2019 Harley-Davidson Street Rod Guide

2019 Harley-Davidson Street Rod

2019 Harley-Davidson Street Rod 2019 Harley-Davidson Street Rod 2019 Harley-Davidson Street Rod 2019 Harley-Davidson Street Rod

GET A LITTLE ADRENALINE SURGING THROUGH YOUR SOUL.

2019 Harley-Davidson Street Rod:

The Street Rod® features high-output 750 cc Revolution X™ engine that redlines at 9000 rpm. Drag-style bars with bar-end mirrors. 43mm inverted front forks and racing-style piggyback reservoir rear shocks. Up to 40-degrees of cornering, traffic-weaving lean angle.

2019 Street Rod®
Turn city streets into a thrill ride. Redlines at 9000 rpm, and carves corners with up to 40 degrees of traffic-weaving lean angle.







2019 Harley-Davidson Street Rod Totalmotorcycle.com Key Features

Engine

High Output Revolution X™ V-Twin

Engine Torque

47 ft-lb

Weight, As Shipped

505 lb.

Seat Height, Laden

29.8 in.



2019 Harley-Davidson Street Rod Totalmotorcycle.com Features and Benefits

STYLING + FEATURES

DIALS IT ALL UP TO THE MODERN EDGE

2019 Street Rod motorcycle Revolution X 750 Engine
High Output Revolution X™ 750 Engine

With a blacked-out finish, the High Output Revolution X™ engine features a dual throttle body, cylinder heads, enhanced intake ports and cams, and a 12.0:1 compression ratio that delivers 18% more horsepower and 8% more torque than the Harley-Davidson Street® 750.

2019 Street Rod Motorcycle Drag-style bars
Drag-Style Bars with Bar-End Mirrors

They make for a sportier and aggressive riding position to take on the traffic-snarled urban jungle.

Harley-Davidson a 2019 Street Rod motorcycle
Lightweight Front Fender and Performance Tail Section

A lightweight front fender with black fender bracket plus the 2-up seat performance tail section give the Street Rod® bike a sleek, refined look from front to back.

2019 Street Rod Motorcycle front end suspension
Responsive Front and Rear Suspension

43mm inverted front forks and rear piggyback shocks offer increased suspension travel and are tuned for a sportier ride and greater lean angle.

2019 Street Rod motorcycle Tear drop gas tank
3.5 Gallon Tear Drop Tank

A 3.5 gallon metal teardrop tank designed with a fast graphic and Harley-Davidson script to show it’s the real deal.

2019 Street Rod motorcycle Seat
Two-Piece 2-Up Seat with Passenger Foot Pegs

You get a two-piece 2-up seat with a 29.8″ seat height, a perforated finish and a French stitch pattern along with foot pegs for your passenger.





2019 Harley-Davidson Street Rod – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8699 – $8994
USD
Canada MSRP Price: $9399 – $9749 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS
  • Pricing6

    • Vivid Black $8,699
    • Color $8,994
    • ABS Option $750
    • Security System Option $395
    • California Emissions $50
    • Freight $435

    Engine

    • Engine 1 High Output Revolution X™ V-Twin
    • Bore 3.4 in.
    • Stroke 2.6 in.
    • Displacement 749 cc (46 cu in)
    • Compression Ratio 12.0:1
    • Fuel System 3 Mikuni Twin Port Fuel Injection, 42 mm bore
    • Exhaust Black two-into-one exhaust

    Dimensions

    • Length 83.9 in.
    • Seat Height, Laden 7 29.8 in.
    • Seat Height, Unladen 30.1 in.
    • Ground Clearance 8.1 in.
    • Rake (steering head) (deg) 27
    • Trail 3.9 in.
    • Wheelbase 59.4 in.
    • Tires, Front Specification 120/70 R17 V
    • Tires, Rear Specification 160/60 R17 V
    • Fuel Capacity 3.5 gal.
    • Oil Capacity (w/filter) 3.3 qt.
    • Weight, As Shipped 505 lb.
    • Weight, In Running Order 525 lb.

    Performance

    • Engine Torque Testing Method J1349
    • Engine Torque 2 47 ft-lb
    • Engine Torque (rpm) 4,000
    • Lean Angle, Right (deg.) 37.3
    • Lean Angle, Left (deg.) 40.2
    • Fuel Economy Testing Method Estimated City/Hwy
    • Fuel Economy 5 54 mpg

    Drivetrain

    • Primary Drive Gear, 36/68 ratio
    • Gear Ratios (overall) 1st 14.272
    • Gear Ratios (overall) 2nd 10.074
    • Gear Ratios (overall) 3rd 7.446
    • Gear Ratios (overall) 4th 6.006
    • Gear Ratios (overall) 5th 5.037
    • Gear Ratios (overall) 6th 4.533

    Chassis

    • Wheels, Front Type 9 Black, 7-Split Open Spoke Cast Aluminum
    • Wheels, Rear Type Black, 7-Split Open Spoke Cast Aluminum
    • Brakes, Caliper Type 2-piston floated front and rear

    Electric

    • Lights (as per country regulation), Indicator Lamps 8 High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning
    • Gauges 3.5 inch electronic speedometer with high beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, blade key ignition and fork lock, and locking gas cap





2019 Harley-Davidson Street Rod – Totalmotorcycle.com Canada Specifications/Technical Details

Pricing6

  • Vivid Black $ 9,399
  • Colour $ 9,749
  • ABS Option $ 560
  • Security System Option $ 355

Engine

  • Engine 1 High Output Revolution X™ V-Twin
  • Bore 85 mm
  • Stroke 66 mm
  • Displacement 749 cc
  • Compression Ratio 12.0:1
  • Fuel System 3 Mikuni Twin Port Fuel Injection, 42 mm bore
  • Exhaust Black two-into-one exhaust

Dimensions

  • Length 2,130 mm
  • Seat Height, Unladen 765 mm
  • Ground Clearance 205 mm
  • Rake (steering head) (deg) 27
  • Trail 99 mm
  • Wheelbase 1,510 mm
  • Tires, Front Specification 120/70 R17 V
  • Tires, Rear Specification 160/60 R17 V
  • Fuel Capacity 13.1 l
  • Oil Capacity (w/filter) 3.1 l
  • Weight, As Shipped 229 kg
  • Weight, In Running Order 238 kg

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque 2 64 Nm
  • Engine Torque (rpm) 4,000
  • Lean Angle, Right (deg.) 37.3
  • Lean Angle, Left (deg.) 40.2
  • Fuel Economy: Estimated City/Hwy 5 4.3 l/100 km

Drivetrain

  • Primary Drive Gear, 36/68 ratio
  • Gear Ratios (overall) 1st 14.272
  • Gear Ratios (overall) 2nd 10.074
  • Gear Ratios (overall) 3rd 7.446
  • Gear Ratios (overall) 4th 6.006
  • Gear Ratios (overall) 5th 5.037
  • Gear Ratios (overall) 6th 4.533

Chassis

  • Wheels, Front Type 9 Black, 7-Split Open Spoke Cast Aluminum
  • Wheels, Rear Type Black, 7-Split Open Spoke Cast Aluminum
  • Brakes, Caliper Type 2-piston floated front and rear

Electric

  • Lights (as per country regulation), Indicator Lamps 8 High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning
  • Gauges 3.5 inch electronic speedometer with high beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, blade key ignition and fork lock, and locking gas cap



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
