2023 Yamaha YDX-Moro05: CAN WE GET A DILLY DILLY?

Introducing the new 2023 Yamaha YDX-Moro05…

More runs, more funs! Step into the world of limitless adventure aboard the YDX-MORO 05. With its ultra-powerful and silent PW-X3 drive unit, bump osmosis technology and high-performance brakes, there’s nothing standing in the way of you and one more run!

Unleash your passion for adventure with long distance refinement, impressive efficiency, and the massively powerful and super silent All-New PW-X3 drive unit to electrify your ride.



Bud Light Dilly Dilly Ad:

2023 Yamaha YDX-Moro05 Totalmotorcycle.com Key Features

  • The all-new PW-X3 mid drive motor
  • The all-new Interface X exceeds rider demands with intuitive movements to access power assist levels, walk assist and automatic support mode.
  • Shimano DEORE SL-M6100-R shifter
  • Shimano DEORE RD-M6100-SGS derailleur
  • 12-speed Shimano SLX CS-M7100-12 cassette
  • 4-piston front and 2-Piston rear calipers engaged by its ergonomic single-finger lever
  • Yamaha 500Wh battery with Charge-life indicator and Self-diagnosis display
  • YAMAHA 27.5+ Alloy rims with MAXXIS 27.5X2.6 tires for optimized traction



Do you see it?

All-New YAMAHA Interface X control switch is a minimalist and ergonomic design which easily accesses the 5 support modes, walk assist and automatic support modes all in a clean handlebar aesthetic.

Clean lines for those dirty trails

Internal Cables and Housing minimize exposure to harsh riding conditions and help maximize time between service schedules.

Like it’s hot

More internal technology than your over-priced ergonomic office chair, the travel distance on this dropper post was specially selected for every frame size to match rider size with the trail’s demands.

Bump osmosis technology

The long-travel and ultra-strong 160mm fork absorbs bumps like a sponge to increase riding confidence even on the most challenging trail terrain.

ALL-NEW YAMAHA PW-X3

Everything you would expect from a Yamaha. Massive power, lip-snarling responsiveness, and impressive efficiency all in a lighter and smaller package now with Garmin Edge 530, Edge 830 and Edge 1030 compatibility.

A little guidance never hurts

Directly bolted to the PW-X3 drive unit, this ISCG05 chain guide will help keep the chain in place even under the gnarliest conditions.

A thing of beauty is worth protecting

This burley and robust chainstay protector is proprietary design by YAMAHA engineers to protect the frame from chains lapping chips to your beautiful paint job.

Patented Dual Twin Frame

The combined hydroforming and forging construction techniques created in Yamaha’s patented Dual Twin frame protects components and delivers the ultimate in handing and control.

Stop us at anytime

With powerful two-finger brake levers and one-piece caliper construction, your bike might be two-tired but your forearms won’t be.





2023 Yamaha YDX-Moro05 Totalmotorcycle.com Features and Benefits

DRIVE TRAIN:

Drive Motor:

  • All-New YAMAHA PW-X3 Class Drive Motor
  • PW-X3 mid drive motor is Yamaha’s smallest and lightest to date and ensures the best power-to-weight ratio with jaw-dropping responsiveness and smooth power delivery.
    • Equipped with Yamaha Quad Sensor with:
      • Automatic Support and Walk Assist Modes
      • Rate power: 250W (nominal), 500W (maximum)
      • Max torque: 85Nm
      • Max speed support: 32.2kph (20mph)
      • Support Modes: ECO, Standard, High, MTB, Extra-Power, Automatic, Walk Assist
    • 2-bolt drive unit mount

Drive Line Components:

  • Shimano DEORE RD-M6100-SGS rear derailer
  • 12-speed Shimano SLX CS-M7100-12 cassette
    • Optimized gears for riders to find the best balance of power and cadence.
  • Shimano DEORE SL-M6100-R shifter
  • 165mm Long PRAXIS E-CRANK Arm



CHASSIS:

Frame:

  • Yamaha’s patented Dual Twin construct combines hydroforming and forging techniques to create a frame to protect components with uncompromised riding control.
    • Features Tapered Headtube
  • Mass has been centralized utilizing a combination that creates a near-perfect weight distribution for ultimate control on the ground or in the air.
  • Internal cable/housing routing for seamless fit and finish
  • 12x148mm rear axle spacing

Suspension:

  • Rear Shock: ROCKSHOX DELUXE SELECT +
    • 150mm travel
    • Features 15 clicks of rebound adjustment, dual-level compression quick switch, and adjustable air pressure options to give riders the ultimate confidence through rough terrain.
  • Front Fork: ROCKSHOX REVELATION RC
    • 160mm travel
    • Features low-speed compression adjustability.





