2009 Victory Arlen Ness Victory Vision

You are here: Home2009 Models — 2009 Victory Motorcycle Models

2009 Victory Arlen Ness Victory Vision
Back to 2009 Victory Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2009 Victory Arlen Ness Victory Vision
2009 Victory Arlen Ness Victory Vision

2009 Victory Arlen Ness Victory Vision
2009 Victory Arlen Ness Victory Vision

2009 Victory Arlen Ness Victory Vision
2009 Victory Arlen Ness Victory Vision

– 2009 Victory Arlen Ness Victory Vision

2009 Victory Arlen Ness Victory Vision

Custom masters Arlen and Cory Ness have once again created incredible customized versions of Victory models that will be produced in limited numbers. Make sure you’re counted in.

New for 2009
Ness Graphics
-Ness Hot Rod billet wheels
-Numbered engine plate
-ARLEN NESS SIGNATURE SERIES display on radio screen
-Ness Key badge
-Leather stitched seat
-Ness logo low windscreen
-Diamond cut engine
-Ness engine covers
-Ness billet grips
-Ness shift and brake peg
-Electric windshield
-Lit badges
-Black body panels
-Black accent panels
-Black forks
-Black hand controls
-Black tip over protection
-Black passenger handles
-Black instrument cluster
-Black anodized belt guard
-Black license plate mount
-Chrome handlebars
-Chrome driver boards
-Chrome passenger boards
-Chrome shift lever
-Chrome brake lever
-Chrome handlebar ends
-Chrome side stand


Features & Benefits

– Freedom 106 Cubic Inch V-Twin Engine

– Gorgeous diamond-cut cylinders and cylinder heads

– Ness custom billet wheels

– Custom leather stitched seats

– Limited edition

– Ness billet engine cover

– Arlen Ness designed paint

– Chrome

– Ness graphics

– Ness display on radio

– Ness logo low windshield

– Ness billet grips

– Ness shifter and brake pedal

– Electric windshield

– Lit badges

– Blacked out









2009 Victory Arlen Ness Victory Vision – USA Specifications
MSRP $24,999.00

ENGINE
Engine 4-stroke, 50° V-twin, single overhead camshafts with 4-valves per cylinder, self-adjusting cam chains, hydraulic lifters

Displacement 106 ci (1,731 cc)

Bore x Stroke 101 x 108 mm

Compression Ratio 9.4:1

Fuel System Electronic Fuel Injection with dual 45 mm throttle bodies

Clutch Wet, multi-plate

Cooling Air / oil

Exhaust Split dual exhaust with crossover

DIMENSIONS
Length 103.5 in. (2,629 mm)

Weight Dry: 804 lbs. (365 kg)

GVWR: 1,414 lbs. (641 kg)

Ground Clearance 5.8 in. (148 mm)

Wheelbase 65.7 in. (1,670 mm)

Fuel Capacity 6 gal. (22.7 l) with 1 gal. (3.8 l) reserve

Oil Capacity 5 qt. (4.75 l)

Seat Height 26.5 in. (673 mm)

DRIVETRAIN
Transmission 6-speed overdrive constant mesh

Primary Drive Gear drive with torque compensator

Final Drive Carbon fiber reinforced belt

Suspension Front: Conventional telescopic fork, 46 mm fork tube; 5.1 in. (130 mm) travel

Rear: Single, mono-tube gas shock, cast aluminum with rising rate linkage swingarm, air adjustable; 4.7 in. (120 mm) travel

BRAKES/WHEELS/TIRES
Brakes Front: Dual 300 mm floating rotor with 3-piston calipers

Rear: 300 mm floating rotor with 2-piston caliper

Tires Front: 130/70R18 Dunlop Elite 3

Rear: 180/60R16 Dunlop Elite 3

Rake 29°

Trail 5.4 in. (137 mm)

Colors Ness Custom Color






2009 Victory Arlen Ness Victory Vision – Canada Specifications
MSRP C$27,874.00


ENGINE
Engine 4-stroke, 50° V-twin, single overhead camshafts with 4-valves per cylinder, self-adjusting cam chains, hydraulic lifters

Displacement 106 ci (1,731 cc)

Bore x Stroke 101 x 108 mm

Compression Ratio 9.4:1

Fuel System Electronic Fuel Injection with dual 45 mm throttle bodies

Clutch Wet, multi-plate

Cooling Air / oil

Exhaust Split dual exhaust with crossover

DIMENSIONS
Length 103.5 in. (2,629 mm)

Weight Dry: 804 lbs. (365 kg)

GVWR: 1,414 lbs. (641 kg)

Ground Clearance 5.8 in. (148 mm)

Wheelbase 65.7 in. (1,670 mm)

Fuel Capacity 6 gal. (22.7 l) with 1 gal. (3.8 l) reserve

Oil Capacity 5 qt. (4.75 l)

Seat Height 26.5 in. (673 mm)

DRIVETRAIN
Transmission 6-speed overdrive constant mesh

Primary Drive Gear drive with torque compensator

Final Drive Carbon fiber reinforced belt

Suspension Front: Conventional telescopic fork, 46 mm fork tube; 5.1 in. (130 mm) travel

Rear: Single, mono-tube gas shock, cast aluminum with rising rate linkage swingarm, air adjustable; 4.7 in. (120 mm) travel

BRAKES/WHEELS/TIRES
Brakes Front: Dual 300 mm floating rotor with 3-piston calipers

Rear: 300 mm floating rotor with 2-piston caliper

Tires Front: 130/70R18 Dunlop Elite 3

Rear: 180/60R16 Dunlop Elite 3

Rake 29°

Trail 5.4 in. (137 mm)

Colors Ness Custom Color
