2021 Yamaha TT-R110E Guide

2021 Yamaha TT-R110E

2021 Yamaha TT-R110E 2021 Yamaha TT-R110E 2021 Yamaha TT-R110E

2021 Yamaha TT-R110E : SMALL PACKAGE. BIG FUN.

2021 Yamaha TT-R110E:

The bike that produces big fun for both young and old riders and everyone in between.

Spark your kids’ 2-wheel passion with a TT-R110E! Learning is a snap with electric start, smooth power delivery and automatic clutch design for easy shifting.

KEY FEATURES

  • Air-cooled, 110 cc, SOHC, 2-valve, 4-stroke engine produces smooth, reliable, novice-friendly power.
  • Push-button electric starting backed up by a manual kick starter too.
  • Lightweight aluminum cylinder features a cast iron liner.
  • Single overhead camshaft
  • Flat top piston and lightweight crankshaft
  • Automatic cam chain adjuster







2021 Yamaha TT-R110E Totalmotorcycle.com Key Features
  • Electric Starter
    The convenient electric starter effortlessly starts the bike.
  • Accessible Performance
    Big fun for the whole family, the YZ-styled, four-stroke-powered TT-R110E begs to be ridden by everyone.
  • Low Seat Height
    A seat height of only 26.4 inches makes the TT-R110E accessible to most riders, but the 7.1 inches of ground clearance and great suspension at both ends means it can almost anywhere too.
  • Auto-Clutch Convenience
    Four-speed auto-clutch transmission has an easily accessible gear for nearly any terrain.



Yamaha Announces 2021 Full Lineup of Trail Motorcycles
Yamaha Celebrates the PW50’s 40th Anniversary

Yamaha Motor Corporation, USA, announces its complete lineup of 2021 trail motorcycles and celebrates the 40th anniversary of the PW50. Designed for experiencing the outdoors, the TT-R lineup is made for trail riding that the entire family can enjoy.

“Yamaha’s trail-focused motorcycle lineup is perfect for those discovering the fun and freedom of the outdoors, trail riding, and enjoying time with friends and family,” said Derek Brooks, Yamaha Motorsports’ Motorcycle Product Line Manager. “With the 40th anniversary of the PW50, Yamaha is celebrating four decades of sharing our passion and introducing generations of kids to the world of off-road riding.”

2021 PW50: 40 Years, One Great Bike
With 40 years under its belt, the 2021 PW50 continues to be one of the best trail bikes for first-time riders. After making its debut, the PW50 established itself as the go-to bike for children just learning how to ride off-road. By focusing on a “toy-like” design, Yamaha engineered a bike that was both visually appealing and approachable to new, younger riders. Selling over 8,000 units in its first year, Yamaha has now shipped more than 380,000 PW50s to over 150 countries.

The 49cc, two-stroke engine coupled with the fully automatic transmission make this a perfect bike for beginners. The PW50’s seat height of only 18.7 inches and the adjustable throttle stop screw offer both rider comfort and parent peace of mind. Additionally, the PW50’s shaft final drive system is virtually maintenance-free while Yamaha’s proven Autolube oil injection system eliminates the need for fuel/oil premixing.

2021 TT-R50E, TT-R110E, TT-R125LE and TT-R230E
The 2021 TT-R50E, TT-R110E, TT-R125LE and TT-R230E are made for ultimate trail riding fun. These electric start, air-cooled, four-stroke motorcycles offer Yamaha’s legendary durability and dependability, along with a broad, accessible powerband for ease of use and great performance in a variety of trail conditions. The low seat height of the entire TT-R line allows smaller and less experienced riders to gain confidence with easy access to the ground and great comfort.