ELECTRONICS:

  • Yamaha 500Wh 36V Battery
    • Charge-life indicator and Self-diagnosis display
    • Anti-vibration mounting plate
    • Weight: 3kg (6.61lbs)
    • Recharge time: 1-hour 80%, 4-hour 100%
  • YAMAHA Interface X Control
    • 3-colour LED support-mode level light indicator
    • (5) Support-mode control switch, plus AUTOMATIC support mode (Aqua LED indicator)
    • Walk Assist mode (Purple LED indicator)
    • Bluetooth™ connectivity
    • LED brightness adjustability
    • Battery capacity (4-LED capacity indicators)









2023 Yamaha YDX-Moro05 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $5,799 USD
Canada MSRP Price: $6,599 CDN
Europe/UK MSRP Price: £ NA GBP (On The Road inc 20% Vat)



SUGGESTED USE All Mountain Class-1 Ebike Off-Road Trail Use
COLORS Forest Green
SIZE Small, Medium, Large
MSRP $5,799
TOTAL WEIGHT 51.1 lb (Medium)
MOTOR YAMAHA PW-X3 Class 1 Labeled Centermount ISIS SplinedCrankarm Spindle YAMAHA Quad Sensor with Automatic Support and Walk Assist Modes
Rate power: 250W (nominal), 500W(maximum)
Max torque: 85Nm
Max speed support: 20MPH
Support Modes: ECO, Standard, High, MTB, Extra-Power, Automatic, Walk Assist
CONTROL SWITCH AND MULTI-FUNCTION COMPUTER YAMAHA Interface X Control functions include: 3-color LED support-mode level light indicator, (5) Support-mode control switch, plus AUTOMATIC support mode (Aqua LED indicator) and Walk Assist mode (Purple LED indicator), Bluetooth™ connectivity, 3-color LED support-mode level light  indicator, LED brightness adjustability, battery capacity (4-LED  capacity indicators)
BATTERY Yamaha 500Wh with Charge-life indicator and Self-diagnosis display
Anti-Vibration Mounting Plate
Weight: 6.61 lbs
500Wh 36V
Re-charge time: 1-hour 80%, 4-hour 100%
FRAME YAMAHA Dual Twin Frame
Tapered Headtube
Internal cable/housing routing
2-bolt drive unit mount
12×148 rear axle spacing
Integrated YAMAHA speed sensor harness
FORK ROCKSHOX REVELATION RC
160mm TRAVEL
35mm Stanchion eMTB rated Motion Control damping with low-speed compression adjustment DebonAir air spring
REAR SHOCK ROCKSHOX DELUXE SELECT +
150mm travel
210X55mm DebonAir+ air spring with 15 clicks of rebound adjustment
2-position compression adjustment
HEADSET Integrated 1 1/8″
STEM Alloy 4-both faceplate
35.0 diameter
40mm length
HANDLEBARS Alloy
35.0 diameter
780mm width
30mm rise
GRIPS VELO Single Ring Locking
SEATPOST/SADDLE CLAMP TRANS-X 30.9 dia.
TRAVEL (S) 125mm (M) 150mm (L) 170mm
SEATPOST COLLAR Single-bolt 35.0mm
SADDLE YAMAHA anti-slip finish with hand rail tail
AXLES MAXLE 15MM X 110MM BOOST THRU AXLE
SHIFTERS Shimano DEORE SL-M6100-R
FRONT DERAILLEUR N/A
REAR DERAILLEUR Shimano DEORE RD-M6100-SGS
CRANKARM PRAXIS E-CRANK ARM
165mm LENGTH
CHAIN KMC eTURBO EPT 122 links
CASSETTE Shimano SLX CS-M7100-12
12-spd
(10-51T)
CHAINRINGS PRAXIS 36T
BRAKES/ROTORS MAGURA MT30
(F) 4-PISTON (R) 2-PISTON
203MM CENTER  LOCK ROTOR (F/R)
Two-finger lever
RIMS YAMAHA 27.5+ Alloy
Tubeless tape installed
Width: 46mm (outside) 40mm (inside)
SPOKES 14g alloy SUS304
HUBS Anodized Alloy
Centerlock brake mount
15x110mm BOOST+ (front)
12x148mm MicroSpline freehub Quick Release Thru Axle Type
TIRES/TUBES MAXXIS 27.5X2.6
(F) MINION DHF (R) REKON
ACCESSORIES Protective motor and battery covers
ISCG05 chainguuide
Safety bell VP Acrylic pedals
(No Keys)
WARRANTY 3-Year on Frame, Motor, Battery*
Component Manufacturer’s warranty** is supported by YAMAHA









