2023 BMW R nineT 100 Years: UNWAVERING BMW BOXER PASSION.
Introducing the 2023 BMW R nineT 100 Years…
The design of the R nineT is shaped by 100 years of motorcycle production and by BMW Motorrad’s unwavering passion for the boxer engine. The classic roadster design recipe begins with a compact tank and an upright seating position and extends to premium materials and stylish design elements. The new R nineT 100 Years becomes an exclusive anniversary edition thanks to numerous special features. The heart is still the air/oil-cooled, 1,170 cc, 109 hp two-cylinder boxer engine. In the anniversary edition, the legendary engine is accompanied by chrome and Option 719 parts, including paint-on-chrome surfaces and exquisitely milled parts and wheels.
Paint finishes in combination with chrome surfaces also have an almost 100-year tradition in motorcycle production. Chrome surfaces, usually consisting of a copper, nickel and final chrome layer are known for their hardness and resulting high durability, very good protection against corrosion, but above all by their radiant, mirror-like shine. This made chrome a common stylistic device for designers, from the late 1920s onwards. The BMW R 75/5 with its chrome-plated tank sides and side covers, for example, is legendary within BMW Motorrad enthusiast circles. With the new BMW R nineT 100 Years and
R 18 100 Years and the Classic Chrome surface finish, BMW Motorrad is reviving this incomparably beautiful and sophisticated interplay of paint and chrome.
50 years ago, the “paint on chrome” technology did not pose much of a problem for motorcycle manufacturers. At that time, the solvent-based paints combined well with chromium — significantly better than the solvent-free paints of today. Today, the 100 Year Edition models use only REACH compliant Chromium III. The chrome plating process and the preparatory work are extremely complex: In preparation, the metal tank for example, is first polished to a high gloss. The surface must be completely free of dust and scratches for further treatment. After this step, the part is immersed in various electroplating baths. Layers of copper, nickel and ultimately chromium are applied. The finished chrome-plated part is then painted in several layers; a final coat of clear coat covers the entire tank.
The metal tanks on both anniversary models feature this paint on chrome process, called Classic Chrome. On the R nineT, the tank finish combines black paint with chrome and white double-pinstriping, knee pads and a 100 Years badge. Classic Chrome is also found on the seat’s rear cover. The front wheel fender is painted in black and features white double-pinstriping. A two-tone seat in black/oxblood red rounds off the design.
Numerous black components such as fork tubes, air intake snorkels and some Option 719 components complement the look. The R nineT 100 Years includes Option 719 Classic wheels with black anodized rims, the Option 719 Billet Pack Shadow with milled cylinder head covers, front engine cover, seat holders, oil filler plug and the Option 719 Billet Pack Shadow II, consisting of adjustable hand levers and foot pegs, passenger foot pegs as well as expansion tank covers and handlebar end mirrors. The 100 Years Edition also includes an adaptive turning headlight, heated grips, cruise control and Riding Modes Pro. An anti-theft alarm system can be fitted as a dealer installed accessory.
The classic from the Heritage family has, in addition to its iconic air/oil-cooled boxer engine, numerous highlights like the adjustable suspension strut, the analog dual round instruments, and the “Rain” and “Road” riding modes. Find out all about the technical data and extensive standard and special equipment here.
2023 BMW R nineT 100 Years Totalmotorcycle.com Key Features
The 2023 BMW R nineT 100 Years and R 18 100 Years Editions.
BMW Motorrad USA proudly presents the 2023 BMW R 18 100 Years Edition and the BMW R nineT 100 Years Edition to commemorate 100 Years of BMW Motorrad. In keeping with the year in which BMW Motorrad was founded, each model will be limited to 1,923 units globally.
In December 1922, BMW chief designer Max Friz put the first full-scale BMW motorcycle on the drawing board. At its heart was a 494 cc, 8.5 hp, air-cooled two-cylinder, four-stroke boxer engine. The first BMW motorcycle, the R 32, was unveiled in September 1923 at the German Motor Show in Berlin. Production began that same month in an area of the BMW engine works on the edge of the Munich’s Oberwiesenfeld airfield. Just 56 motorcycles were built that first year. Those humble beginnings of BMW motorcycle production launched an unprecedented success story that would span a century.
