2016 BMW F800R

Back to 2016 BMW Motorcycle Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2016 BMW F800R
2016 BMW F800R

2016 BMW F800R
2016 BMW F800R

2016 BMW F800R
2016 BMW F800R

2016 BMW F800R
2016 BMW F800R

2016 BMW F800R
2016 BMW F800R



2016 BMW F800R Review

2016 BMW F800R on www.Totalmotorcycle.com

A modern all-rounder….

The F 800 R is a firmly established player in the BMW Motorrad roadster segment. It combines agility, everyday practicality and dynamic riding fun in an integrated sporty package. And the revised F 800 R takes the whole thing a step further.

Design you can enjoy.

The F 800 R is just the right motorbike if you simply want to get on and have fun – and that is just what it looks like. The precise lines and minimalist trim elements give it a sense of light-footed agility, while the new upside-down fork is suggestive of dynamic forward thrust even when stationary. The symmetrical headlamp gives the F 800 R a new distinctive look.

Move ahead safely.

The F 800 R offers uncomplicated riding pleasure – ensured by the powerful yet economical parallel twin engine with 90 bhp – but it is also geared towards safety: ABS as standard, a stable, balanced suspension and the safety package to go with it (ASC, ESA, RDC) guarantee a supreme ride response and absolute control on the road.

Infinite variety.

The touring and all-round capabilities of the F 800 R are reflected not just in the wide range of seat heights and additional luggage fittings but also in the different paint finishes.

The F 800 R stands for maximum riding pleasure like almost no other roadster. BMW Motorrad has now improved this successful concept even further.





2016 BMW F800R www.Totalmotorcycle.com Key Features

• Higher output than its predecessor – 66 kW (90 hp) at 8,000 rpm (previously: 64 kW (87 hp) at 8,000 rpm).

• Modified ratios for first and second gear.

• New body features with an even more dynamic design.

• New colours.

• Symmetrical main headlight arrangement.

• Upside-down fork.

• Radial front brake callipers.

• Lighter wheels with dynamic design.

• Rider foot pegs.

• Seat height reduced to 790 mm (previously 800 mm).

• New tapered aluminium handlebars.

• ASC (Automatic Stability Control) – optional / special accessory.

• ESA (Electronic Suspension Adjustment) – optional.

• Output reduced to 35 kW (48 hp) – special accessory / optional.






2016 BMW F800R www.Totalmotorcycle.com Features and Benefits

The 2016 BMW F 800 R is the latest in the line of characterful parallel twin-cylinder motorcycles from BMW Motorrad. Consistent development of its all-round qualities has ensured the dynamic roadster is ready to delight owners with its sporty performance, agile handling and even greater versatility – all wrapped up in a dynamic package.

Power is sourced, as before, from a liquid-cooled four-valve twin-cylinder engine with 798 cc displacement. With output increasing to 66 kW (90 hp) at 8,000 rpm (up from 64 kW (87 hp) at 8,000 rpm) and shorter ratios for first and second gear, the parallel twin offers even greater sprinting ability while retaining the impressive pulling power, instantaneous responses and low fuel consumption familiar from the predecessor model. Peak torque remains 86 Nm (63 lb-ft) at 5,800 rpm.

The engaging riding experience on board the F 800 R is further enhanced by new suspension components and optimised ergonomics. For example, an upside-down fork now takes care of front suspension duties, while a hydraulic double-disc brake with radial brake callipers provides fade-resistant stopping power. A new seat fixed lower down (at 790 mm instead of the previous 800 mm), combined with new handlebars and rider foot pegs, creates even better ergonomics for the rider.

The design of the F 800 R – which is also pitched at novice riders – also provides a visual showcase for that extra rider engagement. With its newly designed fairings, radiator shields, front mudguard and wheels, plus a new range of colours, the sporty roadster cuts an extremely dynamic figure. The now symmetrical main headlight also gives it a distinctive “face”.

In keeping with the “Safety 360°” principle, the 2016 BMW F 800 R is fitted with ABS as standard. It can also be ordered with optional systems such as ASC (Automatic Stability Control) and ESA (Electronic Suspension Adjustment), ensuring it sets a new benchmark in the segment in terms of its safety performance and all-round qualities.










