Review – Key Features – Features & Benefits – Specifications
2023 Triumph Bonneville Bobber: PURE BRUTAL BEAUTY.
Introducing the 2023 Triumph Bonneville Bobber…
This is a stunning new generation Bobber, with all the award winning custom style, now beautifully evolved with enhanced performance, higher specification and blacked-out finish.
ORIGINAL CUSTOM ICON
Authentic, innovative, and thrilling to ride – now with even more performance, capability, specification and style.
MODERN CAPABILITY WITH SEAMLESSLY INTEGRATED ADVANCED RIDING TECHNOLOGY FOR A CLASS DEFINING HOT ROD RIDE.
BONNEVILLE BOBBER
Nothing thrills like a Bobber – from its muscular look, to its award winning easy ride, now beautifully evolved.
Bonneville Bobber
Triumph’s original custom icon, the Bonneville Bobber, comes in three colours for model year 2023, with a classic Jet Black, a sophisticated Matt Storm Grey and Matt Ironstone scheme, and a striking new Red Hopper option. This new paint scheme includes a Red Hopper fuel tank and Jet Black side panels and mudguards.
2023 Triumph Bonneville Bobber Totalmotorcycle.com Key Features
- Red Hopper NEW
- Matt Storm Grey & Matt Ironstone
- Jet Black
| Engine | 1200cc “High Torque” parallel twin engine with 270° firing interval |
| Clutch | Torque assist clutch |
| Traction Control | Ride-by-wire throttle with switchable traction control |
| Riding Modes | 2 riding modes (Road and Rain) |
| Suspension | 47mm Showa cartridge forks, with hidden monoshock RSU |
| Brakes | Twin Brembo front calipers and Nissin rear caliper, with ABS |
| Wheels and Tires | 16″ 32-spoke wire wheels with Avon Cobra tires |
| Instruments | Single dial analog speedometer with multi-function LCD display |
| Lighting | All-LED lighting. |
| Cruise Control | Cruise control with single button operation |
| Immobilizer | Immobilizer transponder built into the key |
| Fuel Tank | 3.1 gallon fuel tank |
| Seating | Adjustable position floating seat, with low 27.1 in seat height |
| Service | 10,000 miles/12 months service interval, whichever comes first |
EXCITING NEW COLOURS AND NEW NAMES FOR TRIUMPH’S MODERN CLASSICS RANGE
Introducing for model year 2023, a new and exciting range of colour options for the entire Bonneville range, building on the great success of last year’s Gold Line Editions, which responded to customer requests for brighter, more distinctive, and more elegant colour options across the legendary Modern Classics line-up.
These new colours come hand-in-hand with new names for two of the class-defining 900cc models, chosen to better represent the family connections across Triumph’s iconic Bonneville line-up, and their specific engine capacities. From model year 2023, the Street Twin is re-named Speed Twin 900, and the Street Scrambler is re-named the Scrambler 900.
2023 Triumph Bonneville Bobber Totalmotorcycle.com Features and Benefits
UPDATED HIGH TORQUE ENGINE
The 1200cc parallel twin provides effortless acceleration, with its thrilling torque rich power delivery, unique Bobber tune and charismatic 270° firing interval. Now even more responsive.
DISTINCTIVE SOUNDTRACK
The innovative twin-skin exhaust system with eye catching sawn-off peashooter silencers, plus unique twin airbox setup, deliver the signature hot-rod sound, while neatly hiding the catalyst under the bike.
UNMATCHED AUTHENTICITY
With its beautiful silhouette, stripped-back style, wire spoked wheels, wide flat bars, low stance and black powder coated swinging cage, for that distinctive ‘hard tail’ look, the Bobber is a true modern icon.
MUSCULAR STANCE AND POISE
For 2021 the new Bobber was updated with a larger 3.17-gallon sculpted fuel tank, new fat 16” front wheel and chunkier 47mm front forks, which combine to deliver an even more muscular and imposing poise and stance.
DISTINCTIVE FLOATING SEAT
The Bobber’s signature floating aluminum seat brings beautiful lines and comfort. With its adjustable position, low 27.1 in height and narrow stand over, everyone can experience the class-leading ride.
NEW BLACKED-OUT STYLE
Adding to the class-leading finish with an even meaner and moodier look, courtesy of new black powder coated engine covers, cam cover and sprocket cover, for a result that’s as thrilling to look at as it is to ride.
