2023 Yamaha YZ85 Guide

2023 Yamaha YZ85

2023 Yamaha YZ85 2023 Yamaha YZ85 2023 Yamaha YZ85 2023 Yamaha YZ85

2023 Yamaha YZ85: VICTORY: NEVER GIVEN, ALWAYS EARNED.

Introducing the new 2023 Yamaha YZ85…

Built for fun. Built to win. The updated YZ85 serves up big‑bike specs in a small‑bike package.

The YZ85 serves up big-bike specs in a small-bike package. Boasting many premium features to earn its stripes in the YZ lineup, the YZ85 is ready to win races straight off the dealership floor.

Ready to raise your game? This is the bike that is ready to power you to another level. Equipped with dynamic new slimline bodywork and featuring an enhanced chassis, improved riding position and a refined braking system, the sharp new YZ85 is built for the victorYZone.

Victory. Never given, always earned.
Many of today’s pro riders started their careers on the YZ85. And when you take a look at what the new model has to offer you can see why. Its high performance 85cc liquid-cooled 2-stroke engine is equipped with Yamaha’s race-bred YPVS that gives you race-winning performance. And its adjustable suspension systems are built to master the toughest tracks.

The YZ85 also comes with a new, lightweight aluminium rear frame as well as a revised aluminium swingarm, new rear brake system and revised high-efficiency air intake – just like the bigger YZ125. For maximum rider control there’s a new flatter seat, a slimmer body and a redesigned fuel tank. And with a duo-tone Icon Blue colour scheme and revised graphics completing the looks, the YZ85 is ready to power you to the next level.

YZ85
You’ve developed your skills and refined your style on smaller bikes – and now you’re moving on to the next stage. Choosing the right motocross bike is an important decision. And when you take a look at what the new YZ85 has to offer, it’s clear that this is the way to go.



ENGINE

The 85cc liquid-cooled, two-stroke engine features the Yamaha Power Valve System for broad power across the rev range without losing peak power at high rpms—improving rideability and reducing the need for frequent shifting.



CHASSIS

The 85cc liquid-cooled, two-stroke engine features the Yamaha Power Valve System for broad power across the rev range without losing peak power at high rpm—improving rideability and reducing the need for frequent shifting.



SHARP NEW GRAPHICS

Inspired by its YZ125 sibling, the aggressive graphics scheme highlights the YZ’s unmatched racing pedigree. Premium Yamaha Blue and dark blue graphics are embedded to provide excellent durability and scratch resistance.





2023 Yamaha YZ85 Totalmotorcycle.com Key Features
  • Slim bodywork
  • Flat seat and ergonomic fuel tank
  • Lightweight aluminium rear frame
  • Aluminium swingarm
  • 85cc liquid cooled 2-stroke engine with YPVS
  • High-efficiency air intake
  • Fully adjustable 36-mm KYB® upside down front forks
  • Link-type Monocross rear suspension
  • Self-cleaning wave discs
  • YPVS™ Two-Stroke Power
    The 85cc liquid-cooled, two-stroke engine features the Yamaha Power Valve System (YPVS™) for increased low- and mid-range power without losing peak power at high rpms, reducing the need for frequent shifting.
  • Fully-Adjustable Suspension
    Lightweight 36mm KYB® inverted cartridge fork features low-friction outer tubes, external compression and rebound damping adjustability, paired with a race-proven fully-adjustable KYB® rear shock. Both offer loads of suspension travel to tackle serious off-road competition.
  • Optimized Chassis Design
    Built for demanding junior racers, the YZ85’s chassis is optimized for strength, rigidity and overall handling stability. The aluminum swingarm offers refined balance between longitudinal and torsional rigidity, and the removable rear subframe constructed from lightweight, high-strength aluminum reduces weight.
  • Performance-Minded Ergonomics
    The flat seat and narrow fuel tank design, along with smoothly integrated body panels and slim shroud width, combine to enable greater freedom of movement forward and back, allowing the rider to easily shift body weight for increased control and confidence.
  • High-Spec Wheels & Brakes
    Stylish blue, lightweight 17-inch front and 14-inch rear rims are durable, reduce unsprung weight for optimal suspension performance, and come wrapped in Dunlop® MX3S tires for exceptional traction. Big 220mm and 190mm disc brakes offer precise control and outstanding stopping power.
  • High-Quality Embedded Graphics
    Inspired by its YZ125 sibling, the aggressive graphics scheme highlights the YZ’s unmatched racing pedigree. Premium Yamaha Blue and dark blue graphics are embedded to provide excellent durability and scratch resistance.