2023 Yamaha YDX-Moro05 – Totalmotorcycle.com Canada Specifications/Technical Details

SUGGESTED USE All Mountain Class-1 Ebike Off-Road Trail
TOTAL WEIGHT 23.2kg (51.1lb) (M)
SIZE Small, Medium, Large
COLOURS Forest Green



MOTOR

TYPE Yamaha PW-X3 Class 1 Labeled Centermount
TECHNOLOGY Yamaha Quad Sensor with Automatic Support and Walk Assist Modes
RATE POWER 250W (nominal), 500W (maximum)
MAX TORQUE 85Nm
MAX SPEED SUPPORT 32.2 kph (20mph)
SUPPORT MODES ECO, Standard, High, MTB, Extra-Power, Automatic, Walk Assist

BATTERY

OUTPUT 500Wh 36V
WEIGHT 3 kg (6.61 lbs)
TECHNOLOGY Charge-life indicator and Self-diagnosis display
RE-CHARGE TIME 1-hour 80%, 4-hour 100%
MOUNTING SYSTEM Anti-Vibration Mounting Plate

DRIVE LINE COMPONENTS

SHIFTERS Shimano DEORE SL-M6100-R
FRONT DERAILLEUR N/A
REAR DERAILLEUR Shimano DEORE RD-M6100-SGS
CRANKARM PRAXIS E-CRANK ARM 165mm Length
CHAIN KMC eTURBO EPT 122 links
CASSETTE Shimano SLX CS-M7100-12 12-spd (10-51T)
CHAINRINGS PRAXIS 36T

CHASSIS

FRAME Yamaha Dual Twin Frame with Tapered Headtube
FORK ROCKSHOX REVELATION RC with 160mm of travel and Low-speed Compression adjustment
REAR SHOCK ROCKSHOX DELUXE SELECT + with 150mm of travel, 15 clicks of rebound adjustment, 2-position compression adjustment
HEADSET Integrated 1 1/8” (28.6mm)
STEM Alloy 4-both faceplate- 35.0 diameter, 40mm length
HANDLEBAR Alloy- 35.0mm diameter, 780mm width, 30mm rise
SEATPOST/SADDLE CLAMP RANZX dropper post- 30.9 diameter Travel: (S) 125mm (M) 150mm (L) 170m
SEATPOST COLLAR Single-bolt 35.0mm
SADDLE Yamaha anti-slip finish with hand rail tail
AXLES MAXLE 15MM X 110MM Boost Thru Axle
BRAKES/ROTORS MAGURA MT30 (F) 4-Piston (R) 2-Piston 203mm center lock rotor (F/R) Two-finger lever
RIMS Yamaha 27.5+ Alloy Tubeless tape installed Width: 46mm (outside) 40mm (inside)
SPOKES 14g alloy SUS304
HUBS Anodized Alloy Centerlock brake mount 15x110mm BOOST+ (F) 12x148mm MicroSpline freehub Quick Release Thru Axle Type
TIRES/TUBES MAXXIS 27.5X2.6 (F) MINION DHF (R) REKON
GRIPS VELO Single Ring Lock









2023 Yamaha YDX-Moro05 – Totalmotorcycle.com European Specifications/Technical Details

NA





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
