2023 Triumph Bonneville T100: ICONIC. BEAUTIFUL. CAPABLE.

Introducing the 2023 Triumph Bonneville T100…

AN ORIGINAL FOR EVERYONE
Timeless style, thrilling performance, and confidence-inspiring easy ride. The T100 is the perfect introduction to the iconic Bonneville family.

BEAUTIFULLY EVOLVED, THE NEW 2021 BONNEVILLE T100 IS A CONTEMPORARY CLASSIC, ENHANCED WITH GREATER PERFORMANCE, HIGHER SPECIFICATION, AND EVEN MORE STYLE.

With all of the signature touches of a genuine motorcycle legend, the T100 offers beautiful iconic style, easy handling, and modern capability.

Bonneville T100
The iconic Bonneville T100 for model year 2023 comes in three colours, with a timeless Triumph Jet Black, and a classic Carnival Red and Fusion White scheme, plus a stylish interpretation of the original 1959 design, with a stunning new Meriden Blue and Tangerine option, with hand-painted silver coach line detailing on the tank. This striking new colour scheme also features Meriden Blue side panels and mudguards.

The evolution of a genuine motorcycle icon, the Bonneville T100 is now lighter and more powerful, with enhanced style and an even higher level of specification.

PREMIUM QUALITY & FINISH
Rich chrome, deep, lustrous paint and hand-painted aluminium coach lining on the iconic Bonneville tank fulfil the T100’s promise of premium quality with a durable finish.







2023 Triumph Bonneville T100 Totalmotorcycle.com Key Features

  • Meriden Blue & Tangerine NEW
  • Carnival Red & Fusion White
  • Jet Black







2023 Triumph Bonneville T100 Totalmotorcycle.com Features and Benefits

HIGHER POWER AND PERFORMANCE
Now Euro 5 compliant, the famous torque-rich Bonneville 900cc HT engine now delivers 10PS more power, a sharper throttle response and reduced emissions.

The iconic 900cc parallel twin engine is now lighter and more responsive with 10 HP more power, making 64 HP at 7,400 rpm.

INTUITIVE HANDLING

Weight savings throughout the new T100 and higher specification cartridge forks result in a more agile machine with easier handling. Engaging but manageable, neutral yet responsive.

HIGHER SPECIFICATION BRAKES

Paired with the latest ABS system, the updated 2-piston Brembo caliper gives improved power and feel for confident and safe braking in all conditions.

ERGONOMICS AND COMFORT

A comfortable dual seat with low 31.1 in height, relaxed riding position, light action torque-assist clutch and simple, ergonomically designed switches make for a confidence-inspiring, stress-free ride.

WHEELS AND TIRES

The classically-styled 32-spoke wheels combine with specially developed Pirelli Phantom Sportscomp tires for confident, assured handling.

INTEGRATED TECHNOLOGY

Compact, rider-focused technology that includes the latest generation of ABS and switchable traction control, is sensitively incorporated into the T100’s beautiful classic style.

BEAUTIFUL STYLE AND FINISH

Unmistakably iconic Bonneville character in a choice of three classic colors. Hand-painted coach lining on the tank and blacked-out finishes blend tradition with modern style.

TWIN DIAL INSTRUMENTS

Striking, yet easy-to-read in all light conditions, the premium new 3D dial faces deliver all of the key information with precision and clarity.

SAFETY

A high-visibility LED rear light, quality Brembo brakes with ABS, and switchable traction control provide enhanced rider safety in all riding conditions.

HIGHER SPECIFICATION EQUIPMENT
New enhanced specification cartridge forks and uprated Brembo brakes, give you excellent stopping power and more control, for an even more comfortable ride.

HIGH SPECIFICATION TECHNOLOGY
The latest rider technology, beautifully incorporated into the Bonneville’s classic lines, includes ABS, traction control, and torque assist clutch.

ICONIC STYLING
Unmistakably Bonneville, the new T100 gets even more sophisticated detailing with a blacked-out engine and new instrument faces, for a more contemporary style.

MAKE IT YOURS
With 117 Genuine Triumph Accessories to personalise your ride; all designed and tested to the same high standards as our bikes, including the same 2 year, unlimited mileage warranty.

ACCESSORIES
117 Genuine Triumph Accessories to personalise your ride; bespoke luggage, protection, comfort, styling and security all designed to work in perfect harmony with your T100.

BONNEVILLE T100 IN NUMBERS
900 CC ENGINE
64.1 HP POWER
59 LB-FT PEAK TORQUE
117 ACCESSORIES













2023 Triumph Bonneville T100 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: from $10,795  USD
Canada MSRP Price: from $11,945 CDN
Europe/UK MSRP Price: from £9,395 (On The Road inc 20% Vat)

