2023 Yamaha XMAX Guide

2023 Yamaha XMAX
Contents: ReviewKey FeaturesFeatures & BenefitsSpecifications
2023 Yamaha XMAX 2023 Yamaha XMAX 2023 Yamaha XMAX 2023 Yamaha XMAX 2023 Yamaha XMAX
Contents: ReviewKey FeaturesFeatures & BenefitsSpecifications

2023 Yamaha XMAX: MAXIMUM SPORT.

Introducing the new 2023 Yamaha XMAX…

The ultimate Sport Scooter with new Y‑Connect smartphone connectivity and a liquid‑cooled engine that is both fuel efficient and performance proven.

The XMAX is the ultimate Sport Scooter that is both fuel efficient and performance proven. High-tech features distance the XMAX from your typical bare-bones scooter and is ready to go whenever you are, whether you need to get groceries down the street or venture off into the countryside. For 2023, the XMAX receives an overhaul of updates from all-new styling to a new multi-theme screen that boasts smartphone connectivity through the Y-connect app, and a long list of other updates. Ideal for busting city traffic on weekdays and enjoying a relaxed ride on the weekend, what will you do with your XMAX?

With its excellent performance combined with dynamic good looks and class leading functionality, the high specification XMAX 300 Tech MAX is the clear choice for anyone looking for the ultimate riding experience. And now Yamaha is taking this Sport Scooter to the next level with a fully new model that offers you even more.

Equipped with high-tech 4.2-inch full colour TFT instruments featuring a multi-theme infotainment screen, this premium Sport Scooter gives you smartphone connectivity. It’s easy to receive messages and emails, select music and much more – and for stress-free highway commuting and relaxed weekend cruising, XMAX 300 Tech MAX is equipped with a new Garmin compatible navigation system.

The dynamic angular body design with its new X-shaped front lighting gives the XMAX 300 Tech MAX an even more radical and distinctive look – and new shape 3D boomerang side covers reinforce the pure MAX DNA. Featuring dedicated colours as well as exclusive aluminium footplates, a special finish on body parts and a leather style seat cover, this is the smart way to go.

RIDER CONNECTIVITY

Once connected to the Y-connect app, the 4.2-inch colour TFT display can receive messages, emails and notifications that can appear on the display. Riders can play music and various other Smartphone functions can be activated, making each ride a unique and more engaging experience. A wide range of other information and services can be accessed, including volume, weather, language, machine and riding information – and much more.

SPORTY, FUEL EFFICIENT ENGINE

Featuring technology used in Yamaha’s high-performance sport bikes, the XMAX’s 292cc liquid -cooled motor is smooth, efficient and ready for everything from the day-to-day commute to fun rides on the weekend.

CONVENIENCE FEATURES

High-tech features distance the XMAX from your typical bare-bones scooter, including LED lighting and advanced instrumentation. With plenty of lockable onboard storage, a 12V power port to recharge small devices and an adjustable handlebar and windscreen, the XMAX is a ready to go whenever you are, whether you need to get groceries down the street or head across the state.​







2023 Yamaha XMAX Totalmotorcycle.com Key Features

  • All-new styling: dynamic, high-quality MAX look
  • Smartphone connectivity
  • Garmin compatible navigation system*
  • 4.2-inch colour TFT infotainment multi-theme screen
  • Advanced 292cc Liquid Cooled Engine
  • Modern fuel injection featuring a 12-hole injector
  • Fully Automatic Continuously Variable Transmission
  • Large motorcycle-type front fork that bolts to the steering stem at both the top and bottom triple clamps
  • Large 15-inch front and 14-inch rear wheels for enhanced handling and sporty style
  • 267mm front and 245mm rear disc brakes
  • Yamaha’s Smart Key system eliminates the need to use the key to access the machine
  • 4.2-inch full colour TFT instruments
  • Smartphone connectivity
  • Onboard navigation system via smartphone
  • Dynamic body design
  • Radical X-shaped headlight
  • High-mounted front flashers
  • Full LED lighting
  • New shape seat with leather style cover
  • Storage for two full-face helmets
  • EURO5 Blue Core 300cc engine
  • Traction Control System (TCS)
  • Smart Key keyless ignition
  • Adjustable screen and handlebars
  • Tech MAX finishing
  • Dedicated Tech MAX colouring





