2023 Yamaha YZ250F Guide

2023 Yamaha YZ250F

2023 Yamaha YZ250F 2023 Yamaha YZ250F 2023 Yamaha YZ250F 2023 Yamaha YZ250F

2023 Yamaha YZ250F: DOMINATE THE TRACK.

Introducing the new 2023 Yamaha YZ250F…

The multi‑championship‑winning YZ250F dominates on the race track, at the shootouts and basically everywhere it goes.

The multi-championship-winning YZ250F dominates on the race track, at the shootouts and basically everywhere it goes. And with the Monster Energy Yamaha Racing Edition, privateers can have that factory look whether on the practice track or the starting gate.

YZ250F
With an outstanding track record that includes numerous MX2 Grand Prix race wins as well as a string of 250 Supercross titles in the USA, the YZ250F is born to win. And with its reduced unsprung weight and refined suspension performance, this high-tech motocross weapon is sharper, quicker and smoother – ready to own the podium.

Tune. Race. Win.
A key feature of the YZ250F is the high-tech reverse head 250cc engine. Its unique front facing inlet forces fresh air into the fuel injector to give you holeshot-winning acceleration and instant power whenever you need it. And this compact engine layout contributes significantly towards the bike’s agile handling by centralising mass.

When track surfaces or the weather changes, the Power Tuner app enables you to adjust your YZ250F’s engine settings from smooth through to aggressive. The SSS (Speed Sensitive System) front forks and race-proven monocross suspension feature new low speed damping settings – while the sophisticated aluminium chassis with its inbuilt balance of rigidity provides plenty of feedback. Fast, agile and smart, the tuneable YZ250F is built to deliver the ultimate performance at every track.

YZ250F
Motocross is one of the toughest sports there is. If you want to succeed you’ve got to grab every opportunity to sharpen your performance. Because every second counts. And the YZ250F’s reverse head engine delivers holeshot-winning acceleration and instant power that enables you to constantly outsmart the opposition.

ADVANCED 250CC FOUR-STROKE ENGINE

The YZ250F’s liquid-cooled, DOHC 4-valve, fuel-injected powerplant features a forward-positioned straight downdraft intake with symmetrical intake/exhaust ports, high-spec piston, aggressive cam profiles and reversed cylinder head layout. The advanced four-stroke engine is known for its broad, useable powerband and class-leading low-end and mid-range torque.

INNOVATIVE POWER TUNER APP

The free-of-charge Yamaha Power Tuner app brings the power of the GYTR® Power Tuner to your iOS® or Android® device. Using wireless connectivity to talk to the bike’s onboard CAN-bus network, the app allows owners to adjust air/fuel mixture and ignition timing maps to tune engine performance for track conditions, record race log information and monitor a range of data such as maintenance and system diagnosis, engine run time and more.

ADVANCED BILATERAL ALUMINUM FRAME

The YZ250F’s aluminum bilateral beam frame features main spars, engine mounts and mounting position that are designed to centralize mass and provide an ideal balance between cornering feel and straight-line rigidity.









2023 Yamaha YZ250F Totalmotorcycle.com Key Features
  • Best in class suspension
  • Lightweight chassis components
  • MX2 race-winning engine design
  • Wide rear rim and tyre
  • New graphics and duo-tone body colours
  • Handlebar-mounted 2-mode mapping switch
  • Large-piston brake caliper
  • Lightweight aluminium beam frame
  • Easy-to-use Power Tuner app
  • Full Features & Tech Specs
  • Advanced 250cc Four-Stroke Engine
    Featuring a high-spec piston, aggressive cam profiles and reversed cylinder head layout, the YZ250F’s advanced four-stroke engine is known for its broad, useable powerband and class-leading low-end and mid-range torque.
  • Innovative Yamaha Power Tuner App
    Yamaha’s industry-leading Power Tuner App puts the flexibility and precision tunability of the GYTR® Power Tuner into your smartphone. Make fueling and ignition timing changes instantly and upload them to the bike for ultimate track-side tuning. Best of all, it’s free-of-charge.
  • Advanced Bilateral Aluminum Frame
    The YZ250F’s aluminum bilateral beam frame features main spars, engine mounts and mounting position that are designed to centralize mass and provide an ideal balance between cornering compliance and straight-line stability.
  • High Performance Braking System
    Rigid front caliper, large-diameter pistons and large 270mm front brake rotor is the same system fitted to the YZ450F. Compact rear caliper works with a 240mm rotor and aggressive pad material for exceptional stopping power and braking control.
  • Electric Starter System
    Utilizing a compact starter motor and ultra-lightweight lithium battery, the YZ250F brings the convenience of push-button starting to the racetrack for effortless restarts under pressure and relaxed riding when the clock isn’t ticking.
  • Sharp, Durable Graphics Scheme
    Sharp competition-inspired graphics scheme highlights the YZ’s unmatched racing pedigree. Premium Yamaha Blue and dark blue graphics are embedded to provide excellent durability and scratch resistance. Blacked-out radiator louvers add to the aggressive look.





