2022 Harley-Davidson Road Glide ST: DISTINCTIVE AND AERODYNAMIC.

Introducing the 2022 Harley-Davidson Road Glide ST…

A sleek performance bagger that projects more attitude than ever, backed up with the street-scorching power of the Milwaukee-Eight® 117 powertrain.

The sleek Road Glide ST model projects the attitude of the Screamin’ Eagle® Factory championship winning race bike and backs it up with the street-scorching power of the Milwaukee-Eight 117 powertrain. Undiminished rider comfort and the shark nose fixed fairing appeals to a rider who wants to make quick work of the open road.

The distinctive and aerodynamic shark nose Road Glide fairing features triple splitstream venting to limit head buffeting. The fairing is topped with a low-profile dark windshield and holds dual Daymaker® LED headlamps that push out an impressive punch with a bright-white beam that lights up the road. A low-profile engine guard and tank console combine to give the Road Glide ST trim lines.

A new solo seat exposes the rear fender and adds a purposeful attitude along with standard-length saddlebags and a trimmed front fender. The blacked-out front end, controls, powertrain and exhaust contrast with bright pushrod tubes and tappet covers, and machined cylinder fins. Further contrast is provided by a Matte Dark Bronze finish on the cast aluminum Prodigy custom wheels, the color band on the lower rocker box, timer cover medallion, intake medallion, and the classic script tank graphic. There are two paint options – Vivid Black or Gunship Gray. A Heavy Breather intake with forward-facing exposed air cleaner element reinforces performance-first styling.

Emulsion-technology rear shock absorbers feature a single knob to hydraulically adjust pre-load for optimal ride and control. The 49mm forks with dual bending valve suspension technology deliver linear damping characteristics for a smooth ride. Reflex™ linked Brembo® brakes with ABS are standard. The Road Glide ST is equipped with the Boom!™ Box GTS infotainment system with color touch screen, two fairing-mount speakers and hidden radio antenna. Electronic cruise control holds a steady speed for comfort on long rides. Smart Security System with proximity-based, hands-free security fob offers peace of mind.







2022 Harley-Davidson Road Glide ST Totalmotorcycle.com Key Features

STANDARD FEATURES

  • Upright riding position
  • Floorboards
  • Saddlebags
  • Frame mounted fairing
  • Infotainment
  • Rider safety enhancements available



THIS IS THE RIGHT BIKE FOR

  • Performance-hungry distance riders
  • Enthusiasts seeking stand-out power and comfort
  • Classic touring design with premium H-D features



Street Glide ST & Road Glide ST

Harley-Davidson elevates bagger performance and brings the purposeful style of the championship winning MotoAmerica King of the Baggers race bikes to the street with the introduction of the Street Glide® ST and Road Glide® ST models. These hot rod baggers combine the V-Twin muscle of the Milwaukee-Eight 117 powertrain with new dark and bronze finishes. For riders who want to strafe corners in comfort, the STs feature the complete suite of Harley-Davidson Grand American Touring features including Reflex™ linked Brembo® brakes with ABS, Boom!™ Box GTS infotainment system with color touch screen and navigation, cruise control and Daymaker® LED headlamps. The Street Glide ST features the iconic Harley-Davidson batwing fairing, while the Road Glide ST rolls with an aerodynamic frame-mounted sharknose fairing with dual headlamps.







2022 Harley-Davidson Road Glide ST Totalmotorcycle.com Features and Benefits

MILWAUKEE-EIGHT® 117 V-TWIN
The new pinnacle of torque and displacement with a factory-installed powertrain. Precision oil/air cooling. 126 ft. lbs. of torque at 3750 RPM. Tuned heavy breather intake and high flow exhaust maximize engine performance, a boost you can feel with every twist of the throttle.

West Coast Styling

BLACKED OUT EVERYTHING
Front end, controls, powertrain and exhaust. The only bright bits are pushrod tubes and tappet covers, and machined cylinder fins.

SPORT TOURING PROFILE
Standard bag height for a trimmed look and more room to lean.

FIXED SHARKNOSE FAIRING
This frame-mounted fairing keeps the cross-winds and traffic buffeting at bay, with a design that is unmistakably Harley-Davidson.

