FLHTC Electra Glide® Classic Model Overview
The FLHTC Electra Glide Classic has the features of a full dresser touring motorcycle while maintaining opportunity for plenty of customizing. The addition of the Twin Cam 96 engine and 6-speed Cruise Drive transmission make the Electra Glide Classic a powerful touring machine with a passenger and cargo. Reduced clutch lever effort, an adjustable Tour-Pak, comfortable passenger seating area and 40-watt Advanced Audio System by Harman/Kardon surround the rider and passenger in comfort and style. The Electra Glide Classic with standard ESPFI provides even throttle response and engine performance in various weather and elevation conditions. Full engine instrumentation, additional fender and saddlebag trim, locking saddlebags and chrome engine covers are standard. Offered in three solid and four two-tone color options.



FLHTC Electra Glide Classic features:

New Rubber mount 1584cc Twin Cam 96 engine
Black powder-coated engine with chrome treatment
New 6-speed Cruise Drive transmission
Standard Electronic Sequential Port Fuel Injection (ESPFI)
New redesigned football shape air cleaner
Bat-wing, fork-mounted fairing
40-watt CD/AM/FM/WB/MP3 Advanced Audio System by Harman/Kardon
Lockable GTX nylon saddlebags and King Tour-Pak
Comfort-stitch touring saddle and passenger backrest
Full instrumentation
Triple-disc brakes
Air-adjustable rear suspension
Triple Circuit Damping (TCD) front fork




SPECIFICATIONS:

Dimensions
Length 97.5 in. (2497.0 mm)
Overall Width 39.0 in. (990.6 mm)
Overall Height 61.0 in. (1549.4 mm)
Seat Height:
– Laden2
– Unladen
27.3 in. (693.4 mm)
30.7 in. (779.8 mm)
Ground Clearance 5.1 in. (129.5 mm)
Rake (steering head) 26°
Fork Angle 29.3°
Trail 6.2 in. (157.5 mm)
Wheelbase 63.5 in. (1612.9 mm)
Tires (Dunlop® Harley-Davidson Series, narrow whitewall):
– Front – D402F NW
– Rear – D402 NW
MT90B16 72H
MU85B16 77H
Fuel Capacity 5.0 gal. (18.9 L)
(warning light at approximately 1.0 gal.)
Oil Capacity (with filter) 4.0 qts. (3.8 L)
Transmission Capacity 1.0 qts. (0.95 L)
Primary Chain Case
Capacity10
1.4 qts. (1.3 L)
Weight:
– As Shipped
– In Running Order
– Gross Vehicle Weight
Rating
– Gross Axle Weight Rating:
– Front
– Rear
784 lbs. (356 kg)
820 lbs. (372 kg)
1259 lbs. (572 kg)
500 lbs. (227 kg)
827 lbs. (375 kg)



Engine
Engine Air-cooled, Twin Cam 96®
Valve Train Pushrod-operated, overhead valves
with hydraulic, self-adjusting lifters;
two valves per cylinder
Bore x Stroke 3.75 in. x 4.38 in. (95.25 mm x 111.13 mm)
Displacement 96 cu. in. (1584 cc)
Compression Ratio 9.2:1
Fuel System3 Electronic Sequential Port Fuel Injection
(ESPFI)
Air Cleaner Paper, washable
Lubrication System Pressurized, dry-sump



Drivetrain
Primary Drive Chain, 46-34 ratio
Final Drive9 Belt, 32/66 ratio
Clutch 9-plate, wet
Transmission 6-speed Cruise Drive™
Gear Ratios (overall):
– 1st
– 2nd
– 3rd
– 4th
– 5th
– 6th
U.S. HDI JPN
9.312 9.312 9.030
6.421 6.421 6.226
4.774 4.774 4.630
3.926 3.926 3.807
3.279 3.279 3.179
2.790 2.790 2.706


Chassis
Frame Mild steel, square-section backbone with
twin downtubes
Swingarm Mild steel, rectangular tube sections,
stamped junctions; MIG welded
Front Forks 41.3 mm telescopic, cartridge-style damping
Rear Shocks Air-adjustable
Wheels4 (Chrome, Profile Laced
Aluminum option):
Black, 9-spoke Cast Aluminum
– Front
– Rear
16 in. x 3.0 in. (406.4 mm x 76.2 mm)
16 in. x 3.0 in. (406.4 mm x 76.2 mm)
Brakes:
– Caliper Type
– Rotor Type (diameter x width):
– Front (dual)
– Rear
4-piston front and rear
Patented, uniform expansion rotors
11.5 in. x .20 in. (292.1 mm x 5.08 mm)
11.5 in. x .23 in. (292.1 mm x 5.84 mm)
Suspension Travel:
– Front Wheel
– Rear Wheel
4.6 in. (116.8 mm)
3.0 in. (76.2 mm)


