Low on weight and high on innovation, the TE 150 from Husqvarna Motorcycles combines high quality components, 2-stroke simplicity, and the latest technical innovations. The result is an exceptional enduro machine capable of mastering the toughest terrain. Incredibly agile thanks to its expertly crafted frame and advanced WP suspension, the TE 150 makes riders from beginner through to professional feel in total control and able to ride freely and to the very best of their ability. Highlighting Husqvarna Motorcycles’ continued development of the enduro range, the Swedish-inspired dark blue and electric yellow graphics, together with a metallic blue frame, create a distinctive look.
All-new colours, trim and distinctive dark blue graphics with electric yellow accents contribute to a unique look and stylishly adorn the Swedish inspired design, and complement the new metallic blue of the frame
A two-piece carbon fibre composite subframe weighs just over 1 kg and is a major contributor to outstanding handling and rider comfort
WP XPLOR front forks and WP XACT monoshock for consistent damping and exceptional handling
Two switchable Electronic Fuel Injection (EFI) maps on 4-stroke models plus traction control. Two selectable ignition curves and automatic fuelling adjustment on 2-strokes
Advanced linkage progression, shared with the Husqvarna motocross range, for optimum control and comfort
Pankl Racing Systems 6-speed gearbox with enduro specific ratios for perfect command in all conditions
Unparalleled attention to detail and high-quality components for a pure riding experience
The enduro range is fitted with class-leading Michelin Enduro tyres for superior traction; tyres that are race-proven by the Husqvarna Factory Racing team
HUSQVARNA MOTORCYCLES 2023 ENDURO RANGE IS UP TO ANY OFFROAD CHALLENGE – ENDURO RIDERS AT EVERY LEVEL CAN ACHIEVE THEIR BEST-EVER RESULTS WITH CLASS-LEADING AND INNOVATIVE RACE-DEVELOPED MACHINERY
Husqvarna Motorcycles is pleased to announce its 2023 TE and FE enduro line-up, a range of seven 2-stroke and 4-stroke machines which will take enduro riders of all levels of experience and skill to their best possible results. Dynamic performance and advanced ergonomics combine in the 2023 enduro range to deliver unrivalled power and handling to the competitive enduro rider.
Riders of every level will find a machine in a line-up unequalled in its sector for technical advancement, and race-winning reliability and durability. The model range consists of the TE 150, TE 250 and TE 300 2-strokes and the FE 250, FE 350, FE 450 and FE 501 4-strokes.
A distinctive bodywork demonstrates Husqvarna Motorcycles’ progressive approach to Swedish-inspired offroad motorcycle design. Dark blue graphics with electric yellow accents use the familiar colours in all-new combinations for 2023.
The ergonomics of the bodywork are specifically tailored to deliver comfort and control, with narrow contact points making it easy to shift between riding positions. Unique to Husqvarna Motorcycles, a carbon composite subframe weighs just over 1 kg and has been engineered for specific rigidity using computational dynamics, and also contributes to outstanding handling and rider comfort.
Offering unsurpassed damping capability and comfort, compliant WP suspension makes light of the severest bumps, giving all TE and FE models optimal handling and control. The XPLOR 48 mm front fork has a split damping function and easy access preload adjusters. At the rear, a progressive linkage, 300 mm of travel and pressure balance in the shock absorb every surface change.
Predictable control makes for confident riders, able to take on any terrain. BRAKTEC hydraulic braking and clutch systems are used across the enduro range for their consistent operation, no matter how tough the going gets. The clutch delivers even wear and reliable, modulated operation and the braking system is tailored for enduro riding, with abundant stopping power and precise feedback.
In winning yet another FIM SuperEnduro World Championship title, Billy Bolt has again demonstrated the relentlessly effective technical package of his FE 350. A victory which furthers the reputation of Husqvarna Motorcycles, and once more confirms the whole enduro line-up as a competition benchmark.