2021 Yamaha TT-R110E Totalmotorcycle.com Features and Benefits
  • Torque-Rich Motor
    Powerful 110cc air-cooled SOHC four-stroke powerplant is tuned for maximum off-road performance in a wide range of trail conditions.
  • Compact Cylinder Design
    Compact hemispherical combustion chamber with 9.3:1 compression produces max torque at 4000 rpm and max horsepower at 7500 rpm.
  • Auto-Clutch Convenience
    Four-speed gearbox with automatic clutch has the right gear for wherever you ride.
  • Electric Starter
    Convenient electric starter for effortless starting and backup kick starting.
  • Digital Ignition
    CDI ignition system is ultra-reliable and never needs maintenance.
  • Low Maintenance Engine
    Automatic cam chain tensioner means minimal maintenance and longer engine life.
  • Easy Serviceability
    Easy-access, tool-free air filter adds extra convenience during maintenance.
  • Forest-Friendly Exhaust
    Lightweight exhaust system features quiet, USFS-approved spark arrestor.
  • Robust, Compact Frame
    Steel backbone frame ties steering head and swingarm pivot together via a straight line, with the engine mounted at three places for optimum strength and high ground clearance.
  • Well-Damped Front Fork
    The 31mm fork with high-tech internals including a damper valve with oil lock provide excellent damping and great bottoming resistance with 4.5 inches of smooth travel.
  • Advanced Rear Suspension
    Monocross® rear suspension pivoting on a strong, 12mm shaft, along with a gusseted steel swingarm, provide excellent rear wheel control through 4.3 inches of travel.
  • Stylish Aluminum Top Clamp
    Die-cast aluminum top triple clamp provides light, precise handling and looks great, too.
  • Trail-Ready Dimensions
    The 26.4-inch seat height and 7.1 inches of ground clearance inspire confident performance on rugged trails.
  • Enclosed Drum Brakes
    Front and rear drum brakes deliver strong, dependable stopping power.
  • Nimble Wheels and Tires
    The 14-inch front and 12-inch rear wheels inspire great rider confidence by keeping the seat low and the steering light.
  • Durable Knobby Tires
    Knobby tires offer superb grip and exceptional wear.
  • Low Seat Height
    The long, YZ-style gripper seat is low and comfortable and allows for easy rider movement.
  • Racing Style
    Team Yamaha-inspired colors and graphics and front and side number plates create styling similar to larger YZ lineup.
  • Grippy Foot pegs
    Large folding, cleated foot pegs provide excellent footing, even in wet or muddy conditions.
  • Standard Security
    Key-type ignition switch deters unauthorized riding.



2021 Yamaha TT-R110E – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $2299 USD
Canada MSRP Price: Starting at $2,999 CDN
Europe/UK MSRP Price: £ See Dealer GBP (On The Road inc 20% Vat)

Engine Type 110cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke 51.0mm x 54.0mm
Compression Ratio 9.3:1
Fuel Delivery Mikuni® VM16 carburetor
Ignition CDI
Transmission Constant-mesh 4-speed; multiple wet clutch
Final Drive Chain
Suspension / Front 31mm telescopic fork; 4.5-in travel
Suspension / Rear Monocross® shock; 4.3-in travel
Brakes / Front Drum, 95mm
Brakes / Rear Drum, 110mm
Tires / Front 2.50-14-4PR
Tires / Rear 3.00-12-4PR
L x W x H 61.6 in x 26.8 in x 36.3 in
Seat Height 26.4 in
Wheelbase 42.5 in
Rake (Caster Angle) 26.0°
Trail 2.4 in
Maximum Ground
Clearance
7.1 in
Fuel Capacity 1.0 gal
Fuel Economy** n/a
Wet Weight*** 159 lb
Warranty 90 Day (Limited Factory Warranty)
Color Team Yamaha Blue





2021 Yamaha TT-R110E – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE

ENGINE4-stroke, air-cooled, SOHC, 2-valve, single
DISPLACEMENT110cc
BORE AND STROKE51 x 54mm
COMPRESSION RATIO9.3:1
MAXIMUM TORQUE0.8 kg-m (5.8 ft-lb) @ 4,000 rpm
FUEL DELIVERYMikuni VM16
LUBRICATIONWet sump
IGNITION / STARTINGCDI / Electric & kick
TRANSMISSIONConstant mesh, 4-speed
FINAL DRIVEChain



CHASSIS

SUSPENSION (FRONT)31 mm fork / 115mm (4.5″) wheel travel
SUSPENSION (REAR)Monocross, single shock / 110 mm (4.3″) wheel travel
BRAKES (FRONT)Drum
BRAKES (REAR)Drum
TIRES (FRONT)2.50-14 4PR
TIRES (REAR)3.00-12 4PR



CRITICAL DATA

LENGTH1,565 mm (61.6″)
WIDTH680 mm (26.8″)
HEIGHT920 mm (36.2″)
WHEELBASE1,080 mm (42.5″)
GROUND CLEARANCE180 mm (7.1″)
SEAT HEIGHT670 mm (26.4″)
FUEL CAPACITY3.8 litres (0.8 imp. gallons)
WET WEIGHT72 kg (159 lb)
COLOUR(S)Yamaha Racing Blue





2021 Yamaha TT-R110E – Totalmotorcycle.com European Specifications/Technical Details

NA







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
