2022 Yamaha YZ250X: 2‑STROKES. 1 GOAL.
Introducing the new 2022 Yamaha YZ250X…
Engineered with all the reliability and durability you’ve come to expect from Yamaha, this 2‑stroke was born to win Cross Country races. The YPVS-equipped 249 cc two-stroke engine is combined with a wide-ratio five-speed transmission for the ultimate cross country powerplant.
2022 Yamaha YZ250X Totalmotorcycle.com Key Features
- Stunning Two-Stroke Power: Tuned for Cross Country & Hare Scrambles Racing
The YZ250X is optimized for the unique demands of Hare Scrambles and GNCC® racing. The YPVS™-equipped 249cc two-stroke engine is mated to a wide-ratio five-speed transmission for the ultimate cross country power plant. - Advanced Motocross-Derived Chassis
Ultra-lightweight YZ250-spec frame features carefully engineered combination of aluminum castings, forgings and extrusions for the perfect balance of rigidity and flex. The industry-leading fully adjustable KYB® speed sensitive spring-type front fork is matched with a fully adjustable high performance KYB® long-travel rear shock, both tested and tuned specifically for the needs of cross country racers. - GNCC®-Specific Features
Cross country focused suspension setup and Dunlop® Geomax AT81 tires, 18-inch rear wheel, wide ratio transmission, narrow expansion chamber, sealed O-ring chain, a standard side stand and fuel tank petcock with reserve position are perfect for GNCC® racing. - Racing Style and Ergonomics
The YZ250X carries the racing heritage of the YZ250 motocrosser with its aggressive styling from the front fender to the rear brake protector. Complete with an aluminum tapered handlebar, YZ-F-style foot pegs, gripper seat and Dunlop® Geomax AT81 tires, the YZ250X is competition-ready straight out of the crate. - 270mm Front Brake
Large 270mm front rotor coupled with high performance pad material offer excellent machine control and performance, with exceptional stopping power and controllability.
2022 Yamaha YZ250X Totalmotorcycle.com Features and Benefits
ENGINE
- GNCC®-Tuned YZ250 Power
Based on the legendary YZ250 249cc liquid-cooled reed-valve-inducted two-stroke engine, the YZ250X utilizes a revised compression ratio, exhaust port timing, revised Yamaha Power Valve System (YPVS™) timing and a model-specific CDI unit—all focused on creating a wide, controllable power character ideal for cross country racing. - Revised Power Valve
The YZ250X features the patented Yamaha Power Valve System—with broader opening timing compared to the YZ250 for smoother power—to combine bottom-end acceleration with strong mid-range and top-end. - Narrow Exhaust Pipe
Unique compact exhaust expansion chamber is designed especially for the YZ250X to improve both horizontal and vertical clearance on tight, technical trails while still providing excellent exhaust efficiency. - Advanced Carburetor
The 38mm Hitachi Astemo® Keihin PWK carburetor with throttle position sensor provides precise fuel/air mixing and crisp throttle response throughout the powerband. - Racing Intake System
Specially designed carbon fiber reed-valve petals improve throttle response and engine performance across the entire rpm range. - Wide-Ratio five-speed transmission
Smooth-shifting wide-ratio transmission ensures proper gearing from tight woods to wide-open fire roads. - YZ250 Cooling System
Large-capacity radiator features a ten-row core with four louvers for maximum cooling efficiency. - Digital Ignition
Digital CDI ignition system delivers precise spark for faster, stronger response anywhere in the powerband, specifically tuned for the needs of the YZ250X.
