2022 Suzuki Boulevard M109R Guide

2022 Suzuki Boulevard M109R

2022 Suzuki Boulevard M109R 2022 Suzuki Boulevard M109R 2022 Suzuki Boulevard M109R

2022 Suzuki Boulevard M109R: HIGH STYLE, WITH HIGH PERFORMANCE.

Introducing the 2022 Suzuki Boulevard M109R…

Go ahead and admit it. Naturally, you want to be the owner of the most stylish bike on the block. Lucky for you, the Suzuki Boulevard M109R B.O.S.S. grabs attention everywhere it goes. An incomparable black colour scheme coupled with aggressive styling screams in testament to the M109R’s power. But, if looks aren’t enough to sell you on this bike, then let the 1783cc V-Twin engine convince you. Tuned to produce massive torque from idle to redline, the Suzuki Boulevard M109R B.O.S.S. will keep you smiling and styling through your journeys to come.

Without question, the M109R B.O.S.S. delivers unparalleled performance and gorgeous styling to own the night. The M109R B.O.S.S. features an advanced chassis built for effortless cruising across town or state lines. Its unrivalled capabilities are born from Suzuki’s championship-winning race heritage. The M109R’s engine is tuned to produce massive torque from idle to redline, which translates into acceleration that you have to feel to believe. The big V-twin also produces a throaty, aggressive exhaust that identifies the M109R B.O.S.S. as a power cruiser beyond compare.







2022 Suzuki Boulevard M109R Totalmotorcycle.com Key Features









2022 Suzuki Boulevard M109R Totalmotorcycle.com Features and Benefits

V-TWIN ENGINE
V-Twin Engine 1783 cm3, liquid-cooled, DOHC, V-Twin engine is designed to produce a massive tractable power and responsive torque. Suzuki Dual Throttle Valve (SDTV) fuel injection system produces smooth throttle response even at low engine rpm. Suzuki Advanced Sump System (SASS), a compact dry-sump lubrication system. It is designed for reduced engine height, a lower crankshaft position and lower center of gravity.

ALUMINUM-ALLOY PISTONS
Huge 112 mm (4.4 in) forged aluminum-alloy pistons. These are one of the largest reciprocating gasoline engine pistons being used in any production passenger car or motorcycle, while featuring race-proven design to reduce friction and inertial mass.

AIR CLEANER
Dual, triangular air cleaner covers, one on each side of the engine.

SUSPENSION
A cast aluminum-alloy swingarm works with a progressive linkage and a single rear shock to deliver 4.6 inch (118mm) of wheel travel; spring preload can be adjusted to suit rider and passenger weight. The inverted front forks feature race-proven cartridge internals with 1.8 inch (46mm) stanchion tubes producing 5.1 inch (130mm) of wheel travel.

BRAKE SYSTEM
The race-proven front brake system came straight off the sportbike, including radial-mount opposed-four-piston front brake callipers and 12.2 inches (310mm) discs. The system’s combination of stopping power and feel through the front brake lever is unmatched by anything in its class. The rear brake system includes a dual-piston calliper and a 10.8 inch (275mm) disc.

SUZUKI ADVANCED SUMP SYSTEM (SASS)
Suzuki Advanced Sump System (SASS), a compact dry sump lubrication system, provides reduced engine height, a lower crankshaft position, and a lower center of gravity.

THE UNIQUE LOOK OF POWER
One look is all it takes to tell that the SUZUKI BOULEVARD M109R is not an average cruiser. Instead, it is the muscular, innovative look of high performance and high style, with long, sleek, flowing lines emphasizing the powerful V-Twin engine.

FRAME
A high-tensile steel double-cradle frame is built to comfortably handle all the power and torque while delivering agile handling and a plush, smooth ride.

240MM REAR TIRE
The massive, low-profile 240/40 x 18 is the widest rear tire ever used on a Suzuki motorcycle.

HANDLEBARS
Flat-bend, drag-style handlebars are mounted on pull-back risers to be positioned within a short distance from the seat to improve the rider/machine interface, aiding comfort and control.

FUEL TANK AND PASSENGER SEAT
A wide, stretched-out fuel tank with a class-leading capacity of 19.5 litres (5.2 U.S. gallons), and a comfortable, low seat. Integrated frame side covers. A sleek, integrated radiator cowl. A sporty solo-seat cover that can be quickly swapped for the included passenger seat.

HEADLIGHT AND TAILLIGHT
A streamlined headlight cover, carrying a unique, trapezoidal-shaped multi-reflector 60/55W H4 halogen headlight, with integrated position lights in the European market. A maintenance-free LED taillight is built into the tail section: traditional, bullet-shaped, chrome-plated front and rear turn signals with amber lenses.

INSTRUMENT CLUSTER
A handlebar-mounted instrument cluster, including a digital tachometer and LED indicator lights to go with the tank-mounted analog speedometer and LCD odometer, dual trip meters, fuel gauge and clock.









2022 Suzuki Boulevard M109R – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $NA USD
Canada MSRP Price: $16999 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)

NA







2022 Suzuki Boulevard M109R – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE
Type 4-stroke, 2-cylinder, liquid-cooled, DOHC, 54-degree V-Twin
Displacement 1783 cc (108.8 cu. in)
Bore x Stroke 112.0mm x 90.5mm
Compression Ratio 10.5 : 1
Fuel System Fuel Injection
Starter Electric
Ignition Electronic ignition (Transistorized)
DRIVE TRAIN
Transmission 5-speed constant mesh
Final Drive Shaft Drive
CHASSIS
Length 2480 mm (97.6 in)
Width 875 mm (34.4 in)
Height 1130 mm (44.5 in)
Wheelbase 1710 mm (67.3 in)
Seat Height 705 mm (27.8 in)
Curb Mass 347 kg (764 lbs)
Suspension Front Inverted telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Brakes Front Disc, twin
Brakes Rear Disc
Tires Front 130/70R18M/C 63V, tubeless
Tires Rear 240/40R18M/C 79V, tubeless
Fuel Tank 19.5L (5.2 US gal)
WARRANTY
12 month unlimited mileage limited warranty







2022 Suzuki Boulevard M109R – Totalmotorcycle.com European Specifications/Technical Details

NA



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
