2022 Yamaha XSR700: BORN TOMORROW.

Introducing the new 2022 Yamaha XSR700…

Modern classic styling and crossplane concept twin for fun performance, all built to be uniquely customized.

Based on the popular MT-07, the XSR700 is a beautiful blend of twin cylinder performance and eye catching “authentic sports” styling. The XSR incorporates most of the MT-07’s key features including ABS equipped brakes. A natural riding position offers solid riding comfort while the short swingarm and lightweight design highlights the more serious sports side of the XSR. Tasty, timeless styling combined with plenty of Yamaha’s latest technologies, the XSR is guaranteed to provide a fun, exciting ride.

The XSR700 is a true legacy machine, earning it’s stripes on the road. The beating heart of the machine is the versatile character. The XSR700 is a bike to be ridden, anyway you like. From casual cruising to hitting the twisties, the bike can do it all.

Born to Challenge
An accessible motorcycle that is enjoyable for both new and experienced riders. The 2-part frame, tank construction and seat design are still a key factor in the XSR700, safeguarding the easy-to-customise feature the bike is renowned for.

The character of the XSR700 is defined by the sublime combination of a light and agile frame and the torque-rich, playful CP2 engine. The super nimble bike is easy to steer in any setting, from curves and twisty roads to busy city traffic, you’ll have a blast either way.

The XSR700 features its timeless design aspects like retro-in uenced bodywork, a stepped seat and a classically styled head-and-tail light. Respecting the bikes of the past, whilst embracing the contemporary by making use of all the modern technology likes ABS, LED lights, the most e cient CP2 engine to date and a modern inverted LCD meter.

As with its CP2-brothers the XSR700 is tted with the EU5 compliant characterful 689cc engine. Re ning the rideability of the XSR700 even more – but keeping every bit of fun with the multi-talented engine performance.

The livery of the XSR700 pays tribute to the past, the colour schemes were in uenced from iconic motorcycles of Yamaha’s rich history. The famous 2-
stroke RD350LC from the early eighties provides the inspiration for the modern interpretation of the colour schemes, resulting in the a crisp Historic White and a more elegant Historic Black combination.

The XSR700 is a true legacy machine, earning it’s stripes on the road. The beating heart of the machine is the versatile character. The XSR700 is a bike to be ridden, anyway you like. From casual cruising to hitting the twisties, the bike can do it all.

An accessible motorcycle that is enjoyable for both new and experienced riders. The 2-part frame, tank construction and seat design are still a key factor in the XSR700, safeguarding the easy-tocustomise feature the bike is renowned for.

The character of the XSR700 is de ned by the sublime combination of a light and agile frame and the torque-rich, playful CP2 engine. The super nimble bike is easy to steer in any setting, from curves and twisty roads to busy city tra c, you’ll have a blast either way.

With timeless style and modern, sporty performance, the 2022 XSR700 returns to Yamaha’s Sport Heritage lineup with a handful of key updates and a new classic, dark colorway. A favorite among riders seeking an exhilarating machine with a fashionable edge, the 2022 XSR700 matures without losing its versatile, fun-loving character.

Lighting is improved with an all-new heritage-inspired round LED headlight. New integrated headlight stays now connect into the fork shrouds for a more compact front expression.

The cockpit layout is revised with the inverted LCD meter repositioned for improved visibility and information is now controllable from the left handlebar switch. The lines and position are designed to match the all new head light, giving the bike a sleeker ‘snub-nose’ look. Switchgear is also upgraded, making them more user-friendly. The XSR700 also receives larger 298mm front brake discs and new radiator side covers.



2022 Yamaha XSR700 Totalmotorcycle.com Key Features

Standout Style
The XSR700 blends Yamaha’s world-class engineering with timeless style, creating a new type of machine for riders looking for an authentic and honest motorcycle that doesn’t sacrifice performance. Drawing influence from Yamaha’s classic “XS” series of motorcycles, the XSR oozes class with its exposed aluminum details, retro-influenced bodywork, stepped seat and custom lighting and instrumentation.

Updated LED Headlight
New for 2022, lighting is improved with an all-new heritage-inspired round LED headlight. New integrated headlight stays now connect into the fork shrouds for a more compact front expression and a sleeker ‘snub-nose’ look.