The TE 150 has inherited the same fuel-injected technology from the bigger TE 250 and 300. This adds the convenience of a 4-stroke engine by eliminating the need to premix fuel or adjust jetting for altitude. The engine also uses specific shaft arrangements, which are designed to harness the rotating mass of the engine for nimble handling. This, among other developments, makes it a lightweight and compact engine providing usable enduro-specific power while maintaining the low-cost maintenance of a 2-stroke.
Cylinder and Piston
The TE 150 features a cylinder with a 58 mm bore and an innovative power valve design. This allows the lively 150 cc engine to deliver controllable power throughout the RPM range. The piston is designed to perfectly match the contour of the combustion chamber, delivering the highest level of 2-stroke performance. Additionally, the cylinder features injectors mounted at the inlet positions, which deliver the fuel downwards into the transfer port, guaranteeing excellent fuel atomization. This ensures more efficient fuel combustion, reduced fuel consumption and improved emissions.
Designed for minimal weight, the crankcases on the TE 150 engine feature a thin-wall design. To centralize mass, the shaft arrangements are precisely positioned to harness rotating masses at the ideal center of gravity, while improved sealing is taken care of by the reed block which features optimized carbon fiber reed petals.
Tailored specifically for each model using an innovative 3D design process, the header pipe on the TE 150 offers an advanced geometry and performance. This allows for improved ground clearance, making the header pipe resistant to impact out on the trail. The muffler also features an aluminium mounting bracket and advanced internal construction for excellent noise damping and weight saving.
The chromium molybdenum steel frame is expertly crafted using laser-cut, robot-welded, hydro-formed tubes, ensuring the highest level of precision and quality. The specifically crafted geometry utilises advanced longitudinal and torsional flex characteristics, for unparalleled rider feedback, energy absorption and exceptional straight-line stability. The cylinder head mountings are made of forged aluminium, improving handling and comfort. The premium grey powder coated frame features standard frame protectors, providing extra durability.
Composite carbon fibre subframe
The carbon composite subframe is unique to Husqvarna Motorcycles and showcases advanced production technology and innovation. Using 70% polyamide and 30% carbon fibre, the 2-piece subframe has a total weight of just over 2.2 lb. With the help of computational dynamics, specific rigidity was engineered into the light and robust subframe, delivering outstanding handling and rider comfort.
OIL TANK AND PUMP
An electronic oil pump feeds vital 2-stroke oil into the engine. It is located just below the oil tank and feeds the oil via the throttle body, meaning the oil is only mixed with air at this stage. The pump is controlled by the EMS and delivers the optimal amount of oil according to the current RPM and engine load. The oil tank is connected to a filler hose which runs through the upper tube of the frame to a filler cap conveniently located for easy refills. The tank capacity is 0.7 l and is connected to a low-level sensor which illuminates when the tank needs refilling.
INTEGRATED COOLING AND RADIATORS
The radiators are expertly crafted using high-strength aluminium with CFD (computational fluid dynamics) to channel air through the radiators more efficiently. The cooling system is intelligently integrated into the frame, eliminating the need for additional hoses. The large centre tube running through the frame reduces pressure at this point, allowing for a consistent coolant flow. Additionally, the radiators are mounted close to the centre of gravity for improved handling agility. An optional radiator fan can be fitted and is available in the Husqvarna accessories catalogue.
WP XPLOR FRONT FORK
The WP XPLOR 48 front fork is designed specifically for off-road riding. Its open cartridge layout has a spring in each leg with split damping functions. Compression damping is in the left leg and rebound damping is in the right. Adjustment is via easy-to-access clickers (30 clicks) on the top of each fork leg. The standard preload adjusters allow for easier adjustment without the use of tools. The fork’s mid-valve piston delivers consistent damping, while the setting allows the fork to operate higher in the stroke for exceptional rider feedback and bottoming resistance.