Standard Anti-Lock Braking System (ABS)

Boom! Box GTS infotainment system with color touch screen, two fairing-mount speakers and hidden radio antenna

Emulsion-technology rear shocks, with a single knob to hydraulically adjust pre-load for optimal ride and control

49mm forks with dual bending valve suspension technology

Daymaker LED headlamps

Smart Security System with proximity-based, hands-free security fob



OPTIONAL CORNERING RIDER SAFETY ENHANCEMENTS

Cornering Electronically Linked Brakes

Cornering-ABS

Cornering-Traction Control with modes

Drag Torque Slip Control

Vehicle Hold Control

Tire Pressure Monitoring (TPMS)







2022 Harley-Davidson Road Glide ST – Totalmotorcycle.com  Specifications/Technical Details
US MSRP Price: from $29999 (Black), $30574 (Color) USD
Canada MSRP Price: from $36999 (Black), $37699 (Color) CDN
Europe/UK MSRP Price: from £27895 (Black), £28395 (Color) GBP (On The Road inc 20% Vat)
Dimensions FLTRXST Road Glide® ST Notes
Length 94.7 in. (2,405 mm)
Overall Width 37.6 in. (955 mm)
Overall Height 52.2 in. (1,325 mm)
Seat Height, Laden 26.7 in. (678 mm) 2
Seat Height, Laden (Low seat position)
Seat Height, Laden (High seat position)
Seat Height, Laden (Low seat position with optional ARH suspension)
Seat Height, Laden (High seat position with optional ARH suspension)
Seat Height, Unladen 28.1 in. (715 mm)
Seat Height, Unladen (Low seat position)
Seat Height, Unladen (High seat position)
Seat Height, Unladen (Low seat position with optional ARH suspension)
Seat Height, Unladen (High seat position with optional ARH suspension)
Static Ground Clearance 5.5 in. (140 mm)
Dynamic Ground Clearance (with optional suspension)
Rake (steering head) (deg) 26
Fork Angle (deg) 29.25
Trail 6.7 in. (170 mm)
Wheelbase 64 in. (1,625 mm)
Tires, Type Dunlop® Harley-Davidson Series, bias blackwall front and rear
Tires, Front Model D408F
Tires, Front Specification 130/60B19 61H
Tires, Rear Model D407T
Tires, Rear Specification BW 180/55B18 80H
Fuel Capacity 6 gal. (22.7 l)
Reserve Fuel Capacity, Fuel Injection (warning light) 1 gal. (3.8 l)
Oil Capacity (w/filter) 5.2 qt. (4.9 l)
Transmission Capacity 1 qt. (.95 l)
Primary Chain Case Capacity 1.1 qts. (1 l)
Coolant Capacity N/A
Weight, As Shipped 806 lb. (366 kg)
Weight, In Running Order 842 lb. (382 kg)
Gross Vehicle Weight Rating 1,360 lb. (617 kg)
Gross Axle Weight Rating, Front 500 lb. (227 kg)
Gross Axle Weight Rating, Rear 927 lb. (420 kg)
Luggage Capacity -Volume 2.3 cu ft (0.064 m3)



Engine FLTRXST Road Glide® ST Notes
Engine Milwaukee-Eight® 117
Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; four valves per cylinder
Bore 4.075 in. (103.5 mm)
Stroke 4.5 in. (114.3 mm)
Displacement 117 cu in (1,923 cc)
Compression Ratio 10.2:1
Fuel System Electronic Sequential Port Fuel Injection (ESPFI) 3
Air Cleaner Paper, washable
Exhaust Dual, with crossover
Lubrication System Pressurized, dry-sump with oil cooler



Drivetrain FLTRXST Road Glide® ST Notes
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/68 ratio
Clutch Pressurized, dry-sump with oil cooler
Transmission 6-Speed Cruise Drive®
Gear Ratios (overall) 1st 9.593
Gear Ratios (overall) 2nd 6.65
Gear Ratios (overall) 3rd 4.938
Gear Ratios (overall) 4th 4
Gear Ratios (overall) 5th 3.407
Gear Ratios (overall) 6th 2.875