Revised Cockpit Layout
New for 2022, the cockpit layout is revised with the inverted LCD meter repositioned for improved visibility. Switchgear is also upgraded, making them more user-friendly and LCD meter information is now controllable from the left handlebar switch.

Advanced Crossplane Crankshaft Concept Engine
The compact two-cylinder engine provides a unique power character with its outstanding torque and throttle response and complemented with strong high-rpm pulling power. It also features Yamaha’s “Crossplane Concept” 270-degree crank that provides linear torque development in response to the rider’s throttle input.

Powerful Braking with ABS
The XSR700 provides exceptional and confident braking power thanks to its modern brake components which are backed up by the security of ABS. New for 2022, larger 298mm front disks further enhance performance.

Compact, Sporty Chassis
The narrow frame design features sport-oriented geometry to achieve light and nimble handling and is aided by the minimalist 410-pound wet weight and refined ergonomics.



  • XSR family LED lighting
  • 689 cc, DOHC, 4-valve / cylinder, liquid-cooled, inline-twin powerplant
  • Revised cockpit layout with integrated headlight stays
  • Evolved design details
  • Offset, ceramic composite plated cylinder with lightweight forged pistons
  • CP2 crankshaft design with high tech “fracture split” connecting rods
  • Compact 6 speed transmission with overdrive 6th gear
  • Tapered handlebar
  • Low 835 mm (32.9″) seat height
  • XSR family LED lighting
  • Revised cockpit layout with integrated headlight stays
  • Evolved design details
  • 689cc CP2 high-torque EU5 engine
  • Light and slim tubular backbone frame
  • Engineered for optimum riding enjoyment
  • Confidence inspiring riding experience
  • Colouring and graphics inspired by Yamaha’s past
  • Outstanding fuel efficiency



POWER

Liquid-cooled, 689cc in-line twin cylinder fuel-injected engine with a downdraft intake. The engine has been tuned to provide solid low to mid-range torque with linear throttle response.



STYLING

You won’t find a lot of plastic parts on the XSR700. The “authentic sports” styling highlights Yamaha’s long racing heritage, but don’t be fooled, there is plenty of cutting edge technology under the aluminum shrouded fuel tank.



INSTRUMENTATION

Multifunction, digital instrument displays all the info discerning sport riders demand. From a bar style tach to gear position indicator, to instant & average fuel economy, this classic round design liquid crystal instrument adds function and style.



2022 Yamaha XSR700 Totalmotorcycle.com Features and Benefits

ENGINE

  • Advanced Twin Cylinder Engine
    The XSR700 features a compact 689cc liquid-cooled, inline twin-cylinder, DOHC engine with fuel injection. This engine provides a unique power character with its outstanding low- to mid-range torque and very linear throttle response and complemented with strong high-rpm pulling power. This motor develops 50 foot-pounds of torque and is designed to maximize riding excitement in the real world.
  • Crossplane Crankshaft Concept
    The two-cylinder engine features Yamaha’s “Crossplane Concept” 270 degree crank that provides linear torque development in response to the rider’s throttle input. The CP2 engine is also light, slim and compact and offers an excellent level of rider-to-machine communication.
  • Offset Cylinder Block
    The paired cylinders of the XSR engine are shifted slightly forward compared to the center of the crankshaft. This reduces drag during each combustion stroke of the pistons and improves efficiency.
  • Vibration-Reducing Counterbalancer
    To reduce vibration and provide a smooth, modern engine character, the motor uses a geared counterbalancer that is mounted low and forward on the engine.
  • Refined, Efficient Fuel Injection
    Electronic fuel injection settings deliver a smooth throttle response to enhance riding enjoyment from the open roads to the urban sprawl. The system delivers outstanding torque in the low- and mid-rpm range along with exciting acceleration in the upper rpm range. Combined with the efficient overall engine design, the XSR700 delivers an exceptional 58 mpg.
  • Compact Six-Speed Transmission
    The XSR700’s six-speed transmission takes full advantage of the low-to- mid-range torque and excellent response of the twin-cylinder motor while further enhancing the compact engine design thanks to triangulated input and outputs shafts.



