2020 Suzuki GSX-R600 Guide

2020 Suzuki GSX-R600

2020 Suzuki GSX-R600 2020 Suzuki GSX-R600 2020 Suzuki GSX-R600 2020 Suzuki GSX-R600

2020 Suzuki GSX-R600: WINS THE ENVY OF OTHER RIDERS.

2020 Suzuki GSX-R600:

The Suzuki GSX-R600 is a class-leading sportbike worthy of its race-winning GSX-R heritage. Whether you’re carving through your favorite canyon or dominating the racetrack, it offers unparalleled performance. A compact, powerful, four-cylinder engine demonstrates the advanced race-proven technology of the GSX-R line when you hit the throttle and push it to redline, while supremely refined suspension systems front and rear help provide precise, responsive handling. Wrapped in aerodynamic and lightweight bodywork that’s lifted from the racetrack, the GSX-R600 can not only win races, it can win envy.



The Suzuki GSX-R600 continues its dominance in the AMA Pro Road Racing series, taking all 600cc championships in 2012 – including the Daytona Sportbike, Supersport West, and Supersport East. This further solidifies the GSX-R600 as part of a race-winning line of motorcycles from coast to coast.

In 2012, Suzuki celebrated the 1 millionth produced GSX-R motorcycle, a feat only accomplished with the support of fans, race teams, and dealers worldwide. To earn the rights as the top performer in its class, the GSX-R600 is developed with: an advanced race-proven 599cc, 4-cylinder, and liquid-cooled engine; a responsive, agile, and lightweight chassis; compact wheelbase; and race-developed suspension. In short, the GSX-R600 has once again proven to be the winning combination to Own The Racetrack.







2020 Suzuki GSX-R600 Totalmotorcycle.com Key Features

Built to own the racetrack and let loose on the streets. Since 1985, the GSX-R has been continuously refined to deliver new levels of performance and agility. This legacy of innovation continues with over 1 million legends made.

Key Features
Race-ready, iconic GSX-R styling provides sharp looks and a slippery shape with deep, rich paint. Riders can choose between Glass Sparkle Black or Pearl Glacier White colors, each with monochromatic graphics and color-matched cast aluminum wheels.
The GSX-R600’s compact, fuel-injected, 599cc, four-cylinder engine delivers a rush of power from idle to redline. Located between the frame’s spars, the engine’s top end is canted forward to improve cylinder head charging for increased power output.
The Suzuki Drive Mode Selector (S-DMS) lets the rider adjust the engine’s power delivery to suit the riding conditions.
The twin-spar aluminum frame effectively connects the steering head with the swingarm pivot portion of the chassis in a way that balances light weight and strength. The engine is suspended below the frame to keep mass low and the wheelbase short to promote nimble handling.
The Showa Big Piston Front Fork (BPF) and remote reservoir rear shock absorber are fully adjustable to deliver exceptional handling.
Twin Brembo Monobloc, radially mounted front brake calipers grasp fully floating stainless steel brake rotors to deliver strong stopping power.







2020 Suzuki GSX-R600 Totalmotorcycle.com Features and Benefits
Engine Features
A compact 599cc, four-cylinder engine with a race-proven over-square bore/stroke ratio produces remarkably strong high rpm power delivery.
The energy-efficient engine employs forged pistons, shot-peened connecting rods, chrome-nitride-coated upper compression and oil control rings, and pentagonal ventilation holes to reduce frictional and mechanical losses.
Camshafts with aggressive valve-lift profiles were developed using proven MotoGP racing engine technology – the first time this method has been applied to a production Suzuki.
Lightweight titanium alloy valves are controlled by single-coil valve springs to reduce valve train mass, reducing mechanical losses at high rpm.
Lightweight and durable forged pistons were designed using the same Finite Element Method (FEM) and fatigue analysis technology used for MotoGP racing engines.
Suzuki Dual Throttle Valve (SDTV) fuel injection uses eight fine-spray eight-hole injectors for improved fuel atomization, which contributes to more complete combustion.
An Engine Control Module (ECM) provides state-of-the-art engine management and has enhanced settings to suit the intake and exhaust systems, resulting in better fuel economy and linear throttle response.
Advanced, MotoGP-developed transistorized ignition control programming helps maintain more precise spark timing across the range of engine speed and temperature.
Suzuki Drive Mode Selector (S-DMS) offers push-button selection of two racing-developed engine control maps to suit road or track conditions and personal tastes.
Four-into-one stainless steel exhaust system with a titanium muffler is fitted with a Suzuki Exhaust Tuning (SET) valve that maximizes torque and improves throttle response, especially in the low- to mid-rpm range.
The close-ratio six-speed transmission features a taller first-gear ratio and shorter ratios for second, third, fourth, and sixth gears, making it easier for a racer to get a good start while improving straight-line acceleration and drive out of corners.
Race-proven back-torque-limiting clutch contributes to smoother downshifting and corner entry.
Chassis Features
Lightweight and compact twin-spar aluminum alloy frame is constructed of five cast sections to produce a balance of light weight and strength.
The frame is mated with a cast aluminum swingarm and multi-piece rear sub-frame that’s ready for racetrack use.
Race-developed, lightweight Showa Big Piston Front Fork (BPF) delivers superb feedback and consistent performance.
Single Showa rear shock absorber features externally adjustable rebound and compression damping, along with adjustable ride height.
Electronically controlled steering damper provides lighter steering at slower speeds and more damping force at racetrack and highway speeds.
Front brakes with fully floating 310mm discs are grasped by radial-mount, four-piston Brembo Monobloc calipers.
Three-spoke cast aluminum alloy wheels are shod with lightweight, high-grip front and rear tires for sharp handling.
Three-way adjustable foot pegs, adjustable shift lever and short fuel tank help compose a comfortable riding position that permits the rider movement required for performance riding.
Compact, lightweight instrument cluster with a built-in lap timer/stopwatch and programmable engine rpm indicators alert the rider to certain shift points.
Trim, simple, and lightweight bodywork creates an exciting, aerodynamic style that truly works well at speed.
Distinctive multi-reflector headlight with vertically stacked high- and low-beam halogen bulbs is centered between position lights on each side.
Bright, durable LED tail light, with clear lens.
The front turn signals are integrated into the rearview mirrors while the rear tail section houses the rear signals.
The lightweight instruments also include an analog tachometer and LCD readouts that show speed, odometer, dual trip meter, reserve trip meter, clock, coolant temperature/oil pressure indicator, S-DMS, and gear position indicators.
Attention to rider comfort and confidence includes a carefully shaped seat with a high-grip cover.
Additional Features
Stylized Suzuki “S” 3-D emblems on the fuel tank and the fork upper bracket denotes the quality, sophistication, and performance legacy of the brand.
Optional single seat cowl can replace the passenger seat for an even more aggressive look or for use on solo rides or track days.
A variety of Genuine Suzuki Accessories for GSX-R owners are available, including a large selection of Suzuki logo apparel.
12-month limited warranty. Longer coverage periods with other benefits available through Suzuki Extended Protection (SEP).







