BRIDGE THE GAP.
Despite its smaller stature, the powerful 99cc two-stroke engine in the KX™100 motorcycle resembles the jaw dropping “big bike” look of its larger KX counterparts, while maintaining its ability to outperform the competition. Designed using the same championship winning technology as Kawasaki’s full-size motocross models, an adjustable handlebar mounting system allows for riders to place themselves in the best ride position. Backed by winning performance from Kawasaki Team Green, the KX100 has been a natural step for the riders who are looking to make the transition from the 85cc class to a full-size motocross bike.
The powerplant boasts a proven two-stroke engine that features a Nikasil-coated cylinder and two-piece KIPS® powervalve system, producing a powerful and durable engine that delivers broad and responsive power. A large capacity radiator helps maintain operating temperatures, even during competition.
Just like its siblings in the KX lineup, the chassis of the KX100 motorcycle is prepared for a variety of terrain, with 36mm inverted front forks with 20-way adjustable compression damping and 10.8 inches of travel up front. On the rear, the Kawasaki Uni-Trak® linkage provides precise handling and is joined by a high performance rear shock that features a 24-way compression and 21-way rebound damping adjustment, coupled with adjustable spring preload and the same 10.8 inches of travel.
We designed the KX100 from the ground up for teenage chargers who are between the mini 85s and full-size 250s. Its 19-inch front and 16-inch rear wheels are sized just right for adolescent racers and its generous 275mm of front and rear wheel travel is widely tuneable to let your inner-race shine.
2018 Kawasaki KX100 Totalmotorcycle.com Key Features
The Kawasaki KX™ motocross lineup is ingrained with a long list of successes that has stemmed from building champions since the start. The entire lineup returns for 2018 with models to build future champions.
The Kawasaki Team Green™ racing team has been the dominant force in amateur racing for more than 35 years, providing contingency and trackside support to racers. As a result, Kawasaki has relied on the aspiring young stars to provide input and to help develop winning products across its lineup.
Team Green was founded in 1981 and has played an instrumental role in Kawasaki’s industry-leading support program, helping many of the motocross and supercross stars of today reach the pinnacle of the sport. Amateur racers purchasing a Kawasaki KX motocross bike can gain access to the same support received by champions such as Jeremy McGrath and Ryan Villopoto.
Utilizing the Team Green racing program, a trackside support system consisting of more than 50 local, regional, and amateur motocross and off-road events across the country has been put in place. There, Kawasaki technicians and race transporters can be found with critical parts and technical assistance to all riders.
2018 Kawasaki KX100 Totalmotorcycle.com Features and Benefits
THE GAP TO FULL-SIZE BIKES WITH THE KX™100 MOTORCYCLE. WITH MORE POWER AND LARGER WHEELS THAN THE KX85, THIS TWO-STROKE SUPER-MINI GIVES RIDERS THE PERFECT BLEND OF DURABILITY AND PROPORTIONATE POWER INCREASE WITH A LARGER CHASSIS BEFORE TRANSITIONING TO THE BIG BIKES.
- High-performance liquid-cooled, 99cc 2-stroke engine
- 6-position adjustable handlebar mount helps tailor ergonomics for a wide range of riders
- Sophisticated suspension components are adjustable
- Larger (19F, 16R) wheels than the KX85 (17F, 14R) contribute to a taller 34.3 inch seat height and higher 13.0 inch ground clearance
- Front and rear disc brakes
2018 Kawasaki KX100 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $4599 USD
POWER
Engine
2-stroke, 1-cylinder, piston reed valve, water-cooled
Displacement
99cc
Bore x Stroke
52.5 x 45.8mm
Compression ratio
10.2:1 (low speed) – 8.7:1 (high speed)
Fuel System
Keihin PWK28
Ignition
CDI w/digital advance
Transmission
6-speed, return shift
Final Drive
Chain
PERFORMANCE
Front Suspension / Wheel Travel
36mm inverted telescopic cartridge fork with 20-way compression damping/10.8 in
Rear Suspension / Wheel Travel
Uni-Trak® single shock system with 24-way compression and 21-way rebound damping plus adjustable spring preload/10.8 in
Front Tire
70/100-19
Rear Tire
90/100-16
Front Brakes
Disc
Rear Brakes
Disc
DETAILS
Frame Type
High-tensile steel perimeter design with subframe member
Rake/Trail
29°/4.3 in
Overall Length
75.6 in
Overall Width
30.1 in
Overall Height
45.3 in
Ground Clearance
13.0 in
Seat Height
34.3 in
Curb Weight
169.7 lb**
Fuel Capacity
1.32 gal
Wheelbase
51.6 in
Color Choices
Lime Green
Warranty
Not Available
Kawasaki Protection Plus™ (optional)
2018 Kawasaki KX100 – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $5199 CDN
ENGINE
| Displacement | 99cc |
| Type | 2-stroke, Single with KIPS |
| Bore and stroke | 52.5 x 45.8 mm |
| Cooling | Liquid, twin radiators |
| Compression ratio | 10.2 (low speed), 8.7 (high speed) |
| Fuel system | Keihin PWK28 carburetor |
| Ignition | Digital-CDI |
| Lubrication | Petrol mix (32:1), 2-stroke racing oil |
| Induction | 2-petal carbon-fibre piston reed valve |
BRAKES
| Front: type | Single 220 mm disc |
| Front: calipers | Dual-piston caliper |
| Rear: type | Single 184 mm disc |
| Rear: calipers | Single-piston caliper |
DIMENSIONS
| Overall length | 1,920 mm (75.2 in.) |
| Overall width | 765 mm (28.9 in.) |
| Overall height | 1,150 mm (43.5 in.) |
| Wheelbase | 1,310 mm (50.8 in.) |
| Ground clearance | 330 mm (13.0 in.) |
| Seat height | 870 mm (34.3 in.) |
| Curb mass** | 77 kg (157 lbs.) |
| Fuel capacity | 5 litres (1.21 gal.) |
DRIVETRAIN
| Transmission | 6-speed, constant mesh, return shift |
| Final drive | Chain |
| Primary reduction ratio | 3.400 (68/20) |
| Gear ratio: 1st | 2.538 (33/13) |
| Gear ratio: 2nd | 1.875 (30/16) |
| Gear ratio: 3rd | 1.500 (27/18) |
| Gear ratio: 4th | 1.250 (25/20) |
| Gear ratio: 5th | 1.090 (24/22) |
| Gear ratio: 6th | 0.956 (22/23) |
| Final reduction ratio | 3.923 (51/13) |
| Clutch | Wet multi-disc |
FRAME
| Type | Tubular single cradle, high tensile steel perimeter |
| Wheel travel: front | 275 mm (10.8 in.) |
| Tire: front | 70/100-19 |
| Wheel travel: rear | 275 mm (10.8 in.) |
| Tire: rear | 90/100-16 |
| Caster (rake) | 29° |
| Trail | 108 mm (4.1 in.) |
| Steering angle (left/right) | 45° / 45° |
SUSPENSION
| Suspension, front | 36 mm inverted telescopic cartridge fork with 20-way compression damping |
| Suspension, rear | Uni-Trak single-shock system with 24-way compression and 21-way rebound damping, plus adjustable spring preload |
2018 Kawasaki KX100 – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
NA
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