Performance
Engine Torque (per SAE J1349)5:
– North America
– World
– France opt. Germany
– Japan
92.6 ft. lbs. @ 3500 rpm (125.5 NM @ 3500 rpm)
90.2 ft. lbs. @ 3400 rpm (122.3 NM @ 3400 rpm)
90.2 ft. lbs. @ 3400 rpm (122.3 NM @ 3400 rpm)
86.9 ft. lbs. @ 2500 rpm (117.8 NM @ 2500 rpm)
Lean Angle (per SAE J1168):
– Right
– Left
32°
30°
Fuel Economy10
(EPA urban/highway test)
32.5/45.0 mpg (7.24/5.23 L/100 km)


Electric
Battery (per Battery Council
International Rating)
Sealed, maintenance-free, 12V,
28-amp/hour, 270 cca
Charging Three-phase, 50-amp system
(585W @ 13V, 2000 rpm, 650W max power @ 13V)
Starting 1.2 kW electric with solenoid shift starter
motor engagement
Lights (as per country regulation):
– Headlamp (quartz halogen)
– Auxiliary Lamps
– Tail/Stop Lights
– Turn Signal Lights
– Indicator Lamps
55-watt low beam, 60-watt high beam
Two @ 35W each (except where prohibited by law)
8W/28W (5W/21W)
28W (21W) self-canceling
High beam, running lights, front fender running
lights, directional light bar, neutral, low oil
pressure, engine diagnostics, cruise control,
accessory speakers, turn signals, security
system6 (optional), 6-speed, low fuel warning


Styling / Convenience
Engine Trim Black powder-coated with chrome treatment
Exhaust System Chrome, Touring cross-over duals with
taper end caps
Handlebars Stainless steel, easy-reach Touring
Seat One-piece, two-up Road King® classic
comfort stitch
Passenger Backrest Integrated into Tour-Pak® lid with wrap-around
armrests
Foot Supports
and Controls
Height-adjustable rider and passenger
footboards; rider heel/toe shift levers
Fairing Fork-mounted “bat-wing”
Windshield Clear Lexan®
Instruments Electronic speedometer w/ odometer,
dual resettable tripmeter, tachometer, fuel
gauge, voltmeter, low oil pressure gauge,
diagnostics readout, ambient air temperature
gauge, 6-speed indicator light, wired to
accept electronic cruise control
Stereo
Premium sound system (40W per speaker) w/
AM/FM/CD-MP3 player, fairing-mounted
speakers, weather band, clock,
bi-directional seek/scan, track search/
scan, 8 presets and automatic volume
control w/ adjustable sensitivity
Auxiliary Audio Input On radio face; will accommodate any
line-level audio output device, like
personal CD or MP3 player
Antenna Single AM/FM/WB antenna
Cruise Control Wired to accept electronic cruise control
Hand Conrols Turn signals, stereo, engine start
Hazard Warning Integrated into turn signal controls
Electric Power Outlet Cigarette lighter, accessory connector
under seat
Tour-Pak® Fiberglass, side-hinged, 2 full-face helmet
capacity, storage pocket, passenger backrest,
rubber mat liner; Vol.: 2.45 cu. ft. (69.4 L)
Saddlebags Injection-molded GTX®12; Vol.: 2.26 cu. ft. (64.0 L)
Luggage/Fork/
Gas Cap Locks
Tour-Pak®/saddlebags, barrel key;
common with ignition key
Smart Security System Optional, next-generation hands-free security
fob; operates based on proximity to vehicle

Colors12
Vivid Black, Black Cherry Pearl, Pewter Pearl (new), Olive Pearl/Vivid Black
(new), Black Cherry Pearl/Pewter Pearl (new), Fire Red Pearl/Black Pearl
(new), Deep Cobalt Pearl/Pewter Pearl (new)


Warranty
Warranty7 24 months (unlimited mileage)
Service Interval First 1,000 miles (1,600 km),
every 5,000 miles (8,000 km) thereafter8

1 Harley-Davidson reserves the right to discontinue models or change specifications at
any time without incurring any obligations. Vehicle specifications may vary by country
and region depending on local laws. Some models are not available in certain countries.
2 Measurement reflects 180 lb. (81.7 kg) operator weight.
3 Recommended 91 octane or higher fuel (R+M)/2 (87 octane or higher for XL 883
models). Standard and optional fuel systems may vary by country and region.
4 Standard and optional wheels may vary by country and region.
5 Values shown are nominal. Performance may vary by country and region.
6 North America security system includes immobilizer; outside North America the security
system includes immobilizer and siren.
7 See motorcycle owner’s manual for complete details.
8 Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals.
9 U.S. and HDI markets except Japan: Belt 32/64 ratio.
10 Primary case oil fill is 45 oz. or as needed to fill to bottom of diaphragm spring.
11 Estimated from fuel economy tests on a sample motorcycle from the corresponding
family conducted by Harley-Davidson under ideal laboratory conditions. Not all
motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary
among motorcycle models within a family. Your Mileage may vary depending on your
personal riding habits, weather conditions, trip length, vehicle condition and vehicle
configuration and other conditions. Break-in mileage may vary.
12 GTX® is a registered trademark of General Electric Company.
13 Availability may vary from dealer to dealer, and is subject to change without notice.
