2023 Kawasaki KLX230: TORQUEY AND NIMBLE.
Introducing the 2023 Kawasaki KLX230…
Take the playing field by storm with nimble dual-sport performance that’s ready to conquer both on- and off-road. This agile bike features a quick-revving 233cc engine, lightweight chassis, and long-travel suspension. Styling updates include a new front fender and LED headlight. Fuel injection provides easy starting and crisp throttle response in a wide range of elevations and temperatures. The result is a consistent ride on paved streets, dirt trails, and beyond.
The Kawasaki KLX230 is a lightweight dual sport motorcycles with multiple options for on and off-road fun. Both are purpose-built for trail riding with a torquey engine, nimble chassis and off-road suspension. A more aggressive appearance comes from a new compact LED
headlight and cowl, and front fender. The KLX230 enables riders to ride out of town and enjoy the trails with confidence and ease.
2023 Kawasaki KLX230 KRT Totalmotorcycle.com Key Features
- 233cc FUEL-INJECTED, AIR-COOLED, FOUR-STROKE ENGINE WITH ELECTRIC START
- DUAL-SPORT CAPABILITY
- LIGHTWEIGHT PERIMETER FRAME AND LONG-TRAVEL SUSPENSION
- NEW LED headlight and front fender
- KX Inspired styling and ergonomics
- Full-sized wheels
2023 Kawasaki KLX230 KRT Totalmotorcycle.com Features and Benefits
NEW FOR 2023
• New compact LED headlight and shroud is the centerpiece of the KLX230’s more aggressive appearance. Since the LED headlight is shorter from front to back it gives the front end a much sleeker look.
• Revised front fender contributes to the more aggressive appearance.
• Revised ECU settings provide a lower fast-idle speed for reduced engine noise during warm-up, revised atmospheric correction helps improve power delivery when riding at high altitude, and revised injection mapping helps improve throttle response in cold temperatures.
• Long-stroke engine provides ample low-mid range torque for easy low-speed control and a strong pull at smaller throttle openings.
• Simple air-cooled SOHC design helps ease maintenance.
• Digital Fuel Injection (DFI)(KP) helps deliver smooth, precise throttle response for increased engine control on the trail. Fuel injection also provides stable fuel delivery by automatically adjusting for air temperature and changes in altitude, which contributes to cleaner emissions.
• DFI provides consistent starting whether the engine is hot or cold, and combined with the electric starter button makes firing up the engine easy.
• Tuned exhaust contributes to the engine’s easy-to-use performance, and the tapered muffler with oval cross section helps provide a strong off-road image.
• Smooth-shifting six-speed transmission combined with short final gearing complements the engine’s low-mid range power focus to make navigating tight trails easier
CHASSIS
• High-tensile steel perimeter frame was specifically designed to enhance trail performance for increased rider confidence.
• The frame and engine were designed together. Engine height was minimized to help create an optimal frame line for an ideal rigidity balance and precisely positioned center of gravity.
• The frame was also designed so riders can easily grip it with their legs for increased rider control and feedback. Flush seams between the shrouds, seat and side covers, combined with a relatively flat seat design, also aids rider control and help provide freedom of movement.
• Short wheelbase contributes easy maneuverability on the trail.
• Fine-tuned suspension contributes to ample ground clearance for increased trail riding performance.
• New Uni-Trak(KP) rear suspension system provides a supple ride over small bumps without sacrificing stiffness to absorb bigger bumps.
• Gas-pressurized single rear shock is adjustable for preload to help riders set the bike up for their weight.
• Petal disc brakes provide sure stopping power.
• Full-size aluminum wheels, 21-inch front and 18-inch rear, increase trail-riding performance.
• Kawasaki KX styling influences provide an agile, aggressive image
• Bright LED headlight offers excellent illumination.
2023 Kawasaki KLX230 KRT – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $4,999 USD
Canada MSRP Price: $5,749 CDN
Europe/UK MSRP Price: £ NA GBP (On The Road inc 20% Vat)
POWER
Engine 4-stroke single, SOHC, air-cooled
Displacement 233cc
Bore x Stroke 67.0 x 66.0mm
Compression Ratio 9.4:1
Fuel System DFI with 32mm Keihin throttle body
Ignition TCBI Electronic Advance
Transmission 6-speed, return shift with wet multi-disc manual clutch
Final Drive Chain
PERFORMANCE
Front Suspension / Wheel Travel 37mm telescopic fork/8.7 in
Rear Suspension / Wheel Travel Uni-Trak linkage system and single shock with adjustable spring preload/8.8 in
Front Tire 2.75 x 21
Rear Tire 4.10 x 18
Front Brakes Single 240mm petal disc with a dual-piston caliper
Rear Brakes Single 220mm petal disc with single-piston caliper
DETAILS
Frame Type High-tensile steel, box-section perimeter
Rake/Trail 27.5°/4.6 in
Overall Length 82.9 in.
Overall Width 32.9 in.
Overall Height 45.9 in.
Ground Clearance 10.4 in.
Seat Height 34.8 in.
Curb Weight 291.1 lb. / 293.3 lb. CA model*
Fuel Capacity 2.0 gal.
Wheelbase 54.3 in.
Color Choices Battle Gray
Warranty 12 Months
Kawasaki Protection Plus (optional) 12, 24, or 36 months
2023 Kawasaki KLX230 KRT – Totalmotorcycle.com Canadian Specifications/Technical Details
POWER
Engine 233cc, air-cooled, 4-stroke, SOHC 2-valve single
Bore x Stroke 67.0 x 66.0 mm
Compression Ratio 9.4:1
Fuel System Fuel injection: ø32 mm x 1
Ignition Digital
Starting Electric
Lubrication Forced lubrication, wet sump
Transmission 6-speed, return
Clutch Wet multi-disc, manual
Final Drive Chain
PERFORMANCE
Frame Perimeter, high-tensile steel
Front Suspension / Wheel Travel ø37 mm telescopic fork / 220 mm (8.7 in)
Rear Suspension / Wheel Travel New Uni Trak with adjustable spring preload / 223 mm (8.8 in)
Rake / Trail 27.5° / 116 mm
Steering Angle (L/R) 45° / 45°
Front Tire 2.75-21 45P
Rear Tire 4.10-18 59P
Front Brake ø240 mm petal disc with dual-piston caliper
Rear Brake ø220 mm petal disc with single-piston caliper
DETAILS
Dimensions (L x W x H) 2,105 x 835 x 1,165 mm (82.9 x 32.9 x 45.9 in)
Wheelbase 1,380 mm (54.3 in)
Road Clearance 265 mm (10.4 in)
Seat Height 885 mm (34.8 in)
Curb Mass** 132 kg (291 lb)
Fuel Capacity 7.5 litres
Instrumentation LCD screen with speedometer, odometer, dual trip meters, fuel gauge, clock and indicator lamps
Warranty 12 months
Kawasaki Protection Plus 12 / 24 / 36 / 48 months
2023 Kawasaki KLX230 KRT – Totalmotorcycle.com European Specifications/Technical Details
NA
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