Standard Equipment
BMW R nineT 100 Years Edition
- 1,170 cc air/oil-cooled two-cylinder, four-stroke boxer engine.
- 109 hp @ 7,250 rpm and 85.5 lb-ft torque @ 6,000 rpm.
- Constant mesh six-speed transmission with shaft drive.
- ASC Automatic Stability Control.
- BMW Motorrad ABS Pro
- DBC Dynamic Brake Control
- DTC Dynamic Traction Control
- MSR Dynamic Engine Brake Control
- Full LED lighting with Adaptive turning headlight.
- Heated Grips
- Ride Modes Pro (adds DYNAMIC mode to existing ROAD and RAIN modes)
- USB port.
Special Edition Features
- Avus Black paint and Classic Chrome highlights.
- 100 Years “1 of 1923” BMW Motorrad tank badge.
- Classic Chrome / Avus Black 4.5-gallon fuel tank with white double-pinstriping.
- Avus Black front fender with white double-pinstriping.
- Black inverted 45 mm front fork, black frame, and air intake runners.
- Black / oxblood red seat with solo seat back rest.
- Classic Chrome / Avus Black rear seat cover with white double-pinstriping.
- Option 719 Classic spoked wheels with black anodized rims.
- Chrome plated exhaust manifold.
- Option 719 Billet Pack Shadow
- Milled aluminum front engine cover, cylinder head covers, seat brackets, and oil filler plug.
- Option 719 Billet Pack Shadow II
- Milled aluminum adjustable hand control levers and foot controls, foot pegs, expansion tank covers and bar end mirrors.
Optional Equipment
BMW R nineT 100 Years Edition
- Anti-Theft Alarm – Dealer installed accessory.
100 YEARS OF “MAKE LIFE A RIDE” YOUR STORY MAKES OURS COMPLETE
BMW Motorrad’s history is characterised by an urge to succeed. Succeed in challenges and celebrate success. However, there have also been setbacks and it’s taken quite some perseverance. Giving up was never an option. The company’s history is mainly about people sharing a passion: adventurers, dreamers, inventors, athletes, visionaries – men and women aiming to revolutionise the streets with great ideas on two wheels. 100 years of the “Make Life a Ride” spirit. In this spirit, we take the time to simultaneously look at our past and our future: at events and highlights in the anniversary year 2023. And lots of ideas are still to come.
One history, countless stories
The people substantially shaping the history of BMW motorcycles go beyond the norm. It all began with Chief Designer Max Friz, who designed the first BMW motorcycle that was showcased at the German Motor Show on 28 September 1923. He was followed by designers, racers and pioneers who also challenged the status quo. In 1924, Rudolf Schleicher played a leading role in the development of the BMW R 37’s engine, the first BMW Motorrad sports model. In 1937, Ernst Jakob Henne broke the land speed record on a BMW 500 Kompressor fitted with full trim panel, reaching 279.503 km/h. In 1939, Georg “Schorsch” Meier won the Senior TT on the Isle of Man as the first non-British person on a BMW Kompressor. Even today, people at BMW Motorrad are still thinking ahead, developing new vehicle concepts based on new drives, for example.
Two models aimed at aficionados on occasion of the anniversary
In 2023, we will be celebrating our history with two edition models: the BMW R 18 100 Years and the BMW R nineT 100 Years. With its chrome-plated tank and paint-on-chrome technology, the R nineT is reminiscent of the 1969 R 75/5. With its drop-shaped tank, the R 18 reflects the design of the 1936 R 5. These two models aimed at real enthusiasts are each limited to 1,923 units.
2023 BMW R nineT 100 Years Totalmotorcycle.com Features and Benefits
BMW R NINET 100 YEARS OUR LIMITED EDITION MODEL FOR THE 100TH ANNIVERSARY
One hundred years ago, the R 32 kick-started a unique success story. Today we are celebrating our eventful history with a new icon: the BMW R nineT 100 Years.
Limited to 1,923 units, it is a model for absolute aficionados that conveys a feeling of nostalgia. Equipped with a large number of exclusive Option 719 milled parts and, of course, the unmistakable boxer engine, it represents #SoulFuel in its most exclusive form. The Black Storm Metallic paint on the chrome-plated tank is a vital, special feature of the edition. This traditional paint-on-chrome method is a tribute to the 1969 R 75/5.
