2004 Honda CR125R
Back to 2004 Honda Motorcycle Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2004 Honda CR125R
2004 Honda CR125R

2004 Honda CR125R
2004 Honda CR125R


2004 Honda CR125R Review

2004 Honda CR125R

The best made even better…

Redesigned engine, retooled chassis – the 2004 Honda CR125R gets serious enhancements this year, all with one goal in mind: to give you the edge you need in the 125 class. By far our best 125 ever, it’s ready to put you on top of the podium.

2004 Honda CR125R Key Features






2004 Honda CR125R – Specifications/Technical Details
USA MSRP Price: $5,099 USD
Canadian MSRP Price: See dealer for pricing in CDN

DIMENSIONS
Weight 197.0 pounds

Ground Clearance 13.7 inches

Wheelbase 57.48 inches

Seat Height 37.3 inches

ENGINE
Engine 125cc liquid-cooled single-cylinder two-stroke with RC valve

Displacement 125cc

Bore x Stroke 54.0mm x 54.5mm

Compression Ratio 7.48:1

Carburetion 38mm Mikuni TMX-x with throttle position sensor

Fuel Capacity 2.0 gallons

Ignition Digital ignition with three-dimensional mapping and electronic advance

DRIVETRAIN
Transmission Close-ratio five-speed

Final Drive #520 chain; 13T/52T

BRAKES/WHEELS/TIRES
Brakes Front: Single 240mm disc with twin-piston caliper
Rear:Single 240mm disc

Tires Front: 80/100-21 br> 100/90-19

OPERATIONAL
Suspension Front: 46mm inverted Kayaba cartridge fork w/18-position rebound- & 20-position compr.-damping adj.; 12.0-inch travel
Rear:Pro-Link Kayaba single-shock w/spring-preload, 30-position rebound-damping adj., & comp.-damping adj. separated into low-speed (1

OTHER
Colors
Red

Suggested Starting Price shown does not include tax, title, or destination charge. Dealer prices may vary.