2016 BMW F800R – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $9995 (including ABS) USD

Engine
Type Liquid cooled, 4-stroke parallel twin engine, four valves per cylinder, double overhead camshafts, dry sump lubrication
Bore x stroke 82 mm x 75.6 mm
Capacity 798 cc
Rated output 90 hp (66 kW) at 8,000 rpm
Max. torque 63 lb-ft (86 Nm) at 5,800 rpm
Compression ratio 12.0 : 1
Mixture control / engine management Electronic fuel injection
Emission control Closed-loop 3-way catalytic converter, emission standard EU-3
Performance / fuel consumption
Maximum speed Over 125 mph
Fuel consumption per 100 km at constant 90 km/h 65 mpg at a constant 55 mph (3.6 l)
Fuel type Premium Unleaded
Electrical system
Alternator Three-phase 400 W generator
Battery 12 V / 12 Ah, maintenance-free
Power transmission
Clutch Multi-plate wet clutch, mechanically operated
Gearbox Constant-mesh 6-speed gearbox with straight cut gears
Drive Chain drive 2.35:1
Chassis / brakes
Frame Aluminum bridge-type frame with partially load-bearing engine
Front wheel location / suspension Upside-down telescopic fork, Ø 45 mm
Rear wheel location / suspension Cast aluminum 2-sided swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Suspension travel front / rear 4.9″ / 4.9″ (125 mm / 125 mm)
Wheelbase 60.1″ (1,526 mm)
Castor 3.9″ (100 mm)
Steering head angle 64°
Wheels Cast aluminum wheels
Rim, front 3.50 x 17″
Rim, rear 5.50 x 17″
Tyres, front 120/70 ZR 17
Tyres, rear 180/55 ZR 17
Brake, front Dual floating disc brakes, 4-piston fixed calipers, diameter 320 mm
Brake, rear Single disc brake, diameter 265 mm, single-piston floating caliper
ABS BMW Motorrad ABS
Dimensions / weights
Length 84.5″ (2,145 mm)
Width (incl. mirrors) 33.9″ (860 mm)
Height (excl. mirrors) 48.7″ (1,235 mm)
Seat height, unladen weight 31.1″ (790 mm) Standard; variable seat heights available between 30.3″ (770 mm) and 33.1″ (840 mm) (available as accessories and/or factory options, see an authorized BMW Motorrad dealer)
Inner leg curve, unladen weight 70.1″ (1,780 mm) Standard; variable inner leg curve (inseam) between 68.5″ (1,740 mm) and 73.8″ (1,875 mm) (seats available as accessories and/or factory options, see an authorized BMW Motorrad dealer)
Unladen weight, road ready, fully fuelled 1) 444 lbs (202 kg)
Permitted total weight 891 lbs (405 kg)
Payload (with standard equipment) 447 lbs (203 kg)
Usable tank volume 3.9 gal (15 l)
Reserve Approx. 0.8 gal (3.0 l)
” Technical data relate to the unladen weight (DIN)
” 1) According to guideline 93/93/EWG with all fluids, fuelled with at least 90% of usable tank volume