HIGHER SPEC BRAKES
New twin 310mm front brake discs with twin Brembo 2-piston sliding axial calipers, a single Nissin caliper at the rear, and high-performance ABS fitted as standard, deliver excellent stopping power for great rider control.
HIGHER SPEC SUSPENSION
New 47mm Showa cartridge front forks with 3.5 in (90mm) travel and the Bobber’s innovative hidden monoshock rear suspension with linkage, combine for superior suspension performance and comfort.
HIGHER SPEC TECHNOLOGY
Beautifully integrated rider tech includes 2 riding modes, switchable traction control, ABS, ride by wire, immobilizer, and for 2021, cruise control and LED headlight completing the LED lighting setup.
NEW GENERATION BOBBER
Bringing together the authenticity of the Bobber with the higher spec of the Bobber Black, for the best of both worlds.
THRILLING PERFORMANCE
Critically acclaimed 1200cc High Torque twin engine with Bobber tune, now even more responsive.
BEAUTIFULLY REFINED
The Bobber’s ride is enhanced by new twin Brembo front brakes and discs, Showa forks, 3.17-gallon tank and 16’’ front wheel.
ENHANCED TECHNOLOGY
Full-LED headlight and single button cruise control adds to the Bobber’s incredible level of specification.
AUTHENTIC, IMPOSING AND POISED
Peerlessly authentic with stunning features and finish, now with an even more muscular poise and blacked-out style.
YOUR BOBBER IN EVERY WAY
From the unique adjustable seat and clock positions, to the 3 premium color choices and over 75 custom accessories, the Bobber was designed for you to add your personality and truly make it yours.
THE BONNEVILLE BOBBER IN NUMBERS
1200 cc ENGINE
78 LB-FT PEAK TORQUE
76 HP PEAK POWER
10,000 MILES SERVICE
2023 Triumph Bonneville Bobber – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: from $13,995 USD
Canada MSRP Price: from $15,395 CDN
Europe/UK MSRP Price: from £12,395 (On The Road inc 20% Vat)
ENGINE & TRANSMISSION
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Type | Liquid cooled, 8 valve, SOHC, 270° crank angle parallel twin |
| Capacity | 1200 cc |
| Bore | 97.6 |
| Stroke | 80 |
| Compression | 10.0:1 |
| Max Power EC | 76.9 HP @ 6100 RPM |
| Max Torque EC | 78.2 LB-FT @ 4000 rpm |
| System | Multipoint sequential electronic fuel injection |
| Exhaust | Brushed stainless steel 2 into 2 twin-skin exhaust system with brushed stainless silencers |
| Final Drive | Chain |
| Clutch | Wet, multi-plate torque assist clutch |
| Gearbox | 6-speed |
CHASSIS
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Frame | Tubular steel, twin cradle frame |
| Swingarm | Twin sided fabrication |
| Front Wheel | Wire 32-spoke, 16 x 2.5 |
| Rear Wheel | Wire 32-spoke, 16 x 3.5 |
| Front Tire | MT90B16 |
| Rear Tire | 150/80 R16 |
| Front Suspension | Ø 47 mm Showa cartridge forks |
| Rear Suspension | Mono-shock RSU with linkage |
| Front Brakes | Twin Ø310mm disc, Brembo 2-piston sliding axial calipers |
| Rear Brakes | Single Ø255mm disc, Nissin single piston sliding axial caliper |
| Instrument Display and Functions | Analogue speedometer with LCD multi-functional display |
DIMENSIONS & WEIGHTS
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Width Handlebars | 31.5 in (800 mm) |
| Height Without Mirror | 40.3 – 41.5 in (1024 – 1055 mm) |
| Seat Height | 27.2 – 27.6 in (690 – 700 mm) |
| Wheelbase | 59.1 in (1500 mm) |
| Rake | 24.5 º |
| Trail | 3.6 in (92.0 mm) |
| Tank Capacity | 3.2 US gal (12 litres) |
| Wet Weight | 553 lb (251 kg) |
FUEL CONSUMPTION
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Fuel Consumption | 60.9 mpg (4.6 L / 100km) |
| CO2 Figures | EPA Procedure CO2 emissions and fuel consumption data are measured according to regulation 40 CFR Part 86 Subpart F. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results. |
SERVICE
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Service Interval | 10,000 miles/12 months service interval, whichever comes first |
