2022 Yamaha MT-07 Guide

2022 Yamaha MT-07

2022 Yamaha MT-07 2022 Yamaha MT-07 2022 Yamaha MT-07 2022 Yamaha MT-07 2022 Yamaha MT-07

2022 Yamaha MT-07: DARK ATTRACTION.

Introducing the new 2022 Yamaha MT-07…

Featuring a distinctive next generation look and features, as well as an advanced twin‑cylinder engine. Experience the best balance of performance and value the Dark Side has to offer.

Inspired by Japanese subculture and created by some of the most visionary designers in the business, the Yamaha MT-07 marked the real beginning of Yamaha’s “hyper naked” segment when it arrived in 2014. The 2022 MT-07 represents the progressive evolution of Yamaha’s popular naked middleweight, reinforcing the core values of this outstandingly successful and much-loved motorcycle.

For 2022, the next-generation MT-07 gets distinctive new bodywork with twin winglet-type air intakes and a compact new LED headlight, which projects a futuristic Y-shaped face – the signature style for the latest Hyper Naked models. Plus the refined EU5-compliant engine gives you even more linear response with a gutsier exhaust note.

New wider aluminium taper handlebars make turning easier and create a more assertive riding position, while larger 298mm dual front discs deliver stronger braking. Moreover, the inverted LCD instruments, as well as black control levers and compact LED flashers, emphasise the bike’s top specifications and best-in-class value.







2022 Yamaha MT-07 Totalmotorcycle.com Key Features

PREMIUM STYLING

The 2022 MT-07 styling reflects the ongoing evolution of the MT family The LED headlight assembly creates a signature front face, complemented by more attractive LED turn signals, and fuel tank covers with sculpted air ducts to give the MT-07 an aggressive appearance.



689 CC CP2 ENGINE

The EU5-compliant, 689 cc twin-cylinder CP2 engine features an optimized air intake duct design and fuel injector settings, as well as a 2-into-1 exhaust to provide a more linear engine response and high-torque throughout the RPM’s.



ADVANCED BRAKING SYSTEM

Equipped with a high-spec front braking system, the MT-07 features a front 298 mm dual brake rotors giving more stopping power and greater controllability and a 245 mm rear disc which improves performance, particularly in wet conditions.

Advanced Twin-Cylinder Engine
The MT-07 features an updated, compact 689cc liquid-cooled, inline twin cylinder, DOHC engine with fuel injection. The unique power character of the engine provides outstanding low- to mid-range torque with a linear throttle response and strong high-rpm pulling power. Maximizing riding excitement in the real world, the engine maintains the same level of response due to its intake air duct design, exhaust system specs – now integrated 2-into-1 exhaust pipes and muffler – and updated ECU specs. The fuel injection settings were also optimized to bring refinements to the engine’s linear response characteristics while the throttle is slightly open at low rpm. Other updates include new valve seats with excellent abrasion resistance for the exhaust side, improved gearshift feel thanks to different cut angles for the dog gears, and repositioning for the catalytic converter – now closer to the headers – and oxygen sensor.

Assertive Riding Position
To alleviate any sense of narrowness, the MT-07 features a new tapered handlebar that is 32mm wider and 19mm taller and offers improved feelings of control and comfort for a wider range of rider sizes.

Next-Generation Design
Joining the third generation MT style – as featured on the MT-09 – the MT-07’s new look further brings out its distinctive appeal with fashion-leading colors and graphics. The newly designed parts and components are integrated with minimal structural elements, creating an attractive design that emphasizes pure Hyper Naked character. With a silhouette that is synonymous with the MT Series’ signature statement of torque and power, the MT-07 showcases a tight, compact and powerful appearance.

LED Projector Lighting
With new LED lighting for the position lights, headlight and both front and rear turn signals, the MT-07 exhibits clear and powerful illumination with a modern design.

  • Next-generation body design with pure MT family DNA
  • Distinctive winglet-style air intakes
  • EU5-compliant 689 cc crossplane-technology CP2 engine
  • Maximum torque of 49.4 ft-lb produced at 6,500 rpm
  • 298 mm dual front brake discs
  • Inverted LCD spot colour instruments
  • Next-generation design
  • LED projector lighting
  • 690cc 2-cylinder EU5 CP2 engine
  • Bigger front disc brakes for stronger stopping power
  • Assertive riding position
  • Inverted LCD meter
  • LED indicators
  • Latest-generation tyres
  • Colour, graphics and finishing