CHASSIS/SUSPENSION

  • Standout Style
    The XSR700 blends Yamaha’s world-class engineering with timeless style, creating a new type of machine for riders looking for an authentic and honest motorcycle that doesn’t sacrifice performance. Drawing influence from Yamaha’s classic “XS” series of motorcycles, the XSR oozes class with its exposed aluminum details, retro-influenced bodywork, stepped seat and custom lighting and instrumentation.
  • Compact, Sporty Chassis
    A lightweight diamond-type high tensile steel frame provides an optimized rigidity balance for light, agile handling and stability. The engine is a stressed member of the chassis which allows for a lighter, more compact main frame design.
  • Street-Focused Suspension
    The 41mm front fork and link-type Monocross rear shock each provide 5.1 inches of suspension travel and are tuned to provide a balance of comfort and control, making it ideal for the street. The shock uses an almost horizontal alignment which helps make the chassis much more compact while rear spring preload adjustment allows the rider to tailor the suspension to match rider weight or load.
  • Powerful Braking with ABS
    The XSR700 provides strong, controllable braking thanks to its modern braking components. New for 2022, the powerful four-piston calipers are now paired with larger 298mm front brake discs for enhanced performance. ABS comes standard to prevent wheel lock under hard deceleration.
  • Lightweight Wheels & Michelin Road 5 Tires
    Lightweight 10-spoke cast aluminum wheels are now fitted with Michelin Road 5 tires, 120/70ZR17 front and 180/55ZR17 rear, for confident handling and excellent grip in a variety of conditions.



ADDITIONAL FEATURES

  • Advanced Instrumentation
    The round LCD panel features a ton of information: digital tachometer, speedometer, gear position, eco mode indicator, ambient and coolant temperature, a fuel gauge and range of trip computer functions including a clock, instant and average fuel consumption, fuel reserve trip meter and the usual trip meters.
  • Updated LED Headlight
    New for 2022, lighting is improved with an all-new heritage-inspired round LED headlight. New integrated headlight stays now connect into the fork shrouds for a more compact front expression and a sleeker ‘snub-nose’ look.
  • Classically-styled Modern LED Lighting
    Up front, lighting is improved with an all-new heritage-inspired round LED headlight, providing both style and illumination in equal measure. A round all-LED tail and brake light is mounted above the rear fender and turn signals are also compact, stylish LEDs.
  • Stylish & Ergonomic Fuel Tank
    A compact 3.7 gallon fuel tank is shrouded by beautifully shaped, hand-finished aluminum side covers for a timeless design.
  • Casual but Sporty Ergonomics
    A tall, wide handlebar, stitched two-level seat and perfectly placed foot controls provide a comfortable upright riding position that is ideal for either urban traffic or hustling down a twisty road.
  • Unique XSR700 Detailing
    Every aspect of the XSR700 shows Yamaha’s attention to detail: the single-piece stitched saddle, the classic teardrop mirrors with excellent rearward visibility, the compact radiator which is flanked by exposed aluminum covers, a removable subframe that simplifies customization, and the naked aluminum accents and fender mount. The XSR700 demands a second look, every time.



NEW FOR 2022

  • Updated LED Headlight
    Lighting is improved with an all-new heritage-inspired round LED headlight. New integrated headlight stays now connect into the fork shrouds for a more compact front expression and a sleeker ‘snub-nose’ look.
  • Larger Front Brake Discs
    Front brake disc diameter has been increased from 282mm to 298mm for enhanced performance.
  • Revised Cockpit Layout
    Cockpit layout is revised with the inverted LCD meter repositioned for improved visibility. Switchgear is also upgraded, making them more user-friendly and LCD meter information is now controllable from the left handlebar switch.