ENGINE & TRANSMISSION
Type Liquid cooled, 8 valve, SOHC, 270° crank angle parallel twin
Capacity 900 cc
Bore 84.6
Stroke 80
Compression 11.0:1
Max Power EC 64.1 HP @ 7400 RPM
Max Torque EC 59 LB-FT @ 3750 rpm
System Multipoint sequential electronic fuel injection
Exhaust Brushed stainless steel 2 into 2 exhaust system with twin silencers
Final Drive Chain
Clutch Wet, multi-plate torque assist clutch
Gearbox 5 speed
CHASSIS
Frame Tubular steel, with twin cradles
Swingarm Twin sided fabrication
Front Wheel 32 spoke 2.75” x 18”
Rear Wheel 32 spoke, 4.25” x 17”
Front Tire 100/90-18
Rear Tire 150/70 R17
Front Suspension Ø41mm cartridge forks
Rear Suspension Twin RSU’s, with pre-load adjustment
Front Brakes Single Ø310mm floating disc, Brembo 2 piston axial caliper, ABS
Rear Brakes Single Ø255mm disc, Nissin 2 piston floating caliper, ABS
Instrument Display and Functions Twin dial analogue speedometer and tachometer with LCD multi-functional displays
DIMENSIONS & WEIGHTS
Width Handlebars 30.7 in (780 mm)
Height Without Mirror 43.3 in (1100 mm)
Seat Height 31.1 in (790 mm)
Wheelbase 57.1 in (1450 mm)
Rake 25.5 º
Trail 4.1 in (104.0 mm)
Tank Capacity 3.8 US gal (14.5 litres)
Wet Weight 503 lb (228 kg)
FUEL CONSUMPTION
Fuel Consumption 68.9 mpg (4.1 L / 100km)
CO2 Figures EPA Procedure CO2 emissions and fuel consumption data are measured according to regulation 40 CFR Part 86 Subpart F. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.



SERVICE INTERVAL: 10,000 miles/16,000 Km or 12 Months, whichever comes first.







2023 Triumph Bonneville T100 – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE & TRANSMISSION
Type Liquid cooled, 8 valve, SOHC, 270° crank angle parallel twin
Capacity 900 cc
Bore 84.6
Stroke 80
Compression 11.0:1
Max Power EC 64.1 HP @ 7400 RPM
Max Torque EC 59 LB-FT @ 3750 rpm
System Multipoint sequential electronic fuel injection
Exhaust Brushed stainless steel 2 into 2 exhaust system with twin silencers
Final Drive Chain
Clutch Wet, multi-plate torque assist clutch
Gearbox 5 speed
CHASSIS
Frame Tubular steel, with twin cradles
Swingarm Twin sided fabrication
Front Wheel 32 spoke 2.75” x 18”
Rear Wheel 32 spoke, 4.25” x 17”
Front Tire 100/90-18
Rear Tire 150/70 R17
Front Suspension Ø41mm cartridge forks
Rear Suspension Twin RSU’s, with pre-load adjustment
Front Brakes Single Ø310mm floating disc, Brembo 2 piston axial caliper, ABS
Rear Brakes Single Ø255mm disc, Nissin 2 piston floating caliper, ABS
Instrument Display and Functions Twin dial analogue speedometer and tachometer with LCD multi-functional displays
DIMENSIONS & WEIGHTS
Width Handlebars 30.7 in (780 mm)
Height Without Mirror 43.3 in (1100 mm)
Seat Height 31.1 in (790 mm)
Wheelbase 57.1 in (1450 mm)
Rake 25.5 º
Trail 4.1 in (104.0 mm)
Tank Capacity 3.8 US gal (14.5 litres)
Wet Weight 503 lb (228 kg)
FUEL CONSUMPTION
Fuel Consumption 68.9 mpg (4.1 L / 100km)
CO2 Figures EPA Procedure CO2 emissions and fuel consumption data are measured according to regulation 40 CFR Part 86 Subpart F. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.
SERVICE
Service Interval 10,000 miles/12 months service interval, whichever comes first

SERVICE INTERVAL: 10,000 miles/16,000 Km or 12 Months, whichever comes first.









2023 Triumph Bonneville T100 – Totalmotorcycle.com European Specifications/Technical Details

ENGINE & TRANSMISSION
Type Liquid cooled, 8 valve, SOHC, 270° crank angle parallel twin
Capacity 900 cc
Bore 84.6 mm
Stroke 80 mm
Compression 11.0:1
Max Power EC 65 PS / 64.1 bhp (47.8 kW) @ 7400 rpm
Max Torque EC 80 Nm @ 3750 rpm
System Multipoint sequential electronic fuel injection
Exhaust Brushed stainless steel 2 into 2 exhaust system with twin silencers
Final Drive Chain
Clutch Wet, multi-plate torque assist clutch
Gearbox 5 speed
CHASSIS
Frame Tubular steel, twin cradle frame
Swingarm Twin sided fabrication
Front Wheel 32 spoke 18 x 2.75 inches
Rear Wheel 32 spoke, 17 x 4.25 inches
Front Tyre 100/90-18
Rear Tyre 150/70 R17
Front Suspension Ø41mm cartridge forks
Rear Suspension Twin RSU’s, with pre-load adjustment
Front Brakes Single Ø310mm floating disc, Brembo 2 piston axial caliper, ABS
Rear Brakes Single Ø255mm disc, Nissin 2 piston floating caliper, ABS
Instrument Display and Functions Twin dial analogue speedometer and tachometer with LCD multi-functional displays
DIMENSIONS & WEIGHTS
Width Handlebars 780 mm
Height Without Mirror 1100 mm
Seat Height 790 mm
Wheelbase 1450 mm
Rake 25.5 º
Trail 104.0 mm
Tank Capacity 14.5 L
Wet Weight 228 kg
FUEL CONSUMPTION
Fuel Consumption 68.9 mpg (4.1 l/100km)
CO2 Figures 95 g/km EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.
SERVICE
Service Interval 10,000 miles/16,000 Km or 12 Months, whichever comes first





SERVICE INTERVAL: 10,000 miles/16,000 Km or 12 Months, whichever comes first.











Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
