2020 Kawasaki Z400 ABS : BUILT TO BE SEEN.
2020 Kawasaki Z400 ABS.
A fiercely authentic supernaked, the Kawasaki Z400 ABS exudes fresh street style and is immediately recognizable in a crowd with its compact chassis and aggressive styling. Comfortable, balanced and capable, the Z400 ABS offers a visceral riding experience that’s sure to turn heads.
Lightweight. Class-Leading Power. Refined Raw.
With class-redefining weight and performance, the all-new 2020 Z400 establishes itself as the pack leader of lightweight naked streetbikes. Clad in aggressive new styling and inspired by Japanese Sugomi* principles, the Z400 delivers ultralight handling with strong low-end power ideal for rider friendly, nimble street riding. Whether confidently navigating the city streets or parked strikingly on a street corner, this lightweight and powerful streetfighter is sure to turn heads.
FEATURING:
PARALLEL-TWIN 399cc ENGINE
ASSIST & SLIPPER CLUTCH
LIGHTWEIGHT TRELLIS FRAME
Aggressive streetfighter styling
Lightweight chassis
Upright riding position
Low seat height
2020 Kawasaki Z400 ABS Totalmotorcycle.com Key Features
The Z400 was designed to appeal to entry-level riders by retaining the performance of the widely popular Ninja 400 and pairing that performance with the more upright riding position and styling of a naked motorcycle. With its finely tuned 399cc parallel twin four stroke engine and lightweight trellis frame, it offers lightweight handling and stronger low-end feeling – a rider friendly combination that is ideal for fun. Matching its exhilarating performance, the Z400 is clad in aggressive new styling that is inspired by the Sugomi™ styling of the flagship Z models, and a riding position that enhances the rider’s confidence. The Z400 motorcycle is packed with premium class leading components and advanced technology, such as the 310 mm front disc and 41mm inverted fork.
2020 Kawasaki Z400 ABS Totalmotorcycle.com Features and Benefits
‘New school’ gets a new contender with the entry middleweight Kawasaki Z400 ABS naked motorcycle.
A fiercely authentic naked sportbike, the Z400 ABS exudes fresh street style and is immediately recognizable in a crowd with its compact chassis and aggressive styling. Comfortable, balanced and capable, the new Z400 ABS offers a visceral riding experience that’s sure to turn heads
SMOOTH TORQUE & ACCELERATION
A compact parallel-twin 399cc engine is the beating heart of Kawasaki’s new Z400 ABS naked motorcycle, providing exhilarating power with a broad, responsive powerband. Smooth performance is highlighted by the strong mid-range and excellent roll-on acceleration.
AGILE SPORTY HANDLING
Beneath its menacing look lies the soul of a skillfully-tuned naked sportbike. The slim, lightweight trellis frame of the Z400 ABS motorcycle is optimized for lightweight agility and responsive handling. Sport-tuned suspension ensures a smooth, balanced ride. The low seat height and upright riding ergonomics place the rider forward for an aggressive stance and a commanding view of the road, while also providing an easy reach to the ground.
Z STYLING
It’s what’s not there that defines the aggressive edge of the new Kawasaki Z400 ABS naked sportbike. Minimalist bodywork allows the striking details of this middleweight to emerge. It may be a sportbike at its core, but the Z400 ABS commands attention with its streetfighter attitude. Revel in the visceral feel of motorcycling at its purest and ride apart with unmistakable Z styling.
2020 Kawasaki Z400 ABS – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $4,999 USD
Canada MSRP Price: $5999 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
POWER
Engine 4-stroke, 2-cylinder, DOHC, liquid-cooled
Displacement 399cc
Bore x Stroke 70.0 x 51.8mm
Compression Ratio 11.5:1
Maximum Torque 28.0 lb-ft @ 8,000 rpm
Fuel System DFI® with 32mm throttle bodies
Ignition TCBI with digital advance
Transmission 6-speed, return shift
Final Drive Sealed chain
PERFORMANCE
Front Suspension / Wheel Travel Telescopic fork/4.7 in
Rear Suspension / Wheel Travel Uni-Trak® swingarm/5.1 in
Front Tire 110/70-17M/C 54H
Rear Tire 150/60-17M/C 66H
Front Brakes Single disc
Rear Brakes Single disc
DETAILS
Frame Type Trellis, high-tensile steel
Rake/Trail 24.5°/3.6 in
Overall Length 78.3 in
Overall Width 31.5 in
Overall Height 41.5 in
Ground Clearance 5.7 in
Seat Height 30.9 in
Curb Weight 363.8 lb**
Fuel Capacity 3.7 gal
Wheelbase 53.9 in
Color Choices Metallic Matte Graphite Gray/Metallic Spark Black, Candy Steel Furnace Orange/Metallic Flat Spark
Black
Warranty 12 Month Limited Warranty
Kawasaki Protection Plus™ (optional) 12, 24, 26 or 48 months
**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). When equipped, California evaporative
emissions equipment adds approximately 2.2 lb.
2020 Kawasaki Z400 ABS – Totalmotorcycle.com Canadian Specifications/Technical Details
ENGINE
| Displacement | 399cc |
| Type | 4-stroke Parallel Twin |
| Bore and stroke | 70.0 x 51.8 mm |
| Cooling | Liquid-cooled |
| Compression ratio | 11.5:1 |
| Valve system | DOHC, 8 valves |
| Fuel system | Fuel Injection: 32mm x 2 (Keihin) |
| Ignition | Digital |
| Lubrication | Forced Lubrication, wet sump |
BRAKES
| Front: type | Single semi-floating 310 mm petal disc |
| Front: calipers | Single balanced actuation dual-piston |
| Rear: type | Single 220 mm petal disc |
| Rear: calipers | Dual-piston |
DIMENSIONS
| Overall length | 1,990 mm |
| Overall width | 800 mm |
| Overall height | 1,055 mm |
| Wheelbase | 1,370 mm |
| Ground clearance | 145 mm |
| Seat height | 785mm |
| Curb mass** | 165 kg |
| Fuel capacity | 14 litres |
DRIVETRAIN
| Transmission | 6-speed, return |
| Final drive | Chain |
| Primary reduction ratio | 2.219 (71/32) |
| Gear ratio: 1st | 2.929 (41/14) |
| Gear ratio: 2nd | 2.056 (37/18) [ |
| Gear ratio: 3rd | 1.619 (34/21) |
| Gear ratio: 4th | 1.333 (32/24) |
| Gear ratio: 5th | 1.154 (30/26) |
| Gear ratio: 6th | 1.037 (28/27) |
| Final reduction ratio | 2.929 (41/14) |
| Clutch | Wet multi-disc, manual |
FRAME
| Type | Trellis, high-tensile steel |
| Wheel travel: front | 120mm |
| Tire: front | 110/70-17 M/C 54S |
| Wheel travel: rear | 130 mm |
| Tire: rear | 150/60R17 M/C 66H |
| Caster (rake) | 24.5° |
| Trail | 92 mm |
| Steering angle (left/right) | 35° / 35° |
PERFORMANCE
| Maximum Power‡ | 36 kW {49 PS} / 10,000 rpm |
| Maximum Torque‡ | 38 N.m {3.9 kgf.m} / 8,000 rpm |
SUSPENSION
| Suspension, front | 41 mm telescopic fork |
| Suspension, rear | Bottom-Link Uni-Trak, gas-charged shock with adjustable preload |
DETAILS
| Warranty | 12 months warranty |
2020 Kawasaki Z400 ABS – Totalmotorcycle.com European Specifications/Technical Details
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