2023 Yamaha XMAX Totalmotorcycle.com Features and Benefits

TOP FEATURES

  • Updated XMAX Styling
    For the new 2023 XMAX, Yamaha designers focused on creating a bold, modern new look. Virtually every part of the XMAX’s sleek and sporty exterior has been redesigned to create a more compact and visually impressive machine. Radical new X-shaped LED headlights and taillights complement the aggressive styling and instantly distinguish the new XMAX from anything else on the road. New high-mount LED front indicators add to the streamlined look, while a completely redesigned seat increases comfort and decreases leg reach to the ground for greater accessibility.
  • New Full-Color 4.2-inch TFT Display
    The 2023 XMAX comes equipped with one of the most impressive dashboards to be found on any Sport Scooter. This comprehensive instrumentation features a 3.2-inch LCD speedometer located above the new high-tech 4.2-inch color TFT infotainment display.
  • New Yamaha Y-Connect Smartphone Connectivity
    New for 2023, Yamaha is introducing Yamaha Motorcycle Connect (Y-Connect) smartphone connectivity for the VMAX, allowing riders to connect their smartphone directly to their scooter to enable a wide-range of convenient new capabilities including phone and music control, extensive vehicle running information collection and shareability, along with a full Garmin turn-by-turn navigation system facilitated through Garmin’s StreetCross app. Y-Connect rider selections are made via intuitive new handlebar-mounted switchgear and displayed on the new TFT screen. Best of all, Yamaha Motorcycle Connect, the Y-Connect app and the Garmin StreetCross app are all free-of-charge (available for iOS and Android).
  • Sporty, Fuel Efficient Engine
    Featuring technology used in Yamaha’s high-performance sport bikes, the XMAX’s 292cc single-cylinder Blue Core engine is smooth, efficient and ready for everything from the day-to-day commute to fun rides on the weekend.
  • Convenience & Technology
    With a fully-automatic transmission, the XMAX is exceedingly simple to ride and comes standard with an extensive list of rider aids, including Traction Control and ABS. Combined with a frame designed for light and neutral handling, the XMAX makes for a confidence-inspiring ride on any road.
  • Luxury + Comfort + Practicality
    High-tech features distance the XMAX from your typical bare-bones scooter, including the unique new LED lighting and advanced new instrumentation. With plenty of lockable onboard storage, a 12V power port to recharge small devices and an adjustable handlebar and windscreen, the XMAX is a ready to go whenever you are, whether you need to get groceries down the street or head across the state.



ENGINE

  • Advanced 292cc Engine
    The XMAX is powered by an advanced 292cc liquid-cooled, four-valve single that develops smooth, tractable power. The cylinder is crafted from Yamaha’s DiASil aluminum for excellent heat dissipation, with a lightweight forged piston and forged crankshaft. A counterbalancer ensures minimal vibration while the offset cylinder layout and semi-dry-sump lubrication system help reduce friction and drag inside the engine.
  • Full Automatic Convenience
    Thanks to Yamaha’s Continuously Variable Transmission, the XMAX offers the convenience of truly ‘twist and go’ riding, with no gears and no clutch. This gives the XMAX an easy-going riding character that is ideal for busting city traffic on weekdays and enjoying a relaxed ride on the weekend. The CVT system also features a large air-cooling path for the drive belt, reducing heat and engine noise significantly.
  • Fuel Injection & Traction Control
    Modern fuel injection features a 12-hole injector for excellent response, and just like Yamaha’s cutting edge supersport and sport-touring machines, the XMAX features a Traction Control System. The TCS continuously monitors wheel speeds, and if the system detects rear tire slip, the engine smoothly cuts power to help prevent uncontrolled wheelspin.
  • Impressive Fuel Economy & Range
    Thanks to the efficient engine design features and advanced powertrain, the XMAX delivers 75 mpg. Combined with a large 3.4-gallon fuel tank, the XMAX boasts impressive cruising range.



