2022 Honda CBR650R Guide

2022 Honda CBR650R

2022 Honda CBR650R 2022 Honda CBR650R 2022 Honda CBR650R 2022 Honda CBR650R

2022 Honda CBR650R: DISCOVER A PLACE WITHOUT BORDERS.

Introducing the 2022 Honda CBR650R…

Designed to be appreciated on the street, but drawing inspiration from the supersport realm, the CBR650R excites riders with its sharp lines, complete bodywork and corner-carving abilities, but it also delivers comfort, practicality and value. A full-fairing sport variant of the standard CB650R, this model has a high-quality Showa Separate Function Big Piston fork, stylish aesthetics and excellent emissions performance. With a finely tuned chassis delivering light, responsive handling, and a high-revving inline four-cylinder engine that offers enjoyable power, the CBR650R is exciting to ride and a pleasure to own, a gratifying intersection of values for the modern sport bike rider.

Honda’s versatile middleweight sports bike continues to carve out a strong following. Specification includes 41mm Showa Separate Function Big Piston USD forks, high-revving four-cylinder engine, HSTC, assist/slipper clutch, underseat USB Type-C socket and LCD display. Both paint options receive visual updates for 2022.

Honda’s fully faired CBR650F, launched in 2014 alongside the naked CB650F, provided a healthy slice of four cylinder middleweight performance, very much at the sporty end of the ‘sports touring’ spectrum. In 17YM it received sharper styling, highlighting the engine more, plus a peak power boost, Showa Dual Bending Valve front fork and revised Nissin brake calipers.

For its 2019 evolution the CBR650F became the CBR650R. The upgrade from ‘F’ to ‘R’ indicating an even more potent shot of sporty ability designed to be explored, used and enjoyed on the street.

In the process of its transformation the CBR650R became, deliberately, a rare breed: a four cylinder sports bike that provides similar pleasure, enjoyment and adrenaline to an RR machine, yet with enough practicality – and sensible running costs – to make it a viable option as day-to-day transport in addition to weekend fun.

It’s a direction that’s been well received. In its 2019 debut year, the CBR650R was the second best-selling sports bike in Europe. For 2021, continued its development curve with user-driven detail improvements and a major upgrade for the front suspension.

For 2022, the CBR650R – the best selling sports bike in 2021 – gains updates to both colour options.

The CB650R received a significant refresh for 2021. The major news was application of 41mm Showa Separate Function Big Piston (SSF-BP) USD forks – high quality suspension that really elevates the bike’s handling ability.

EURO5 compliance for the engine was achieved with no loss of top end power; other detail improvements included improved visibility for the LCD display and USB Type-C charging socket under the seat. The headlight reflectors, side panels and rear mudguard were all also updated.



2022 Honda CBR650R Totalmotorcycle.com Key Features

SPORTBIKE SUPERSTAR
Nothing defines a motorcycle like its engine, and that’s never been as apparent as with a Honda CBR650R. What makes it so special? It’s a transverse inline four, a design pioneered by Honda in the motorcycling world. Fours like this are smooth, well balanced, and most of all responsive—in other words, they’re a spectacular choice for a sportbike like the CBR650R. And this bike’s overall size hits a huge sweet spot as well: light, maneuverable, and a joy to ride, it’s like a shot of espresso for the enthusiast’s soul. Last year we gave it a big suspension upgrade with 41mm Showa® SFF-BP “Big Piston” front suspension that made the great bike better than ever. Fours aren’t as common today as they once were, but that’s okay. Because the CBR650R is a bike for those who appreciate riding a little more than most, too.

  • 70kW peak power, 63Nm peak torque with 35kW A2 licence option
  • Honda Selectable Torque Control (HSTC)
  • Assist/slipper clutch
  • Full EURO5 compliance
  • Minimal panels and rear mudguard/number plate mount
  • LCD display easy to read
  • USB Type-C socket under the seat
  • Showa Separate Function Big Piston (SFF-BP) USD forks
  • Four-piston, radial-mount front brake calipers and floating discs
  • 120/70-ZR17 and 180/55-ZR17 front and rear tyres

ASSIST/SLIPPER CLUTCH

Hard braking, rapid downshifting, smoothly controlled corner entry: the Assist/Slipper Clutch allows you to confidently experience the impressive abilities of the CBR650R while easily managing the six-speed gearbox.

