2020 Harley-Davidson Ultra Limited Guide

2020 Harley-Davidson Ultra Limited

2020 Harley-Davidson Ultra Limited 2020 Harley-Davidson Ultra Limited 2020 Harley-Davidson Ultra Limited 2020 Harley-Davidson Ultra Limited 2020 Harley-Davidson Ultra Limited

EXPERIENCE A RIDE THAT IS ANYTHING BUT STANDARD.

2020 Harley-Davidson Ultra Limited:

From its Twin-Cooled™ Milwaukee-Eight® 114 V-Twin engine down to its heated hand grips, the Ultra Limited motorcycle has just the right balance: batwing fairing and a splitstream air vent for optimal air flow and reduced head buffeting, H-D Connect Service for keeping an eye on it’s vitals and security, a BOOM!™ GTS infotainment system, electronic cruise control, responsive front and rear suspension, and a Tour-Pak® carrier with room for two full-face helmets. If that’s not enough, you have the option of going with new bold Black finish, enveloping your ride in blacked-out styling fresh from us to you.

It’s loaded. From the Milwaukee-Eight® 114 engine to the heated hand grips. Classic Batwing fairing, all new BOOM!™ GTS infotainment system, and plenty more. Yes, you can have it all.



2020 Harley-Davidson Ultra Limited Totalmotorcycle.com Key Features

There’s a wide-open world to experience out there. We’ve been building the motorcycles to help you discover it in the most epic way possible since we invented the fully dressed touring machine in the 1960’s. Entire continents; and all the mountain ranges, canyons, glaciers, small towns, deserts, cities, roadside attractions, adventures, and stories they contain; are yours for the taking in the saddle of a Harley-Davidson® Touring machine. no one builds them better.

Engine

Twin-Cooled™ Milwaukee-Eight™ 114

Engine Torque

114 ft-lb

Weight, As Shipped

880 lb.

Seat Height, Laden

27.5 in.







2020 Harley-Davidson Ultra Limited Totalmotorcycle.com Features

Milwaukee-Eight® 114 Engine

The most displacement in standard H-D® Touring models. You get 114 cubic inches of passing and horizon-chasing power.

H-D™ Connect Service

With subscription-based cellular connectivity, you can connect to your bike through your smart phone using the latest version of the Harley-Davidson® App. Check your bike’s vitals including fuel level, get tamper alerts and stolen-vehicle tracking, and more.



Reflex™ Linked Brembo® Brakes with Standard ABS

Designed to help prevent the wheels from locking under braking to assist the rider in maintaining control when braking in a straight-line. ABS operates independently on front and rear brakes to keep the wheels rolling and help prevent uncontrolled wheel lock in urgent situations.

Reflex™ Defensive Rider Systems (Optional)

A new collection of technologies that help give you confidence and control in less-than-ideal situations. The systems utilize advanced chassis control, electronic brake control and powertrain technology to assist you with accelerating and braking in a straight line or while in a turn.



BOOM!™ Box GTS Infotainment System

An evolved interface experience that offers a contemporary look, feel and function, with exceptional durability and features designed specifically for motorcycling. Every element is optimized to enhance the rider’s interaction with the bike and connectivity with the world.



Heated Handgrips

Equipped with six settings, so you can easily adjust on the fly for the heat you need.



Batwing Fairing & Splitstream Air Vent

Designed to deliver smoother airflow and reduced head buffeting with a pressure-equalizing duct on the front. It opens and closes with one touch of a button.



Electronic Cruise Control

Set your own speed on the 6-Speed Cruise Drive® Transmission. It provides smooth, quiet shifting and adapts to whatever terrain you’re riding on.



Responsive Suspension

High-performing front and rear suspension with easily adjustable rear shocks put you in control of a plush ride.



Premium Tour-Pak® Luggage Carrier

A sleek yet spacious Tour-Pak® luggage carrier that can easily house both rider and passenger helmets along with extra travel essentials.



One-Touch Opening Saddlebags

Tight on the outside, roomy on the inside. The hinges are simple and clean and the lids open with one touch of one hand.







