2009 Yamaha V-Star 1100 Custom

You are here: Home2009 Models — 2009 Yamaha Motorcycle Models

2009 Yamaha V-Star 1100 Custom
Back to 2009 Yamaha Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2009 Yamaha V-Star 1100 Custom
2009 Yamaha V-Star 1100 Custom

2009 Yamaha V-Star 1100 Custom
2009 Yamaha V-Star 1100 Custom

– 2009 Yamaha V-Star 1100 Custom

2009 Yamaha V-Star 1100 Custom

Blast from the Past.

Authentic cruiser styling and the lowest seat height of any Star Motorcycle.

The timeless V-Star 1100 Custom comes chrome-plated, tear-drop tanked and with the piston-pounding appeal of a V-twin cruiser. It is one of the best cruiser values. The styling and attention to detail is only surpassed by the performance and reliability.

With a long, low, lean-and-mean profile, traditional spoked wheels, and a bobbed tail rear fender, the V-Star 1100 Custom has the look and feel of a classic “chopper.”

In fact, when you see the low price tag, you might think that you’ve gone back in time. But one short ride will rule time travel out, thanks to the incredible attention to detail and the quality fit and finish that the Star family is famous for. Its powerful air-cooled, 65-cubic-inch V-twin pumps out lots of low-end torque, while a smooth-shifting 5-speed transmission and clean, quiet shaft drive put the power to the ground. Customization possibilities are endless.

Long, low, stripped-down to the bare beautiful essentials and powered by a modern SOHC twin, the V-Star 1100 Custom goes as good as it looks.



– 1,063cc V-twin

– Exceptional cruising performance


Key Features:


1,063cc, air-cooled, SOHC, 2 valves per cylinder, 75°, V-twin produces outstanding low- and mid-range torque – maximum torque is reached at only 2,500 rpm – for exceptional cruising performance.

Forged, lightweight pistons provide excellent durability while reducing reciprocating mass for fast throttle response. Connecting rods are carburized for durability.

Ceramic composite cylinder plating ensures superior heat dissipation for better cooling, reduced friction and longer engine life.

Thick cylinder cooling fins enhance the stylish look while increasing cooling efficiency and reducing mechanical noise.

Dual Mikuni BSR 37mm carburetors with throttle position sensors feature an electronic fuel pump, carburetor heaters and handy side-mounted air filter to ensure consistent fuel flow, great throttle response and optimum power throughout the rev range.

Maintenance-free, transistorized coil ignition provides a hot spark for sure starts.

Automatic cam chain tensioners reduce maintenance while silent-type cam chain also reduces mechanical engine noise.

One-way, cam clutch-type starter decreases mechanical noise during starting.

Smooth-shifting, 5-speed transmission is perfect for city or highway use. 5th gear is an overdrive gear for reduced engine rpms at highway speeds for a smooth comfortable ride.

Low-maintenance, chrome, exposed shaft drive delivers superior reliability and a clean, quiet ride. No chain to adjust or lube!

2-into-2 exhaust system with dual shotgun-style staggered pipes plays outstanding V-twin music. Mufflers can easily be changed to aftermarket components, if desired.

Air Induction System (A.I.S.) reduces harmful CO and HC exhaust emissions.

Numerous chromed engine parts reinforce this motorcycle’s quality image.



Low-slung, large-diameter, double-cradle frame with 32° rake creates a strong, stylish machine with precise, predictable handling.

Extra-long 1640mm (64.6″) wheelbase produces a long and low retro profile, with spacious ergonomics for added rider comfort and relaxed, stable handling.

Class-lowest, 690mm (27.2″) seat height enhances maneuverability and provides extra rider confidence.

41mm front fork with 140mm (5.5″) of travel smoothes out the bumps and features chrome-plated chip protectors for added insurance against fork tube damage.

7-step spring preload-adjustable single rear shock is mounted horizontally under the engine, thereby lowering the centre of gravity for better handling and a plush ride.

Rear shock location provides that hidden classic, hardtail look. Rear wheel travel is 113mm (4.5″).

Large-diameter, dual 298mm front discs with twin piston calipers provide strong, confidence-inspiring stopping power.

282mm rear disc brake with opposed piston caliper

Narrow, custom-style front tire on 18″ spoked chrome wheel means sportier handling.

Wide, 15″ rear tire and stylish “bobtail” fender with mudguard add a timeless touch and provides excellent mud and splash protection.

Low-profile, split tandem seats offer all-day rider comfort. Passenger seat is removable.

Large, 17-litre, teardrop fuel tank provides an extra long cruising range.

Eye-catching, tank-mounted speedometer features a large face for easy viewing. Digital odometer and tripmeter displays.



Industry-leading Star Family fit and finish features rich, lustrous paint and extensive chrome accents creating a stunningly timeless machine.

Locking compartment under side cover provides handy, secure storage for small items.

Chrome, “bullet-style”, 60/55-watt, halogen headlight adds a custom image.

Low-maintenance, sealed battery ensures reliable, no-hassle starting.

Self-cancelling turn signals with stylish clear lenses

Helmet lock

Steering lock

Convenient, handlebar-mounted choke lever

Forward-mounted footpegs provide a roomy, laid back riding position.

Convienien bungee cord hooks on rear passenger footpeg mounts.


2009 Yamaha V-Star 1100 Custom – USA Specifications
MSRP* $8,799 (Candy Red) Available from June 2008; CA model from August 2008
$8,899 (Raven – Midnight Custom) Available from June 2008; CA model from August 2008

Type 65-cubic-inch (1063cc) air-cooled 75° V-twin; SOHC, 2 valves/cylinder

Bore x Stroke 95mm x 75mm

Compression Ratio 8.3:1

Carburetion (2) 37mm Mikuni®; throttle position sensor

Ignition TCI

Transmission 5-speed, multiplate wet clutch

Final Drive Shaft

Fuel Capacity Steel; hidden shock

Suspension/Front Telescopic fork; 5.5-in travel

Suspension/Rear Single shock; adjustable preload, 4.5-in travel

Brakes/Front Dual hydraulic disc, 298mm

Brakes/Rear Hydraulic disc, 282mm

Tires/Front 110/90-18

Tires/Rear 170/80-15

Wheels Laced

Length 94.7 in

Width 35.2 in

Height 43.3 in

Seat Height 27.2 in

Wheelbase 64.6 in

Ground Clearance 5.7 in

Fuel Capacity 4.5 gal

Wet Weight 606 lb / C: 612 lb

Warranty 1 Year (Limited Factory Warranty)



2009 Yamaha V-Star 1100 Custom – Canada Specifications
MSRP $9,199

Engine Air-cooled, SOHC, 2-valve, 75°, V-twin
Displacement 1,063cc
Bore and Stroke 95 x 75mm
Compression Ratio 8.3:1
Maximum Torque 8.8kg-m (63.7 ft-lb)@ 2,500 rpm
Fuel Delivery Mikuni BSR37 x 2
Ignition Digital TCI
Transmission 5-speed
Drive Train Shaft

Suspension (Front) 41mm fork
Suspension (Rear) Adjustable link Monocross
Brakes (Front) Dual 298mm discs
Brakes (Rear) 282mm disc
Tires (Front) 110/90-18
Tires (Rear) 170/80-15

Length 2,405mm (94.7″)
Width 895mm (35.2″)
Height 1,100mm (43.3″)
Wheelbase 1,640mm (64.6″)
Seat Height 690mm (27.2″)
Fuel Capacity 17 litres (3.7 imp. gallons)
Wet Weight 275kg (605 lb)
Colour(s) Dark Metallic Red
Metallic Black

*Prices and specifications subject to change without notice.