FOUR-CYLINDER ENGINE

The CBR650R is equipped with a powerful four-cylinder, DOHC 16-valve engine. It has a 12,000rpm redline and features Honda Selectable Torque Control (HSTC) to maintain rear wheel traction. You have the power, all of, firmly in your right hand.

EXHAUST & MUFFLER

Thrill. Harmony. Power. That’s what the CBR650R is all about. The four exhaust downpipes sweep together around the front of the engine, and the muffler has been designed to deliver a spine-tingling roar as revs climb.

FULL LED LIGHTING

Every detail of the CBR650R has been designed for passionate riders. The premium, dual LED headlights feature new reflectors and throw out crisp white beams, marking out this motorcycle’s difference. And the taillight has a sleek, minimalist form.

LCD DISPLAY

The view forward from the cockpit is pure sports. The digital LCD instruments are clear and now even easier to read, because you need the information, fast. Gear Position and Shift Up indicators are included in the display.

ASSIST/SLIPPER CLUTCH

Hard braking, rapid downshifting, smoothly controlled corner entry: the Assist/Slipper Clutch allows you to confidently experience the impressive abilities of the CBR650R while easily managing the six-speed gearbox.

FOUR-CYLINDER ENGINE

The CBR650R is equipped with a powerful four-cylinder, DOHC 16-valve engine. It has a 12,000rpm redline and features Honda Selectable Torque Control (HSTC) to maintain rear wheel traction. You have the power, all of, firmly in your right hand.

EXHAUST & MUFFLER

Thrill. Harmony. Power. That’s what the CBR650R is all about. The four exhaust downpipes sweep together around the front of the engine, and the muffler has been designed to deliver a spine-tingling roar as revs climb.

FULL LED LIGHTING

Every detail of the CBR650R has been designed for passionate riders. The premium, dual LED headlights feature new reflectors and throw out crisp white beams, marking out this motorcycle’s difference. And the taillight has a sleek, minimalist form.

LCD DISPLAY

The view forward from the cockpit is pure sports. The digital LCD instruments are clear and now even easier to read, because you need the information, fast. Gear Position and Shift Up indicators are included in the display.

This is a bike for born competitors. Sculpted by high-speed aerodynamics the CBR650R – with suspension, equipment and style upgrades – is an ultra-sharp tool with focused, sporting intent, thrilling power, and exceptional torque. Discover a place without borders: Your obsession.



PUTTING THE R INTO THE CBR
Born on the racetrack, turning heads on the street.
The CBR650R has honed its racetrack DNA for aggressive road performance. The footpegs and handlebars give you the optimal riding position, for fluid movement around the machine, finding the perfect cornering balance as you tackle thrilling roads. The front tyre is beautifully weighted, for precise turn-in capability, while the 180-section rear has huge grip. Up front, piercing dual LED headlights fill out the tightly wrapped fairing, mirrored by the minimal seat unit and re-shaped, slimmer side panels. Even the rear number plate mount has been sharply re-styled. And, the electrifying roar of the exhaust, chasing the redline will make your hair stand on end.

A THRILLING RUSH TO THE REDLINE
It’s what we do. Four-cylinder power at its very best.
The inline four-cylinder DOHC 16-valve engine is built to be used. Close, short gearing and a smooth rush of power delivers exhilarating acceleration – and then there’s the evocative howl as rpm climbs high. It’s addictive. An assist/slipper clutch eases upshifts and manages hard down changes, while Honda Selectable Torque Control (HSTC) maintains rear wheel traction. It’s an engineering masterpiece. Have fun with it.

PREMIUM EQUIPMENT
High performance means high specification.
The CBR650R stands alone. A true, sporting middleweight it has the specification to match its single-minded intent. Lithe, agile and styled by speed dual LED headlights feature new reflectors, for an even more piercing stare, and lead the bike’s aggressive angles. Handlebars clip-in below the top-yoke, for complete control and the LCD instrument cluster is now even easier to read. And, because sometimes life will interfere with your riding, there’s now a USB charging socket under the seat.