” 100 YEARS OF PURE PASSION ”
One of 1,923
The glamour of ten decades can be this timeless and modern. This motorcycle was, is and remains a design icon. A statement. This limited edition will become a collectors’ item for aficionados thanks to its attention to historic details. It’s striking, it stands out. Included, black Option 719 milled parts lend it a dominant, high-quality look. A true masterpiece. The 100 Years badge makes it official: “1 of 1923” says it all. This means that it’s not a bike for everyone, it’s one for genuine aficionados.
Exclusive and striking
Elegant appearance: the 100 Years model comes with high-quality Option 719 Shadow and Shadow II Billet packs. These include, for example, handlebar end mirrors, footrest systems and many other parts. There are other useful features such as adaptive headlights.
Classic chrome
The Classic chrome paint sets exciting highlights. The paint-on-chrome method ensures a high-quality look. The white lines underscore its historic origin.
More exclusive than ever
As the model that established the Heritage world, the R nineT always carries a piece of BMW’s past with it while invariably remaining contemporary. The BMW R nineT 100 Years sets the scene for the iconic components even more strikingly. Option 719 Shadow and Shadow II parts lend it a distinctive, very exclusive look. The many black highlights create an exciting contrast to the Oxblood single rider seat and the Option 719 Classic wheel rounds off this exclusive look.
2023 BMW R nineT 100 Years – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: from $19,995 USD
Canada MSRP Price: from $23,830 CDN
Europe/UK MSRP Price: from £ See Dealer GBP (total selling price)
Engine
Type
Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially-arranged valves per cylinder as well as central counterbalance shaft
Bore x stroke
4.0” x 2.9”
Capacity
1,170 cc
Rated output
109 hp at 7,250 rpm
Max. torque
85.5 lbs-ft. at 6,000 rpm
Compression ratio
12.0 : 1
Mixture control
Electronic port fuel injection
Emission Control
Closed-loop 3-way catalytic converter
Performance / fuel consumption
Maximum speed
over 124 mph
Fuel type
Unleaded super(premium)
Electrical system
Alternator
Three-phase alternator with 720 Watt nominal power
Battery
12 V / 12 Ah
Power transmission
Clutch
Single dry plate clutch, hydraulically operated
Gearbox
Claw-shifted six-speed transmission with helical-cut splines
Drive
Shaft drive
Chassis / brakes
Frame
Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame removeable for one-up riding
Front wheel location / suspension
Upside-down telescopic forks, 46 mm fixed-fork-tube diameter
Rear wheel location / suspension
Cast aluminum single swing arm with BMW Motorrad Paralever; central spring strut, spring preload fully adjustable by handwheel, adjustable rebound-stage damping
Suspension travel, front / rear
4.7″ / 4.7″
Wheelbase
58.5”
Caster
4.3″
Steering head angle
63.2°
Wheels
Spoke wheels
Rim, front
3.50 x 17″
Rim, rear
5.50 x 17″
Tire, front
120/70 ZR 17
Tire, rear
180/55 ZR 17
Brake, front
Twin-disc brakes, diameter 12.6″, 4-piston calipers
Brake, rear
Single disc brake, diameter 10.4″, double-piston floating caliper
ABS
BMW Motorrad ABS Pro
Dimensions / weights
Seat height
31.7”
Inner leg curve
70.3”
Usable tank volume
4.5 gal.
Reserve
app. 0.8 gal.
Length
82.9”
Height (incl. mirrors)
48.8”
Width (incl. hand levers)
34.8”
Unladen weight, road ready, fully fueled
487 lbs.
1)
Permitted total weight
948 lbs.
Payload (with standard equipment)
460 lbs.
1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable tank capacity.
