2006 Suzuki Bandit 1200 – Europe Model

The iconic Bandit 1200 leaps on to centre stage in 2006 with a long list of updates and changes geared at making the machine even more appealing to the masses.



Features unique Suzuki Advanced Cooling System (SACS), which enhances air cooling with a seperate high-volume flow of oil though the cylinder head and a large oil cooler.

Suzuki’s lightweight Pulsed-secondary Air-injection (PAIR) syste, injects filtered, fresh air in to the exhaust ports to reduce unburned hydrocarbons.

Banit 1200 models meet Euro 2 and Tier 1 emissions standards.

Fairing developed in wind tunnel to enhance wind protection for both the rider and passenger.


Overall Length: 2,130 mm (83.9 in.)
Overall Width: 765 mm (30.1 in.)
Overall Height: 1,100 mm (43.3 in.)
Wheelbase: 1,480 mm (58.3 in.)
Ground Clearance: 130 mm (5.1 in.)
Seat Height: Adjustable, 785 / 805 mm (30.9 / 31.7 in.)
Dry Mass: 212 kg
Fuel Capacity: 20 litres

Engine Type: 4-stroke, 4-cylinder inline, DOHC air-cooled with SACS
Bore x Stroke: 79.0 mm × 59.0 mm
Max Power:
Max Torque:
Piston Displacement: 1157 cc
Compression Ratio: 9.5:1
Carburettor: MIKUNI BSR36
Lubrication: Wet sump

Ignition Type: Electric
Starter System: Electric

Transmission: 5-speed constant mesh
Drive System: Chain

Front Suspension: 43 mm telescopic, coil spring, oil damped spring preload fully adjustable
Rear Suspension: Link type, coil spring, oil damped, spring preload 7-way adjustable
Rake/Trail: 25.3 degrees / 104 mm (4.1 in.)
Front Brake: 4-piston calipers, 310 mm dual discs
Rear Brake: 1-piston caliper, 240 mm disc
Front Tyre: 120/60 ZR-17M/C (58W)
Rear Tyre: 180/55 ZR-17M/C (73W)