2023 Yamaha YZ250F Totalmotorcycle.com Features and Benefits

ENGINE

  • Advanced 250cc Four-Stroke Engine
    The YZ250F’s liquid-cooled, DOHC 4-valve, fuel-injected powerplant features a forward-positioned straight downdraft intake with symmetrical intake ports, high-spec piston, aggressive cam profiles and reversed cylinder head layout. The advanced four-stroke engine is known for its broad, useable powerband and class-leading low-end and mid-range torque.
  • Innovative Yamaha Power Tuner App
    The free-of-charge Yamaha Power Tuner App brings the power of the GYTR® Power Tuner to your iOS® or Android® device. Using wireless connectivity to talk to the bike’s onboard CAN-bus network, the app allows owners to adjust air/fuel mixture and ignition timing maps to tune engine performance for track conditions, record race log information and monitor a range of data such as maintenance and system diagnosis, engine run time and more.
  • Adjustable Engine Maps
    Two-mode adjustable engine mapping allows the rider to adjust engine character with the push of a button, making it easy to make immediate adjustments to changing track or weather conditions.
  • Piston, Rod & Crankshaft Balance
    A flat-top forged piston features a bridge-box design for additional strength with minimal weight. The piston, rings and DLC-coated piston pin, along with the offset cylinder configuration, all reduce friction loss and contribute to quick response. The engine’s intake ports, cam profiles, high-strength connecting rod and optimized crank and counter-balancer all work together to produce potent high-rpm power with user-friendly delivery and exceptional reliability.
  • Advanced Fuel Injection
    The adjustable fuel injection system uses a 44mm throttle body, fed by a high-pressure electric fuel pump, to inject fuel through a 12-hole Denso® injector. This ensures optimum fuel atomization and air/fuel calibration for excellent rideability in a wide range of riding conditions.
  • Wraparound Rear-Positioned Exhaust Layout
    An innovative exhaust pipe design improves mass centralization and power development characteristics. This layout moves the rear end of the exhaust pipe farther forward and positions the muffler closer to the bike’s center of mass.
  • Durable Transmission
    The transmission gears, dogs and shift mechanisms are designed to smooth gear changes and improve durability under the heavy demands of motocross racing. The YZ250F also features a large-diameter clutch to boost reliability even further under high-heat conditions.



CHASSIS/SUSPENSION

  • Advanced Bilateral Aluminum Frame
    The bilateral aluminum frame features flex characteristics that give riders the ultimate combination of precise cornering performance and handling stability. Large upper frame bracing improves rigidity and durability. The wider rear frame spars, and the YZ250F-specific engine mounts centralize mass for the best possible balance of impact absorption, stiffness and feeling of grip.
  • Class-Leading Suspension
    Fully adjustable KYB® coil spring-type fork with speed-sensitive damping delivers exceptional balance between handling and bump absorption for championship-winning performance. The linkage-type rear suspension features a KYB® shock optimized to provide less pitch on corner entry/exit and improved stability.
  • High Performance Braking System
    Rigid front caliper, large-diameter pistons and large 270mm front brake rotor is the same system fitted to the YZ450F. Compact rear caliper works with a 240mm rotor and aggressive pad material for exceptional stopping power and braking control.
  • Compact Body & Seat Design
    The YZ250F utilizes compact bodywork from tip to tail, including a narrow fuel tank specifically designed for motocross demands. In addition to shaving weight, the body design provides more comfortable knee grip for better control, with a seat shaped to give the rider additional room to move aboard the machine.
  • Enhanced Mass-Centralization
    The compact engine, wraparound exhaust and fuel tank are strategically positioned to enhance mass centralization for a lightweight handling feeling on the track. The wide 55mm footpegs help lower the rider’s center of gravity for improved balance, control and rider comfort.
  • Reduced Unsprung Weight
    Lightweight rear hub, rear sprocket and drive chain reduce unsprung weight and driveline inertia, contributing to more agile handling.
  • Strong, Lightweight Wheels
    Careful computer-aided refinement of each wheel’s cross-sectional profile shaves valuable weight without sacrificing durability. Three-cross-spoke pattern on the rear wheel improves impact absorption and overall feel.