CHASSIS/SUSPENSION
- Industry-Leading KYB® Fork
The industry-leading, fully adjustable KYB® spring-type fork with speed-sensitive damping uses piston speed to control the damping force for super-precise handling and a smooth ride. With minimal wasted stroke or abrupt shocks for the rider, this bike is tuned for the demands of cross country racing. - Smooth KYB® Shock
Fully adjustable KYB® rear shock features 12.4 inches of travel, separate adjusters for high- and low-speed compression damping and a full lock oil rebound system for increased comfort, control and fantastic rear wheel traction in challenging conditions. - YZ250-Based Frame
A carefully engineered aluminum frame and swingarm give the YZ250X the famous handling proven by the championship-winning YZ motocross riders on tracks around the world. - Lightweight Subframe
Removable aluminum rear subframe is constructed of square-section tubing for reduced weight. - 270mm Front Brake
Large 270mm front rotor coupled with high performance pad material offer excellent machine control and performance, with exceptional stopping power and controllability. - Enduro-Specific Wheels and Tires
Cross country-spec Dunlop® Geomax AT81 tires are competition-ready, while the 18-inch rear tire has a taller sidewall to improve comfort and reduce pinch flats.
ADDITIONAL FEATURES
- Cross Country Ergonomics
A racy “gripper”-type seat and narrow fuel tank combined with a tapered aluminum handlebar and adjustable mounts create greater freedom of movement and more comfortable ergonomics for riders. - Cross Country Features
The YZ250X is focused on cross country competition with an 18-inch rear wheel, wide-ratio gearing, a standard side stand, sealed O-ring chain and a reserve fuel petcock.
- ”Re-tuned” engine Vs. YZ250 (head, ignition, porting & YPVS)
- Wider ratio transmission gears Vs. YZ250 (3rd gear & higher)
- Heavy duty clutch
- Expansion chamber shape
- Unique front & rear suspension settings
- 18″ rear wheel
2022 Yamaha YZ250X – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $7799 USD
Canada MSRP Price: $9199 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Engine Type 249cc liquid-cooled 2-stroke; reed-valve inducted
Bore x Stroke 66.4mm × 72.0mm
Compression Ratio 7.9~9.4:1
Fuel Delivery Hitachi Astemo® Keihin PWK38S
Transmission Constant-mesh 5-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front KYB® Speed-Sensitive System inverted fork;
fully adjustable, 11.8-in travel
Suspension / Rear KYB® single shock; fully adjustable, 12.4-in
travel
Brakes / Front Hydraulic disc, 270mm
Brakes / Rear Hydraulic disc, 245mm
Tires / Front 90/90-21 Dunlop® Geomax AT81F
Tires / Rear 110/100-18 Dunlop® Geomax AT81
L x W x H 86.0 in x 32.5 in x 50.8 in
Seat Height 38.2 in
Wheelbase 58.5 in
Rake (Caster Angle) 27.7°
Trail 4.8 in
Ground Clearance 14.2 in
Fuel Capacity 2.1 gal
Wet Weight 229 lb
Warranty 30 Day (Limited Factory Warranty)
Color Team Yamaha Blue
*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
2022 Yamaha YZ250X – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE
ENGINE 2-stroke, liquid-cooled, reed-valve, single
DISPLACEMENT 249 cc
BORE AND STROKE 66.4 x 72 mm
COMPRESSION RATIO 7.9 ~ 9.4:1
FUEL DELIVERY Keihin PWK38S
IGNITION / STARTING CDI / Kick
TRANSMISSION Constant mesh, 5-speed
FINAL DRIVE Chain
CHASSIS
SUSPENSION (FRONT) Fully adjustable 48 mm inverted fork / 300 mm (11.8″) travel
SUSPENSION (REAR) Fully adjustable link Monocross / 315 mm (12.4″) travel
BRAKES (FRONT) 270 mm floating disc / twin piston caliper
BRAKES (REAR) 245 mm disc / single piston caliper
TIRES (FRONT) 90/90-21
TIRES (REAR) 110/100-18
CRITICAL DATA
LENGTH 2,185 mm (86″)
WIDTH 825 mm (32.5″)
HEIGHT 1,290 mm (50.8″)
WHEELBASE 1,485 mm (58.5″)
GROUND CLEARANCE 360 mm (14.2″)
SEAT HEIGHT 970 mm (38.2″)
FUEL CAPACITY 8 litres (1.8 imp. gallons)
WET WEIGHT 104 kg (229 lbs)
COLOUR(S) Yamaha Racing Blue
2022 Yamaha YZ250X – Totalmotorcycle.com European Specifications/Technical Details
NA
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