2022 Yamaha MT-07 Totalmotorcycle.com Features and Benefits

ENGINE

  • Advanced Twin-Cylinder Engine
    The MT-07 features an updated, compact 689cc liquid-cooled, inline twin cylinder, DOHC engine with fuel injection. The unique power character of the engine provides outstanding low- to mid-range torque with a linear throttle response and strong high-rpm pulling power. Maximizing riding excitement in the real world, the engine maintains the same level of response due to its intake air duct design, exhaust system specs – now integrated 2-into-1 exhaust pipes and muffler – and updated ECU specs. The fuel injection settings were also optimized to bring refinements to the engine’s linear response characteristics while the throttle is slightly open at low rpm. Other updates include new valve seats with excellent abrasion resistance for the exhaust side, improved gearshift feel thanks to different cut angles for the dog gears, and repositioning for the catalytic converter – now closer to the headers – and oxygen sensor.
  • Crossplane Crankshaft Concept
    The two-cylinder engine features Yamaha’s Crossplane Crankshaft Concept 270-degree crank that provides linear torque development in response to the rider’s throttle input. Offering excellent rider-machine communication, the CP2 engine is also light, slim and compact.
  • Compact Stacked Transmission
    The six-speed transmission “stacks” the input/output shafts in a triangular layout. Keeping the overall engine size shorter from front-to-back, the placement in the frame is optimized for outstanding weight balance. The transmission ratios bring out the best of the low- to mid-speed torque with excellent response characteristics to reduce the need for frequent shifts.
  • Midship Exhaust System
    By placing the muffler low in the frame and as close to the center of the machine as possible, the bike’s mass is centralized for improved all around handling. The MT-07 also features a new exhaust system with integrated 2-into-1 exhaust pipes and muffler.
  • Offset Cylinder Block
    The CP2 engine shifts its cylinder bores slightly forward, towards the exhaust side which reduces piston-to-cylinder wall friction, resulting in more power and improved fuel economy.
  • Refined Fuel Injection
    From the open roads to the urban sprawl, the new electronic fuel injection settings deliver a smooth throttle response for enhanced riding enjoyment. The system delivers outstanding torque in the low- and mid-rpm range with exciting acceleration in the upper rpm range while the new fuel injection settings have been optimized to bring refinements to the engine’s linear response characteristics when the throttle is slightly open at low rpm.



CHASSIS/SUSPENSION

  • Assertive Riding Position
    To alleviate any sense of narrowness, the MT-07 features a new tapered handlebar that is 32mm wider and 19mm taller and offers improved feelings of control and comfort for a wider range of rider sizes.
  • Compact Frame Design
    The high-strength steel frame provides an optimized balance of rigidity for nimble, agile handling. As a stressed member of the chassis, the engine allows for a lighter, more compact main frame design, contributing to a low wet weight of only 406 lb.
  • Lightweight Wheels
    Lightweight 10-spoke cast aluminum wheels reduce unsprung weight for great handling and suspension performance. The Michelin Road 5 tires offer excellent grip and agility with 120/70ZR17 front and 180/55ZR17 rear sizes.
  • Stronger Stopping Power
    For excellent stopping power and greater control and feel while braking, the MT-07 features bigger 298mm front brake discs with four-piston calipers. Rear braking is handled by a 245mm disc, and ABS comes standard to boost rider confidence and prevent wheel lock-ups in reduced traction conditions.
  • KYB® Front Fork
    The MT-07’s front suspension features a 41mm KYB® fork with 5.1 inches of travel. With carefully selected spring rates and damping settings, the suspension has a refined feel and responsively performs across a wide range of riding styles.
  • Adjustable KYB® Rear Shock
    The MT-07 features a link-type KYB® rear shock adjustable for both rebound damping and spring preload. With 5.1 inches of rear travel, the shock is positioned below the seat with an almost horizontal alignment to help make the chassis even more compact.
  • Sporty Chassis Dimensions
    Working with the characteristics of the compact twin-cylinder engine, the wheelbase, seat height, fuel tank width, rake and other dimensions achieve a sporty, light and neutral handling character.

ADDITIONAL FEATURES

  • New LCD Meter
    The MT-07 features a new multifunction negative-display LCD dash with a black background and white readouts while RPMS of 10k – 12k are indicated with a red color. Designed specifically for the MT-07’s cockpit, the arrangement of the information features a larger display for the clock, current gear, trip/odometers and tachometer. Trip 1, Trip 2 and Trip F, the temperature and other meter functions can be toggled and reset with the left handlebar thumb switch while key displays like the gear indicator are on the right while the tachometer are positioned along the top.
  • Next-Generation Design
    Joining the 3rd generation MT style – as featured on the MT-09 – the MT-07’s new look further brings out its distinctive appeal with fashion-leading colors and graphics. The newly designed parts and components are integrated with minimal structural elements, creating an attractive design that emphasizes pure Hyper Naked character. With a silhouette that is synonymous with the MT Series’ signature statement of torque and power, the MT-07 showcases a tight, compact and powerful appearance.
  • LED Projector Lighting
    With new LED lighting for the position lights, headlight and both front and rear turn signals, the MT-07 exhibits clear and powerful illumination with a modern design.
  • Accessories
    Accessorize your new MT-07 with a front cowl, fly screen, fender eliminator and many more!