ADDITIONAL FEATURES

  • Race-Winning Details
    The YZ250F boasts top-spec details including 1-1/8-inch aluminum tapered handlebars secured to four-position adjustable handlebar mounts, wide 55mm footpegs, a quick-adjust clutch perch, stylish blue rims and a lightweight gold drive chain.
  • Simplified Servicing
    Sleek air cleaner cover provides tool-free access to the air filter, positioned at the front of the bike to avoid roost from the rear wheel.









2023 Yamaha YZ250F – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8599 USD
Canada MSRP Price: $10299 – $10499 CDN
Europe/UK MSRP Price: from £8400 GBP (On The Road inc 20% Vat)

Engine Type 250cc liquid-cooled DOHC 4-stroke; 4 valves
Bore x Stroke 77.0mm × 53.6mm
Compression Ratio 13.8:1
Fuel Delivery Mikuni® fuel injection, 44mm
Transmission Constant-mesh 5-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front KYB® Speed-Sensitive System inverted fork;
fully adjustable, 12.2-in travel
Suspension / Rear KYB® single shock; fully adjustable, 12.5-in
travel
Brakes / Front Hydraulic disc, 270mm
Brakes / Rear Hydraulic disc, 240mm
Tires / Front 80/100-21 Dunlop® Geomax MX33F
Tires / Rear 110/90-19 Dunlop® Geomax MX33
L x W x H 85.6 in x 32.5 in x 50.6 in
Seat Height 38.2 in
Wheelbase 58.1 in
Rake (Caster Angle) 26.8°
Trail 4.7 in
Maximum Ground
Clearance
13.2 in
Fuel Capacity 1.6 gal
Wet Weight 234 lb
Warranty 30 Day (Limited Factory Warranty)
Color Team Yamaha Blue





2023 Yamaha YZ250F – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE

ENGINE 4-stroke, liquid-cooled, DOHC, 4-valve (titanium), single
DISPLACEMENT 250 cc
BORE AND STROKE 77 x 53.6 mm
COMPRESSION RATIO 13.8:1
FUEL DELIVERY 44 mm Mikuni throttle body F.I.
LUBRICATION Wet sump
IGNITION / STARTING TCI
TRANSMISSION Constant-mesh 5-speed
FINAL DRIVE Chain



CHASSIS

SUSPENSION (FRONT) Fully adj. 48mm KYB SSS inverted fork / 310 mm (12.2 in) wheel travel
SUSPENSION (REAR) Fully adj. KYB monoshock / 317 mm (12.5 in) wheel travel
BRAKES (FRONT) 270 mm, floating hydraulic wave disc / twin-piston caliper
BRAKES (REAR) 240 mm hydraulic wave disc / single piston caliper
TIRES (FRONT) 80/100-21 Dunlop® Geomax MX33F
TIRES (REAR) 110/90-19 Dunlop® Geomax MX33



CRITICAL DATA

LENGTH 2,175 mm (85.6 in)
WIDTH 825 mm (32.5 in)
HEIGHT 1,285 mm (50.6 in)
WHEELBASE 1,475 mm (58.1 in)
GROUND CLEARANCE 335 mm (13.2″)
SEAT HEIGHT 970 mm (38.2″)
FUEL CAPACITY 6 litres (1.3 imp. gal.)
WET WEIGHT 106 kg (234 lb)
COLOUR(S) Yamaha Racing Blue, Monster Energy Yamaha Racing Edition









2023 Yamaha YZ250F – Totalmotorcycle.com European Specifications/Technical Details

Engine
Engine type 4-stroke;Liquid-cooled;DOHC;4-valves;Single cylinder
Displacement 250cc
Bore x stroke 77.0 × 53.6 mm
Compression ratio 13,8 : 1
Lubrication system Wet sump
Clutch type Wet;Multiple Disc
Ignition system TCI
Starter system Electric
Transmission system 5-speed;Constant Mesh
Final transmission Chain
Fuel system Electronic Fuel Injection
Chassis
Frame Semi double cradle
Caster angle 26° 50
Trail 119 mm
Front suspension system Upside-down telescopic fork
Rear suspension system link suspension;Swingarm
Front travel 310 mm
Rear travel 317 mm
Front brake Hydraulic Single Disc, Ø270 mm
Rear brake Hydraulic Single Disc, Ø240 mm
Front tyre 80/100-21 51M Tube type
Rear tyre 110/90-19 62M Tube type
Dimensions
Overall length 2175 mm
Overall width 825 mm
Overall height 1285 mm
Seat height 970 mm
Wheel base 1475 mm
Minimum ground clearance 335 mm
Wet weight (including full oil and fuel tank) 106 kg
Fuel tank capacity 6.2 L
Oil tank capacity 0.95 L







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