2016 BMW F800R – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See Dealer for pricing in CDN

Engine
Type Water-cooled 4-stroke in-line two-cylinder engine, two overhead camshafts, four valves per cylinder, dry sump lubrication
Bore x stroke 82 mm x 75.6 mm
Capacity 798 cc
Rated output 66 kW (90hp) at 8.000 rpm
(output reduction 35 kW (48 hp) at 6,750 rpm possible)
Max. torque 86 Nm at 5.800 rpm
(performance reduction: 69 Nm at 3,500 rpm)
Compression ratio 12.0 : 1
Mixture control / engine management Electronic injection
Emission control Closed-loop 3-way catalytic converter, emission standard EU-3
Performance / fuel consumption
Maximum speed Over 200 km/h
Fuel type Unleaded super, minimum octane rating 95 (RON)
Electrical system
Alternator permanent magenet alternator 400 W
Battery 12 V / 12 Ah, maintenance-free
Power transmission
Clutch Multiple-disc clutch in oil bath, mechanically operated
Gearbox Constant mesh 6-speed gearbox integrated into crankcase
Drive Endless O-ring chain with shock damping in rear wheel hub
Chassis / brakes
Frame Bridge-type frame, cast aluminium
Front wheel location / suspension upside-down fork
Rear wheel location / suspension Cast aluminium dual swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
Suspension travel front / rear 125 mm / 125 mm
Wheelbase 1,526 mm
Castor 100 mm
Steering head angle 64°
Wheels Cast aluminium wheels
Rim, front 3.50 x 17″
Rim, rear 5.50 x 17″
Tyres, front 120/70 ZR 17
Tyres, rear 180/55 ZR 17
Brake, front Dual disc brake, floating brake discs, diameter 320 mm, 4-piston brake calipers radial mounted
Brake, rear Single disc, diameter 265 mm, single-piston floating caliper
ABS BMW Motorrad ABS
Dimensions / weights
Length 2,145 mm
Width (incl. mirrors) 860 mm
Height (excl. mirrors) 1,235 mm
Seat height, unladen weight 790 mm (OE low seat: 770 mm, OE high seat: 820 mm)
Inner leg curve, unladen weight 1,780 mm (OE low seat: 1,740 mm, OE high seat: 1,835 mm)
Unladen weight, road ready, fully fuelled 1) 202 kg
Dry weight 2) n.s.
Permitted total weight 405 kg
Payload (with standard equipment) 203 kg
Usable tank volume 15 l
Reserve approx. 3 l
” Technical data relate to the unladen weight (DIN)
” 1) According to Directive 93/93/EEC with all fluids, fuelled to at least 90% of usable fuel tank
” 2) Unladen weight without fluids







2016 BMW F800R – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ See Dealer for pricing in GBP (On The Road inc 20% Vat)

Engine
Type Water-cooled four-stroke twin-cylinder engine, double overhead camshaft, four valves per cylinder, dry sump lubrication
Bore x stroke 82 mm x 75.6 mm
Capacity 798 cc
Rated output 66 kW (90hp) at 8.000 rpm
Output reduction: 35 kW (48 hp) at 6,750 rpm possible
Max. torque 86 Nm at 5.800 rpm
Output reduction: 69 Nm at 3,500 rpm
Compression ratio 12.0 : 1
Mixture control / engine management Digital engine management
Emission control Regulated three-way catalytic converter, emission standard EU-3
Performance / fuel consumption
Maximum speed Over 200 km/h
Fuel type Premium unleaded, minimum 95 octane (RON)
Electrical system
Alternator Permanent magenet alternator 400 W
Battery 12 V / 12 Ah, maintenance-free
Power transmission
Clutch Multiple-disc clutch in oil bath, mechanically operated
Gearbox Six-speed gearbox
Drive Chain drive
Chassis / brakes
Frame Bridge-type frame, cast aluminium
Front wheel location / suspension Upside-down fork
Rear wheel location / suspension Aluminium double-sided swing-arm: Spring preload hydraulically adjustable, steplessly adjustable rebound damping
Suspension travel front / rear 125 mm / 125 mm
Wheelbase 1,526 mm
Castor 100 mm
Steering head angle 64°
Wheels Cast aluminium wheels
Rim, front 3.50 x 17″
Rim, rear 5.50 x 17″
Tyres, front 120/70 ZR 17
Tyres, rear 180/55 ZR 17
Brake, front Double disc with four piston radial brake calipers, diameter 320 mm
Brake, rear Single disc, diameter 265 mm
ABS BMW Motorrad ABS
Dimensions / weights
Length 2,145 mm
Width (incl. mirrors) 860 mm
Height (excl. mirrors) 1,235 mm
Seat height, unladen weight 790 mm (OE low seat: 770 mm, OE high seat: 820 mm)
Inner leg curve, unladen weight 1,780 mm (OE low seat: 1,740 mm, OE high seat: 1,835 mm)
Unladen weight, road ready, fully fuelled 1) 202 kg
Permitted total weight 405 kg
Payload (with standard equipment) 203 kg
Usable tank volume 15 litres
Reserve approx. 3 litres
” Technical data relate to the unladen weight (DIN)
” 1) According to Directive 93/93/EEC with all fluids, fuelled to at least 90% of usable fuel tank




Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