2023 Triumph Bonneville Bobber – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE & TRANSMISSION
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Type | Liquid cooled, 8 valve, SOHC, 270° crank angle parallel twin |
| Capacity | 1200 cc |
| Bore | 97.6 |
| Stroke | 80 |
| Compression | 10.0:1 |
| Max Power EC | 76.9 HP @ 6100 RPM |
| Max Torque EC | 78.2 LB-FT @ 4000 rpm |
| System | Multipoint sequential electronic fuel injection |
| Exhaust | Brushed stainless steel 2 into 2 twin-skin exhaust system with brushed stainless silencers |
| Final Drive | Chain |
| Clutch | Wet, multi-plate torque assist clutch |
| Gearbox | 6-speed |
CHASSIS
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Frame | Tubular steel, twin cradle frame |
| Swingarm | Twin sided fabrication |
| Front Wheel | Wire 32-spoke, 16 x 2.5 |
| Rear Wheel | Wire 32-spoke, 16 x 3.5 |
| Front Tire | MT90B16 |
| Rear Tire | 150/80 R16 |
| Front Suspension | Ø 47 mm Showa cartridge forks |
| Rear Suspension | Mono-shock RSU with linkage |
| Front Brakes | Twin Ø310mm disc, Brembo 2-piston sliding axial calipers |
| Rear Brakes | Single Ø255mm disc, Nissin single piston sliding axial caliper |
| Instrument Display and Functions | Analogue speedometer with LCD multi-functional display |
DIMENSIONS & WEIGHTS
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Width Handlebars | 31.5 in (800 mm) |
| Height Without Mirror | 40.3 – 41.5 in (1024 – 1055 mm) |
| Seat Height | 27.2 – 27.6 in (690 – 700 mm) |
| Wheelbase | 59.1 in (1500 mm) |
| Rake | 24.5 º |
| Trail | 3.6 in (92.0 mm) |
| Tank Capacity | 3.2 US gal (12 litres) |
| Wet Weight | 553 lb (251 kg) |
FUEL CONSUMPTION
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Fuel Consumption | 60.9 mpg (4.6 L / 100km) |
| CO2 Figures | EPA Procedure CO2 emissions and fuel consumption data are measured according to regulation 40 CFR Part 86 Subpart F. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results. |
SERVICE
| BONNEVILLE BOBBER Specifications | |
| Feature | Details |
| Service Interval | 10,000 miles/12 months service interval, whichever comes first |
2023 Triumph Bonneville Bobber – Totalmotorcycle.com European Specifications/Technical Details
| ENGINE & TRANSMISSION | |
| Type | Liquid cooled, 8 valve, SOHC, 270° crank angle parallel twin |
| Capacity | 1200 cc |
| Bore | 97.6 mm |
| Stroke | 80 mm |
| Compression | 10.0:1 |
| Max Power EC | 78 PS / 76.9 bhp (57.5 kW) @ 6100 rpm |
| Max Torque EC | 106 Nm @ 4000 rpm |
| System | Multipoint sequential electronic fuel injection |
| Exhaust | Brushed stainless steel 2 into 2 twin-skin exhaust system with brushed stainless silencers |
| Final Drive | Chain |
| Clutch | Wet, multi-plate torque assist clutch |
| Gearbox | 6-speed |
| CHASSIS | |
| Frame | Tubular steel, twin cradle frame |
| Swingarm | Twin sided fabrication |
| Front Wheel | Wire 32-spoke, 16 x 2.5 inches |
| Rear Wheel | Wire 32-spoke, 16 x 3.5 inches |
| Front Tyre | MT 90 B16 |
| Rear Tyre | 150/80 R16 |
| Front Suspension | Ø 47 mm Showa cartridge forks |
| Rear Suspension | Mono-shock RSU with linkage |
| Front Brakes | Twin Ø310mm disc, Brembo 2-piston sliding axial calipers, ABS |
| Rear Brakes | Single Ø255mm disc, Nissin single piston sliding axial caliper, ABS |
| Instrument Display and Functions | Analogue speedometer with LCD multi-functional display |
| DIMENSIONS & WEIGHTS | |
| Width Handlebars | 800 mm |
| Height Without Mirror | 1024 – 1055 mm |
| Seat Height | 690 – 700 mm |
| Wheelbase | 1500 mm |
| Rake | 25.4 º |
| Trail | 92.0 mm |
| Tank Capacity | 12 L |
| Wet Weight | 251 kg |
| FUEL CONSUMPTION | |
| Fuel Consumption | 60.9 mpg (4.6 l/100km) |
| CO2 Figures | 105 g/km EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results. |
| SERVICE | |
| Service Interval | 10,000 miles (16,000 km) /12 months service interval, whichever comes first |
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
