Is it the Handling? The Horsepower? Or the Looks?

The all-new 2004 Yamaha YZF-R6 begins with a radical new DeltaBox III frame. The first street motorcycle ever to use our new Controlled Filling Die Casting technique, resulting in a lighter aluminum frame that’s stiffer. What once took 16 welds now requires two.


2003 Yamaha YZF-R6 Features and Benefits

Revisions to the steering head give even greater feedback. And a 10mm longer swingarm and repositioned swingarm pivot improve traction.






2003 Yamaha YZF-R6 – Specifications/Technical Details
USA MSRP Price: $7,999; $8,099 Black with Red flame graphics USD
Canadian MSRP Price: See dealer for pricing in CDN

DIMENSIONS
Length 79.7 in.

Height 42.9 in.

Width 27.2 in.

Weight 357 lbs.

Wheelbase 54.3 in.

Seat Height 32.3 in.

ENGINE
Engine 600cc, liquid-cooled, 4-stroke, forward inclined in-line 4-cylinder, DOHC 16 valves

Displacement 600cc

Bore x Stroke 65.5 x 44.5mm

Compression Ratio 12:4:1

Carburetion Suction-piston fuel injection w/38mm throttle bodies (4), w/throttle position and RPM sensors

Fuel Capacity 4.5 gal.

Ignition Digital DC-CDI

Clutch Multi-plate

DRIVETRAIN
Transmission 6-Speed

Final Drive #530 O-ring chain

BRAKES/WHEELS/TIRES
Brakes Front: Dual 298mm floating discs w/4-piston calipers
Rear: 220mm disc w/single-piston caliper

Tires Front: 120/60-ZR17
Rear: 180-55-ZR17

OPERATIONAL
Suspension Front: 43mm telescopic fork w/adj. preload, compression and rebound damping; 4.7 in. travel
Rear: Single shock w/piggyback reservoir and adj. preload, compression and rebound damping; 4.7 in. travel

OTHER
Colors
Team Yamaha Blue/White
Liquid Silver
Black with Red flame graphics

Specifications are subject to change without notice, in accordance with national regulation and legislations. Suggested Starting Price shown does not include tax, title, or destination charge. Dealer prices may vary.
