2023 KTM 50 SX: PODIUMS START HERE.
Introducing the 2023 KTM 50 SX…
The 2023 KTM 50 SX is a true READY TO RACE motocross machine. It is a genuine dirt bike that, like its bigger siblings, is produced with top-quality components, real race-bred input, and thoughtful development. It goes without saying that the KTM 50 SX is the only choice when stepping into the world of MX.
2023 KTM 50 SX Totalmotorcycle.com Key Features
ARE YOU READY TO GET SERIOUS?
At KTM we’re familiar with setting the standard. We’re buddies with the benchmark.
Unparalleled torque, power and weight ratios, cornering agility and the sharpest feeling, enviable starting prowess and styling: our KTM SX model range has been dropping milestones for a number of years now. Never tried one of our KTM SXs? Look around any racetrack – hobby or Pro – to see the strength orange. Speaking of professional racing: we’ve won a title or two in the last decade.
Right now, we want your attention more than ever. Why? We’ve been working. Our objectives are the same. Our mission objective is the same. Our processes are the same. But our achievements have reached a new sphere of performance, of conception.
It’s time to show how riding, thinking, and living motocross has changed.
2023 KTM 50 SX Totalmotorcycle.com Features and Benefits
Engine & Exhaust
Exhaust
The exhaust system was designed to perfectly match the characteristics of the engine, ensuring maximum output and a smooth power delivery over the entire rev range.
Engine
This little ripper of an engine features a high-performance cylinder, exhaust pipe and reed intake system, which are perfectly arranged for maximum performance, setting the standard in the highly competitive 50 cc class.
Cylinder
Engineered to withstand anything a budding young racer can throw at it, this high performance cylinder provides the goods in the highly contested and highly competitive 50 cc class.
Clutch
The KTM 50 SX features a centrifugal multi-disc automatic clutch, which provides manageable acceleration for any young beginner. By simply twisting the throttle, young riders can experience the full READY TO RACE world of KTM. Plus, it can be adjusted to the specific requirements of the track and the rider in minutes and without any special tools.
Power reduction kit
For those future stars who are still absolute beginners, the engine power can be reduced using a kit from the PowerParts program. Afterall, we all had to start somewhere.
Cooling
Like the full-size KTM SX range, the KTM 50 SX has a liquid cooling system, which even cools the crankcase. This is supported by large radiators providing outstanding heat dissipation, for remarkable reliability.
Exhaust
The exhaust system was designed to perfectly match the characteristics of the engine, ensuring maximum output and a smooth power delivery over the entire rev range.
Engine
This little ripper of an engine features a high-performance cylinder, exhaust pipe and reed intake system, which are perfectly arranged for maximum performance, setting the standard in the highly competitive 50 cc class.
Chassis
Fuel tank
Don’t let its 2.3 liter fuel capacity fool you – the 2023 KTM 50 SX is no slouch when it comes to going full race distance.
Frame
This modern frame is made from lightweight, high strength chromoly steel profiles and combines maximum longitudinal stiffness with optimum torsional rigidity. It guarantees easy handling and precise cornering, but also outstanding stability at speed.
Wheels
Like the full-size KTM Factory racers, the 2023 KTM 50 SX is fitted with lightweight, black anodized, aluminum rims which provide the highest strength and durability for any eventuality. These are wrapped in new MAXXIS MX-ST tires, to provide unmatched traction on any surface.
Front suspension
The KTM 50 SX boasts a modern WP XACT fork with AER technology – just like the big bikes! The upside-down front fork with a 35 mm tube diameter and 205 mm of travel ensures outstanding comfort, damping characteristics and directional stability. Another main benefit for junior riders is that the air spring fitted in the left fork leg can be adjusted perfectly to the rider’s weight using a simple air pump.
Rear suspension
The high quality WP XACT shock absorber is linked directly to the swingarm, providing excellent damping performance. It is fully adjustable, meaning you can set the damping perfectly to suit any growing young racer and track conditions. The shock absorber allows for 185 mm of rear wheel travel, meaning less chance of bottoming out.
Brakes
The KTM 50 SX is fitted with front and rear hydraulic brakes by FORMULA, combined with lightweight wave discs that are easy to control even for the youngest riders, helping to build thier confidence, and taching them correct brake control.
Fuel tank
Don’t let its 2.3 liter fuel capacity fool you – the 2023 KTM 50 SX is no slouch when it comes to going full race distance.
Frame
This modern frame is made from lightweight, high strength chromoly steel profiles and combines maximum longitudinal stiffness with optimum torsional rigidity. It guarantees easy handling and precise cornering, but also outstanding stability at speed.
Ergonomics & Comfort
Footpegs
The KTM 50 SX MINI has “”no-dirt” footpegs, which have a simple but effective self-cleaning system that expels mud and soil to prevent excess dirt build-up, with a spring that ensures the footpegs return to their original position, providing complete control in all conditions.
Handlebar
The KTM 50 SX uses a perfectly shaped handlebar made from a high-quality aluminum alloy. It provides a great feeling of control for the rider, helping with overall stability. A pad around the center brace also protects the rider from hard knocks.
Footpegs
The KTM 50 SX MINI has “”no-dirt” footpegs, which have a simple but effective self-cleaning system that expels mud and soil to prevent excess dirt build-up, with a spring that ensures the footpegs return to their original position, providing complete control in all conditions.
Handlebar
The KTM 50 SX uses a perfectly shaped handlebar made from a high-quality aluminum alloy. It provides a great feeling of control for the rider, helping with overall stability. A pad around the center brace also protects the rider from hard knocks.
Bodywork & Graphics
Decals
The 2023 KTM 50 SX features the latest in-mold graphics, with a bold orange black and purple design that perfectly sets off the factory-look orange frame, orange seat and race-sharpened bodywork.
2023 KTM 50 SX – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $4699 USD
Canada MSRP Price: $5299 CDN
Europe/UK MSRP Price: £ NA (On The Road inc 20% Vat)
ENGINE
TRANSMISSION Single-speed automatic
STROKE 40 mm
BORE 39.5 mm
CLUTCH Centrifugal clutch (adjustable)
DISPLACEMENT 49 cm³
EMS Seletra 2p D36
DESIGN 1-cylinder, 2-stroke engine
CHASSIS
WEIGHT (WITHOUT FUEL) 41.5 kg
TANK CAPACITY (APPROX.) 2.3 l
FRONT BRAKE DISC DIAMETER 160 mm
REAR BRAKE DISC DIAMETER 160 mm
FRONT BRAKE Disc brake
REAR BRAKE Disc brake
CHAIN 1/2 x 3/16″
FRAME DESIGN Chrome-molybdenum steel central-tube frame
FRONT SUSPENSION XACT 35 WP Upside-Down fork, Ø 35 mm
GROUND CLEARANCE 252 mm
REAR SUSPENSION XACT WP PDS mono shock
SEAT HEIGHT 665 mm
STEERING HEAD ANGLE 66 °
SUSPENSION TRAVEL (FRONT) 205 mm
SUSPENSION TRAVEL (REAR) 185 mm
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
