2023 Yamaha BWs 125: A ZUMA OF A DIFFERENT COLOR.

Introducing the new 2023 Yamaha BWs 125…

The ultra‑modern BWs 125 is a rugged and fuel efficient scooter with big features in a compact package. Powered by its Yamaha Blue Core 125cc 4-stroke engine and a fully-automatic V-belt transmission, the BWs 125 impresses with its peppy & lightweight characteristics . Featuring cavernous storage compartments in the front and rear, you can be sure there is ample room to bring along everything you need. And with its plush & roomy riding position, the BWs 125 maximizes comfort, even with a passenger making it the pinnacle of convenient transportation.

ENGINE

Powering the BWs 125 is a compact Yamaha Blue Core 125cc 4-stroke engine offering reliable and economical performance. With its Variable Valve Actuation (VVA) changing valve timing at different rpm, the result is linear acceleration, strong torque at lower speeds and power that lasts into the top-end.

STORAGE

The cavernous underseat storage compartment is roomy enough for a full-face helmet and features two helmet hangers. The front storage compartment is equipped with an electric USB socket for conveniently charging your device on the go.

MODERN DESIGN

The 2023 BWs125 features rugged asymmetric headlights with easily adjustable beams optimize view angles for a wide range of riders. It’s stylish LCD meter features a fuel gauge, clock, oil change indicator, trip meter 1 and 2, as well as a full range of indicator lights with easy-to-read visibility.









2023 Yamaha BWs 125 Totalmotorcycle.com Key Features

  • Blue Core VVA 125cc engine
  • Automatic V-Belt Transmission
  • Robust steel-tube frame
  • 120/70-12 front and 130/70-12 rear DURO tubeless tires
  • Telescopic front fork and twin rear shocks
  • 245mm hydraulic wave-type front disc and 230mm rear
  • Unified brake system for smooth controlled stops
  • Adjustable headlights
  • LCD Instruments
  • Significant Storage with USB-A charging port





2023 Yamaha BWs 125 Totalmotorcycle.com Features and Benefits

MOTOR

  • Yamaha’s Blue Core 125cc liquid-cooled, four-stroke, single-cylinder engine
    • Excellent fuel efficiency and significant power for its compact size
    • SOHC 4-valve head with 11.2:1 compression ratio
    • DiASil cylinder and an aluminum alloy forged piston
  • Fuel injection provides the optimal fuel mixture for varying conditions, including easy cold starts
  • Fuel consumption rating of 2.3 L/100KM (101 mpg)
    • Carrying the 1.6 gallon fuel tank
    • Fuel tank emissions system includes a charcoal canister to control gasoline evaporation and reduce air pollution
  • Decompression mechanism reduces the engine cranking compression pressure
    • Combined with a starter generator control unit for smooth, quiet engine starts with better fuel consumption.
  • Yamaha’s Variable Valve Actuation (VVA) technology
    • Changing valve timing at different rpm, for linear acceleration, strong torque at lower speeds and power that lasts into the top-end
  • Upswept muffler incorporates two exhaust catalysts to reduce air pollution and meet emission regulations.
  • Fully-automatic V-belt transmission and push-button electric starting



CHASSIS

  • Built around a strong steel frame with aggressive tread tires, and tough suspension.
    • Boasts capability on roads of all sorts, with plenty of attitude for your daily commute
  • A reliable steel engine bracket with rubber bushing linkage contributes a comfortable ride with reduced vibration
    • Link mechanisms are positioned on the underside of the chassis to maximize space for the storage compartment
  • The telescopic fork features beefy outer tubes for strength, while fork boots help protect the large 33mm inner tubes from debris.
  • The rear wheel swingarm features twin rear shocks with a full 3.1 in of travel for comfortable riding both on streets and on unpaved roads.
  • DURO tubeless tires have an aggressive looking block pattern combined with newly designed lightweight wheels for great handling
  • 245mm hydraulic front disc and 230mm rear disc brakes provide plenty of stopping power while the wave-type front rotor design adds cutting-edge style
    • With a unified brake system, the rear brake lever applies some braking force to the front brake, while keeping the front brake from operating alone
  • 8″ Wheelbase
  • 9″ seat height with a narrow seat design for easier flat-footing at stops



DETAILS

  • Features a stylish LCD meter features a fuel gauge as well as a full range of indicator lights with easy-to-read visibility
  • Under seat storage compartment is roomy enough for a full-face helmet and features two helmet hangers
  • Front storage compartment is equipped with an electric USB socket for conveniently charging your device on the go
  • Secure passenger handholds and foot rests
  • New rugged asymmetric headlight design with easily adjustable beams to optimize view angles for a wide range of riders
  • Step-through floorboards making getting on and off a breeze
  • Both a center stand and side stand for parking convenience
  • For extra security when parked, the main switch is equipped with a keyhole lock cover
  • For easy refueling, the fuel filler is found just left of the ignition switch











2023 Yamaha BWs 125 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $NA USD
Canada MSRP Price: $4699 CDN
Europe/UK MSRP Price: £ NA GBP (On The Road inc 20% Vat)

See 2023 Yamaha Zuma 125





2023 Yamaha BWs 125 – Totalmotorcycle.com Canada Specifications/Technical Details

MOTOR
ENGINE 4-stroke, Liquid-cooled, SOHC, 4-valve, single
DISPLACEMENT 125 cc
BORE AND STROKE 52.0 x 58.7 mm
COMPRESSION RATIO 11.2 : 1
FUEL DELIVERY Fuel injection
ESTIMATED FUEL CONSUMPTION± 2.3 L/100 km (101 mpg)
LUBRICATION Wet sump
IGNITION / STARTING TCI / Electric Start
TRANSMISSION Fully Automatic CVT
FINAL DRIVE V-belt / Spur gear

CHASSIS
SUSPENSION (FRONT) Telescopic upright fork with 3.2 in of travel
SUSPENSION (REAR) Dual shock absorber with swingarm with 79mm (3.1 in) of wheel travel
BRAKES (FRONT) Disc brake / 245mm / single disc with double-piston caliper
BRAKES (REAR) Disc brake / 230mm / single disc with single-piston caliper
TIRES (FRONT) 120/70-12
TIRES (REAR) 130/70-12

CRITICAL DATA
LENGTH 1 920mm (75.6″)
WIDTH 759mm (29.9″)
HEIGHT 1,151mm (45.3″)
WHEELBASE 1,341 mm (52.8″)
SEAT HEIGHT 785 mm (30.9″)
FUEL CAPACITY 7.3 litres
WET WEIGHT 128 kg (282 lb.)
COLOUR(S) Team Yamaha Blue
Matte Black





2023 Yamaha BWs 125 – Totalmotorcycle.com European Specifications/Technical Details\

NA







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
