2010 BMW K1300S

– 2010 BMW K1300S

2010 BMW K1300S

The interceptor. The athlete. Aerodynamic, avant-garde. Do you know of another sporty bike with this profile? A bike that develops such pulling power with 175 hp that it take the heat out of many a 200 hp bike? But a bike you can still take out on a quick trip simply because it has great everyday suitability? At the same time a technological treat? The reasons: 103 lb/ft (140 Nm) from 1,293 cc – and at 8,250 rpm too. With a throaty sound from a cool, hexagonal tube. With catalytic converter and exhaust valve. And with fuel consumption and exhaust emission values which would suit many a machine with half the dynamic performance.

With this jet, the whole concept of speed moves into a new dimension. This in-line 4-cylinder delivers its power in such a way that you can almost feel it when standing still. That’s because within the engine speed ranges in which you move more than 80% of the time – i.e. the lower and medium speed ranges – it delivers performance from the first yard. The real thing. And in terms of safety features, this machine is unique: ABS as standard with ASC and ESA optional. And the extras are amazing: race through the gears with the automatic shift function, pure racing in view with the 2D dashboard.

The BMW K 1300 S: supreme power with the sportiest of understatement. Why not try it out right away!

Extreme power. Thrilling acceleration. Instant responses across the rev range. Welcome to the ultimate sports tourer – the new BMW K 1300 S.

Its styling alone promises speed and performance. And with an output of 175hp and 140Nm of torque, speed and performance is exactly what you get. Your heart races with the engine all the way up to 11,000 rpm. And yet you remain completely calm, thanks to a highly practical design, outstanding safety features and a chassis that is a marvel of precision engineering. If you want to be the best, there’s no room for half measures.

The designers of the BMW K 1300 S were very clear about their aims: even more power, even more performance. The result is a machine that combines the excitement of a track bike with the practical features needed for long-distance riding on the road, such as the famous BMW Motorrad Duolever and BMW Motorrad ABS.

The K 1300 S is also available with ESA II Electronic Suspension Adjustment as an option, allowing you to modify the suspension set-up depending on the load you are carrying.

Conceived consistently as a sports machine, the K1300S has not only maintained, but in many areas even enhanced the qualities of its predecessor. As a result, this new high-performer combines fascinating and innovative technology of the highest calibre with outstanding all-round qualities and safety. On the road this means even greater riding precision and agility, even more dynamic power and performance, and, at the same time, the superior safety and ease of control in all situations so typical of a BMW.

Features and Specifications

Standard Factory Equipment:

Engine/Driveline
4 Cylinder in line engine, mounted across the frame and inclined at 55°
4 Valve cylinder heads
6 Speed gearbox
Stainless steel exhaust system
Digital engine management (BMS-K)
Closed loop 3 way catalytic converter with oxygen sensor
Shaft drive
Knock control (95 – 98 ROZ)

Running Gear
BMW Motorrad duolever front suspension and paralever (EVO) rear suspension
Twin disk front brake (EVO, 320mm dia.)
Single disk rear brake
Hydraulic rear spring preload adjuster
Prop stand with starter inhibit
Continuously adjustable rear rebound damping
Cast Aluminium wheels
Cast Aluminium single swing arm
Sports wheel, 190/55 ZR17
Electronics
Permanent headlamp beam
Free-form surface headlights
Electronic immobiliser
Diagnostic interface Grouptester 1
Info flat screen (digital clock, gear indicator, fuel gauge, coolant temperature and cruising range indicator, total and 2 trip odometers, service interval indicator)
Single wire system (Can Bus)
Power socket
Hazard warning flasher

Equipment
One key system for ignition, steering, fuel filler cap and dual seat locks
Storage compartment with tool kit
Adjustable handbrake and clutch lever
Integral ignition switch and steering lock
One piece dual seat

2010 BMW K1300S – USA Specifications
USA MSRP: $15,550 USD

Engine

Type Water-cooled 4-stroke in-line four-cylinder-engine, four valves per cylinder, two overhead camshafts, dry sump lubrication

Bore x stroke 80 mm x 64.3 mm

Capacity 1293 cc

Rated output 175hp (129 kW) at 9,250 rpm

Max. torque 103 lb/ft (140 Nm) at 8,250 rpm

Compression ratio 13,0 : 1

Mixture control / engine management Electronic intake pipe injection/digital engine management including knock sensor (BMS-K)

Emission control Closed-loop 3-way catalytic converter, emission standard EU-3

Performance / fuel consumption

Maximum speed Over 125mph 200 km/h

Fuel consumption per 100 km at constant 90 km/h 4,7 l

Fuel consumption per 100 km at constant 120 km/h 5,3 l

Fuel type Unleaded Premium

Electrical system

Alternator three-phase alternator 580 W

Battery 12 V / 14 Ah, maintenance-free

Power transmission

Clutch Multiple-disc clutch in oil bath, hydraulically operated

Gearbox Constant mesh 6-speed gearbox

Drive Shaft drive

Chassis / brakes

Frame Bridge-type frame, cast aluminium, load-bearing engine

Front wheel location / suspension BMW Motorrad Duolever; central spring strut

Rear wheel location / suspension Cast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut with lever system, spring pre-load adjustable hydraulically (continuously variable) at handwheel, adjustable rebound damping

Suspension travel front / rear 4.5 inches (115 mm) / 5.3 inches (135 mm)

Wheelbase 62.4 inches (1585 mm)

Castor 4.1 inches (104.4 mm)

