2022 Yamaha TT-R110E: SMALL PACKAGE. BIG FUN.
Introducing the new 2022 Yamaha TT-R110E…
The bike that produces big fun for both young and older riders and everyone in between. The versatile TT‑R110E is a bike for the whole family.
Spark your kids’ 2-wheel passion with a TT-R110E! Learning is a snap with electric start, smooth power delivery and automatic clutch design for easy shifting.
2022 Yamaha TT-R110E Totalmotorcycle.com Key Features
- Electric Starter
Convenient push-button electric start feature for effortless engine startup with a backup kick starter. - Accessible Performance
Big fun for the whole family, the YZ-styled, four-stroke-powered TT-R110E begs to be ridden by everyone. - Low Seat Height
A seat height of only 26.4 inches makes the TT-R110E accessible to most riders, but the 7.1 inches of ground clearance and great suspension at both ends means it can go almost anywhere too. - Auto-Clutch Convenience
Four-speed auto-clutch transmission has an easily accessible gear for nearly any terrain.
2022 Yamaha TT-R110E Totalmotorcycle.com Features and Benefits
ENGINE
- Torque-Rich Engine
Powerful 110cc air-cooled SOHC four-stroke engine is tuned for off-road performance in a wide range of trail conditions. - Compact Cylinder Design
Compact hemispherical combustion chamber with 9.3:1 compression produces max torque at 4,000 rpm and max horsepower at 7,500 rpm. - Auto-Clutch Convenience
Four-speed gearbox with automatic clutch has the right gear for wherever you ride. - Electric Starter
Convenient push-button electric start feature for effortless engine startup with a backup kick starter. - Digital Ignition
CDI ignition system is ultra-reliable and never needs maintenance. - Low Maintenance Engine
Automatic cam chain tensioner means minimal maintenance and longer engine life. - Easy Serviceability
Easy-access, tool-free air filter adds extra convenience during maintenance. - Forest-Friendly Exhaust
Lightweight exhaust system features quiet, USFS-approved spark arrestor.
CHASSIS/SUSPENSION
- Robust, Compact Frame
Steel backbone frame ties steering head and swingarm pivot together via a straight line, with the engine mounted at three places for optimum strength and high ground clearance. - Well-Damped Front Fork
The 31mm fork with high-tech internals including a damper valve with oil lock provide excellent damping, great bottoming resistance and 4.5 inches of smooth travel. - Advanced Rear Suspension
Monocross® rear suspension and gusseted steel swingarm provide excellent rear wheel control through 4.3 inches of travel. - Stylish Aluminum Top Clamp
Die-cast aluminum top triple clamp provides light, precise handling and looks great too. - Trail-Ready Dimensions
The 26.4-inch seat height and 7.1 inches of ground clearance inspire confident performance on rugged trails. - Enclosed Drum Brakes
Front and rear drum brakes deliver strong, dependable stopping power. - Nimble Wheels and Tires
The 14-inch front and 12-inch rear wheels inspire great rider confidence by keeping the seat low and the steering light. - Durable Knobby Tires
Knobby tires offer superb grip and exceptional wear.
ADDITIONAL FEATURES
- Low Seat Height
The long, YZ-style gripper seat is low and comfortable and allows for easy rider movement. - Racing Style
Team Yamaha-inspired colors and graphics and front and side number plates create motocross styling similar to the competition YZ lineup. - Grippy Foot Pegs
Large folding, cleated foot pegs provide excellent footing, even in wet or muddy conditions. - Standard Security
Key-type ignition switch deters unauthorized riding.
2022 Yamaha TT-R110E – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $2299 USD
Canada MSRP Price: $2999 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Engine Type 110cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke 51.0mm x 54.0mm
Compression Ratio 9.3:1
Fuel Delivery Mikuni® VM16 carburetor
Ignition CDI
Transmission Constant-mesh 4-speed; multiple wet clutch
Final Drive Chain
Suspension / Front 31mm telescopic fork; 4.5-in travel
Suspension / Rear Monocross® shock; 4.3-in travel
Brakes / Front Drum, 95mm
Brakes / Rear Drum, 110mm
Tires / Front 2.50-14-4PR
Tires / Rear 3.00-12-4PR
L x W x H 61.6 in x 26.8 in x 36.2 in
Seat Height 26.4 in
Wheelbase 42.5 in
Rake (Caster Angle) 26.0°
Trail 2.4 in
Maximum Ground
Clearance
7.1 in
Fuel Capacity 1.0 gal
Fuel Economy n/a
Wet Weight 159 lb
Warranty 90 Day (Limited Factory Warranty)
Color Team Yamaha Blue
*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
2022 Yamaha TT-R110E – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE
ENGINE 4-stroke, air-cooled, SOHC, 2-valve, single
DISPLACEMENT 110cc
BORE AND STROKE 51 x 54mm
COMPRESSION RATIO 9.3:1
MAXIMUM TORQUE 0.8 kg-m (5.8 ft-lb) @ 4,000 rpm
FUEL DELIVERY Mikuni VM16
LUBRICATION Wet sump
IGNITION / STARTING CDI / Electric & kick
TRANSMISSION Constant mesh, 4-speed
FINAL DRIVE Chain
CHASSIS
SUSPENSION (FRONT) 31 mm fork / 115mm (4.5″) wheel travel
SUSPENSION (REAR) Monocross, single shock / 110 mm (4.3″) wheel travel
BRAKES (FRONT) Drum
BRAKES (REAR) Drum
TIRES (FRONT) 2.50-14 4PR
TIRES (REAR) 3.00-12 4PR
CRITICAL DATA
LENGTH 1,565 mm (61.6″)
WIDTH 680 mm (26.8″)
HEIGHT 920 mm (36.2″)
WHEELBASE 1,080 mm (42.5″)
GROUND CLEARANCE 180 mm (7.1″)
SEAT HEIGHT 670 mm (26.4″)
FUEL CAPACITY 3.8 litres (0.8 imp. gallons)
WET WEIGHT 72 kg (159 lb)
COLOUR(S) Yamaha Racing Blue
2022 Yamaha TT-R110E – Totalmotorcycle.com European Specifications/Technical Details
NA
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