CHASSIS/SUSPENSION

  • MAX Series DNA
    The XMAX pushes the design envelope with advanced sport styling and aggressive, angular cues that set this Yamaha way ahead of the competition with its high-class appearance that elevates the XMAX beyond expectations.
  • Motorcycle-Type Front Fork
    Unlike most scooters, the XMAX features a large motorcycle-type front fork that bolts to the steering stem at both the top and bottom triple clamps. This provides an ideal balance of strength and chassis rigidity, and better damping feel and shock absorption when compared to typical scooter-style forks.
  • Lightweight Steel Frame
    Designed for light and neutral handling character, the XMAX’s steel frame results in a wet weight of only 397 pounds fully fueled which makes for exceptional maneuverability.
  • Large Wheels & Tires
    The XMAX features large 15-inch front and 14-inch rear wheels for enhanced handling and sporty style. The XMAX also mounts the latest Dunlop® Scoot Smart tires for excellent traction in both wet and dry conditions.
  • Anti-Lock Braking System
    With large 267mm front and 245mm rear disc brakes, the XMAX gives the rider controllable braking power. Backed by the security of Yamaha’s anti-lock braking system, you’ll have confidence in all sorts of road conditions.



ADDITIONAL FEATURES

  • Smart Key System
    Yamaha’s Smart Key system eliminates the need to use the key to access the machine. Starting the bike, accessing the storage compartments and fuel tank, and locking the handlebar can all be done using the proximity Smart Key.
  • Redesigned Seat
    A completely redesigned seat is more comfortable and decreases leg reach to the ground for greater accessibility.
  • All-Inclusive Storage
    Further boosting convenience is a huge underseat storage area that locks securely to keep valuables safe and is large enough for two full-face helmets. LED lighting comes standard, and the fairing also includes two additional storage bays, one of which locks electronically and includes a 12V DC outlet.
  • Distinctive New LED Lighting
    Boosting both style and visibility, the XMAX uses LED lighting for sharp, visible taillights and brilliant, roadway illuminating headlights. Radical new X-shaped LED headlights and taillights complement the aggressive styling and instantly distinguish the new XMAX from anything else on the road. New high-mount LED front indicators add to the streamlined look. LEDs also use less power and last much longer than conventional bulbs, reducing maintenance needs.
  • Adjustable Handlebar & Windscreen
    The XMAX includes an adjustable handlebar with 20mm of rearward adjustment, and can be changed quickly with zero additional parts. The XMAX also features a two-position windscreen that can be shifted two inches higher for additional wind protection. Finally, the sculpted saddle makes it easier to reach the ground at stops and works with the floorboards for a flexible all-day riding position.
  • Ready to Accessorize
    Personalize your XMAX with a range of Yamaha Genuine Accessories, including luggage, accessory mounts, backrests and more. See the full range of accessories on ShopYamaha.com.



NEW FOR 2023

  • Updated XMAX Styling
    For the new 2023 XMAX, Yamaha designers focused on creating a bold, modern new look. Virtually every part of the XMAX’s sleek and sporty exterior has been redesigned to create a more compact and visually impressive machine. Radical new X-shaped LED headlights and taillights complement the aggressive styling and instantly distinguish the new XMAX from anything else on the road. New high-mount LED front indicators add to the streamlined look, while a completely redesigned seat increases comfort and decreases leg reach to the ground for greater accessibility.
  • New Full-Color 4.2-inch TFT Display
    The 2023 XMAX comes equipped with one of the most impressive dashboards to be found on any Sport Scooter. This comprehensive instrumentation features a 3.2-inch LCD speedometer located above the new high-tech 4.2-inch color TFT infotainment display.
  • New Yamaha Y-Connect Smartphone Connectivity
    New for 2023, Yamaha is introducing Yamaha Motorcycle Connect (Y-Connect) smartphone connectivity allowing riders to connect their smartphone directly to the XMAX, enabling a wide-range of convenient new capabilities including phone and music control, extensive vehicle running information collection and shareability, along with a full Garmin turn-by-turn navigation system enabled through Garmin’s StreetCross app. Y-Connect rider selections are made via intuitive new handlebar-mounted switchgear and displayed on the new TFT screen. Best of all, Yamaha Motorcycle Connect, the Y-Connect app and the Garmin StreetCross app are all free-of-charge (available for iOS and Android).