Chassis FLTRXST Road Glide® ST Notes
Frame Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded.
Swingarm Mild steel; two-piece drawn and welded section; forged junctions; MIG welded.
Front Fork 49mm Dual Bending Valve
Front Fork, Optional
Rear Shocks Premium standard height hand-adjustable rear suspension
Rear Shocks, Optional
Wheels, Optional Style Type N/A 4
Wheels, Front Type Bronze Prodigy 4
Wheels, Front Width 3.5 in. (89 mm)
Wheels, Front Height 19 in. (483 mm)
Wheels, Rear Type Bronze Prodigy 4
Wheels, Rear Width 5 in. (127 mm)
Wheels, Rear Height 18 in. (457 mm)
Brakes, Caliper Type 32 mm, 4-piston fixed front and rear
Brakes, Rotor Type Dual floating rotors (front), fixed rotor (rear)
Brakes, Front Diameter 11.8 in. (300 mm)
Brakes, Front Thickness 0.2 in. (5.1 mm)
Brakes, Front is dual Yes
Brakes, Rear Diameter 11.8 in. (300 mm)
Brakes, Rear Thickness 0.28 in. (7.1 mm)
Front brake lever free travel N/A
Rear brake pedal free travel N/A
Brakes, Anti-Lock Braking System (ABS) Standard
Suspension Travel, Front 4.6 in. (117 mm)
Suspension Travel, Rear 3 in. (76 mm)



Performance FLTRXST Road Glide® ST Notes
Engine Torque Testing Method J1349
Engine Torque 127 ft-lb (172 Nm) 5
Engine Torque (rpm) 3,750
Power (Hp/kW) 106 HP / 79 kW @ 4750 rpm
Lean Angle Testing Method J1168
Lean Angle, Right (deg.) 32
Lean Angle, Left (deg.) 31
Maximum hill-starting ability N/A
Fuel Economy Testing Method Estimated City/Hwy
Fuel Economy 41 mpg (5.7 l/100 km) 6
CO₂ Emissions Testing Method N/A
CO₂ Emissions N/A



Electric FLTRXST Road Glide® ST Notes
Battery Sealed, maintenance-free, 12V, 28-amp/hour, 405 cca (per Battery Council International Rating)
Charging Three-phase, 48-amp system (600W @ 13V, 2000 rpm, 625W max power @ 13V)
Starting 1.6 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation), Headlamp LED 40-watt, 1,060 lumen low beam, 60-watt, 1560 lumen high beam.
Lights (as per country regulation), Tail/Stop 8W/28W
Lights (as per country regulation), Front Signal Lights 8W/28W
Lights, Rear Turn Signals 8W/28W
Gauges Gauges styled to complement each vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators.
Auxiliary Lamps N/A
Electric Power Outlet Electric power accessory port in fairing
GPS System Boom!™ Box GTS audio system with GPS and touchscreen
Reverse Gear N/A



Warranty And Service FLTRXST Road Glide® ST Notes
Warranty 24 months (unlimited mileage) 7
Service Interval First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter 8



Notes

  1. Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and prices listed may differ from specifications and prices of vehicles manufactured and delivered. All product descriptions (including depictions, specifications, dimensions, measurements, ratings and competitive comparisons) are based on available information at the time of publication. Although such descriptions are believed correct, errors and changes can occur and complete accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and specifications, and may change or discontinue models, without notice and without incurring any obligation. Attention: Vehicles in the configurations shown and many of the accessories described in this catalog may not be available for sale or use in some locations. Please check with your dealer for complete product details and the latest information. All models feature 6-speed transmission (VRSC™ models and Sportster® models are 5-speed) and carbon fiber belt final drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
  2. Measurement reflects 180 lb. (81.7 kg) operator weight.
  3. Recommended 91 octane or higher fuel (R+M)/2.
  4. Standard and optional wheels may vary by country and region.
  5. Values shown are nominal. Performance may vary by country and region.
  6. The combined fuel economy numbers were derived using a combination of estimated city and highway values. Fuel economy estimates are derived from US EPA exhaust emission certification data on a sample motorcycle from the corresponding family under ideal laboratory conditions. Your actual fuel economy will vary depending on your personal riding habits, road and driving conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
  7. See motorcycle owner’s manual for complete details.
  8. Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals. See Owner’s Manual for full details.







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