2020 Harley-Davidson Ultra Limited – Totalmotorcycle.com  American Specifications/Technical Details
US MSRP Price from: $28699
USD
Canada MSRP Price from: $33899 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

Pricing

  • Vivid Black $28,699
  • Color $29,299
  • Two-Tone $29,749
  • Custom Color $29,999
  • Two-Tone Custom Color $30,899
  • Special Edifion – Police & Fire $28,699
  • Black Pearl Trim Option $1,900
  • ABS Option Standard
  • Reflex™ Defensive Rider System (RDRS) $995
  • Security System Option Standard
  • Cruise Control Option Standard
  • Premium Radio Option Standard
  • California Emissions $200
  • Freight $435

Engine

  • Engine1 Twin-Cooled™ Milwaukee-Eight™ 114
  • Bore 4.016 in.
  • Stroke 4.5 in.
  • Displacement 1,868 cc (114 cu in)
  • Compression Ratio 10.5:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Chrome, 2-1-2 dual exhaust with tapered mufflers

Dimensions

  • Length 102.3 in.
  • Seat Height, Laden7 27.5 in.
  • Ground Clearance 5.3 in.
  • Rake (steering head) (deg) 26
  • Trail 6.7 in.
  • Wheelbase 64 in.
  • Tires, Front Specification BW 130/70B18 63H
  • Tires, Rear Specification BW 180/55B18 80H
  • Fuel Capacity 6 gal.
  • Oil Capacity (w/filter) 5 qt.
  • Weight, As Shipped 880 lb.
  • Weight, In Running Order 917 lb.
  • Luggage Capacity -Volume 4.7 cu ft

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 114 ft-lb
  • Engine Torque (rpm) 3,250
  • Lean Angle, Right (deg.) 32
  • Lean Angle, Left (deg.) 32
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy5 43 mpg

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.593
  • Gear Ratios (overall) 2nd 6.65
  • Gear Ratios (overall) 3rd 4.938
  • Gear Ratios (overall) 4th 4
  • Gear Ratios (overall) 5th 3.407
  • Gear Ratios (overall) 6th 2.875

Chassis

  • Wheels, Optional Style Type Denim Black and Contrast Gloss Black Tomahawk, Gloss Black and Contrast Smoked Satin Tomahawk
  • Wheels, Front Type9 Gloss Black and Contrast Satin Tomahawk
  • Wheels, Rear Type Gloss Black and Contrast Satin Tomahawk
  • Brakes, Caliper Type 32 mm, 4-piston fixed front and rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 Headlight, running lights, directional lights, neutral, low oil pressure, check engine, turn signals, security/fault indication,gear indication, neutral, low fuel warning, cruise control, ABS, Low Tire Pressure/TPMS indicator, Traction Control, Rain Mode, Vehicle Hold Control (VHC), fog/aux lamp indicator
  • Gauges Gauges styled to complement each vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators.

Infotainment

  • Infotainment system Boom!™ Box GTS
  • Type Full Color TFT
  • Watts Per Channel 25
  • Speakers 4
  • Speaker Size 5.25 inch standard
  • Headset Specification (if equipped) 16-64 ohms
  • AM Standard
  • FM Standard
  • Weather Band (WB) Standard
  • SD Card, Flash Drive and MP3 – via USB Connection Supported
  • SiriusXM Presets 20 – P&A Upgrade (USA & Canada only)
  • Languages English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, Portuguese (Portugal/Brazil), Russian, Czech, Polish, Dutch, Turkish, Japanese
  • Hands-free Mobile Phone – via Bluetooth Standard
  • Voice Recognition Languages: Phone functions only English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, Portuguese (Portugal/Brazil), Russian, Czech, Polish, Dutch, Turkish, Japanese
  • Voice Recognition Languages: Tuner/Media/Navigation English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, Portuguese (Portugal/Brazil), Russian, Czech, Polish, Dutch, Turkish, Japanese
  • Rider/Passenger Intercom Standard
  • Vehicle Information Screen (Air temperature, oil pressure and EITMS) Standard
  • Text-to-Speech (TTS) Languages English (US/UK), German, Spanish (Mexico/Spain), French (Canada/France), Italian, Portuguese (Portugal/Brazil), Russian, Czech, Polish, Dutch, Turkish, Japanese
  • USB USB/MTP/iPod/iPhone
  • Bluetooth Phone/Media Supported