2022 Yamaha MT-07 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $7899 USD
Canada MSRP Price: $9399 CDN
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)

Engine Type 689cc liquid-cooled, DOHC, 4-stroke, 4-valves per
cylinder
Bore x Stroke 80.0mm x 68.6mm
Compression Ratio 11.5:1
Fuel Delivery Fuel injection
Transmission 6-speed; wet multiplate clutch
Final Drive Chain
Suspension / Front 41mm telescopic fork; 5.1-in travel
Suspension / Rear Single shock, adjustable preload and rebound
damping; 5.1-in travel
Brakes / Front Dual 298mm hydraulic disc; ABS
Brakes / Rear 245mm hydraulic disc; ABS
Tires / Front 120/70ZR17
Tires / Rear 180/55ZR17
L x W x H 82.1 in x 30.7 in x 43.5 in
Seat Height 31.7 in
Wheelbase 55.1 in
Rake (Caster Angle) 24° 50′
Trail 3.5 in
Maximum Ground
Clearance
5.5 in
Fuel Capacity 3.7 gal
Fuel Economy** 58 mpg
Wet Weight*** 406 lb
Warranty 1 Year (Limited Factory Warranty)
Color Cyan Storm; Team Yamaha Blue; Matte Raven
Black







2022 Yamaha MT-07 – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE
ENGINE Liquid-cooled, DOHC, 8-valves (4-valves/cylinder), inline twin cylinder
DISPLACEMENT 689cc
BORE AND STROKE 80 x 68.6 mm
COMPRESSION RATIO 11.5:1
MAXIMUM TORQUE 6.9 kg-m (50 ft-lbs.) @ 6,500 rpm
FUEL DELIVERY Mikuni 38 mm dual bore throttle body F.I.
ESTIMATED FUEL CONSUMPTION± 24.5 kpl / 69.2 mpg (Imp.)
LUBRICATION Wet sump
IGNITION / STARTING TCI / Electric
TRANSMISSION 6-speed
FINAL DRIVE “O”-ring chain

CHASSIS
SUSPENSION (FRONT) 41mm fork / 130mm (5.1″) wheel travel
SUSPENSION (REAR) Adjustable link Monocross / 130mm (5.1″) wheel travel
BRAKES (FRONT) Dual 282mm discs / 4-piston calipers / ABS equipped
BRAKES (REAR) 245mm disc / single piston caliper / ABS equipped
TIRES (FRONT) 120/70ZR17
TIRES (REAR) 180/55ZR17

CRITICAL DATA
LENGTH 2,085mm (82.1″)
WIDTH 745mm (29.3″)
HEIGHT 1,090mm (42.9″)
WHEELBASE 1,400mm (55.1″)
RAKE / TRAIL 24.5° / 90mm
GROUND CLEARANCE 140 mm (5.5″)
SEAT HEIGHT 805mm (31.7″)
FUEL CAPACITY 14 litres (3.1 imp. gallons)
WET WEIGHT 183 kg (403 lb.)









2022 Yamaha MT-07 – Totalmotorcycle.com European Specifications/Technical Details

Engine
Engine type 2-cylinder;4-stroke;Liquid-cooled;DOHC;4-valves
Displacement 689 cc
Bore x stroke 80.0 mm x 68.6 mm
Compression ratio 11.5 : 1
Maximum power 54.0 kW (73.4PS) @ 8,750 rpm
Limited power version 35.0kW
Maximum torque 67.0Nm (6.8kg-m) at 6,500 rpm
Lubrication system Wet sump
Clutch type Wet;Multiple Disc
Ignition system TCI
Starter system Electric
Transmission system Constant Mesh;6-speed
Final transmission Chain
Fuel consumption 4,2 l/100km
CO2 emission 98 g/km
Fuel system Fuel Injection
Chassis
Frame Diamond
Caster angle 24º50
Trail 90mm
Front suspension system Telescopic forks
Rear suspension system Swingarm;(Link type suspension)
Front travel 130 mm
Rear travel 130 mm
Front brake Hydraulic dual disc, Ø 298mm
Rear brake Hydraulic single disc, Ø245 mm
Front tyre 120/70 ZR 17M/C(58W) (Tubeless)
Rear tyre 180/55 ZR 17M/C(73W) (Tubeless)
Dimensions
Overall length 2,085 mm
Overall width 780 mm
Overall height 1,105 mm
Seat height 805 mm
Wheel base 1,400 mm
Minimum ground clearance 140 mm
Wet weight (including full oil and fuel tank) 184 kg
Fuel tank capacity 14L
Oil tank capacity 3.0L







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
