2020 Harley-Davidson Forty-Eight Guide

2020 Harley-Davidson Forty-Eight

2020 Harley-Davidson Forty-Eight 2020 Harley-Davidson Forty-Eight 2020 Harley-Davidson Forty-Eight 2020 Harley-Davidson Forty-Eight 2020 Harley-Davidson Forty-Eight

STAND ALL THE WAY OUT.

2020 Harley-Davidson Forty-Eight:

The Forty-Eight® featuresfat tires on a skinny bike with an iconic peanut tank that made its debut in 1948. Designed with signature bulldog stance and 1200cc of torque. In addition to the look, it features a large 49mm front forks, an adjustable rear suspension, cast aluminum wheels with floating rotors and powerful brakes for plenty of handling and comfort.

Heavy-hitting style with fat tires and an iconic peanut tank. Designed with its signature bulldog stance and 1200cc of corner cranking torque.



2020 Harley-Davidson Forty-Eight Totalmotorcycle.com Key Features

The Sportster® motorcycle has been a feature on the motorcycling landscape since it first hit the scene in 1957. This is the machine that’s done it all. Drag racing, flat track racing, land speed records, and every kind of street riding or cross-country trek riders could dream up. Simple, righteous, bare-knuckle style. Legendary engine. Easily affordable. Infinitely customizable. Updated for the modern era. Take it wherever you want to go.

Engine

Air-cooled, Evolution®

Engine Torque

73 ft-lb

Weight, As Shipped

545 lb.

Seat Height, Laden

26.2 in.





2020 Harley-Davidson Forty-Eight Totalmotorcycle.com Features

1200 cc Air-Cooled Evolution® Engine

An iconic V-Twin engine that is renowned for its massive low-end torque and soul-satisfying sound. Lightweight aluminum heads and cylinders improve air-cooling efficiency.



Fat Front Wheel

Custom rubber reminiscent of the lead-sled culture. You get a beefy front end with a tall, fat MT90 tire that gives the bike a dominating presence up front and provides a smooth ride and solid handling.



49mm Fork with Cartridge Dampening

The brawny 49mm front fork is accentuated by massive triple clamps and fork brace. We’ve also added cartridge damping technology to keep the handling crisp and confident, no matter how rough or winding the road ahead.



Emulsion Rear Shock with Screw Adjuster

Features an Emulsion rear shock with a screw pre-load adjuster that soaks up every bump the street throws your way, and easily adjusts to fit your riding style.



Split 9-Spoke Cast Aluminum Wheels

A set of black hardcore rims with added machined highlights to set off the design. They’re built of lightweight cast aluminium, so even with the plentitude of fat black rubber rolling underneath the ride feels light and nimble.



Foundation Brake System

An innovative, high-performing system that gives riders more confidence on the road and more power and predictability when you squeeze the brakes.



Iconic 2.1 Gallon Fuel Tank

A classic peanut fuel tank design that adds to the machine’s low, powerful bulldog look, showing off the solid mass of the engine and the rawboned style of the lean Sportster® frame.







2020 Harley-Davidson Forty-Eight – Totalmotorcycle.com  American Specifications/Technical Details
US MSRP Price from: $11299
USD
Canada MSRP Price from: $12999 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

Pricing

  • Vivid Black $11,299
  • Color $11,649
  • Custom Color $11,999
  • ABS Option $795
  • Security System Option $395
  • California Emissions $100
  • Freight $360

Engine

  • Engine1 Air-cooled, Evolution®
  • Bore 3.5 in.
  • Stroke 3.8 in.
  • Displacement 73.4 cu in
  • Compression Ratio 10:01
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Black, staggered exhaust with slash-cut mufflers

Dimensions

  • Length 85.2 in.
  • Seat Height, Laden7 26.2 in.
  • Ground Clearance 4.3 in.
  • Rake (steering head) (deg) 30.2
  • Trail 5.3 in.
  • Wheelbase 58.9 in.
  • Tires, Front Specification 130/90B16 73H
  • Tires, Rear Specification 150/80B16 77H
  • Fuel Capacity 2.1 gal.
  • Oil Capacity (w/filter) 2.8 qt.
  • Weight, As Shipped 545 lb.
  • Weight, In Running Order 556 lb.

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 73 ft-lb
  • Engine Torque (rpm) 3,500
  • Lean Angle, Right (deg.) 27.1
  • Lean Angle, Left (deg.) 27.1
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy5 48 mpg

Drivetrain

  • Primary Drive Chain, 38/57 ratio
  • Gear Ratios (overall) 1st 9.315
  • Gear Ratios (overall) 2nd 6.653
  • Gear Ratios (overall) 3rd 4.948
  • Gear Ratios (overall) 4th 4.102
  • Gear Ratios (overall) 5th 3.517

Chassis

  • Wheels, Front Type7 Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
  • Wheels, Rear Type Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
  • Brakes, Caliper Type Dual-piston front, Dual-piston rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
  • Gauges Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights







2020 Harley-Davidson Forty-Eight – Totalmotorcycle.com  Canadian Specifications/Technical Details

Pricing

  • Vivid Black $ 12,999
  • Colour $ 13,399
  • Custom Colour $ 13,849
  • ABS Option $ 615
  • Security System Option $ 355

Engine

  • Engine1 Air-cooled, Evolution®
  • Bore 88.9 mm
  • Stroke 96.8 mm
  • Displacement 1,202 cc
  • Compression Ratio 10:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Black, staggered exhaust with slash-cut mufflers

Dimensions

  • Length 2,165 mm
  • Seat Height, Unladen 710 mm
  • Ground Clearance 110 mm
  • Rake 30.2
  • Trail 135 mm
  • Wheelbase 1,495 mm
  • Tires, Front Specification 130/90B16 73H
  • Tires, Rear Specification 150/80B16 77H
  • Fuel Capacity 7.9 l
  • Oil Capacity 2.6 l
  • Weight, As Shipped 247 kg
  • Weight, In Running Order 252 kg

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 99 Nm
  • Engine Torque (rpm) 3,500
  • Lean Angle, Right (deg.) 27.1
  • Lean Angle, Left (deg.) 27.1
  • Fuel Economy: Estimated City/Hwy5 4.9 l/100 km

Drivetrain

  • Primary Drive Chain, 38/57 ratio
  • Gear Ratios (overall) 1st 9.315
  • Gear Ratios (overall) 2nd 6.653
  • Gear Ratios (overall) 3rd 4.948
  • Gear Ratios (overall) 4th 4.102
  • Gear Ratios (overall) 5th 3.517

Chassis

  • Wheels, Front Type9 Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
  • Wheels, Rear Type Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
  • Brakes, Caliper Type Dual-piston front, Dual-piston rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
  • Gauges Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights











Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