2023 Yamaha XMAX – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $6099 USD
Canada MSRP Price: $7599 CDN
Europe/UK MSRP Price: £6700 GBP (On The Road inc 20% Vat)

Engine Type 292cc liquid-cooled 4-stroke, SOHC single
cylinder; 4 valves
Bore x Stroke 70.0mm x 75.9mm
Compression Ratio 10.9:1
Fuel Delivery Fuel Injection
Ignition TCI: Transistor Controlled Ignition
Transmission Automatic CVT
Final Drive V-Belt
Suspension / Front 33mm telescopic fork; 4.3-in travel
Suspension / Rear Dual shocks; 3.1-in travel
Brakes / Front Hydraulic disc, 267mm; ABS
Brakes / Rear Hydraulic disc, 245mm; ABS
Tires / Front 120/70-15 Dunlop® Scoot Smart
Tires / Rear 140/70-14 Dunlop® Scoot Smart
L x W x H 86.0 in x 30.5 in x 55.7 in – 57.7 in
Seat Height 31.3 in
Wheelbase 60.6 in
Rake (Caster Angle) 26.5°
Trail 3.7 in
Maximum Ground
Clearance
5.3 in
Fuel Capacity 3.4 gal
Fuel Economy** 76 mpg
Wet Weight*** 397 lb
Warranty 1 Year (Limited Factory Warranty)
Color Granite Gray





2023 Yamaha XMAX – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE
ENGINE Liquid-cooled, SOHC, 4-valve, single
DISPLACEMENT 292cc
BORE AND STROKE 70.2 x 75.9 mm
COMPRESSION RATIO 10.9 : 1
MAXIMUM TORQUE 1.4 kg-m (10 ft-lb) @ 6,000 rpm
FUEL DELIVERY Fuel Injection
ESTIMATED FUEL CONSUMPTION± 3.14 L/100km / 75 mpg
LUBRICATION Wet Sump
IGNITION / STARTING TCI / Electric Start
TRANSMISSION Fully automatic CVT
FINAL DRIVE V-belt

CHASSIS
SUSPENSION (FRONT) 33mm telescopic fork / 109.2 mm (4.3″) wheel travel
SUSPENSION (REAR) Dual shocks / 78.7 mm (3.1″) wheel travel
BRAKES (FRONT) 267mm disc / twin piston caliper / ABS
BRAKES (REAR) 245mm disc / single piston caliper / ABS
TIRES (FRONT) 120/70-15
TIRES (REAR) 140/70-14

CRITICAL DATA
LENGTH 2,184mm (86″)
WIDTH 774.7mm (28.1″)
HEIGHT 1,415mm (55.7″)
WHEELBASE 1,539mm (60.6″)
GROUND CLEARANCE 135mm (5.3″)
SEAT HEIGHT 795mm (31.3″)
FUEL CAPACITY 12.9 litres (2.8 Imp. gallons)
WET WEIGHT 180kg (397 lb)
COLOUR(S) Matte Grey





2023 Yamaha XMAX – Totalmotorcycle.com European Specifications/Technical Details

Engine
Engine type 4-stroke;Liquid-cooled;SOHC;4-valves;EURO5;Single
cylinder
Displacement 292cc
Bore x stroke 70.0 × 75.9 mm
Compression ratio 10.9:1
Maximum power 20.6 kW @ 7,250 rpm
Maximum torque 29.0 Nm @ 5,750 rpm
Lubrication system Wet sump
Fuel system Fuel Injection
Ignition system TCI
Starter system Electric
Transmission system V-Belt Automatic
Fuel consumption 3.0L/100km
CO2 emission 70 g / km
Chassis
Front suspension system Telescopic forks
Front travel 110 mm
Rear suspension system Unit Swing
Rear travel 95 mm
Front brake Hydraulic single disc, Ø267 mm
Rear brake Hydraulic single disc, Ø245 mm (ABS)
Front tyre 120/70-15
Rear tyre 140/70-14
Dimensions
Overall length 2180 mm
Overall width 795 mm
Overall height 1410 mm – 1460 mm (adjustable windscreen)
Seat height 795 mm
Wheelbase 1540 mm
Minimum ground clearance 135 mm
Wet weight 183 kg
Fuel tank capacity 13.2L







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