2022 Honda CBR650R Totalmotorcycle.com Features and Benefits

STYLING
While its four-cylinder power unit is still firmly on display, the CBR650R’s wrapping offers pure sporting appeal; dual LED headlights emit a penetrating, uncompromising stare, while the upper and lower fairings blend muscularity with sharp, slim lines and angles. The LCD display has excellent visibility, while the side panels and license-plate holder add stylish appeal. The seat unit is compact and truncates the rear of the machine, adding to the hard-edged sense of purpose. The aggressive riding position starts with clip-on handlebars that mount beneath the top triple clamp; they’re pushed forward and low to create a performance-focused seating position, as are the rearward-set footpegs. Seat height is 31.9 inches.

CHASSIS
The steel diamond frame uses pressed (rather than forged) swingarm pivot plates; it’s light and uses twin elliptical spars with a rigidity balance specifically tuned (stiffer around the headstock and more flexible in the spar sections) to deliver balanced handling characteristics with high levels of rider feedback.

Curb weight is 458 pounds (measured with all fluids), thanks not only to the lightweight frame, but also savings to both the fuel tank and the super-sport-style footpegs.

The CBR650R has a 41 mm inverted Showa Separate Function Big Piston fork, offering high-performance handling in any type of riding, while a single-tube shock operates directly on the curvaceous gravity die-cast aluminum swingarm. The shock is adjustable for seven-stage spring preload.

Four-piston radial-mount front brake calipers work on 310 mm floating rotors and are paired with a single-piston rear caliper and 240 mm rotor. ABS is standard. The cast aluminum wheels have five Y-shaped spokes, which keeps weight to a minimum and improves handling by minimizing inertia and unsprung mass.

ENGINE
Honda’s development engineers wanted to create the purest, most enjoyable midsized four-cylinder performance possible for the CB650R rider, so the 649 cc, DOHC 16-valve engine has been tuned to deliver good power above 10,000 rpm. Peak power arrives at 12,000 rpm, with peak torque delivered at 8,500. The net result is a motor that spins well at high rpm, with a smooth, linear torque delivery that builds strongly as revs rise, and sounds great in the process.

Direct cam actuation makes for a compact cylinder head; compression ratio is 11.6:1. The valve train is reinforced and iridium spark plugs are employed.

Asymmetric piston skirts minimize bore contact, reducing friction. Ferrous spines on the outer surface of the cylinder sleeves reduce oil consumption (and friction) with improved heat transfer, and a silent SV cam chain minimizes frictional losses by using a Vanadium coating on its pins. Internal water channeling from the cylinder head to the cylinders does away with most of the exterior hoses.

Twin air ducts on either side of the fuel tank feed a large volume of air, raising atmospheric pressure in the airbox. They also produce a throaty intake roar. The exhaust features a large, 1.5 inch-bore tail pipe inside the muffler with its exit pipe angled upward to emit an emotional howl.

The engine uses a compact internal architecture, stacked six-speed gearbox and starter layout with the cylinders canted forward 30°. An assist/slipper clutch eases upshifts while managing rear-wheel lock up under rapid downshifts, while Honda Selectable Torque Control (HSTC) manages rear-wheel traction; it can be turned off should the rider choose.

Transferable one-year, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.

  • Meets current EPA standards.
  • Models sold in California meet current CARB standards and may differ slightly due to emissions equipment.



EUROPEAN FEATURES

Chassis

The CBR650R’s steel diamond frame uses pressed swingarm pivot plates and twin elliptical spars with a rigidity balance specifically tuned (stiffer around the headstock and more flexible in the spar sections) to deliver balanced handling characteristics, with high levels of rider feedback. Rake is set at 25.5° with trail of 101mm and wheelbase of 1,450mm. Kerb weight is 208kg.

Showa’s Separate Function Big Piston (SFF-BP) 41mm USD forks offer high-quality reaction. A pressure separation damper in one fork tube and spring mechanism in the other deliver high damping performance and lighter weight. Together with the use of a larger sized piston the result is increased feel, bump absorption and control. Adjustable for 10-stage spring preload, the single-tube monoshock operates directly on the curvaceous gravity die-cast aluminium swingarm.