2022 Yamaha XSR700 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8799 USD
Canada MSRP Price: $10399 CDN
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)

Engine Type 689cc liquid-cooled DOHC inline twin cylinder; 8
valves
Bore x Stroke 80.0mm x 68.6mm
Compression Ratio 11.5:1
Fuel Delivery Fuel injection
Ignition TCI: Transistor Controlled Ignition
Transmission Constant mesh 6-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front 41mm telescopic fork; 5.1-in travel
Suspension / Rear Single shock, adjustable preload; 5.1-in travel
Brakes / Front Dual hydraulic disc, 282mm; ABS
Brakes / Rear Hydraulic disc, 245mm; ABS
Tires / Front 120/70ZR17 Michelin® Road 5
Tires / Rear 180/55ZR17 Michelin® Road 5
L x W x H 81.7 in x 32.3 in x 44.5 in
Seat Height 32.9 in
Wheelbase 55.3 in
Rake (Caster Angle) 25.0°
Trail 3.5 in
Maximum Ground
Clearance
5.5 in
Fuel Capacity 3.7 gal
Fuel Economy** 58 mpg
Wet Weight*** 410 lb
Warranty 1 Year (Limited Factory Warranty)
Color Raven







2022 Yamaha XSR700 – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE
ENGINE Liquid-cooled, DOHC, 8-valves (4-valves/cylinder), inline twin cylinder
DISPLACEMENT 689cc
BORE AND STROKE 80 x 68.6 mm
COMPRESSION RATIO 11.5:1
MAXIMUM TORQUE 6.9 kg-m (50 ft-lbs.) @ 6,500 rpm
FUEL DELIVERY Mikuni 38 mm dual bore throttle body F.I.
ESTIMATED FUEL CONSUMPTION± 24.5 kpl / 69.2 mpg (Imp.)
LUBRICATION Wet sump
IGNITION / STARTING TCI / Electric
TRANSMISSION 6-speed
FINAL DRIVE “O”-ring chain

CHASSIS
SUSPENSION (FRONT) 41 mm fork / 130mm (5.1″) wheel travel
SUSPENSION (REAR) Adjustable link Monocross / 130 mm (5.1″) wheel travel
BRAKES (FRONT) Dual 282 mm discs / 4-piston calipers / ABS equipped
BRAKES (REAR) 245 mm disc / single piston caliper / ABS equipped
TIRES (FRONT) 120/70ZR17
TIRES (REAR) 180/55ZR17

CRITICAL DATA
LENGTH 2,075mm (81.7″)
WIDTH 820 mm (32.3″)
HEIGHT 1,130 mm (44.5″)
WHEELBASE 1,405 mm (55.3″)
RAKE / TRAIL 25° / 90 mm
GROUND CLEARANCE 140 mm (5.5″)
SEAT HEIGHT 835 mm (32.9″)
FUEL CAPACITY 14 litres (3.1 imp. gallons)
WET WEIGHT 186 kg (410 lb.)
COLOUR(S) Radical White







2022 Yamaha XSR700 – Totalmotorcycle.com European Specifications/Technical Details

Engine
Engine type CP2;Two cylinder;4-valves;4-stroke;Liquidcooled;DOHC
Displacement 689cc
Bore x stroke 80.0×68.6 mm
Compression ratio 11.5:1
Maximum power 54.0kW(73.4PS)/8750r/min
Maximum torque 67.0Nm (6.8kgm)/6500r/min
Lubrication system Wet sump
Clutch type Wet;Multiple Disc
Ignition system Electronic ignition (TCI)
Starter system TCI
Transmission system Constant Mesh;6-speed
Final transmission Chain
Fuel consumption 4.3 l/100 km
CO2 emission 100 g / km
Fuel system Fuel Injection
Chassis
Frame Diamond
Caster angle 24°30′
Trail 90 mm
Front suspension system Telescopic fork
Rear suspension system (link suspension);Swingarm
Front travel 130 mm
Rear travel 130 mm
Front brake 298 mm
Rear brake 245 mm
Front tyre 120/70 ZR 17M/C(58W) Tubeless
Rear tyre 180/55 ZR 17M/C(73W) Tubeless
Track n/a
Dimensions
Overall length 2,075 mm
Overall width 820 mm
Overall height 1,130 mm
Seat height 835 mm
Wheel base 1,405 mm
Minimum ground clearance 140 mm
Wet weight (including full oil and fuel tank) 188 kg
Fuel tank capacity 14 L
Oil tank capacity 3.00 L