WP XACT REAR SHOCK
The WP XACT shock provides advanced damping characteristics to the range. New valve seals with reduced hardness offer improved shock feedback. The compact and lightweight shock features a pressure balance inside, ensuring consistent damping and superior rider comfort. Using the same linkage progression found in the Husqvarna Motocross range, the rear end sits low for improved control in extreme enduro conditions. The fully adjustable component delivers 300 mm rear wheel travel, as well as unrivalled traction, feeling and energy absorption.
The highest level of quality is guaranteed with the new BRAKTEC braking system, offering the highest level of braking performance while being specifically tailored for enduro riding and delivering a sensitive and modulated feel. GSK wave disks (260 mm disc front and 220 mm rear) complete the high-quality braking package for complete confidence.
The new high quality BRAKTEC clutch system guarantees even wear, reliable and near maintenance-free operation as well as perfect modulation in every condition. Meaning that play is constantly compensated so that the pressure point and function of the clutch remain identical in cold or hot conditions, as well as over time.
The TE 150 features a bodywork which clearly showcases Husqvarna Motorcycles’ progressive approach to offroad motorcycles while the Swedish inspired dark blue and electric yellow graphics create a distinctive look. The ergonomics are specifically tailored to deliver great comfort and control. As a result of extensive testing, the slim contact points make shifting between riding positions easier and allow the rider to flow with movement. The flat seat profile, together with the seat cover texture, deliver superior comfort and control in all conditions.
Wheels and tyres
Black high-strength alloy rims by D.I.D are coupled to CNC machined hubs using lightweight spokes and silver anodised aluminium nipples. Fitted to the wheels are Dunlop tires which offer superior grip on a wide variety of terrain. New for 2023, a Dunlop MX33 is mounted on the front and is paired with a Dunlop AT81 on the rear.
CNC machined triple clamp
The 22 mm offset black-anodized CNC machined triple clamps offer premium quality and style standard on all Husqvarna enduro models. The triple clamps have been expertly crafted using superior techniques and materials to provide high levels of quality and reliability. A 2-way handlebar adjustment is standard and allows for customisable ergonomics.
By using the MAP SELECT SWITCH, the engine characteristics can be tailored to modify the power delivery according to rider preference, conditions and terrain. It has two settings which can be toggled on the fly, namely, Map 1, for standard and full power, and Map 2, for softer power and delayed ignition timing for terrain with less traction.
The TE 150 uses a 39 mm throttle body which regulates the amount of air entering the engine via a butterfly operated by dual throttle cables connected to a handlebar throttle assembly. 2-stroke oil is mixed with the air and enters the engine to lubricate the crankshaft, cylinder and piston. Additionally, a throttle position sensor (TPS) relays airflow data to the ECU which in turn calculates the amount of oil and fuel delivered to the engine while a bypass screw regulates the idling speed and a cold start device opens a bypass providing more air for cold starts.
ELECTRIC START AND WIRING HARNESS
All TE models come standard with an electric starter. The system uses a compact and lightweight Li-Ion battery which is 2.2 lb lighter than a conventional battery. With several years of experience of developing and perfecting electric starting, the proven reliability on the Husqvarna enduro range is second to none, ensuring a quick and seamless start in any condition. Additionally, the wiring harness concentrates all needed electrical components into a common area below the seat for easy accessibility.
ENGINE MANAGEMENT SYSTEM
The TE 150 features an electronic control unit (ECU) which is responsible for a number of functions. The unit determines the ignition timing, the amount of fuel and oil injected into the cylinder and additionally, translates the information received from various sensors to adapt values and make corrections for automatic temperature and altitude compensation. This means the engine always runs at the optimum fuel/air mixture at any altitude.
2023 Husqvarna TE150 – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: $ 9899 USD
Canada MSRP Price: $10949 CDN
Europe/UK MSRP Price: £9049 GBP (On The Road inc 20% Vat)