Steering head angle 60.4°

Wheels Cast aluminium

Rim, front 3,50 x 17″

Rim, rear 6,00 x 17″

Tyres, front 120/70 ZR 17

Tyres, rear 190/55 ZR 17

Brake, front Twin disc, floating brake discs, diameter 320 mm, 4-piston fixed calipers

Brake, rear Single disc brake, diameter 265 mm, double-piston floating caliper

ABS Standard equipment: BMW Motorrad Integral ABS (part-integral)

Dimensions / weights

Length 86 inches (2182 mm)

Width (incl. mirrors) 35.6 inches (905 mm)

Height (excl. mirrors) 48 inches (1221 mm)

Seat height, unladen weight 32.3 inches (820 mm) (low seat: 31.1 inches [790 mm])

Inner leg curve, unladen weight 71.2 inches (1810 mm) (low seat: 68.9 inches [1750 mm])

Unladen weight, road ready, fully fuelled 1) 560 lbs (254 kg)

Dry weight 2) 503 lbs (228 kg)

Permitted total weight 1014 lbs (460 kg)

Payload (with standard equipment) 454 lbs (206 kg)

Usable tank volume 5 U.S. gallons (19 litres)

Reserve approx. 1 U.S. gallon (4.0 litres)

Technical data relate to the unladen weight (DIN)

Base MSRP: $15,550

Standard Package: $15,800

* Heated Grips

Premium Package: $17,800

* Heated Grips

* Gear Shift Assistant

* ESA II

* ASC (Traction Control)

* Tire Pressure Monitor (TPM)

Options

* Gear Shift Assistant: $450

* ESA II: $900

* Heated Grips: $250

* Tire Pressure Monitor (TPM): $250

* Anti-Theft Alarm: $395

* ASC: $400

* Luggage Grid: $150

* Low Seat (31.1 Inches): n/c

*Actual price determined by dealer. Price excludes taxes, license, options and $495 in destination/handling charges. Prices and specifications subject to change without notice.

1) According to guideline 93/93/EWG with all fluids, fuelled with at least 90% of usable tank volume
2) Unladen weight without fluids

2010 BMW K1300S – Canada Specifications
Canada MSRP: $16,990 CDN

Technical data relate to the unladen weight (DIN)

1) According to guideline 93/93/EWG with all fluids, fuelled with at least 90% of usable tank volume
2) Unladen weight without fluids

2010 BMW K1300S – UK Specifications
UK MSRP: £8,804.35. OTR £10,450.00

Engine
Type Water-cooled 4-stroke in-line four-cylinder-engine, four valves per cylinder, two overhead camshafts, dry sump lubrication
Bore x stroke 80 mm x 64,3 mm
Capacity 1.293 ccm
Rated output 129 kW (175 hp) at 9,250 rpm
Max. torque 140 Nm at 8,250 rpm
Compression ratio 13,0 : 1
Mixture control / engine management Electronic intake pipe injection/digital engine management including knock sensor (BMS-K)
Emission control Closed-loop 3-way catalytic converter, emission standard EU-3

Performance / fuel consumption
Maximum speed Over 200 km/h
Fuel consumption per 100 km at constant 90 km/h 4,7 l
Fuel consumption per 100 km at constant 120 km/h 5,3 l
Fuel type Unleaded premium, octane number 98 (RON), automatic knock control permits operation with minimum octane number 95 (RON).
Electrical System
Alternator three-phase alternator 580 W
Battery 12 V / 14 Ah, maintenance-free
Power transmission
Clutch Multiple-disc clutch in oil bath, hydraulically operated
Gearbox Constant mesh 6-speed gearbox
Drive Shaft drive

Chassis / brakes
Frame Bridge-type frame, cast aluminium, load-bearing engine
Front wheel location / suspension BMW Motorrad Duolever; central spring strut
Rear wheel location / suspension Cast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut with lever system, spring pre-load adjustable hydraulically (continuously variable) at handwheel, adjustable rebound damping
Suspension travel front / rear 115 mm / 135 mm
Wheelbase 1.585 mm
Castor 104,4 mm
Steering head angle 60,4°
Wheels Cast aluminium
Rim, Front 3,50 x 17″
Rim, rear 6,00 x 17″
Tyre, front 120/70 ZR 17
Tyre, rear 190/55 ZR 17
Brake, front Twin disc, floating brake discs, diameter 320 mm, 4-piston fixed calipers
Brake, rear Single disc brake, diameter 265 mm, double-piston floating caliper
ABS Standard equipment: BMW Motorrad Integral ABS (part-integral)

Dimensions / weights
Length 2.182 mm
Width (incl. mirrors) 905 mm
Height (excl. mirrors) 1.221 mm
Seat height, unladen weight 820 mm (low seat: 790 mm)
Inner leg curve, unladen weight 1,810 mm (low seat: 1,750 mm)
Unladen weight, road ready, fully fueled 254 kg
Dry weight 228 kg
Permitted total weight 460 kg
Payload (with standard equipment) 206 kg
Usable tank volume 19 litres
Reserve approx. 4.0 litres

Factory Fit Options:
Description Price inc. VAT
ABS £895.00
Gear Shift Assist £299.00
Electronic Suspension Adjustment 2 (ESA 2) £617.00
Heated Handlebar Grips £196.00
Tyre Pressure Control £172.00
On Board Computer £123.00
Anti Theft Alarm System £172.00
ASC £250.00
Low Seat (790mm) £0.00
