2004 Ducati Monster S4R Review

2004 Ducati Monster S4R

A new wind

The S4R is the top of the range Monster – the most powerful, highest-performance Monster ever. It all starts with the 996 cc Superbike engine and lightweight Superbike-derived trellis frame to ensure the perfect combination of power and handling. A Showa fully-adjustable front fork with low friction TiN treatment and a fully-adjustable Showa rear shock handle suspension duties.

The exclusive Ducati Superbike rising rate, ride height adjustable rear suspension system includes a new single-sided aluminum swingarm. An extraordinarily beautiful “two into one into two” exhaust has been designed for the S4R. With both silencers positioned high and on the right side of the bike, the system has an aggressive and powerful new look.

113 horsepower combined with the S4R’s lightweight of 193 kg/425 lbs results in an inspiring power-to-weight ratio. Twisting the throttle of the S4R is thrilling. A close ratio gearbox just adds to the excitement.


2004 Ducati Monster S4R Key Features








2004 Ducati Monster S4R – Specifications/Technical Details
USA MSRP Price: See dealer for pricing in USD
Canadian MSRP Price: See dealer for pricing in CDN

Engine
TYPE
L-Twin cylinder, 4 valve per cylinder Desmodromic, liquid cooled
DISPLACEMENT
996cc
BORE X STROKE
98x66mm
COMPRESSION RATIO
11.6:1
POWER
113hp – 83.4kw @ 8750rpm
TORQUE
9.68kgm – 95.5Nm – @ 7000rpm
FUEL INJECTION
Marelli electronic fuel injection, 50mm throttle body
EXHAUST
2 aluminium mufflers with 3-way catalytic converter (non-catalytic on USA version)
Transmission
GEARBOX
6 speed
PRIMARY DRIVE
Straight cut gears, ratio 1.84
RATIO
1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28
FINAL DRIVE
Chain; Front sprocket 15; Rear sprocket 42
CLUTCH
Dry multiplate with hydraulic control
Chassis
FRAME
Tubular steel trellis
FRONT SUSPENSION
Showa 43mm fully adjustable upside-down fork with TiN surface treatment
FRONT WHEEL
5-spoke light alloy 3.50×17
FRONT TYRE
120/70 ZR17
REAR SUSPENSION
Progressive linkage with Showa fully adjustable monoshock. Aluminium single-sided swingarm
REAR WHEEL
5-spoke light alloy 5.50 x 17
REAR TYRE
180/55 ZR17
FRONT WHEEL TRAVEL
130mm / 5.1in
REAR WHEEL TRAVEL
148mm / 5.8in
FRONT BRAKE
2 x 320 mm discs, 4-piston caliper
REAR BRAKE
245mm disc, 2-piston caliper
INSTRUMENTATION
Electronic panel: speedometer, rev counter, neutral light, oil pressure warning light, low fuel warning light, high beam indicator, turn signals, immobilizer, LCD water temperature, LCD clock
Dimensions and weight
DRY WEIGHT
193kg / 425lb
SEAT HEIGHT
800mm / 31.5in
WHEELBASE
1440mm / 56.7in
RAKE
24°
FUEL TANK CAPACITY
15l (of which 3.5l reserve) / 3.9 US gal (of which 1 US gal reserve)
VERSIONS
Standard
Warranty
WARRANTY
2 years unlimited mileage
Emissions and Consumption
STANDARD
Euro2 (except USA version)


Suggested Starting Price shown does not include tax, title, or destination charge. Dealer prices may vary. Specifications subject to change without notice.