Four-piston radial-mount front brake calipers work 310mm wave-pattern floating discs, and are paired with a single-piston rear caliper and 240mm disc. The ABS is a two-channel system.

Cast aluminium wheels mount 120/70-ZR17 and 180/55-ZR17 front and rear tyres.



Styling & equipment

With its four-cylinder power unit clearly on display the CBR650R’s wrapping ramps up the pure sporting appeal; dual LED headlights emit a penetrating, uncompromising stare and the upper and lower fairings blend muscularity with slim lines and angles.

The seat unit, too is compact and truncates the rear of the machine, adding to the hard-edged sense of purpose. Trim side panels accentuate the minimalism, as does the steel rear mudguard/number plate mount.

The aggressive riding position starts with clip-on handlebars that mount beneath the top yoke, matched to rear set footpegs. There’s also a USB Type-C socket located under the seat, for easy charging of a mobile device. Seat height is set at 810mm.

Stylish, easy-to-read LCD instruments include Shift Up, Gear Position and Peak Hold indicators.



Engine

The 649cc, DOHC 16-valve engine is tuned to create the purest, most enjoyable mid-sized four-cylinder performance possible, with the classically fast ‘pick-up’ through the rev range and hard-hitting, high-revving top-end for which Honda’s in-line’s fours are renowned. Peak power of 70kW arrives @ 12,000rpm with peak torque @ 63Nm delivered at 9,500 rpm. An easy 35kW conversion is available for A2 licence holders. EURO5 compliance required revisions to the ECU, cam lobes, intake timing, exhaust pipe, catalyser and silencer, as well as the addition of a crank pulsar.

Direct cam actuation makes for a compact cylinder head; bore and stroke is set at 67mm x 46mm with compression ratio of 11.6:1. Iridium spark plugs are employed and twin air ducts – either side of the fuel tank – feed the airbox and produce a throaty intake roar.

Asymmetric piston skirts minimise bore contact and reduce friction. Ferrous spines on the outer surface of the cylinder sleeves reduce oil consumption (and friction) with improved heat transfer and a silent SV cam chain reduces frictional losses by using a Vanadium coating on its pins. Internal water channelling from cylinder head to cylinders does away with most of the exterior hoses.

The engine uses a compact internal architecture, stacked six-speed gearbox and starter layout with the cylinders canted forward 30°. An assist/slipper clutch eases upshifts while managing rear-wheel lock up under hard braking and rapid downshifts. Honda Selectable Torque Control (HSTC) manages rear wheel traction; it can be turned off should the rider choose.

Fuel consumption of 20.4km/l (WMTC mode) gives a range of over 300km from the 15.4L fuel tank.





Accessories

A range of Genuine Honda Accessories are available for the CBR650R:

Front mudguard panels, side covers, seat cowl (aluminium parts or aluminium inserts)

Wheel stripes

Tank bag and seat bag

Quick shifter

Tall screen – clear or smoked

Heated grips









2022 Honda CBR650R – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $9799 USD
Canada MSRP Price: $ 10899 CDN
Europe/UK MSRP Price: £ See Dealer GBP (On The Road inc 20% Vat)
Model

CBR650R

ENGINE


Type

649 cc liquid-cooled 30º inline four-cylinder four-stroke

Valve Train

DOHC; 4 valves per cylinder

Bore x Stroke

67.0 mm x 46.0 mm

Compression Ratio

11.6:1

Induction

PGM-FI; 32 mm bore

Ignition

Full transistorized

Starter

Electric

Transmission

Manual 6-speed

Clutch

Multiplate wet

Final Drive

#525 chain; 15T/42T

SUSPENSION


Front 41 mm inverted Showa Separate Function Fork (SFF); 4.7 in. travel
Rear

Showa single shock w/ adjustable preload; 5.0 in. travel

BRAKES


Front Dual four-piston, radial-mount Nissin hydraulic calipers w/ 310 mm floating discs; 2-channel ABS
Rear Single one-piston hydraulic caliper w/ 240 mm disc; 2-channel ABS

TIRES


Front

120/70-17

Rear

180/55-17

MEASUREMENTS


Rake (Castor Angle)

25.5º

Trail

101 mm (4.0 in.)