2023 Yamaha YZ85 Totalmotorcycle.com Features and Benefits

ENGINE

  • Potent YPVS™ Two-Stroke Engine
    The 85cc liquid-cooled, two-stroke engine features the Yamaha Power Valve System (YPVS™) for broad power across the rev range without losing peak power at high rpms, reducing the need for frequent shifting.
  • Tuned Crankcase & Intake
    The crankcase design features a spacer-style reed valve intake for improved air/fuel flow, which inhales through a 28mm Hitachi Astemo® Keihin flat-slide carburetor for seamless throttle response.
  • Tuned Expansion Chamber
    Carefully matched to suit the YPVS™-equipped engine, the exhaust expansion chamber optimizes gas flow for enhanced power delivery, especially in the low- and mid-range.
  • Durable Transmission
    The transmission features oversized gears to provide enhanced engagement and smoother shifts.
  • High Capacity Radiator
    Lightweight radiator has large cores and louvers. Water pump features a cast aluminum (vs. resin) impeller for maximum cooling efficiency.
  • Advanced Intake Design & High-Flow Airbox
    Advanced intake design allows for a straighter, more efficient draw of air into the intake tract. High-flow airbox ensures excellent air filter performance and easy maintenance.



CHASSIS/SUSPENSION

  • Fully-Adjustable Fork
    The lightweight 36mm KYB® inverted cartridge fork features 10.8 inches of travel with compression and rebound damping adjustability. Complete with low-friction outer tubes and internals, the damping settings offer enhanced performance across a range of conditions and rider abilities.
  • Fully-Adjustable Shock
    Rear suspension features fully adjustable KYB® link-type shock with race-tested valving and 11.1 inches of travel. The progressive linkage-type design improves bottoming resistance, allowing racers to charge harder and improve lap times.
  • Optimized Chassis Design
    Built for demanding junior racers, the YZ85’s chassis is optimized for strength, rigidity and overall handling stability. The aluminum swingarm offers refined balance between longitudinal and torsional rigidity, and the removable rear subframe constructed from lightweight, high-strength aluminum reduces weight.
  • Large-Diameter Brakes
    Big wave-style brake discs offer improved self-cleaning and cooler-running performance. The 220mm front disc and 190mm rear disc deliver strong, precise stopping power. Rear brake master cylinder also includes built-in sub-reservoir to provide more linear brake response and increased control.
  • Lightweight Wheels
    Lightweight 17-inch front and 14-inch rear rims are durable and reduce unsprung weight for optimal suspension performance.
  • High Performance Tires
    Dunlop® MX3S tires provide exceptional traction on a variety of tracks and terrain.

ADDITIONAL FEATURES

  • Adjustable Rider Ergonomics
    The four-position adjustable handlebar mounts and taper-style handlebar allow the rider to tune the handlebar position to suit their size and preferences. Flat seat and narrow fuel tank design, along with smoothly integrated body panels and slim shroud width, combine to enable greater freedom of movement for increased control and confidence.