2020 Suzuki GSX-R600 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $11,399 USD
Canada MSRP Price: $ 12399 CDN
Europe/UK MSRP Price: £ NA GBP (On The Road inc 20% Vat)
Engine
Engine 599cc, 4-stroke, liquid-cooled, 4-cylinder, DOHC
Bore x Stroke 67.0 mm x 42.5 mm (2.638 in. x 1.673 in.)
Compression Ratio 12.9:1
Fuel System Fuel injection with SDTV
Starter Electric
Lubrication Wet sump
Drivetrain
Clutch Wet, multi-plate type
Transmission 6-speed constant mesh
Final Drive Chain, RK525SMOZ8, 114 links
Chassis
Suspension Front Inverted telescopic, coil spring, oil damped
Suspension Rear Link type, single shock, coil spring, oil damped
Brakes Front Brembo, 4-piston, twin disc
Brakes Rear Nissin, 1-piston, single disc
Tires Front 120/70ZR17M/C (58W), tubeless
Tires Rear 190/50ZR17M/C (73W), tubeless
Fuel Tank Capacity 17.0 L (4.5 US gal.) / 16.0 L (4.2 US gal.) CA model
Color Glass Sparkle Black or Pearl Glacier White
Electrical
Ignition Electronic ignition (transistorized)
Spark Plugs NGK CR9EIA-9 or DENSO IU27D
Headlight 12V 65W (H9 high-beam) and 12V 55W (H7 low-beam)
Tail Light LED
Dimensions
Overall Length 2030 mm (79.9 in.)
Overall Width 710 mm (28.0 in.)
Overall Width 1135 mm (44.7 in.)
Wheelbase 1385 mm (54.5 in.)
Ground Clearance 130 mm (5.1 in.)
Seat Height 810 mm (31.9 in.)
Curb Weight 187 kg (412 lb.)
Warranty
Warranty 12 month unlimited mileage limited warranty
Extension Longer coverage periods with other benefits available through Suzuki Extended Protection (SEP).





Manufacturer’s Suggested Retail Price (also referred to as “MSRP”, “Base MSRP” or the “Starting At” price), excludes taxes, title, license and registration fees, destination freight and delivery charges, dealer fees, and optional equipment.







2020 Suzuki GSX-R600 – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE FEATURES
Type 4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement 599cc
Bore x Stroke 67.0 mm x 42.5 mm (2.638 in x 1.673 in)
Compression Ratio 12.9 : 1
Fuel System Suzuki Fuel Injection
Starter Electric
Lubrication Wet sump
Ignition Electronic ignition (Transistorized)
DRIVETRAIN FEATURES
Transmission 6-speed, constant mesh
Final Drive RK525SMOZ8, 114 links, Chain
CHASSIS FEATURES
Suspension Front Inverted Telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Brakes Front Brembo, Disc, Twin
Brakes Rear Disc
Tires Front 120/70ZR17M/C (58W), tubeless
Tires Rear 180/55ZR17M/C (73W), tubeless
Fuel Tank Capacity 17.0 L (4.5 US gal )
DIMENSIONS
Overall Length 2030 mm (79.9 in)
Overall Width 710 mm (28.0 in)
Overall Height 1135 mm (44.7 in)
Wheelbase 1385 mm (54.5 in)
Ground Clearance 130 mm ( 5.1 in)
Seat Height 810 mm (31.9 in)
Curb Weight 187 kg (412 lbs )
WARRANTY
Standard Warranty 12 Month unlimited mileage limited warranty









2020 Suzuki GSX-R600 – Totalmotorcycle.com European Specifications/Technical Details

NA







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