Length

83.8 in.

Width

29.5 in.

Height

45.2 in.

Ground Clearance

5.2 in.

Seat Height

31.9 in.

Wheelbase

57.0 in.

Fuel Capacity

4.1 gal. (0.8 gal. reserve)

Color

Matte Black Metallic

Curb Weight*

456 lbs.

*Includes all standard equipment, required fluids and full tank of fuel—ready to ride
Meets current CARB and EPA emissions standards





2022 Honda CBR650R – Totalmotorcycle.com Canada Specifications/Technical Details

Engine & Drivetrain
Engine Type Liquid-cooled inline four-cylinder
Displacement 649 cc
Bore & Stroke 67 mm x 46 mm
Compression Ratio 11.6:1
Valve Train Chain-driven DOHC, four valves per cylinder
Fuel Delivery PGM-FI electronic fuel injection with 32 mm throttle bodies
Transmission Six-speed
Final Drive #525 O-ring-sealed chain (15T/42T)
Chassis & Suspension
Front Suspension 41 mm Showa SFF-BP (Separate Function- Big Piston front Fork) inverted fork
Rear Suspension Showa monoshock damper with 7-stage adjustable preload
Additional Information
Tires Front: 120/70ZR-17
Rear: 180/55ZR-17
Brakes Front: Dual 310 mm discs with radial-mounted four-piston calipers
Rear: 240 mm disc with single-piston caliper
ABS: 2-channel ABS
Seat Height 810 mm (31.9 in.)
Wheelbase 1,450 mm (57.1 in.)
Curb Weight 207 kg (456 lb) including required fluids and full tank of gas – ready to ride
Fuel Capacity 15.4 L
Colour Mat Gunpowder Black Metallic
Warranty 12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus





2022 Honda CBR650R – Totalmotorcycle.com European Specifications/Technical Details
ENGINE
Type Liquid-cooled 4-stroke 16-valve DOHC inline-4 cylinder
Engine Displacement (cm³) 649cc
Bore x Stroke (mm) 67.0mm x 46.0mm
Compression Ratio 11.6:1
Max. Power Output 70kW/12,000rpm
Max. Torque 63Nm/9,500rpm
Oil Capacity 2.7L
FUEL SYSTEM
Carburation PGM-FI electronic fuel injection
Fuel Tank Capacity 15.4L
Fuel Consumption 20.4km/litre
ELECTRICAL SYSTEM
Starter Electric
Battery Capacity 12V/8.6AH
ACG Output 370W
DRIVETRAIN
Clutch Type Wet, multiplate disc
Transmission Type 6-speed
Final Drive Chain
FRAME
Type Steel diamond
CHASSIS
Dimensions (LxWxH) 2120 x 750 x 1,150mm
Wheelbase 1450mm
Caster Angle 25.5°
Trail 101mm
Seat Height 810mm
Ground Clearance 130mm
Kerb Weight 208kg
Turning radius
SUSPENSION
Type Front 41mm Showa Separate Function front Fork Big Piston (SFF-BP) USD forks
Type Rear Monoshock damper with 10 stage adjustable preload, 43.5mm stroke
WHEELS
Rim Size Front Hollow section 6-spoke cast aluminium
Rim Size Rear Hollow section 6-spoke cast aluminium
Tyres Front 120/70ZR17 M/C (58W)
Tyres Rear 180/55ZR17 M/C (73W)
BRAKES
ABS System Type 2 channel; hydraulic dual disc 310mm front, hydraulic disc 240mm rear
INSTRUMENTS & ELECTRICS
Instruments Digital speedometer, digital bar graph tachometer, dual trip meter, digital bar graph fuel gauge, gear position and upshift indicator, digital clock
Headlight LED
Taillight LED



# Please note that the figures provided are results obtained by Honda under standardised testing conditions prescribed by WMTC. Tests are conducted on a rolling road using a standard version of the vehicle with only one rider and no additional optional equipment. Actual fuel consumption may vary depending on how you ride, how you maintain your vehicle, weather, road conditions, tire pressure, installation of accessories, cargo, rider and passenger weight, and other factors.







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