2023 Yamaha YZ85 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $5099 USD
Canada MSRP Price: $6799 CDN
Europe/UK MSRP Price: from £ GBP (On The Road inc 20% Vat)

Engine Type 85cc liquid-cooled 2-stroke; reed-valve inducted
Bore x Stroke 47.5mm x 47.8mm
Compression Ratio 8.2~9.6:1
Fuel Delivery Hitachi Astemo® Keihin PWK28 carburetor
Transmission 6-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front KYB® inverted fork; fully adjustable, 10.8-in
travel
Suspension / Rear KYB® single shock; fully adjustable, 11.1-in
travel
Brakes / Front Hydraulic disc, 220mm
Brakes / Rear Hydraulic disc, 190mm
Tires / Front 70/100-17 Dunlop® Geomax MX3SF
Tires / Rear 90/100-14 Dunlop® Geomax MX3S
L x W x H 71.7 in x 29.9 in x 44.7 in
Seat Height 33.1 in
Wheelbase 49.4 in
Rake (Caster Angle) 26.3°
Trail 3.5 in
Maximum Ground
Clearance
12.6 in
Fuel Capacity 1.3 gal
Wet Weight 161 lb
Warranty 30 Day (Limited Factory Warranty)
Color Team Yamaha Blue





2023 Yamaha YZ85 – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE
ENGINE 2-stroke, liquid-cooled, crankcase-reed-valve single with YPVS
DISPLACEMENT 85cc
BORE AND STROKE 47.5 x 47.8 mm
COMPRESSION RATIO 8.2-9.6:1
FUEL DELIVERY Keihin PWK28
IGNITION / STARTING CDI / Kick
TRANSMISSION Constant mesh, 6-speed
FINAL DRIVE Chain

CHASSIS
SUSPENSION (FRONT) Fully adjustable KYB 36 mm inverted fork / 275 mm (10.8 in) wheel travel
SUSPENSION (REAR) Fully adjustable KYB shock / 282 mm (11.1 in) wheel travel
BRAKES (FRONT) 220 mm disc / twin-piston caliper
BRAKES (REAR) 190 mm disc / single-piston caliper
TIRES (FRONT) 70/100-17 Geomax MX3SF
TIRES (REAR) 90/100-14 Geomax MX3S

CRITICAL DATA
LENGTH 1,820 mm (71.7 in)
WIDTH 760 mm (29.9 in)
HEIGHT 1135 mm (44.7 in)
WHEELBASE 1255 mm (49.4 in)
GROUND CLEARANCE 320 mm (12.6 in)
SEAT HEIGHT 840 mm (33.1 in)
FUEL CAPACITY 5 litres (1.1 imp. gal.)
WET WEIGHT 73 kg (161 lb)
COLOUR(S) Yamaha Racing Blue







2023 Yamaha YZ85 – Totalmotorcycle.com European Specifications/Technical Details

Engine
Engine type Liquid-cooled;Single cylinder;Reed valve with YPVS;2-
stroke
Displacement 85cc
Bore x stroke 47.5 × 47.8 mm
Compression ratio 8,2 – 9,6 : 1
Lubrication system Premix
Clutch type Wet;Multiple Disc
Ignition system CDI
Starter system Kick
Transmission system Constant Mesh;6-speed
Final transmission Chain
Fuel system Keihin PWK28/1
Chassis
Frame Semi double cradle
Caster angle 26° 00
Trail 99 mm
Front suspension system Telescopic fork
Rear suspension system Swingarm;(Link type suspension)
Front travel 275 mm
Rear travel 287 mm
Front brake Hydraulic Single Disc, Ø220 mm
Rear brake Hydraulic Single Disc, Ø190 mm
Front tyre 70/100-19 42M Tube type
Rear tyre 90/100-16 52M Tube type
Dimensions
Overall length 1895 mm
Overall width 760 mm
Overall height 1175 mm
Seat height 885 mm
Wheel base 1285 mm
Minimum ground clearance 360 mm
Wet weight (including full oil and fuel tank) 75 kg
Fuel tank capacity 5.0 L
Oil tank capacity 0.5 L







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
