2022 Yamaha PW50: THE PERFECT FIRST STEP.
Introducing the new 2022 Yamaha PW50…
A fully automatic transmission and adjustable throttle control expands thrills along with skills. The world‑renowned PW50 ensures fun‑filled first ride experiences.
One of the industry’s best-selling mini-bikes, the affordable PW50 is a fantastic entry-level youth bike that’s helped young riders learn the ropes of motorcycling for decades.
2022 Yamaha PW50 Totalmotorcycle.com Key Features
- Fully Automatic Transmission
Fully automatic transmission means no shifting required. The PW50 is a twist-and-go package. - Entry-Level Two-Stroke Engine
Gutsy 49cc two-stroke is built to thrill without intimidating beginners. - Ultra-Low Seat Height
A seat only 18.7 inches high makes the PW50 the ideal choice for even the littlest riders in the group. - Adjustable Restrictor
An adjustable throttle stop screw keeps the adult in charge to gradually increase speed as skills improve. - Low Maintenance Requirements
Shaft final drive means no chain maintenance while Yamaha’s exclusive autolube oil injection system eliminates the need for fuel/oil premixing.
2022 Yamaha PW50 Totalmotorcycle.com Features and Benefits
ENGINE
- Entry-Level Two-Stroke Engine
49cc air-cooled, case-reed-inducted, two-stroke single is tuned to deliver predictable power that gently eases the new rider up the off-road learning curve. - Fully Automatic Transmission
Single-speed automatic transmission allows the rider to simply twist the throttle and go, allowing him/her to concentrate on the ride ahead. - Maintenance-Free Shaft Drive
The class-exclusive shaft drive system is virtually maintenance-free and comes fully enclosed for added durability. - Convenient Oil Injection System
Exclusive autolube oil injection system eliminates the need for fuel/oil premixing.
CHASSIS/SUSPENSION
- Ultra-Low Seat Height
Low 18.7-inch seat height allows most kids to put both feet down for added confidence. - Robust Front Suspension
A large 26mm telescopic front fork with 2.4 inches of travel smooths out the bumps for responsive handling. - Dual Shocks
Dual rear shocks with 2 inches of travel smooth the trail to deliver confidence-inspiring ride quality. - Maintenance-Free Mag Wheels
Mag-style wheels mean there’s no need to tighten or replace spokes. - Enclosed Drum Brakes
Front and rear drum brakes provide smooth, predictable stopping power. - Durable Knobby Tires
Durable 10-inch front and rear knobby tires provide excellent traction and superior wear. - Quiet, Compact Exhaust
A quiet exhaust pipe, complete with a removable baffle, is routed away from the rider. - Simplified Servicing
The rear fender, seat and side panel unit remove quickly for easy maintenance.
ADDITIONAL FEATURES
- Comfortable Saddle
A thick seat enhances rider comfort. - Racy Styling
Team Yamaha-inspired colors, graphics and front and side number plates create styling just like the bigger off-roaders. - Grippy Foot Pegs
Large, folding foot pegs with rubber grips provide excellent footing.
2022 Yamaha PW50 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $1699 USD
Canada MSRP Price: $1999 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Engine Type 49cc air-cooled 2-stroke; reed-valve induction
Bore x Stroke 40.0mm x 39.2mm
Compression Ratio 6.0:1
Fuel Delivery VM12 carburetor
Ignition CDI
Transmission Wet centrifugal automatic
Final Drive Shaft
Suspension / Front 26mm telescopic fork; 2.4-in travel
Suspension / Rear Unit swingarm; 2.0-in travel
Brakes / Front Drum
Brakes / Rear Drum
Tires / Front 2.50-10-4PR
Tires / Rear 2.50-10-4PR
L x W x H 49.0 in x 24.0 in x 27.8 in
Seat Height 18.7 in
Wheelbase 33.7 in
Rake (Caster Angle) 25.5°
Trail 2.0 in
Maximum Ground
Clearance
3.7 in
Fuel Capacity 0.5 gal
Wet Weight 90 lb
Color Team Yamaha Blue
*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
2022 Yamaha PW50 – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE
ENGINE 4-stroke, air-cooled, SOHC, 2-valve, single
DISPLACEMENT 110cc
BORE AND STROKE 51 x 54mm
COMPRESSION RATIO 9.3:1
MAXIMUM TORQUE 0.8 kg-m (5.8 ft-lb) @ 4,000 rpm
FUEL DELIVERY Mikuni VM16
LUBRICATION Wet sump
IGNITION / STARTING CDI / Electric & kick
TRANSMISSION Constant mesh, 4-speed
FINAL DRIVE Chain
CHASSIS
SUSPENSION (FRONT) 31 mm fork / 115mm (4.5″) wheel travel
SUSPENSION (REAR) Monocross, single shock / 110 mm (4.3″) wheel travel
BRAKES (FRONT) Drum
BRAKES (REAR) Drum
TIRES (FRONT) 2.50-14 4PR
TIRES (REAR) 3.00-12 4PR
CRITICAL DATA
LENGTH 1,565 mm (61.6″)
WIDTH 680 mm (26.8″)
HEIGHT 920 mm (36.2″)
WHEELBASE 1,080 mm (42.5″)
GROUND CLEARANCE 180 mm (7.1″)
SEAT HEIGHT 670 mm (26.4″)
FUEL CAPACITY 3.8 litres (0.8 imp. gallons)
WET WEIGHT 72 kg (159 lb)
COLOUR(S) Yamaha Racing Blue
2022 Yamaha PW50 – Totalmotorcycle.com European Specifications/Technical Details
NA
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