2023 BMW R nineT 100 Years – Totalmotorcycle.com Canada Specifications/Technical Details
Engine
Type
Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft
Bore x stroke
101 mm x 73 mm
Capacity
1,170 cc
Rated output
80 kW (109 hp) at 7,250 rpm
Max. torque
116 Nm at 6,000 rpm
Compression ratio
12.0 : 1
Mixture control
Electronic intake pipe injection
Emission Control
Closed-loop 3-way catalytic converter, emission standard EU-5
Performance / fuel consumption
Maximum speed
over 200 km/h
Fuel consumption per 100 km based on WMTC
5.1 l
CO2 emission based on WMTC
119 g/km
Fuel type
Unleaded super(premium), octane number 95-98 (RON) (rated output at 98 RON)
Electrical system
Alternator
Three-phase alternator with 720 Watt nominal power
Battery
12 V / 12 Ah, maintenance-free
Power transmission
Clutch
Single dry plate clutch, hydraulically operated
Gearbox
Claw-shifted six-speed transmission with helical-cut splines
Drive
Shaft drive
Chassis / brakes
Frame
Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame removeable for one-up riding
Front wheel location / suspension
Upside-down telescopic forks, 46 mm fixed-fork-tube diameter
Rear wheel location / suspension
Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut, spring preload fully adjustable by handwheel, adjustable rebound-stage damping
Suspension travel, front / rear
120 mm / 120 mm
Wheelbase
1,487 mm
Castor
107.9 mm
Steering head angle
63.2°
Wheels
Spoke wheels
Rim, front
3.50 x 17″
Rim, rear
5.50 x 17″
Tire, front
120/70 ZR 17
Tire, rear
180/55 ZR 17
Brake, front
Twin-disc brakes, diameter 320 mm, 4-piston calipers
Brake, rear
Single disc brake, diameter 265 mm, double-piston floating caliper
ABS
BMW Motorrad ABS Pro
Dimensions / weights
Seat height
805 mm
Inner leg curve
1,785 mm
Usable tank volume
18 l
Reserve
app. 3 l
Length
2,105 mm
Height (incl. mirrors)
1,240 mm
Width (incl. hand levers)
865 mm
Unladen weight, road ready, fully fuelled 1)
221 kg
1)
Permitted total weight
430 kg
Payload (with standard equipment)
209 kg
1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refueled with min. 90% of the usable tank capacity.
2023 BMW R nineT 100 Years – Totalmotorcycle.com European Specifications/Technical Details
Engine
Type
Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft
Bore x stroke
101 mm x 73 mm
Capacity
1,170 cc
Ratet output
80 kW (109 hp) at 7,250 rpm
Max. torque
116 Nm at 6,000 rpm
Compression ratio
12.0 : 1
Mixture control
Electronic intake pipe injection
Emission Control
Closed-loop 3-way catalytic converter, emission standard EU-5
Performance / fuel consumption
Maximum speed
over 200 km/h
Fuel consumption per 100 km based on WMTC
5.1 l
CO2 emission based on WMTC
119 g/km
Fuel type
Unleaded super(premium), octane number 95-98 (RON) (rated output at 98 RON)
Electrical system
Alternator
Three-phase alternator with 720 Watt nominal power
Battery
12 V / 12 Ah, maintenance-free
Power transmission
Clutch
Single dry plate clutch, hydraulically operated
Gearbox
Claw-shifted six-speed transmission with helical-cut splines
Drive
Shaft drive
Chassis / brakes
Frame
Four-part frame concept with front frame and three-part rear frame, load-bearing engine-gearbox unit, rear-seat frame removeable for one-up riding
Front wheel location / suspension
Upside-down telescopic forks, 46 mm fixed-fork-tube diameter
Rear wheel location / suspension
Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut, spring preload fully adjustable by handwheel, adjustable rebound-stage damping
Suspension travel, front / rear
120 mm / 120 mm
Wheelbase
1,487 mm
Castor
107.9 mm
Steering head angle
63.2°
Wheels
Spoke wheels
Rim, front
3.50 x 17″
Rim, rear
5.50 x 17″
Tyre, front
120/70 ZR 17
Tyre, rear
180/55 ZR 17
Brake, front
Twin-disc brakes, diameter 320 mm, 4-piston callipers
Brake, rear
Single disc brake, diameter 265 mm, double-piston floating calliper
ABS
BMW Motorrad ABS Pro
Dimensions / weights
Seat height
805 mm
Inner leg curve
1,785 mm
Usable tank volume
18 l
Reserve
app. 3 l
Length
2,105 mm
Height (incl. mirrors)
1,240 mm
Width (incl. hand levers)
865 mm
Unladen weight, road ready, fully fuelled 1)
221 kg
1)
Permitted total weight
430 kg
Payload (with standard equipment)
209 kg
1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable tank capacity.
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
