2020 Harley-Davidson Heritage Classic Guide

2020 Harley-Davidson Heritage Classic

2020 Harley-Davidson Heritage Classic 2020 Harley-Davidson Heritage Classic 2020 Harley-Davidson Heritage Classic 2020 Harley-Davidson Heritage Classic 2020 Harley-Davidson Heritage Classic

FROM THE SHADY SIDE OF THE FAMILY TREE.

2020 Harley-Davidson Heritage Classic:

The chrome, leather, Milwaukee-Eight® 107 engine, Softail® frame and suspension, windshield, and hard saddlebags perfectly balance a classic with modern comfort.

The refined finishes, modern edge and reinvigorated ride of the Heritage model take nostalgia ripping into the here and now.

The Heritage Classic motorcycle drapes the Harley-Davidson Softail® platform in pure nostalgia, and for 2020 it has been re-styled, exchanging the blacked-out look of the previous model for bright finishes to give this bike a more-appealing look to riders who love the gleam and sparkle of rich Harley-Davidson chrome. Re-styled components include a bright powertrain with chrome air cleaner and covers; chrome steel laced wheels; chrome headlamp bucket and auxiliary light buckets, bright fork legs and chrome fork covers and nacelle; chrome rear fender struts and side covers; a chrome console; a polished stainless steel handlebar with a chrome riser and top clamp; and a full clear windscreen with chrome support hardware. The Heritage Classic is powered by the Milwaukee-Eight 107 powertrain and is mechanically identical to the 2019 model. Features include lockable and sealed hard saddlebags, a detachable windscreen, a two-piece skirted seat and pillion with black studs, and standard cruise control and Antilock Braking System (ABS). Color options include: Vivid Black, Billiard Burgundy, two-tone Silver Pine/Spruce and Billiard Red/Vivid Black. The Heritage Classic 114 model powered by the Milwaukee-Eight 114 engine will retain the model’s original, blacked-out look.





2020 Harley-Davidson Heritage Classic Totalmotorcycle.com Key Features

One look at the Low Rider S is all it takes to see how far the Softail® family has come. It’s the latest in a new revolution of custom motorcycles we launched in 2018. With every Softail, you get a lighter frame, responsive new suspension, and the power of the Milwaukee-Eight® v-twin engine. In keeping with the custom tradition, each model has its own attitude and style. Ranging from the blacked-out nostalgia of the Heritage Classic to the futuristic edge of the Fat Bob® and FXDR 114 models. Find the one that fits your style. You’re in for one hell of a ride.

Engine

Milwaukee-Eight®
107 OR 114

Engine Torque

109 ft-lb

Weight, As Shipped

697 lb.

Seat Height, Laden

26.3 in.







2020 Harley-Davidson Heritage Classic Totalmotorcycle.com Features

A Dark Classic with Modern Edge

Dripping with gangster-era style and vintage details. If Bonnie and Clyde rode a Harley® motorcycle, this would be the one.



Softail®Frame

The frame retains the classic Softail® lines, but its lightweight design and stiffness translate to a responsive ride unlike anything you’ve felt before.



Milwaukee-Eight® Big Twin Engine

A powerful, cool-running engine with crisp throttle response and a pure, soul-satisfying rumble. Available with a 107 engine in chrome finish or 114 engine in blacked-out finish.



Signature LED Forward Lighting

Darkness-defying lighting that gives you great visibility at night.



Lockable and Sealed Saddlebags

A sleek look on the outside and roomy on the inside with enough space to stash your riding essentials. The lids open with one touch.



Detachable Windscreen

Go from touring to cruising in a heartbeat. Leave the screen on for a clean envelope of air over the long haul. Or remove it in seconds for a completely new look and ride.



High Performance Front Suspension

Sophisticated suspension technology provides the performance of a racing-style cartridge fork for reduced weight with linear damping characteristics.



High Performance Rear Mono Shock

Easily adjustable mono-shock rear suspension allows for dynamic cornering capability while preserving the hardtail look.







2020 Harley-Davidson Heritage Classic – Totalmotorcycle.com  American Specifications/Technical Details
US MSRP Price from: $18999
USD
Canada MSRP Price from: $231499 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

Pricing

  • Vivid Black $18,999
  • Color $19,399
  • Two-Tone $19,749
  • Custom Color $19,949
  • ABS Option Standard
  • Security System Option Standard
  • Cruise Control Option Standard
  • California Emissions $200
  • Freight $390

Engine

  • Engine1 Milwaukee-Eight® 107
  • Bore 3.937 in.
  • Stroke 4.374 in.
  • Displacement 107 cu in
  • Compression Ratio 10.0:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-2 shorty dual; catalyst in muffler

Dimensions

  • Length 95.1 in.
  • Seat Height, Laden7 26.3 in.
  • Ground Clearance 4.7 in.
  • Rake (steering head) (deg) 30
  • Trail 5.5 in.
  • Wheelbase 64.2 in.
  • Tires, Front Specification 130/90B16,73H,BW
  • Tires, Rear Specification 150/80B16,77H,BW
  • Fuel Capacity 5 gal.
  • Oil Capacity (w/filter) 5 qt.
  • Weight, As Shipped 697 lb.
  • Weight, In Running Order 728 lb.
  • Luggage Capacity -Volume 1.5 cu ft

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 109 ft-lb
  • Engine Torque (rpm) 3,000
  • Lean Angle, Right (deg.) 27.3
  • Lean Angle, Left (deg.) 28.5
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy5 47 mpg

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type9 Chrome Steel Laced
  • Wheels, Rear Type Chrome Steel Laced
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, turn signals, neutral, low oil pressure, engine diagnostics, auxilary lighting, cruise, ABS, security, low battery voltage, low fuel
  • Gauges 5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication





2020 Harley-Davidson Heritage Classic – Totalmotorcycle.com  Canadian Specifications/Technical Details

Pricing

  • Vivid Black $ 23,149
  • Colour $ 23,599
  • Two-Tone $ 23,999
  • Custom Color $ 24,349
  • ABS Option Standard
  • Security System Option Standard
  • Cruise Control Option Standard

Engine

  • Engine1 Milwaukee-Eight® 107
  • Bore 100 mm
  • Stroke 111.1 mm
  • Displacement 1,746 cc
  • Compression Ratio 10.0:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-2 shorty dual; catalyst in muffler

Dimensions

  • Length 2,415 mm
  • Seat Height, Unladen 680 mm
  • Ground Clearance 120 mm
  • Rake (steering head) (deg) 30
  • Trail 140 mm
  • Wheelbase 1,630 mm
  • Tires, Front Specification 130/90B16,73H,BW
  • Tires, Rear Specification 150/80B16,77H,BW
  • Fuel Capacity 18.9 l
  • Oil Capacity (w/filter) 4.7 l
  • Weight, As Shipped 316 kg
  • Weight, In Running Order 330 kg
  • Luggage Capacity -Volume 0.043 m3

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 148 Nm
  • Engine Torque (rpm) 3,000
  • Lean Angle, Right (deg.) 27.3
  • Lean Angle, Left (deg.) 28.5
  • Fuel Economy: Estimated City/Hwy5 5 l/100 km

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type9 Chrome Steel Laced
  • Wheels, Rear Type Chrome Steel Laced
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, turn signals, neutral, low oil pressure, engine diagnostics, auxilary lighting, cruise, ABS, security, low battery voltage, low fuel
  • Gauges 5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication











Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
