Thickness||0.2 in. (5.1 mm)|
|Brakes, Front is dual||Yes|
|Brakes, Rear Diameter||11.8 in. (300 mm)|
|Brakes, Rear Thickness||0.28 in. (7.1 mm)|
|Front brake lever free travel||N/A|
|Rear brake pedal free travel||N/A|
|Brakes, Anti-Lock Braking System (ABS)||Standard|
|Suspension Travel, Front||4.6 in. (117 mm)|
|Suspension Travel, Rear||3 in. (76 mm)|
|Performance||FLTRKSE CVO™ Road Glide® Limited||Notes|
|Engine Torque Testing Method||J1349|
|Engine Torque||125 ft-lb (169 Nm)||5|
|Engine Torque (rpm)||3,500|
|Power (Hp/kW)||105 HP / 78 kW @ 4850 rpm|
|Lean Angle Testing Method||J1168|
|Lean Angle, Right (deg.)||34.3|
|Lean Angle, Left (deg.)||33.4|
|Maximum hill-starting ability||N/A|
|Fuel Economy Testing Method||Estimated City/Hwy|
|Fuel Economy||41 mpg (5.7 l/100 km)||6|
|CO₂ Emissions Testing Method||N/A|
|Electric||FLTRKSE CVO™ Road Glide® Limited||Notes|
|Battery||Sealed, maintenance-free, 12V, 28-amp/hour, 405 cca (per Battery Council International Rating)|
|Charging||Three-phase, 48-amp system (600W @13V, 2000 RPM, 625W max power @ 13V)|
|Starting||1.6 kW electric with solenoid shift starter motor engagement|
|Lights (as per country regulation), Headlamp||LED 34-watt, 915 lumen low beam, 37-watt, 915 lumen high beam.|
|Lights (as per country regulation), Tail/Stop||LED|
|Lights (as per country regulation), Front Signal Lights||LED|
|Lights, Rear Turn Signals||LED|
|Gauges||– Custom gauges styled to complement each CVO vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators.|
|Electric Power Outlet||Electric power accessory port in fairing and tourpak|
|GPS System||Boom!™ Box GTS audio system with GPS and touchscreen|
|Warranty And Service||FLTRKSE CVO™ Road Glide® Limited||Notes|
|Warranty||24 months (unlimited mileage)||7|
|Service Interval||First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter||8|
- Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and prices listed may differ from specifications and prices of vehicles manufactured and delivered. All product descriptions (including depictions, specifications, dimensions, measurements, ratings and competitive comparisons) are based on available information at the time of publication. Although such descriptions are believed correct, errors and changes can occur and complete accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and specifications, and may change or discontinue models, without notice and without incurring any obligation. Attention: Vehicles in the configurations shown and many of the accessories described in this catalog may not be available for sale or use in some locations. Please check with your dealer for complete product details and the latest information. All models feature 6-speed transmission (VRSC™ models and Sportster® models are 5-speed) and carbon fiber belt final drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
- Measurement reflects 180 lb. (81.7 kg) operator weight.
- Recommended 91 octane or higher fuel (R+M)/2.
- Standard and optional wheels may vary by country and region.
- Values shown are nominal. Performance may vary by country and region.
- The combined fuel economy numbers were derived using a combination of estimated city and highway values. Fuel economy estimates are derived from US EPA exhaust emission certification data on a sample motorcycle from the corresponding family under ideal laboratory conditions. Your actual fuel economy will vary depending on your personal riding habits, road and driving conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
- See motorcycle owner’s manual for complete details.
- Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals. See Owner’s Manual for full details.
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