2020 Harley-Davidson Ultra Limited – Totalmotorcycle.com  Canadian Specifications/Technical Details

Pricing

  • Vivid Black $ 33,899
  • Colour $ 34,499
  • Two-Tone $ 35,099
  • Custom Colour $ 35,399
  • Two-Tone Custom Colour $ 36,399
  • Black Pearl Trim Option $ 2,300
  • ABS Option Standard
  • Reflex™ Defensive Rider System (RDRS) Standard
  • Security Option Standard
  • Cruise Control Option Standard
  • Premium Radio Option Standard

Engine

  • Engine1 Twin-Cooled™ Milwaukee-Eight® 114
  • Bore 102 mm
  • Stroke 114 mm
  • Displacement 1,868 cc
  • Compression Ratio 10.5:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Chrome, 2-1-2 dual exhaust with tapered mufflers

Dimensions

  • Length 2,600 mm
  • Seat Height, Unladen 740 mm
  • Ground Clearance 135 mm
  • Rake 26
  • Trail 170 mm
  • Wheelbase 1,625 mm
  • Tires, Front Specification BW 130/70B18 63H
  • Tires, Rear Specification BW 180/55B18 80H
  • Fuel Capacity 22.7 l
  • Oil Capacity (w/filter) 4.7 l
  • Weight, As Shipped 399 kg
  • Weight, In Running Order 416 kg
  • Luggage Capacity -Volume 0.132 m3

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 166 Nm
  • Engine Torque (rpm) 3,000
  • Lean Angle, Right (deg.) 32
  • Lean Angle, Left (deg.) 32
  • Fuel Economy: Estimated City/Hwy5 5.5 l/100 km

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.593
  • Gear Ratios (overall) 2nd 6.65
  • Gear Ratios (overall) 3rd 4.938
  • Gear Ratios (overall) 4th 4
  • Gear Ratios (overall) 5th 3.407
  • Gear Ratios (overall) 6th 2.875

Chassis

  • Wheels, Optional Style Type Gloss Black Slicer II
  • Wheels, Front Type9 Slicer II cast aluminum with clear coat
  • Wheels, Rear Type Slicer II cast aluminum with clear coat
  • Brakes, Caliper Type 32 mm, 4-piston fixed front and rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, running lights, front fender running lights, directional light bar, low oil pressure, engine diagnostics, cruise control, speakers, accessory, security system, 6-speed, low fuel warning, ABS
  • Gauges Gauges styled to complement each vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators.

Infotainment

  • Infotainment system Boom!™ Box GTS
  • Type Full Color TFT
  • H-D™ Connect Service Supported
  • Watts Per Channel 25
  • Speakers 4
  • Speaker Size 5.25 inch standard
  • Headset Specification (if equipped) 16-64 ohms
  • AM Standard
  • FM Standard
  • SD Card, Flash Drive and MP3 – via USB Connection Supported
  • SiriusXM Presets 20 – P&A Upgrade (USA & Canada only)
  • Languages English (US/UK),German,Spanish (Mexico/Spain),French (Canada/France),Italian,Portuguese (Portugal/Brazil),Russian,Czech,Polish,Dutch,Turkish,Japanese
  • Hands-free Mobile Phone – via Bluetooth Standard
  • Voice Recognition Languages: Phone functions only English (US/UK),German,Spanish (Mexico/Spain),French (Canada/France),Italian,Portuguese (Portugal/Brazil),Russian,Czech,Polish,Dutch,Turkish,Japanese
  • Voice Recognition Languages: Tuner/Media/Navigation English (US/UK),German,Spanish (Mexico/Spain),French (Canada/France),Italian,Portuguese (Portugal/Brazil),Russian,Czech,Polish,Dutch,Turkish,Japanese
  • Rider/Passenger Intercom Standard
  • Vehicle Information Screen (Air temperature, oil pressure and EITMS) Standard
  • Text-to-Speech (TTS) Languages English (US/UK),German,Spanish (Mexico/Spain),French (Canada/France),Italian,Portuguese (Portugal/Brazil),Russian,Czech,Polish,Dutch,Turkish,Japanese
  • USB USB/MTP/iPod/iPhone
  • Bluetooth Phone/Media Supported











Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
