2022 Kawasaki KLX140R: HIGH-REVVING.

Introducing the 2022 Kawasaki KLX140R…

The KLX140R motorcycle is available in three model variations and is designed to provide an off-road experience with memories to last a lifetime. The powerful 144cc, four-stroke, air-cooled, single-cylinder engine features an electric starter and keyless ignition. Its broad and smooth high-revving 144cc engine utilizes a manual clutch and five-speed transmission to offer an efficient and user-friendly feel. The KLX140R uses a 17” front and 14” rear wheel.

Kawasaki offers a complete family of KLX®140R models to get the whole family involved in off-road motorcycling. The KLX®140R is designed more for the youngsters with the smallest wheels and lowest seat height


2022 Kawasaki KLX140R Totalmotorcycle.com Key Features




2022 Kawasaki KLX140R Totalmotorcycle.com Features and Benefits


The Kawasaki KLX family of off-road motorcycles are widely popular with their easy-to-ride character, incredible capabilities while on trails and their low maintenance needs. The eight off-road models consist of four engine configurations and are built to suit a wide variety of riders.






2022 Kawasaki KLX140R – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $3199 USD
Canada MSRP Price: $3899 CDN
Europe/UK MSRP Price: £ See Dealer GBP (On The Road inc 20% Vat)

Engine Type 4-Stroke, Air-Cooled, SOHC, Single, 2-Valve Cylinder Head
Displacement 144 cc
Bore & Stroke 58.0 x 54.4 mm
Compression Ratio 9.5:1
Carburetor Keihin PB20
Ignition Digital DC-CDI
Transmission 5-Speed
Rake/Trail 27˚/3.3 in. (KLX140R) 27˚/3.8 in. (KLX140R L) 27˚/4.6 in. (KLX140R F)
Front Tire Size 70/100-17 (KLX140R); 70/100-19 (KLX140R L); 2.75 x 21 (KLX140R F)
Rear Tire Size 90/100-14 (KLX140R); 90/100-16 (KLX140R L); 4.10 x 18 (KLX140R F)
Front Suspension 33 mm Telescopic Forks
Front Suspension Travel 7.1 in. (KLX140R/R L); 7.5 in. (KLX140R F)
Rear Suspension Uni-Trak, Single Shock w/5-way preload adjustment (KLX140R);
Single shock w/piggyback reservoir, threaded preload, 4-way compression and
22-position rebound damping adjustment (KLX140R L/R F)
Rear Suspension Travel 7.1 in. (KLX140R/R L); 7.9 in (KLX140R F)
Wheelbase 49.6 in. (KLX140R); 50.6 in. (KLX140R L); 52.4 in. (KLX140R F)
Front Brake Type 220mm Petal Disc
Rear Brake Type 186mm Petal Disc
Fuel Tank Capacity 1.5 gal.
Ground Clearance 9.3 in. (KLX140R); 10.0 in. (KLX140R L); 12.4 in. (KLX140R F)
Seat Height 30.7 in. (KLX140R); 31.5 in. (KLX140R L); 33.9 (KLX140R F)
Curb Weight= 205 lb. (KLX140R); 209 lb. (KLX140R L); 218 lb. (KLX140R F)
Warranty 6 months
Kawasaki Protection Plus™ 12, 24, or 36 months
Specifications subject to change without notice.
Ask about Kawasaki’s Team Green™ amateur rider support program.
(KP) = See Kaw-Pedia section for more details.
* = Changes from previous model year.
= = Includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90% of capacity) and tool kit (if supplied).



2022 Kawasaki KLX140R – Totalmotorcycle.com  Canadian Specifications/Technical Details

Engine 144cc, air-cooled, 4-stroke, SOHC 2-valve single
Bore x Stroke 58.0 x 54.4 mm
Compression Ratio 9.5:1
Fuel System Carburettor: Keihin PB20
Ignition Digital DC-CDI
Starting Electric
Lubrication Forced lubrication, wet sump
Transmission 5-speed, return
Clutch Wet multi-disc, manual
Final Drive Chain

Frame Perimeter, box-section, high-tensile steel
Front Suspension / Wheel Travel ø33 mm telescopic fork / 180 mm (7.1 in)
Rear Suspension / Wheel Travel Uni Trak, single shock with adjustable spring preload / 180 mm (7.1 in)
Rake / Trail 27.0° / 85 mm
Steering Angle (L/R) 41° / 41°
Front Tire 70/100-17 40M
Rear Tire 90/100-14 49M
Front Brake Single ø220 mm petal disc with dual-piston caliper
Rear Brake ø186 mm petal disc with single-piston caliper

Dimensions (L x W x H) 1,820 x 790 x 1,050 mm (71.7 x 31.1 x 41.3 in)
Wheelbase 1,260 mm (49.6 in)
Road Clearance 235 mm (9.3 in)
Seat Height 780 mm (30.7 in)
Curb Mass** 93 kg (205 lb)
Fuel Capacity 5.8 litres
Warranty 6 months
Kawasaki Protection Plus 12 / 24 / 36 / 48 months





2022 Kawasaki KLX140R – Totalmotorcycle.com European Specifications/Technical Details
